OYILITEBASELite Base

Wireless eSystems, Inc.

Click to zoom

Application Details

Equipment Class: DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant: Dec 11, 2005
Application Purpose: Original Equipment
Date of Application: Dec 11, 2005
Equipment Note: Lite Base
Frequency Range: 2432.83170000 - 2435.43170000
Company: Wireless eSystems, Inc.
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

1 Installation and Setup Installation and Set Up Procedure Installation and setup is quick and easy. Follow the procedures as described and illustrated on the following pages. Setup Procedure Unpack the iRespond Lite System Install the iRespond Software Perform Session Setup Battery Installation • iRespond Lite remote units arrive with two AA Energizer batteries already installed. Under normal use, a remote will run for approximately 130 hours before battery replacement is required. • To replace the batteries, remove casing on back of unit by sliding downwards. Replace batteries. Attach casing back to remote by sliding upwards. iRespond System Setup Follow the instructions below for setting up the Base and Remote Units. iRespond Base Unit iRespond Lite Remote Units 2 Linksys USB Hub Setup • Attach USB cable to hub. Locate an available USB port on the computer and attach the other end of the USB cable to this port. Attach the power adapter into the hub. Plug the adapter into a standard electrical outlet. The hub will be automatically detected by the computer and is now ready for use. Base Unit Setup • Screw in the base unit antenna on the top of the unit. To maximize transmission, orient the antenna so that it sticks straight up from the unit. • Using the USB cable provided with the system, connect the end with the mini USB connector to the base unit. Locate an available USB port on the Linksys hub. Connect the other end of the USB cable to the port. • Apply power to the base unit by pressing the Power On/Off button in the upper-left of the unit. • Setup for the base unit is now complete. Remote Unit Setup • Apply power to the remote units by pressing the Power On/Off button in the upper-left of each unit. Take note of the UID number that appears on the back of the remote unit below the FCC Label. • The hardware setup is now complete. Using the Base and Remote Units Key Function Power On/Off This key, located top-left, turns power on and off the unit. Once a session is established pressing this key prompts the user to confirm unit shutoff to prevent accidental powering off. Go This multipurpose key is used in combination with other keys, such as powering up the unit in programming mode and selecting a question number in Homework mode. F1 The F1 key may be used to access Homework mode. Flag This key allows the user to mark items for later review in a session. Arrow Keys These keys are used to navigate through items on the display. Used to toggle between Logout no / Logout yes and Shutoff no / Shutoff yes. Send This key submits the user's input to the base unit for recording or scoring. Letter Keys A - E Used to select responses to multiple choice and multiple response questions in a session. Number Keys 0 - 9 Used to enter a PIN number or responses to fill-in type questions. Special Char + - / . These keys are used with fill-in responses to enter decimals, fractions, change a positive number to negative, or change a negative number back to positive. 3 4 Software Installation and Setup System Requirements The iRespond System runs on customer supplied Windows TM -based desktop PCs and laptops. Please verify system compliance before proceeding. The Windows TM -based system requirements: • 400 MHz or higher Pentium II processor • Windows TM 95/98/ME/2000/NT/XP • CD ROM drive • 1 free USB port • 10 MB available disk space • 128 MB RAM Installation and Set Up Procedure Software installation and setup is quick and easy. Locate the iRespond installation CD shipped with the system, and then follow the procedures as described. Procedure: Install the software Set up the software to run sessions ♦ Log In and Account Administration ♦ Set Up your Class Rosters ♦ Set Up your Test Banks ♦ Set Up your Remote Units Installation To ensure compatibility, please review the system requirements before installing the software, and then follow the steps below. • Insert the iRespond software installation disc in your CD-ROM drive. • The iRespond Software will automatically launch the installation program. During this process, be sure to answer the items that appear on the screen. • If your computer is not configured to auto-start, select Run from the Start Menu and browse the installation CD for "Setup.exe." Select that file and click OK to start the installation procedure. Sun's Java TM JRE file system is required to run the iRespond software. If the JRE files are not already installed on your computer, setup will automatically load the requisite files. 5 Introduction After installing the software, it is necessary for you to set up user accounts, enter your class rosters, enter your test banks, and set up the remote units before a session can be started. This guide is a step-by-step procedure through those set up dialogs. Toolbar menu selection names and dialog names described in this guide are shown in green. Text entries and toolbar button clicks required by you are shown in bright blue. Log In and Account Administration Launch the iRespond software and the iRespond Login dialog appears. This dialog prompts you for your user name and password. First-time log in is done as administrator. Enter the default user name admin, and the default password changeme, and click the Login button. Successful login opens the iRespond Session Setup window. From the iRespond Session Setup screen, change the administrator password by selecting Tools/Change Password from the toolbar. The Change Password dialog will appear. Enter the old and new passwords, confirm the new password, and click Change. NOTE: All standard Windows™ conventions apply to iRespond. NOTE: Username and Password are case sensitive. 6 Account Administrator Dialog The sole function of logging in as administrator is to create or edit your user accounts. When your user account has been set up, log out as administrator and then log back in using your user name. Then you can set up your Classes, Test Banks, and Remote Devices. From the main toolbar menu, s…

Text truncated - open the document above for the full version.

