OX6VB736Tablet PC

Tablet PC User's Guide [ English ] M/N: VB736 TABLE OF CONTENTS ‧Notice ‧Preface 1.1 Notes for this Manual 1.2 For Your Records ‧Getting to know the basics 2.1 Product Overview 2.2 Side View 1. Camera 9. Mini-HDMI Port 2. Display (800x480) 10. USB/PC Connector (OTG) 3. Status light 11. Charger Port (5V DC) 4. Back (Soft Key) 12. Power ON/OFF Button 5. Home (Soft Key) 13. Volume Up Button 6. Menu (Soft Key) 14. Volume Down Button 7. MIC 15. Micro-SD Port 2.3 Cleaning the screen 2.4 Device setting overview ‧How to Start 3.1 Home Shell 3.2 Music 3.3 Programs / Settings / Mail / Wallpapers Programs : Display all installed applications. Settings : Link to default Android Settings. 3.4 Gallery 3.5 Camera 3.6 WiFi 3.7 G Sensor 3.8 How to do file transfer 4.0 How to connect to App Store 5.0 Updating Tablet PC ‧Accessory ‧Customer Support ‧Compliance Information & Limited Warranty │TOP│ Notice The illustrations in this user's manual are for reference only. Actual product specifications may vary with territories. The information in this user's manual is subject to change without notice. THE MANUFACTURER OR RESELLER SHALL NOT BE LIABLE FOR ERRORS OR OMISSIONS CONTAINED IN THIS MANUAL AND SHALL NOT BE LIABLE FOR ANY CONSEQUENTIAL DAMAGES, WHICH MAY RESULT FROM THE PERFORMANCE OR USE OF THIS MANUAL. The information in this user's manual is protected by copyright laws. No part of this manual may be photocopied or reproduced in any form without prior written authorization from the copyright owners. Product names mentioned herein may be trademarks and/or registered trademarks of their respective owners/companies. The software described in this manual is delivered under a license agreement. The software may be used or copied only in accordance with the terms of the agreement. This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property rights. Reverse engineering or disassembly is prohibited. │TOP│ Preface ● 1.1 Notes for this Manual CAUTION : Important information that must be followed for safe operation. NOTE : Information for special situations. │TOP│ Product Registration To meet your future needs, and to receive any additional product information as it becomes available, please register your product on the Internet at: www.viewsonic.com. ● 1.2 For Your Records Product Name: Tablet PC Model Number: VB736 │TOP│ Getting to know the basics This User's Manual provides instructions and illustrations on how to operate this Tablet PC. It is recommended to read this manual carefully before using this Tablet PC. │TOP│ ● 2.1 Product Overview This section provides the description of basic aspects of the Tablet PC. Refer to the following illustration to identify the components on this side of the Tablet PC. Features and configurations vary by model. │TOP│ ● 2.2 Preparing your Tablet PC Note that the AC adapter included in the package is approved for your Tablet PC; using other adapter model may damage either the Tablet PC or other devices attached to it. Plug the AC adapter cable into the DC power connector on the right side of your Tablet PC. Press the power button to turn on your Tablet PC. CAUTION: Do not use inferior extension cords as this may result in damage to your Tablet PC. The Tablet PC comes with its own AC adapter. Do not use a different adapter to power the computer and other electrical devices. NOTE : The power adapter may become warm to hot when in use. Be sure not to cover the adapter and keep it away from your body. │TOP│ ● 2.3 Cleaning the screen Follow these rules for cleaning the outside and handling your screen on the computer : 1. Turn off the system and disconnect all cables. 2. Use a damp, or cleaning cloth, soft, lint-free cloth with gentle water only and gently wipe the screen surface. 3. Do not spray liquid directly on the screen. NOTE : The product's color and specification will depend upon the actual shipping product. │TOP│ ● 2.4 Device setting overview 1. To select your language. 2. To set the date, time zone and time. 3. Finish the Setup Wizard, you can start to enjoy your tablet. │TOP│ How to Start ● 3.1 Home Shell Indicator bar- Notification: Display related real-time information. Indicator bar- Status: Display Home, Back, Battery, Volume, WiFi, Bluetooth, 3G, Signal strength, Clock...etc. a. To tap to browse website. b. To tap to display all of installed applications. c. To tap to do WiFi settings. Widgets: Quick Search Box, input text strings on the blank to start a new search. Tool bar: Mail, Internet, Gallery, Camera, Music, Settings, AppDownload Warning: Please do safe remove for your Micro SD card. (Setting → "SD card & device storage" → Unmount SD card) │TOP│ ● 3.2 Music Music Catalog Now Playing Now Playing on Pull Down Notification Bar NOTE : Before using Music function, please ensure your Micro SD card is inside. Sort all supported file formats on Android OS. To select Artists、Album、Songs、Playlists、Now playing. Play / Pause / Next / Previous song Time bar Playlist / Shuffle / Repeat All(One) Current song │TOP│ ● 3.3 Programs / Settings / Mail / Wallpapers Programs : Display all installed applications. Settings : Link to default Android Settings. Click Settings icon to launch default Android Settings Mail : Link to default Android Mail. Long Click on desktop Wallpapers : │TOP│ ● 3.4 Gallery Group View- Folder mode NOTE : Before using Gallery function, please ensure your Micro SD card is inside. Tap Gallery application (Please Insert an SD card before using the Gallery.) Thumbnail View / Single view Next / Previous Folder Name in SD card Select All / Deselect All Group View- Folder mode. Display by folder name in sequence. Share / Delete / More │TOP│ ● 3.5 Camera NOTE : Before using Camera function, please ensure your Micro SD card is inside. Tap Camera application. Please Insert an SD card before using the camera. Select photograph mode or Video mode Tap (photograph mode) or (Video mode) You can see a pre-vie…

