OYCBT030Wireless Bluetooth speaker

User Manual Wireless Bluetooth speaker Model name:BT030 Brand name:iKANOO FCC ID:OYCBT030 Dear user, Thank you very much for choosing BT030 walkman Bluetooth speaker. Please read this user manual carefully in order to operate this device correctly and bring its excellent performance. I. Notice Please store and use this product at normal temperature; DO NOT expose this product to rain or damp; DO NOT toss this product and prevent it from falling and being damaged; DO NOT disassemble, repair and modify this product; As it is inbuilt with lithium battery, DO NOT cast or place it in fire to avoid danger. II. Kind Reminder IIII 1, To extend the speaker‘ s service life ,and your physical and mental health, please don't listen to music under big volume for a long time to avoid hearing damage. 2, When something wrong with the speaker, please immediately shut off the power switch, plug off the USB ,to prevent the speaker and other parts are damaged. 3, Power shortage will affect Bluetooth distance or Bluetooth easy to disconnect, please charge in time. III. Overview V -：Decrease the volume & previous song V +：Increase the volume & next song ：Answer/ Hang up the call IV. Parameters Model: BT030 Bluetooth specification: Bluetooth V2.1+EDR Transmission distance: 10M (It var≦ies when the environmental factors and the connected Bluetooth devices are different) USB charging voltage: DC 5V Built-in battery: Lithium battery Output power: 3W Frequency response: 90Hz-20KHz Sensitivity: 80db±2db S/N ratio: ≥ 76dB V. Packing List 1. Speaker *1 2. Mini-USB power cable * 1 3. User’s manual*1 VI. Common Functions Start: Turn on the sound box it would give off “du-du” as tip and the blue light begins to flicker, the default power is 60%. Bluetooth connection: When the power is switched on, the blue light begins to flicker at the same time, the speaker give off “du-du”. At this moment, turn on the Bluetooth device and click “pair “option in Bluetooth device. BT030 will automatically stop if no Bluetooth device is found within 5 minutes, so as to save the power. Tip: If the connection fails, please turn off the machine and restart it or please charge it as there maybe no sufficient power. Bluetooth mode: Connect BT030 with Bluetooth device and press V -、V + to control the volume & song. Tip: Under Bluetooth mode, the music is controlled by the music player. Hands-free: Connect BT030 with Bluetooth device when calls in, BT030 would give off “ du-du” as tip. Press to answer the call and re-press to hang up the call. AUX source: Insert the attached audio cable into the AUX port on BT030 and the other sider audio port on PC. The player begins to play. The sound box will start the music. The volume, the songs are freely controlled by the player. Quick charge: Charge in power-off state. Insert the attached USB power cable with the micro USB end into the USB power port of BT030 and the other end into the USB port of PC or the USB charger to start charging. When the charging is over, the red indicator will be off. VII. Compatibility Device equipped with BLUETOOTH 2.1+EDR or higher version (for details please refer to the relevant agreements, general specification), such as the IPAD, IPHONE (the second generation and IPHONE with updated IPHONE 3.1 software), IPOD TOCH, MAC with BLUETOOTH , and majority of smart phone or computer support BLUETOOTH. Bluetooth 2.1+EDR including agreements as：A2DP, AVRCP,HFP VIII.Troubleshooting Problem Troubleshooting Failure in connection and pairing for many times 1. Inspect whether the sound box is in the status of searching, or, restart the machine. 2. The surrounding Bluetooth equipments are plentiful, which causes the difficulty in searching. So, please close the other Bluetooth equipments. The sound is small or distorted 1. Inspect the volume of the Bluetooth equipment and adjust the volume. 2. The power of battery is insufficient, please charge it. Discontinuous music See whether the effective connection distance of sound is exceeded, or, whether there is obstacle between the sound box and the Bluetooth equipment. The indicator for Bluetooth mode is not on 1. It indicates that the power of the battery is not sufficient. Please try again after charging it. 2. Restart the machine. Hints: Another trouble, please consult the dealer or an experienced radio/TV technician for help. IX:Statement This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Phenomenon

Feb.26, 2014 Federal Communication Commission Authorization and Evaluation Division FCC ID: OYCBT030 Re: Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the applicant hereby requests confidential treatment of information applied this application as outlined below: 1: Block Diagram 2: Circuit Diagram 3: Parts List 4.Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rules 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Dongguan Taide Industrial Co., Ltd. Contact person: Emily Lee Title: Sales

External Photos ALL VIEW OF EUT TOP VIEW OF EUT BOTTOM VIEW OF EUT FRONT VIEW OF EUT BACK VIEW OF EUT LEFT VIEW OF EUT RIGHT VIEW OF EUT

