Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
FLC-BTM101 Datasheet Flaircomm Microelectronics Confidential -1- FLC-BTM101 Datasheet Document Type: Bluetooth Module Datasheet Document Number: FLC-BTM101-DS Document Version: V1.4 Release Date: 2012/8/29 Copyright 2012 ~ 2014 by Flaircomm Microelectronics Inc., All Right Reserved Without written permission from Flaircomm Microelectronics Inc., reproduction, transfer, distribution or storage of part or all of the contents in this document in any form is prohibited FLC-BTM101 Datasheet Flaircomm Microelectronics Confidential -2- Release Record Version Release Date Comments 1.0 2012/6/26 Initial Release 1.1 2012/8/1 Update Table 2. 1.2 2012/8/6 Add the weight. Add Part 5.1.1 & 5.2 & 5.3. Modify PCB footprint and reference design. 1.3 2012/8/8 Add BT/CE/FCC logo. Add Cautions & Warnings. 1.4 2012/8/29 Update FCC 2200 logo. Add module statement. FLC-BTM101 Datasheet Flaircomm Microelectronics Confidential -3- CONTENTS 1. INTRODUCTION .................................................................................................................. 7 1.1 BLOCK DIAGRAM ................................................................................................................... 7 1.2 FEATURES .............................................................................................................................. 7 1.3 APPLICATIONS ....................................................................................................................... 8 2. GENERAL SPECIFICATION ........................................................................................... 10 3. PIN DEFINITION ................................................................................................................ 11 3.1 PIN CONFIGURATION ............................................................................................................ 11 3.2 PIN DEFINITION .................................................................................................................... 11 4. PHYSICAL INTERFACES ................................................................................................ 14 4.1 POWER SUPPLY .................................................................................................................... 14 4.2 RESET .................................................................................................................................. 14 4.2.1 Digital Pin States on Reset ........................................................................................... 14 4.2.2 Power-on Reset ............................................................................................................ 14 4.3 GENERAL PURPOSE DIGITAL IO ........................................................................................... 15 4.4 GENERAL PURPOSE ANALOGUE IO ...................................................................................... 15 5. SERIAL INTERFACES ...................................................................................................... 16 5.1 UART .................................................................................................................................. 16 5.1.1 UART Configuration While in Deep Sleep ................................................................. 16 5.2 I 2 C INTERFACE ..................................................................................................................... 16 5.3 SPI MASTER INTERFACE ...................................................................................................... 17 5.4 PROGRAMMING AND DEBUG INTERFACE .............................................................................. 18 5.4.1 Instruction Cycle ........................................................................................................... 19 5.4.2 Multi-slave Operation .................................................................................................... 19 6. ELECTRICAL CHARACTERISTICS ............................................................................. 21 6.1 ABSOLUTE MAXIMUM RATINGS .......................................................................................... 21 6.2 RECOMMENDED OPERATING CONDITIONS ........................................................................... 21 6.3 INPUT/OUTPUT TERMINAL CHARACTERISTICS ..................................................................... 21 6.3.1 Digital Terminals.......................................................................................................... 21 FLC-BTM101 Datasheet Flaircomm Microelectronics Confidential -4- 6.4 AIO ..................................................................................................................................... 22 6.5 POWER CONSUMPTION ......................................................................................................... 22 7. REFERENCE DESIGN ....................................................................................................... 23 8. MECHANICAL CHARACTERISTIC .............................................................................. 24 9. RECOMMENDED REFLOW PROFILE ......................................................................... 27 10. ORDERING INFORMATION ........................................................................................ 29 10.1 PRODUCT PACKAGING INFORMATION ............................................................................... 29 10.2 ORDERING INFORMATION ................................................................................................. 31 10.2.1 Product Revision ....................................................................................................... 31 10.2.2 Shipping Package ...................................................................................................... 31 10.2.3 Product Package ........................................................................................................ 31 1…
Text truncated - open the document above for the full version.
SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (current) 2.0 3.0 Jan-31-2012 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 3.0
SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 August 21, 2012 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: P4IBTM101 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Client’s name / title Marvin.Zhao/ President Address: 7F,Guomai Building,116 East JiangBin Ave,Fuzhou,Fujian,China. Tel: 0591-88833388 E-mail: [email protected]
SCS-F26 Modular Approval Letter Page 1 of 2 Rev 7.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Modular Approval Declaration Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (Obsolete) 1.0 1.0 Dec-04-2006 Added IC Modular Letter (Obsolete) 1.0 2.0 Feb 16 2009 Add LMA and MA option (Obsolete) 2.0 3.0 April 14 2010 Revised per RSS Gen issue 3.0 (Obsolete) 3.0 4.0 Jan 12 2011 Removed Foot(2) (obsolete) 4.0 5.0 July 19 2011 Adding New note per KDB996369 D01 V01R03 (obsolete) 5.0 6.0 August 29 2011 Updated company template & Added text box (current) 6.0 7.0 Jan-31-2012 SCS-F26 Modular Approval Letter Page 2 of 2 Rev 7.0 August 21, 2012 FLC-BTM101 FCC ID : P4IBTM101 , is seeking FCC Authorization as a Single Modular transmitter / Single Limited Modular Approval (Please check one). The EUT meets the requirements for Single Modular approval / Single Limited Modular Approval (please check one) as detailed in FCC public Notice DA00-1407. Compliance to each of the requirements is described below : Questions are: * Please provide a detailed explanation if the answer is “No.” 1. “The modular transmitter must have its own RF shielding.” Yes / No 2. “The modular transmitter must have buffered modulation/data inputs.” Yes / No 3. “The modular transmitter must have its own power supply regulation.” Yes / No 4. “The modular transmitter must comply with the antenna requirements of section 15.203 and 15.204(c).” Yes / No 5. “The modular transmitter must be tested in a stand-alone configuration.” Yes / No 6. “The modular transmitter must be labeled with its own FCC ID number.” Yes / No 7. “The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacture must provide adequate instruction along with the module to explain any such requirements.” Yes / No 8. “The modular transmitter must comply with any applicable RF exposure requirements.” Yes / No Note: (1) LMA may be granted when one or more of the requirements in the table above cannot be demonstrated. LMA will also be issued in those instances where applicants can demonstrate that they will retain control over the final installation of the device, such that compliance of the end product is assured. In such cases, an operating condition on the LMA for the module must state that the module is only approved for use when installed in devices produced by a specific manufacturer. When LMA is sought, the application for equipment certification must specifically state how control of the end product into which the module will be installed, and will be maintained, such that full compliance of the end product is always ensured. (2) Please provide Clear and specific instructions describing the conditions, limitations and procedures for third-parties to use and/or integrate the module into a host device. (3) For non-Software Defined Radio transmitter modules where software is used to ensure compliance of the device, technical description of how such control is implemented to ensure prevention of third party modification must be provided (see KDB 594280). Note 1: Compliance of a module in its final configuration is the responsibility of the applicant. A host device will not be considered certified if the instructions regarding antenna configuration provided in the original description, of one or more separately certified modules it contains, were not followed. Example: A separately certified low-power transceiver module using Bluetooth technology which is housed in a desktop computer, laptop or peripheral does not require the overall system to be recertified, if the desktop computer, laptop or peripheral, as a stand-alone unit, complies with all applicable technical standards. Client’s name / title Marvin.Zhao/ President Address: 7F,Guomai Building,116 East JiangBin Ave,Fuzhou,Fujian,China. Tel: 0591-88833388 E-mail: [email protected]
