Compliance Certification Services Inc. Report No: KS121030A05-SF FCCID: OX6VIEWPAD97AK2 Date of Issue : November 7, 2012 Page 1 of 66 Rev. 01 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. ANSI/IEEE Std. C95.1-1999 In accordance with the requirements of FCC Report and Order: ET Docket 93-62, and OET Bulletin 65 Supplement C FCC SAR TEST REPORT For Product Name: Tablet PC Brand Name: ViewSonic Model No.: ViewPad97a K2 Series Model: N/A Test Report Number: KS121030A05-SF Issued for ViewMate Electronic Technology Limited 6F, Building L, Section E, Block71, Baoan District, Shenzhen, China Issued by Compliance Certification Services Inc. Kun shan Laboratory No.10 Weiye Rd., Innovation park, Eco&Tec, Development Zone, Kunshan City, Jiangsu, China TEL: 86-512-57355888 FAX: 86-512-57370818 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. The client should not use it to claim product endorsement by A2LA or any government agencies. The test results in the report only apply to the tested sample. Compliance Certification Services Inc. Report No: KS121030A05-SF FCCID: OX6VIEWPAD97AK2 Date of Issue : November 7, 2012 Page 2 of 66 Rev. 01 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. TABLE OF CONTENTS 1. CERTIFICATE OF COMPLIANCE (SAR EVALUATION) ........................................................... 3 2. EUT DESCRIPTION....................................................................................................................4 3. REQUIREMENTS FOR COMPLIANCE TESTING DEFINED BY THE FCC................................ 4 4. TEST METHODOLOGY.............................................................................................................. 5 5. TEST CONFIGURATION ............................................................................................................ 5 6. DOSIMETRIC ASSESSMENT SETUP........................................................................................ 5 6.1 MEASUREMENT SYSTEM DIAGRAM ...........................................................................................................6 6.2 SYSTEM COMPONENTS...............................................................................................................................7 7. EVALUATION PROCEDURES ................................................................................................. 11 8. MEASUREMENT UNCERTAINTY............................................................................................ 14 9. EXPOSURE LIMIT .................................................................................................................... 15 10. EUT ARRANGEMENT .............................................................................................................. 16 10.1 ANTHROPOMORPHIC HEAD PHANTOM .................................................................................................16 10.2 DEFINITION OF THE “CHEEK/TOUCH” POSITION...................................................................................17 10.3 DEFINITION OF THE “TILTED” POSITION ................................................................................................18 11. MEASUREMENT RESULTS..................................................................................................... 19 11.1 TEST LIQUIDS CONFIRMATION ...............................................................................................................19 11.2 LIQUID MEASUREMENT RESULTS ..........................................................................................................20 11.3 PROBE CALIBRATION PROCEDURE .......................................................................................................20 11.4 SYSTEM PERFORMANCE CHECK...........................................................................................................25 11.5 EUT TUNE-UP PROCEDURES AND TEST MODE....................................................................................28 EUT SETUP PHOTOS ........................................................................................................................................30 SAR TESTED FOR BODY-WORN: .....................................................................................................................30 11.6 SAR MEASUREMENT RESULTS...............................................................................................................31 11.7 EUT PHOTO................................................................................................................................................32 12. EQUIPMENT LIST & CALIBRATION STATUS........................................................................ 35 13. FACILITIES............................................................................................................................... 36 14. REFERENCES.......................................................................................................................... 36 15. ATTACHMENTS ....................................................................................................................... 37 Appendix A: Plots of Performance Check..................................................................................... 38 Appendix B: DASY Calibration Certificate .................................................................................... 40 Appendix C: Plots of SAR Test Result .......................................................................................... 66 Compliance Certification Services Inc. Report No: KS121030A05-SF FCCID: OX6VIEWPAD97AK2 Date of Issue : November 7, 2012 Pa…

Text truncated - open the document above for the full version.

