P4M-ACT200DVehicle Tracking Device

Personal GPS Locator Users Manual (ACT200-D) All Rights Reserved. 1/12 CDMA VEHICLE TRACKER Users Manual NOV, 2011 ACT200-D, V0.2 AnyDATA AnyTime AnyPlace Any Wireless Data Solutions™ Personal GPS Locator Users Manual (ACT200-D) All Rights Reserved. 2/12 AnyDATA CDMA ACT200-D Copyright © 2009 AnyDATA Corp. All Rights Reserved. Any part of this document may not be distributed, communicated, reproduced or transmitted in any form or by any means, electronic or mechanical or otherwise, for any purpose, without the permission of AnyDATA Corp. This document can be subjected to revision without further notice. Contact Address Headquarter AnyData Corporation 5 Oldfield, Irvine, CA 92618, http://www.anydata.net e-mail: [email protected] Rep:1-949-833-0011 Fax: 1-949-833-0022 AnyData(China) 489 Song Tao Road, Sector B, 1st Fl. Pudong ZhanJiang Hi- Tech Park, Shanghai, 201203, P.R.China http://www.anydata.net.cn e-mail: [email protected] Rep:+86-21-5080-4828 Fax:+86-21-5080-3828 AnyData.Net Inc.(Korea) DaeGo Bldg, 8th., 1591-10 Kwanyang-dong, Dongan_gu, Anyang City, Kyunggi-do Korea. http://www.anydata.co.kr e-mail: [email protected] Rep:+82-31-380-7100 Fax:+82-31-476-6021 Personal GPS Locator Users Manual (ACT200-D) All Rights Reserved. 3/12 Contents Contents 3 Figures 4 Tables 4 1 Introduction 5 1.1 Purpose ......................................................................................................................... 5 1.2 Technical Detail ...................................................................................................... 5 1.3 Revision History ...................................................................................................... 5 2 Physical Contents 6 3 Description: Vehicle GPS Locator (ACT200-D) 7 3.1 The Latest in GPS Technology ............................................................................. 7 3.2 Alerts & Messages .................................................................................................... 7 3.3 Tracking Reports ...................................................................................................... 7 4 handing the Vehicle GPS Locator 9 4.1 Set-up ........................................................................................................................... 9 4.2 Power supply from vehicle (typical 13.8V) .................................................. 9 5 Powering On/Off the Vehicle GPS Locator 10 5.1 Powering On/OFF ...................................................................................................... 10 6 Vehicle GPS Locator Specifications 11 6.1 Form Factor .............................................................................................................. 11 6.2 Hardware Specifications ..................................................................................... 11 6.3 Software Specifications ..................................................................................... 11 6.4 Mechanical ................................................................................................................. 11 6.5 External INTERFACE ................................................................................................ 11 6.6 Environmental .......................................................................................................... 12 7 Limitations of Liability 12 Personal GPS Locator Users Manual (ACT200-D) All Rights Reserved. 4/12 Figures Figure 2.1: Package Contents ............................................................................................... 6 Figure3.1: External Interface ............................................................................................. 8 Figure4.1: Installation of ACT200-D in vehicle ......................................................... 9 Tables Table 1.1: Revision History .............................................................................................. 5 ! RF Exposure Warning: The radiated output power of this device is below the FCC radio frequency exposure limits. Nevertheless, the device should be used in such a manner that the potential for human contact during normal operation is minimized. In order to avoid the possibility of exceeding the FCC radio frequency exposure limit, human proximity to the a ntenna should not be less than 20 mm. Information to user (FCC Part 15.21): No changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Personal GPS Locator Users Manual (ACT200-D) All Rights Reserved. 5/12 1 INTRODUCTION 1.1 PURPOSE This manual discusses the purpose and usage of the Vehicle GPS Locator (ACT200-D). 1.2 TECHNICAL DETAIL Please refer to Technical Manual.pdf for a more detailed description of the ACT200-D. 1.3 REVISION HISTORY The revision history for this manual is shown in Table 1.1. Table 1.1: Revision History Version Date Description v 0.1 OCT 2011 Initial Release –ACT200-D V 0.2 NOV 2011 RF Exposure Warning changed. Personal GPS Locator Users Manual (ACT200-D) All Rights Reserved. 6/12 2 PHYSICAL CONTENTS Figure 2.1: Package Contents The box should contain: • One ACT200-D Vehicle GPS Tracker • One User Guide If any of items on Figure 2.1 are missing, please contact AnyDATA or distributor/reseller where device was purchased. Personal GPS Locator Users Manual (ACT200-D) All Rights Reserved. 7/12 3 DESCRIPTION: VEHICLE GPS LOCATOR (ACT200-D) 3.1 THE LATEST IN GPS TECHNOLOGY Utilizing both assisted and standalone GPS, ACT200-D is able to determine your location via a combination of cell triangulation and the greatest number of GPS satellites available. ACT200-D charges via the included USB wall charger. ACT200-D is equipped with a battery life of 3-7 days with normal usage. 3.2 ALERTS & MESSAGES ACT200-D has no button for user-set alert functions; the LBS (Location based server) can only know the device location and alrets including the vehicle in…

Text truncated - open the document above for the full version.

