Operational Description (SV1) SV1 has a FM transmitter. It is fixed inside the vehicle and powered 12V from car battery or adaptor. FM transmitter is designed to operate on frequency in the 88.1 ~ 107.9 MHz (range into 200 KHz Step) The u-com in the SV1 tunes the OSD frequency to the car stereo select by using + CH - button. The selected frequency varies as voltage and the voltage inputs to the RF OSC port of FM stereo transmitter IC (BH1415F). The stereo audio signal is modulated the selected frequency and the modulated RF is amplified by FM stereo transmitter IC (BH1415F). The amplified RF is transmitted via transmitting antenna. All tuning and verification are performed by the manufacturer and there are adjustments which can be made by the user within the 88.1 ~ 107.9 MHz (range into 200 KHz Step). External ground is the chassis of vehicle and transmitting antenna of the EUT is built-in inside the EUT.