Annex B. EUT External Photo EUT - Front View EUT - Rear View
BTM101 Label FCC ID: P4IBTM101 Model:BTM101 5.50mm 12.00mm FCC ID: P4IBTM101 Model:FLC-BTM101 5.50mm 12.00mm FLC-BTM101 Label
FLC-BTM101 Label Location FCC ID: P4IBTM101 Model:BTM101 22.00mm 13.40mm Label Location
Annex B. EUT Internal Photo Uncover Without Shielding - Front View Uncover Without Shielding – Rear View Antenna - Front View BT antenna
FCC ID : P4IBTM101 Portable device According to §15.247(e)(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to KDB 447498 (2)(a)(i) Frequency Range Low Frequency (MHz) High Frequency(MHz) Center frequency (MHz) 60/f SAR Limitation (mw) 2402 2480 2440 24.59 Maximum measured transmitter power Conducted Power (mw) Max Antenna Gain (dBi) EIRP (mw) 3.47 4.1 8.92 Threshold at which no SAR required is 24.59 mw. Maximum Tx power is 8.92mw EIRP. Conclusion: No SAR is required. SIMULTANEOUS TRANSMISSION EVALUATION N/A
Fujian Flaircomm Microelectronics,Inc. Bluetooth Module Main Model: FLC-BTM101 Serial Model: FLC-BTM101CQ1A, FLC-BTM101CQ2A,FLC- BTM101VQ1A, FLC-BTM101VQ2A August 17, 2012 Report No.: 12020627-FCC-R1 (This report supersedes NONE) Modifications made to the product : None This test report may be reproduced in full only. Test result presented in this test report is applicable to the representative sample only. This Test Report is Issued Under the Authority of: Alan Lv Compliance Engineer Alex Liu Technical Manager Title: RF Test Report for Bluetooth Module Model: FLC-BTM101 To: FCC Part 15.247: 2012, ANSI C63.4: 2009 Report No.: 12020627-FCC-R1 Issue Date: August 17, 2012 Page: 2 of 44 www.siemic.com.cn Laboratory Introduction SIEMIC, headquartered in the heart of Silicon Valley, with superior facilities in US and Asia, is one of the leading independent testing and certification facilities providing customers with one-stop shop services for Compliance Testing and Global Certifications. In addition to testing and certification, SIEMIC provides initial design reviews and compliance management through out a project. Our extensive experience with China, Asia Pacific, North America, European, and international compliance requirements, assures the fastest, most cost effective way to attain regulatory compliance for the global markets . Accreditations for Conformity Assessment Country/Region Accreditation Body Scope USA FCC, A2LA EMC , RF/Wireless , Telecom Canada IC, A2LA, NIST EMC, RF/Wireless , Telecom Taiwan BSMI , NCC , NIST EMC, RF, Telecom , Safety Hong Kong OFTA , NIST RF/Wireless ,Telecom Australia NATA, NIST EMC, RF, Telecom , Safety Korea KCC/RRA, NIST EMI, EMS, RF , Telecom, Safety Japan VCCI, JATE, TELEC, RFTEMI, RF/Wireless, Telecom Mexico NOM, COFETEL, Caniety Safety, EMC , RF/Wireless, Telecom Europe A2LA, NIST EMC, RF, Telecom , Safety Accreditations for Product Certifications Country/Region Accreditation Body Scope USA FCC TCB, NIST EMC , RF , Telecom Canada IC FCB , NIST EMC , RF , Telecom Singapore iDA, NIST EMC , RF , Telecom EU NB EMC & R&TTE Directive Japan MIC, (RCB 208) RF , Telecom Hong Kong OFTA (US002) RF , Telecom Title: RF Test Report for Bluetooth Module Model: FLC-BTM101 To: FCC Part 15.247: 2012, ANSI C63.4: 2009 Report No.: 12020627-FCC-R1 Issue Date: August 17, 2012 Page: 3 of 44 www.siemic.com.cn This page has been left blank intentionally. Title: RF Test Report for Bluetooth Module Model: FLC-BTM101 To: FCC Part 15.247: 2012, ANSI C63.4: 2009 Report No.: 12020627-FCC-R1 Issue Date: August 17, 2012 Page: 4 of 44 www.siemic.com.cn CONTENTS 1 EXECUTIVE SUMMARY & EUT INFORMATION ..........................................................................................5 2 TECHNICAL DETAILS .........................................................................................................................................6 3 MODIFICATION.....................................................................................................................................................7 4 TEST SUMMARY....................................................................................................................................................8 5 MEASUREMENTS, EXAMINATION AND DERIVED RESULTS ..................................................................9 ANNEX A. TEST INSTRUMENT & METHOD ........................................................................................................33 ANNEX B. EUT AND TEST SETUP PHOTOGRAPHS ...........................................................................................38 ANNEX C. TEST SETUP AND SUPPORTING EQUIPMENT................................................................................39 ANNEX D. USER MANUAL / BLOCK DIAGRAM / SCHEMATICS / PART LIST ............................................43 ANNEX E. DECLARATION OF SIMILARITY ........................................................................................................44 Title: RF Test Report for Bluetooth Module Model: FLC-BTM101 To: FCC Part 15.247: 2012, ANSI C63.4: 2009 Report No.: 12020627-FCC-R1 Issue Date: August 17, 2012 Page: 5 of 44 www.siemic.com.cn 1 EXECUTIVE SUMMARY & EUT INFORMATION The purpose of this test programme was to demonstrate compliance of the Fujian Flaircomm Microelectronics,Inc., Bluetooth Module and model: FLC-BTM101 against the current Stipulated Standards. The Bluetooth Module has demonstrated compliance with the FCC Part 15.247: 2012, ANSI C63.4: 2009 EUT Information EUT Description : Bluetooth Module Main Model : FLC-BTM101 Antenna Gain : Bluetooth: 4.1 dBi Input Power : Input: 1.8 ~ 3.6V DC Classification Per Stipulated Test Standard : FCC Part 15.247: 2012, ANSI C63.4: 2009 Title: RF Test Report for Bluetooth Module Model: FLC-BTM101 To: FCC Part 15.247: 2012, ANSI C63.4: 2009 Report No.: 12020627-FCC-R1 Issue Date: August 17, 2012 Page: 6 of 44 www.siemic.com.cn 2 TECHNICAL DETAILS Purpose Compliance testing of Bluetooth Module with stipulated standard Applicant / Client Fujian Flaircomm Microelectronics,Inc. 7F,Guomai Building,116 East JiangBin Ave,Fuzhou,Fujian,China. Manufacturer Fujian Flaircomm Microelectronics,Inc. 7F,Guomai Building,116 East JiangBin Ave,Fuzhou,Fujian,China. Laboratory performing the tests SIEMIC Nanjing (China) Laboratories NO.2-1,Longcang Dadao, Yuhua Economic Development Zone, Nanjing, China Tel:+86(25)86730128/86730129 Fax:+86(25)86730127 Email:[email protected] Test report reference number 12020627-FCC-R1 Date EUT received July 25, 2012 Standard applied FCC Part 15.247: 2012, ANSI C63.4: 2009 Dates of test (from – to) August 3, 2012 to August 15, 2012 No of Units : #1 Equipment Category : DTS Trade Name : N/A RF Operating Frequency (ies) Bluetooth : 2402-2480 MHz Number of Channels Bluetooth:40CH Modulation Bluetooth: GFSK FCC ID P4IBTM101 Title: RF Test Report for Bluetooth Module Model: FLC-BTM101 To: FCC Part 15.247: 2012, ANSI C63.4: 2009 Report No.: 12020627-FCC-R1 Is…
Text truncated - open the document above for the full version.
Annex B. Test Setup Photo Conducted Emissions Setup Front View Conducted Emissions Setup Side View Radiated Emissions Test Setup Below 1GHz - Rear View Radiated Emissions Test Setup Below 1GHz - Rear Closer View Radiated Emissions Test Setup Above 1GHz – Rear View Radiated Emissions Test Setup Above 1GHz – Rear Closer View
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 2.40 GHz - 2.48 GHz | 2.22 mW |

Bluetooth Module
Equipment Class
DSS - Part 15 Spread Spectrum Transmitter
WiFi and BT combo module
Equipment Class
DSS - Part 15 Spread Spectrum TransmitterBluetooth module
Equipment Class
DSS - Part 15 Spread Spectrum Transmitter
WIFI Module
Equipment Class
DTS - Digital Transmission System
Bluetooth module
Equipment Class
DSS - Part 15 Spread Spectrum Transmitter