-l€eu.. tW$$AnyDATA' FCC Confidential Authorization t0nU20tl FEDERAL COMMUNICATIONS COMMIS SIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request regarding application for certification of ilc 'ID: P4M.ACT2OOD In accordance with Sections 0.457 and 0.459 of the Commission's Rules, AnyDATA hereby requests long-term confidential treatment of information accompanying this application as outlined below: The above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Sincerelv. Client's si h-- T el: 9 49 -9 00-6040 ex\322 Fax:949-600-9909 5 Oldfield Irvine, CA926I8 Doug Kwon / Project

AnyDATA Corporation FCC ID: P4M-ACT200D Report Number: R1110171-2224 Page 40 of 43 FCC Part 22H/24E Test Report 14 EXHIBIT C - EUT PHOTOGRAPHS 14.1 EUT- Front Side View 14.2 EUT- Back Side View AnyDATA Corporation FCC ID: P4M-ACT200D Report Number: R1110171-2224 Page 41 of 43 FCC Part 22H/24E Test Report 14.3 EUT – Port View 1 14.4 EUT – Port View 2

[ACT200-D] Label Format Before Printing After Printing Refer to CAD File for Label ’ s OUTLINE 24.5mm 14.5mm 6C123456 Thickness = 0.05mmColor : Background Color is White and Letter’s Color is BlackBar code : S/N : 7 digit, 1234567 20110730 ACT200-D P4M-ACT200D Production Code : YYYYMMLL BAR Code : 128A Font size : Arial 4 [ACT200-D] Label Location

AnyDATA Corporation FCC ID: P4M-ACT200D Report Number: R1110171-2224 Page 42 of 43 FCC Part 22H/24E Test Report 14.5 EUT-Uncovered View 14.6 EUT Internal – Board Assembly Top View AnyDATA Corporation FCC ID: P4M-ACT200D Report Number: R1110171-2224 Page 43 of 43 FCC Part 22H/24E Test Report 14.7 EUT Internal – Board Assembly Bottom View 14.8 EUT Internal – With OBD-II power cable --- END OF REPORT ---

AnyDATA Corporation FCC ID: P4M-ACT200D Report Number: R1110171-2224 Page 34 of 43 FCC Part 22H/24E Test Report 11 FCC §1.1307(b)(1) & §2.1091 - RF EXPOSURE INFORMATION 11.1 Applicable Standard According to FCC §1.1310 and §2.1091 (Mobile Devices) RF exposure is calculated. Limits for General Population/Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (minute) Limits for General Population/Uncontrolled Exposure 0.3-1.34 614 1.63 *(100) 30 1.34-30 824/f 2.19/f *(180/f 2 ) 30 30-300 27.5 0.073 0.2 30 300-1500 / / f/1500 30 1500-100,000 / / 1.0 30 Note: f = frequency in MHz * = Plane-wave equivalent power density 11.2 MPE Prediction Predication of MPE limit at a given distance, Equation from OET Bulletin 65, Edition 97-01 S = PG/4πR² Where: S = power density P = power input to antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Cellular Band Maximum peak output power at antenna input terminal (dBm):25.00 Maximum peak output power at antenna input terminal (mW):316.23 Prediction distance (cm):20 Prediction frequency (MHz):824.7 Antenna Gain, typical (dBi):3 Antenna Gain numeric:2 Power density at predication frequency and distance (mW/cm 2 ):0.1258 MPE limit for uncontrolled exposure at predication frequency (mW/cm 2 ):0.5498 PCS Band Maximum peak output power at antenna input terminal (dBm):25.01 Maximum peak output power at antenna input terminal (mW):316.96 Prediction distance (cm):20 Prediction frequency (MHz):1880 Antenna Gain, typical (dBi):3 Antenna Gain numeric :2 Power density at predication frequency and distance (mW/cm 2 ):0.1261 MPE limit for uncontrolled exposure at predication frequency (mW/cm 2 ):1.0 AnyDATA Corporation FCC ID: P4M-ACT200D Report Number: R1110171-2224 Page 35 of 43 FCC Part 22H/24E Test Report Results For Cellular band, the highest power density level at 20 cm is below the uncontrolled exposure limit. For PCS band; the highest power density level at 20 cm is below the uncontrolled exposure limit.

Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in part without prior written consent from Bay Area Compliance Laboratories Corp. This report must not be used by the customer to claim product certification, approval, or endorsement by NVLAP*, NIST, or any agency of the Federal Government. * This report may contain data that are not covered by the NVLAP accreditation and are marked with an asterisk “*” (Rev.2) FCC PART 22H, 24E TEST AND MEASUREMENT REPORT For AnyDATA Corporation 5 Oldfield, Irvine, CA 92618, USA Report Type: Original Report Product Type: CDMA Vehicle Tracker Test Engineer: Arthur Tie Report Number: R1110171-2224 Report Date: 2011-11-08 Reviewed By: Victor Zhang EMC & RF Lead Prepared By: (SP) Bay Area Compliance Laboratories Corp. 1274 Anvilwood Avenue, Sunnyvale, CA 94089, USA Tel: (408) 732-9162 Fax: (408) 732 9164 FCC ID: P4M- ACT200D AnyDATA Corporation FCC ID: P4M-ACT200D Report Number: R1110171-2224 Page 2 of 43 FCC Part 22H/24E Test Report TABLE OF CONTENTS 1 GENERAL INFORMATION ..............................................................................................................................5 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT).........................................................................5 1.2 MECHANICAL DESCRIPTION............................................................................................................................5 1.3 OBJECTIVE.......................................................................................................................................................5 1.4 RELATED SUBMITTAL(S)/GRANT(S) ................................................................................................................5 1.5 TEST METHODOLOGY......................................................................................................................................6 1.6 MEASUREMENT UNCERTAINTY.......................................................................................................................6 1.7 TEST FACILITY.................................................................................................................................................6 2 SYSTEM TEST CONFIGURATION..................................................................................................................7 2.1 JUSTIFICATION.................................................................................................................................................7 2.2 EUT EXERCISE SOFTWARE..............................................................................................................................7 2.3 SPECIAL ACCESSORIES....................................................................................................................................7 2.4 EQUIPMENT MODIFICATIONS...........................................................................................................................7 2.5 REMOTE SUPPORT EQUIPMENT........................................................................................................................7 2.6 INTERNAL CONFIGURATION.............................................................................................................................7 2.7 POWER SUPPLY AND LINE FILTERS..................................................................................................................7 2.8 INTERFACE PORTS AND CABLING....................................................................................................................7 3 SUMMARY OF TEST RESULTS.......................................................................................................................8 4 FCC §2.1046, §22.913(A) & §24.232 – RF OUTPUT POWER .........................................................................9 4.1 APPLICABLE STANDARD..................................................................................................................................9 4.2 TEST PROCEDURE............................................................................................................................................9 4.3 TEST SETUP BLOCK DIAGRAM.......................................................................................................................10 4.4 TEST EQUIPMENT LIST AND DETAILS............................................................................................................10 4.5 TEST ENVIRONMENTAL CONDITIONS.............................................................................................................11 4.6 TEST RESULTS...............................................................................................................................................11 5 FCC §2.1047 - MODULATION CHARACTERISTIC....................................................................................13 5.1 APPLICABLE STANDARD................................................................................................................................13 6 FCC §2.1049, §22.917, §22.905 & §24.238 - OCCUPIED BANDWIDTH......................................................14 6.1 APPLICABLE STANDARD................................................................................................................................14 6.2 TEST PROCEDURE..........................................................................................................................................14 6.3 TEST EQUIPMENT LIST AND DETAILS............................................................................................................14 6.4 TEST ENVIRONMENTAL CONDITIONS.............................................................................................................14 6.5 TEST RESULTS & PLOTS..................................................................................................................…

Text truncated - open the document above for the full version.

AnyDATA Corporation FCC ID: P4M-ACT200D Report Number: R1110171-2224 Page 38 of 43 FCC Part 22H/24E Test Report 13 EXHIBIT B - TEST SETUP PHOTOGRAPHS 13.1 Radiated Emissions below 1 GHz - Front View 13.2 Radiated Emissions below 1 GHz - Rear View AnyDATA Corporation FCC ID: P4M-ACT200D Report Number: R1110171-2224 Page 39 of 43 FCC Part 22H/24E Test Report 13.3 Radiated Emissions above 1 GHz - Front View 13.4 Radiated Emissions above 1 GHz - Rear View
