OYCBT040Bluetooth Speaker

Taide Industrial Co.,Ltd User’s Manual for the Bluetooth Speaker BT040 Brand name：iKANOO FCC ID:OYCBT040 Thank you for purchasing this Bluetooth speaker BT040. Before getting started, please read the user's manual carefully so as to ensure proper operation and optimized performance of this product. I. Precautions Please store and use this product at the ambient temperature; Do not expose this product to the rain or damp surroundings; Prevent this product from falling that could result in serious damage; Do not dismantle, repair or modify this product on your own; In order to avoid any risk, do not dispose this product inappropriately or toss it into the fire as there is a built-in lithium battery. II. Considerate Hints 1) Do not turn up the volume to a high level constantly as this could shorten the service life of this product or impair your hearing; 2) When encountering any fault during operation, please cut off the power supply and disconnect the USB cable to prevent further damage to the speaker or other components; 3) The Bluetooth transmission range or connectivity could be affected by low battery power. In that case, please recharge immediately. Outer Appearance and Function Buttons ：Click to pause during Bluetooth play and click to play during Bluetooth pause. Click to receive calls at Bluetooth state. Hold down the button to refuse the calls. III. Product Parameters Product Model： BT040 Bluetooth Specifications：Bluetooth V2.1+EDR（A2DP） Transmission Distance：≤10M （depending upon operation environment and devices to which it connects)） USB Recharge Voltage：DC 5V/500mA Built-in Battery：Lithium battery Output Power: 3W×2 Frequency Response: 90Hz-20KHz Sensitivity: 80db±2db Signal to Noise Ratio (SNR): ≥76dB IV. System Composition 1. Speaker 1 set 2．USB Power Cable 1 set 3. User's Manual 1copy V．Common Function Description Power-on state: Switch on the power supply of speaker. The speaker will give out prompt tone of “click-click” and the Bluetooth indicator light flashes at the same time. Bluetooth Connection: after the power supply is switched on, the speaker will enter Bluetooth search state automatically. For automatic pairing, Your Bluetooth enabled device will ask whether to pair or not. Click pairing, Bluetooth indicator light will flash slowly after successful connection and the speaker gives out prompt tone. If Bluetooth speaker fails to detect any equipment within five minutes when the power is switched on, Bluetooth will shut itself down automatically. To make another connection, it is necessary to switch on again. This device is provided with back connection function. The Bluetooth items that are connected successfully will connect automatically when Bluetooth is activated next time. Considerate hints: if connection fails, please switch off the device to restart. It may be that the electric quantity of battery is not sufficient. Please charge. Power MicroUSB charge 3.5 Aux input Indicator light and functional buttons Bluetooth music playback: after Bluetooth connection is successful, the equipment will play music directly. Press and hold“ ” to pause during playback; Press “” to play during pause. Hand free calls: After connected with the mobile phone successfully, the speaker beeps when a call comes in. Press to pick it up and to talk with the person. press again to hang up to terminate the talk. When a call comes, Hold down the button to refuse coming calls. Double click on “ ” button to redial the last phone number at Bluetooth connection state. AUX playback: insert the video cable into AUX of speaker, and audio interface of players such as computers, and the AUX indicator light is on. The player begins to play. The device will start music immediately. volume, song selection, etc is controlled by the player at ease. Considerate hints: at AUX playback state, press “ ” to enter mute mode and press “” again to release sound. Smart automatic quick charge: charge at standby or switch-off state. Insert the MICRO USB to speaker and computer or USB charger. Charging begins. The charging indicator light will be off after full charge VI. Compatibility Wireless：Devices configured with Bluetooth 2.1+EDR or higher version such as IPAD, IPHONE , IPOD TOUCH and MAC as well as a majority of intelligent phones or computers that support Bluetooth. Bluetooth V2.1+EDR consists of protocols like A2DP, AVRCP and HFP and so on. VII. Toubleshooting (problem) Solutions Unable to pair up with other devices 1. Check whether the speaker is still in the process of search or switch it off and then on. 2. There are too many Bluetooth devices in the proximity that cause difficulty in connection. Please turn them off. The sound is rather low or distorted 1. Check the Bluetooth device’s volume and then adjust it to a proper level. 2. Recharge the battery The music stops from time to time 1. Check whether the speaker’s effective transmission range is exceeded or there is an obstacle standing between the speaker and other Bluetooth devices. The Bluetooth indicator remains off 1. It suggests the battery power drops quite low and retry once being recharged. 2. Turn it on again. Hints: Another trouble, please consult the dealer or an experienced radio/TV technician for help. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

Mar.12, 2014 Federal Communication Commission Authorization and Evaluation Division FCC ID: OYCBT040 Re: Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the applicant hereby requests confidential treatment of information applied this application as outlined below: 1: Block Diagram 2: Circuit Diagram 3: Parts List 4.Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rules 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Dongguan Taide Industrial Co., Ltd. Contact person: Emily Lee Title: Sales

External Photos Model: BT040A TOP VIEW OF EUT BOTTOM VIEW OF EUT FRONT VIEW OF EUT BACK VIEW OF EUT LEFT VIEW OF EUT RIGHT VIEW OF EUT Model: BT040B FRONT VIEW OF EUT Model: BT040C FRONT VIEW OF EUT