Text truncated - open the document above for the full version.

Authorization Letter We, (the approval holder) Company name Addresss 6 F, BuildingL,SectionE,Block71, Baoan District, City Shenzhen Country China declare that the following representative (agent): Name (person) Bovey.yang Company name NTEK Testing Technology Co., Ltd. Addresss 1/F, Building E, Fenda Science Park Sanwei Community, Xixiang Street, Baoan District City Shenzhen Country China to act on our behalf on all matters concerning the application and documents submitted to PHOENIX TEST-LAB for product certification below Product Description Tablet PC Type or Model(s) VB100a Tradename or Brand(s) ViewSonic Product Description Tablet PC Type or Model(s) VB736 Tradename or Brand(s) ViewSonic Attestation: City and Country: Date: Name: (this must be a person) Function:Signature: (or official company stamp) shenzhen 2012/9/4 Finley Fan Manager ViewMate Electronic Technology Limited

FCC Confidentiality Request To the FCC and FCC TCB handling this application for certification Pursuant to 47 CFR Section 0.459(a) & (b), we, (the applicant / grantee) Company name ViewMate Electronic Technology Limited Addresss 6 F, BuildingL,SectionE,Block71, Baoan District, City Shenzhen Country China request non-disclosure and confidential treatment for our certification under: Grantee Code Product Number FCC ID: OX6 VB736 FCC ID: OX6 VB100A of the following materials submitted within this certification application: (please cross what is applicable, or add other documents) X Operational Description X Block Diagrams X Schematics Diagrams Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. We understand that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. Attestation: City and Country: Date:Name: (this must be a person) Function:Signature: (or official company stamp) shenzhen 2012/9/4 Finley Fan Manager

Date:2012-09-04 FCC ID: OX6VB736 Subject: Ad Hoc Mode Function Declaration To Whom it may concern, This device is acting as slave and operating in the 2.4 GHz (2412 – 2462 MHz) band. Ad Hoc function is supported but not able to operate on non-US frequencies. Please contact the one signed below or the authorized agent for this filing. Thank you. Regards, Yours sincerely, Signatory Signature Name: Finley Fan Title: manager Company : ViewMate Electronic Technology Limited Add: 6 F, BuildingL,SectionE,Block71, Baoan District, Shenzhen,China ViewMate Electronic Technology Limited

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7

Photo 7 Photo 8 Photo 9 Photo 10 Photo 11 Photo 12 Photo 13 Photo 14 Photo 15 Photo 16 Photo 17

ViewMate Electronic Technology Limited 6 F, BuildingL,SectionE,Block71, Baoan District,Shenzhen,Chian TUNE-UP PROCEDURE Programming of this product's transmit frequencies can be performed ONLY by the manufacturer or by service or maintenance personnel. The operator cannot program transmit frequencies using the equipment's external operation. 802.11b： max possible output power(Conducted) ：17±1dbm(PK),14±1dbm(AV), 802.11g： max possible output power(Conducted) ：16±1dbm(PK), 13±1dbm(AV), 802.11n： max possible output power(Conducted) ：15±1dbm(PK), 13±1dbm(AV), Data: 2012/9/4 Name: Finley Fan Title: manager Company : ViewMate Electronic Technology Limited Add: 6 F, BuildingL,SectionE,Block71, Baoan District, Shenzhen,China