Block Diagram

26.00MHz crystal CC2500 RF Transceiver AT91SAMS128 ARM Micorocontroller 6 Key Keypad 16 X 2 Character LCD Display LDO Voltage regulator 18.432 MHz crystal SPI Port +3.3V Power Antenna Factor Dipole antenna USB connector AY05730 Lite Base Block Diagram Thursday, November 03, 2005

External Photos

Wireless eSystems, Inc. FCC ID: OYILITEBASE Report # R0511143Exhibits FCC Part 15.249 Test Report EXHIBIT C - EUT PHOTOGRAPHS EUT Front View EUT Rear View Wireless eSystems, Inc. FCC ID: OYILITEBASE Report # R0511143Exhibits FCC Part 15.249 Test Report EUT Side View

ID Label/Location Info

EXHIBIT A - FCC ID LABEL INFORMATION Proposed FCC ID Label Specifications: Text is black or white in color and is left justified. Labels are silk-screened and shall be “permanently affixed” at a conspicuous location on the EUT. Proposed Label Location on EUT Bottom view of EUT / Proposed Label location FCC ID: OYILITEBASE This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received,

Internal Photos

Wireless eSystems, Inc. FCC ID: OYILITEBASE Report # R0511143Exhibits FCC Part 15.249 Test Report Cover Off View Component View Wireless eSystems, Inc. FCC ID: OYILITEBASE Report # R0511143Exhibits FCC Part 15.249 Test Report Solder View

Test Report

Note: The test report is specially limited to the above company and this particular sample only. It may not be duplicated without prior written consent of Bay Area Compliance Laboratory Corporation. This report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST or any agency of the US Government. FCC PART 15.249 EMI MEASUREMENT AND TEST REPORT For Wireless eSystems, Inc. 65 Hill Ave. Fort Walton Beach, Florida 32548 FCC ID: OYILITEBASE This Report Concerns: Original Report Equipment Type: Lite Base Test Engineer: James Ma Report No.: R0511143 Report Date: 2005-12-02 Reviewed By: Snell Leong / Prepared By: Bay Area Compliance Laboratory Corporation 230 Commercial Street Sunnyvale, CA 94085 Tel (408) 732-9162 Fax (408) 732-9164 Wireless eSystems, Inc. FCC ID: OYILITEBASE Report # R0511143Rpt Page 2 of 16 FCC Part 15.249 Test Report TABLE OF CONTENTS GENERAL INFORMATION.......................................................................................................................................3 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ....................................................................................3 OBJECTIVE...................................................................................................................................................................3 RELATED SUBMITTAL(S)/GRANT(S).............................................................................................................................3 TEST METHODOLOGY..................................................................................................................................................3 TEST FACILITY.............................................................................................................................................................3 SYSTEM TEST CONFIGURATION ..........................................................................................................................5 JUSTIFICATION.............................................................................................................................................................5 SCHEMATICS AND BLOCK DIAGRAM............................................................................................................................5 EQUIPMENT MODIFICATIONS.......................................................................................................................................5 TEST SETUP CONFIGURATION......................................................................................................................................6 TEST SETUP BLOCK DIAGRAM.....................................................................................................................................6 SUMMARY OF TEST RESULTS ...............................................................................................................................7 §15.203 - ANTENNA REQUIREMENT......................................................................................................................8 STANDARD APPLICABLE..............................................................................................................................................8 ANTENNA CONNECTED CONSTRUCTION......................................................................................................................8 § 15.207 (A) - CONDUCTED EMISSIONS TEST DATA .........................................................................................9 MEASUREMENT UNCERTAINTY....................................................................................................................................9 EUT SETUP..................................................................................................................................................................9 RECEIVER SETUP..........................................................................................................................................................9 TEST EQUIPMENT LIST AND DETAILS...........................................................................................................................9 TEST PROCEDURE........................................................................................................................................................9 ENVIRONMENTAL CONDITIONS....................................................................................................................................9 SUMMARY OF TEST RESULTS.....................................................................................................................................10 CONDUCTED EMISSIONS TEST DATA.........................................................................................................................10 PLOT OF CONDUCTED EMISSIONS TEST DATA...........................................................................................................10 §15.205, §15.209 (A), §15.249 (A) - RADIATED EMISSION DATA......................................................................13 APPLICABLE STANDARD............................................................................................................................................13 MEASUREMENT UNCERTAINTY..................................................................................................................................13 EUT SETUP................................................................................................................................................................13 RECEIVER SETUP........................................................................................................................................................14 TEST EQUIPMENT LIST AND DETAILS.........................................................................................................................14 ENVIRONMENTAL CONDITIONS.............…

Text truncated - open the document above for the full version.

Test Setup Photos

Wireless eSystems, Inc. FCC ID: OYILITEBASE Report # R0511143Exhibits FCC Part 15.249 Test Report EXHIBIT B - TEST SETUP PHOTOGRAPHS Conducted Emission – Front View Conducted Emission – Rear View Wireless eSystems, Inc. FCC ID: OYILITEBASE Report # R0511143Exhibits FCC Part 15.249 Test Report Radiated Emission – Front View Radiated Emission – Rear View