FCC ID Label Location Wireless NFC & Bluetooth speaker Model: BT040 Brand Name: iKANOO FCC ID: OYCBT040 BT040A,BT040B,BT040C, SBT560,BM209, NGS-040BT,SSBT040, ETC, 79xxxB(X means number from 0 to 9), 3xxxB(X means number from 0 to 9)

Internal Photos OPEN VIEW OF EUT INTERNAL VIEW OF EUT-1 INTERNAL VIEW OF EUT-2 INTERNAL VIEW OF EUT-3 BT Antenna INTERNAL VIEW OF EUT-4 INTERNAL VIEW OF EUT-5

Report No.: AGC00931140301FE03 Page 1 of 60 FCC Test Report Report No.: AGC00931140301FE03 FCC ID : OYCBT040 APPLICATION PURPOSE : Original Equipment PRODUCT DESIGNATION : Wireless NFC& Bluetooth speaker BRAND NAME : iKANOO MODEL NAME : BT040A, BT040B, BT040C, BT040, SBT560, BM209, NGS‐040BT, SSBT040, ETC, 79xxxB(X means number from 0 to 9), 3xxxB(X means number from 0 to 9) CLIENT : DONGGUAN TAIDE INDUSTRIAL CO.,LTD. DATE OF ISSUE : Mar.11, 2014 STANDARD(S) : FCC Part 15 Rules REPORT VERSION : V1.0 Attestation of Global Compliance (Shenzhen) Co., Ltd CAUTION: This report shall not be reproduced except in full without the written permission of the test laboratory and shall not be quoted out of context. Report No.: AGC00931140301FE03 Page 2 of 60 Report Revise Record Report Version Revise Time Issued Date Valid VersionNotes V1.0 / Mar.11, 2014Valid Original Report Report No.: AGC00931140301FE03 Page 3 of 60 TABLE OF CONTENTS 1. VERIFICATION OF CONFORMITY ...................................................................................... 5 2. GENERAL INFORMATION .................................................................................................. 6 2.1. PRODUCT DESCRIPTION ........................................................................................................... 6 2.2. TABLE OF CARRIER FREQUENCYS .......................................................................................... 6 2.3. RECEIVER INPUT BANDWIDTH ................................................................................................. 7 2.4. EXAMPLE OF A HOPPING SEQUENCY IN DATA MODE ........................................................... 7 2.5. EQUALLY AVERAGE USE OF FREQUENCIES AND BEHAVIOUR ............................................ 7 2.6. RELATED SUBMITTAL(S) / GRANT (S) ....................................................................................... 8 2.7. TEST METHODOLOGY................................................................................................................ 8 2.8. SPECIAL ACCESSORIES ............................................................................................................ 8 2.9. EQUIPMENT MODIFICATIONS ................................................................................................... 8 3. MEASUREMENT UNCERTAINTY........................................................................................ 9 4. DESCRIPTION OF TEST MODES ........................................................................................ 9 5. SYSTEM TEST CONFIGURATION .................................................................................... 10 5.1. CONFIGURATION OF EUT SYSTEM ........................................................................................ 10 5.2. EQUIPMENT USED IN EUT SYSTEM ....................................................................................... 10 5.3. SUMMARY OF TEST RESULTS ................................................................................................ 10 6. TEST FACILITY .................................................................................................................. 11 7. PEAK OUTPUT POWER .................................................................................................... 12 7.1. MEASUREMENT PROCEDURE ................................................................................................ 12 7.2. TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ....................................................... 12 7.3. LIMITS AND MEASUREMENT RESULT .................................................................................... 13 8. 20DB BANDWIDTH ............................................................................................................ 19 8.1. MEASUREMENT PROCEDURE ................................................................................................ 19 8.2. TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ....................................................... 19 8.3. LIMITS AND MEASUREMENT RESULTS .................................................................................. 19 9. CONDUCTED SPURIOUS EMISSION ............................................................................... 26 9.1. MEASUREMENT PROCEDURE ................................................................................................ 26 9.2. TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ....................................................... 26 9.3. MEASUREMENT EQUIPMENT USED ....................................................................................... 26 9.4. LIMITS AND MEASUREMENT RESULT .................................................................................... 26 10. RADIATED EMISSION ..................................................................................................... 30 10.1. MEASUREMENT PROCEDURE .............................................................................................. 30 10.2. TEST SETUP ............................................................................................................................ 32 Report No.: AGC00931140301FE03 Page 4 of 60 10.3. TEST RESULT .......................................................................................................................... 33 11. BAND EDGE EMISSION .................................................................................................. 37 11.1. MEASUREMENT PROCEDURE .............................................................................................. 37 11.2. TEST SET-UP ........................................................................................................................... 37 11.3. TEST RESULT .......................................................................................................................... 38 12. NUMBER OF HOPPING FREQUENCY ............................................................................ 42 12.1. MEASUR…

Text truncated - open the document above for the full version.

APPENDIX IV PHOTOGRAPHS OF TEST SETUP FCC LINE CONDUCTED EMISSION TEST SETUP FCC RADIATED EMISSION TEST SETUP