FCC ID Label Location Wireless Bluetooth speaker Model: BT030 Brand Name: iKANOO FCC ID: OYCBT030 FJ BT 1222, NGS‐030BT, SSBT030, ETC

Internal Photos OPEN VIEW OF EUT INTERNAL VIEW OF EUT-1 INTERNAL VIEW OF EUT-2 BT Antenna INTERNAL VIEW OF EUT-3 INTERNAL VIEW OF EUT-4

Report No.: AGC00931140202FE03 Page 1 of 58 FCC Test Report Report No.: AGC00931140202FE03 FCC ID : OYCBT030 APPLICATION PURPOSE : Original Equipment PRODUCT DESIGNATION : Wireless Bluetooth speaker BRAND NAME : iKANOO MODEL NAME : BT030, FJ BT 1222, NGS‐030BT, SSBT030, ETC CLIENT : DONGGUAN TAIDE INDUSTRIAL CO.,LTD. DATE OF ISSUE : Feb.25, 2014 STANDARD(S) : FCC Part 15 Rules REPORT VERSION : V1.0 Attestation of Global Compliance (Shenzhen) Co., Ltd CAUTION: This report shall not be reproduced except in full without the written permission of the test laboratory and shall not be quoted out of context. Report No.: AGC00931140202FE03 Page 2 of 58 Report Revise Record Report Version Revise Time Issued Date Valid VersionNotes V1.0 / Feb.25, 2014Valid Original Report Report No.: AGC00931140202FE03 Page 3 of 58 TABLE OF CONTENTS 1. VERIFICATION OF CONFORMITY ...................................................................................... 5 2. GENERAL INFORMATION .................................................................................................. 6 2.1. PRODUCT DESCRIPTION ........................................................................................................... 6 2.2. TABLE OF CARRIER FREQUENCYS .......................................................................................... 6 2.3. RECEIVER INPUT BANDWIDTH ................................................................................................. 7 2.4. EXAMPLE OF A HOPPING SEQUENCY IN DATA MODE ........................................................... 7 2.5. EQUALLY AVERAGE USE OF FREQUENCIES AND BEHAVIOUR ............................................ 7 2.6. RELATED SUBMITTAL(S) / GRANT (S) ....................................................................................... 8 2.7. TEST METHODOLOGY................................................................................................................ 8 2.8. SPECIAL ACCESSORIES ............................................................................................................ 8 2.9. EQUIPMENT MODIFICATIONS ................................................................................................... 8 3. MEASUREMENT UNCERTAINTY........................................................................................ 9 4. DESCRIPTION OF TEST MODES ........................................................................................ 9 5. SYSTEM TEST CONFIGURATION .................................................................................... 10 5.1. CONFIGURATION OF EUT SYSTEM ........................................................................................ 10 5.2. EQUIPMENT USED IN EUT SYSTEM ....................................................................................... 10 5.3. SUMMARY OF TEST RESULTS ................................................................................................ 10 6. TEST FACILITY .................................................................................................................. 11 7. PEAK OUTPUT POWER .................................................................................................... 12 7.1. MEASUREMENT PROCEDURE ................................................................................................ 12 7.2. TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ....................................................... 12 7.3. LIMITS AND MEASUREMENT RESULT .................................................................................... 13 8. 20DB BANDWIDTH ............................................................................................................ 19 8.1. MEASUREMENT PROCEDURE ................................................................................................ 19 8.2. TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ....................................................... 19 8.3. LIMITS AND MEASUREMENT RESULTS .................................................................................. 19 9. CONDUCTED SPURIOUS EMISSION ............................................................................... 26 9.1. MEASUREMENT PROCEDURE ................................................................................................ 26 9.2. TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ....................................................... 26 9.3. MEASUREMENT EQUIPMENT USED ....................................................................................... 26 9.4. LIMITS AND MEASUREMENT RESULT .................................................................................... 26 10. RADIATED EMISSION ..................................................................................................... 30 10.1. MEASUREMENT PROCEDURE .............................................................................................. 30 10.2. TEST SETUP ............................................................................................................................ 32 Report No.: AGC00931140202FE03 Page 4 of 58 10.3. TEST RESULT .......................................................................................................................... 33 11. BAND EDGE EMISSION .................................................................................................. 37 11.1. MEASUREMENT PROCEDURE .............................................................................................. 37 11.2. TEST SET-UP ........................................................................................................................... 37 11.3. TEST RESULT .......................................................................................................................... 38 12. NUMBER OF HOPPING FREQUENCY ............................................................................ 42 12.1. MEASUREMENT PROCEDURE .......................................................................................…

Text truncated - open the document above for the full version.

APPENDIX IV PHOTOGRAPHS OF TEST SETUP FCC LINE CONDUCTED EMISSION TEST SETUP FCC RADIATED EMISSION TEST SETUP