Compliance Certification Services Inc. Reference No .: KS121030A05-SF Date of Issue:November 7, 2012 Report No .: KS121030A05-SF Page 1 of 4 IEEE 802.11b- Body Up Low CH1..................................................................................................... 2 IEEE 802.11b- Body Down Low CH1................................................................................................ 3 IEEE 802.11b- Body Top Low CH1................................................................................................... 4 Compliance Certification Services Inc. Reference No .: KS121030A05-SF Date of Issue:November 7, 2012 Report No .: KS121030A05-SF Page 2 of 4 Test Laboratory: Compliance Certification Services Inc. November 6, 2012 IEEE 802.11b- Body Up Low CH1 DUT: Tablet PC; Type: ViewPad97a K2; Serial: N/A Communication System: IEEE 802.11b; Communication System Band: ISM 2.4GHz Band; Frequency: 2412 MHz;Communication System PAR: 0 dB Ambient: Temperature: 21 °C Relative humidity: 58% Liquid : Temperature: 20 °C Medium parameters used (interpolated): f = 2412 MHz; σ = 1.959 mho/m; ε r = 52.83; ρ = 1000 kg/m 3 Phantom section: Flat Section Measurement Standard: DASY5 (IEEE/IEC/ANSI C63.19-2007) DASY5 Configuration: • Probe: EX3DV4 - SN3798; ConvF(6.92, 6.92, 6.92); Calibrated: 7/25/2012; • Sensor-Surface: 2.5mm (Mechanical Surface Detection) • Electronics: DAE4 - SD 000 D04 BJ - SN:1245; Calibrated: 7/20/2012 • Phantom: Twin SAM Phantom; Type: QD 000 P40 CD; Serial: 1609 • DASY52 52.8.1(838); SEMCAD X 14.6.5(6469) IEEE 802.11b /802.11b Body up Low CH1/Area Scan (201x131x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.323 mW/g IEEE 802.11b /802.11b Body up Low CH1/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 9.250 V/m; Power Drift = 0.12 dB Peak SAR (extrapolated) = 0.385 W/kg SAR(1 g) = 0.294 mW/g; SAR(10 g) = 0.198 mW/g Maximum value of SAR (measured) = 0.341 mW/g Compliance Certification Services Inc. Reference No .: KS121030A05-SF Date of Issue:November 7, 2012 Report No .: KS121030A05-SF Page 3 of 4 Test Laboratory: Compliance Certification Services Inc. November 6, 2012 IEEE 802.11b- Body Down Low CH1 DUT: Tablet PC; Type: ViewPad97a K2; Serial: N/A Communication System: IEEE 802.11b; Communication System Band: ISM 2.4GHz Band; Frequency: 2412 MHz;Communication System PAR: 0 dB Ambient: Temperature: 21 °C Relative humidity: 58% Liquid : Temperature: 20 °C Medium parameters used (interpolated): f = 2412 MHz; σ = 1.959 mho/m; ε r = 52.83; ρ = 1000 kg/m 3 Phantom section: Flat Section Measurement Standard: DASY5 (IEEE/IEC/ANSI C63.19-2007) DASY5 Configuration: • Probe: EX3DV4 - SN3798; ConvF(6.92, 6.92, 6.92); Calibrated: 7/25/2012; • Sensor-Surface: 2.5mm (Mechanical Surface Detection) • Electronics: DAE4 - SD 000 D04 BJ - SN:1245; Calibrated: 7/20/2012 • Phantom: Twin SAM Phantom; Type: QD 000 P40 CD; Serial: 1609 • DASY52 52.8.1(838); SEMCAD X 14.6.5(6469) IEEE 802.11b /802.11b Body Down Low CH1/Area Scan (201x131x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.527 mW/g IEEE 802.11b /802.11b Body Down Low CH1/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 14.250 V/m; Power Drift = 0.14 dB Peak SAR (extrapolated) = 0.588 W/kg SAR(1 g) = 0.379 mW/g; SAR(10 g) = 0.242 mW/g Maximum value of SAR (measured) = 0.554 mW/g Compliance Certification Services Inc. Reference No .: KS121030A05-SF Date of Issue:November 7, 2012 Report No .: KS121030A05-SF Page 4 of 4 Test Laboratory: Compliance Certification Services Inc. November 6, 2012 IEEE 802.11b- Body Top Low CH1 DUT: Tablet PC; Type: ViewPad97a K2; Serial: N/A Communication System: IEEE 802.11b; Communication System Band: ISM 2.4GHz Band; Frequency: 2412 MHz;Communication System PAR: 0 dB Ambient: Temperature: 21 °C Relative humidity: 58% Liquid : Temperature: 20 °C Medium parameters used (interpolated): f = 2412 MHz; σ = 1.959 mho/m; ε r = 52.83; ρ = 1000 kg/m 3 Phantom section: Flat Section Measurement Standard: DASY5 (IEEE/IEC/ANSI C63.19-2007) DASY5 Configuration: • Probe: EX3DV4 - SN3798; ConvF(6.92, 6.92, 6.92p); Calibrated: 7/25/2012; • Sensor-Surface: 2.5mm (Mechanical Surface Detection) • Electronics: DAE4 - SD 000 D04 BJ - SN:1245; Calibrated: 7/20/2012 • Phantom: Twin SAM Phantom; Type: QD 000 P40 CD; Serial: 1609 • DASY52 52.8.1(838); SEMCAD X 14.6.5(6469) IEEE 802.11b /802.11b Body Top Low CH1/Area Scan (201x131x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.524 mW/g IEEE 802.11b /802.11b Body Top Low CH1/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 13.209 V/m; Power Drift = 0.09 dB Peak SAR (extrapolated) = 0.615 W/kg SAR(1 g) = 0.326 mW/g; SAR(10 g) = 0.209 mW/g Maximum value of SAR (measured) = 0.595 mW/g

FCC RADIO TEST REPORT FCC ID:OX6VIEWPAD97AK2 Product： Tablet PC Trade Name： ViewSonic Model Name： ViewPad97a K2 Serial Model： N/A Report No.： NTEK- 2012NT1010075F Prepared for ViewMate Electronic Technology Limited 6F, Building L, Section E, Block71, Baoan District, Shenzhen, China Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community,Xixiang Street Bao’an District, Shenzhen P.R. China Tel.: +86-0755-61156588 Fax.: +86-0755-61156599 Website:www.ntek.org.cn Page 2 of 66 Report No.: NTEK-2012NT1010075F TEST RESULT CERTIFICATION Applicant’s name................. : ViewMate Electronic Technology Limited Address ................................. : 6F, Building L, Section E, Block71, Baoan District, Shenzhen, China Manufacture's Name............ : ViewMate Electronic Technology Limited Address ................................. : 6F, Building L, Section E, Block71, Baoan District, Shenzhen, China Product description Product name ........................... : Tablet PC Model and/or type reference : ViewPad97a K2 Serial Model .............................. : N/A Standards............................. : FCC Part15.247 Test procedure .............................. ANSI C63.4-2003 This device described above has been tested by NTEK, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK, this document may be altered or revised by NTEK, personal only, and shall be noted in the revision of the document. Date of Test............................................: Date (s) of performance of tests .............: 10 Oct. 2012 ~ 30 Oct. 2012 Date of Issue...........................................: 30 Oct. 2012 Test Result...............................................: Pass Testing Engineer : (Jason Chen) Technical Manager : (Tom Zhang) Authorized Signatory : (Bovey Yang) Page 3 of 66 Report No.: NTEK-2012NT1010075F Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST MODES 9 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 11 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 12 3 . EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 13 3.1.2 TEST PROCEDURE 14 3.1.3 DEVIATION FROM TEST STANDARD 14 3.1.4 TEST SETUP 14 3.1.5 EUT OPERATING CONDITIONS 14 3.1.6 TEST RESULTS 15 3.2 RADIATED EMISSION MEASUREMENT 17 3.2.1 RADIATED EMISSION LIMITS 17 3.2.2 TEST PROCEDURE 18 3.2.3 DEVIATION FROM TEST STANDARD 18 3.2.4 TEST SETUP 19 3.2.5 EUT OPERATING CONDITIONS 20 3.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 21 3.2.7 TEST RESULTS (BETWEEN 30MHZ – 1GHZ) 22 3.2.8 TEST RESULTS (ABOVE 1000 MHZ) 24 4 . POWER SPECTRAL DENSITY TEST 48 4.1 APPLIED PROCEDURES / LIMIT 48 4.1.1 TEST PROCEDURE 48 4.1.2 DEVIATION FROM STANDARD 48 4.1.3 TEST SETUP 48 4.1.4 EUT OPERATION CONDITIONS 48 4.1.5 TEST RESULTS 49 5 . BANDWIDTH TEST 55 5.1 APPLIED PROCEDURES / LIMIT 55 5.1.1 TEST PROCEDURE 55 Page 4 of 66 Report No.: NTEK-2012NT1010075F Table of Contents Page 5.1.2 DEVIATION FROM STANDARD 55 5.1.3 TEST SETUP 55 5.1.4 EUT OPERATION CONDITIONS 55 5.1.5 TEST RESULTS 56 6 . PEAK OUTPUT POWER TEST 62 6.1 APPLIED PROCEDURES / LIMIT 62 6.1.1 TEST PROCEDURE 62 6.1.2 DEVIATION FROM STANDARD 62 6.1.3 TEST SETUP 62 6.1.4 EUT OPERATION CONDITIONS 62 6.1.5 TEST RESULTS 63 7 . ANTENNA REQUIREMENT 64 7.1 STANDARD REQUIREMENT 64 7.2 EUT ANTENNA 64 8 . EUT TEST PHOTO 65 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Page 5 of 66 Report No.: NTEK-2012NT1010075F 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247 (a)(2) 6dB Bandwidth PASS 15.247 (b) Peak Output Power PASS 15.247 (c) Radiated Spurious Emission PASS 15.247 (d) Power Spectral Density PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Page 6 of 66 Report No.: NTEK-2012NT1010075F 1.1 TEST FACILITY Sehnzhen NTEK Testing Technology Co., Ltd Add.:1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC Registration No.:238937; IC Registration No.:9270A-1 CNAS Registration No.:L5516 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Page 7 of 66 Report No.: NTEK-2012NT1010075F 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment Tablet PC Trade Name ViewSonic Model Name ViewPad97a K2 Serial Model N/A Model Difference N/A Product Description The EUT is a Tablet PC Operation Frequency: 2412~2462 MHz Modulation Type: 802.11b: DQPSK, DBPSK, CCK 802.11g/n: OFDM/64-QAM,16-QAM, QPSK, BPSK Bit Rate of Transmitter 802.11b:11/5.5/2/1 Mbps 802.11g:54/48/36/24/18/12/9/6Mbps 802.11n(20MHz):72.2/65/58.5/57.8/52/ 43.3/39/28.9/26/21.7/19.5/14.4/13/7.2/ 6.5Mbps Number Of Channel 11 CH, Please see Note 2. Antenna Designation: Please see Note 3. Output Power(Conducted): 802.11b: 21.34 dBm (Max.) 802.11g: 19.46 dBm (Max.) 802.11n(20M) : 19.31 dBm (Max.) Antenna Gain (dBi) 1.6dBi Based on the application, features, or specification exhibited in User's Manual, the EUT is considered as an Portable Intentional Radiator Device. More …
