P4SMTC9508Radio Control Helicopt
Megatech International Inc.
Click to zoom
Application Details
- Equipment Class
- DXX - Part 15 Low Power Communication Device Transmitter
- Date of Grant
- Dec 19, 2007
- Application Purpose
- Original Equipment
- Date of Application
- Dec 18, 2007
- Equipment Note
- Radio Control Helicopt
- Frequency Range
- 27.14500000 - 27.14500000
- Company
- Megatech International Inc.
- Country
- United States
Documents & Files
Document Text
Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
Cover Letter(s)
CONFIDENTIALITY FORM Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: This letter is to comply with Sections 0.457 and 0.459 pertaining to confidential material. Magethch International Inc. would like the following documents regarding this submission for FCC ID: P4SMTC9508 to be kept confidential. 1. Schematics. 2. Block Diagram. 3. Operation Description The above material contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want these documents to be accessible to the general public. Sincerely, President
ID Label/Location Info
ID label & location info. ID label location FCC ID: P4SMTC9508
Test Report
Page 1 of 18 FCC ID: P4SMTC9508 ACCURATE TECHNOLOGY CO. LTD REPORT NO. ATE20073040 FCC CERTIFICATION On Behalf of Megatech International Inc. Radio Control Helicopt Model No.: MTC9508 FCC ID: P4SMTC9508 Prepared for : Megatech International Inc Address : 8300 Tonnelle Avenue, North Bergen, NJ 07047, USA Prepared by : ACCURATE TECHNOLOGY CO. LTD Address : F1, Bldg. A, Changyuan New Material Port, Keyuan Rd. Science & Industry Park, Nanshan, Shenzhen, Guangdong P.R. China Tel: (0755) 26503290 Fax: (0755) 26503396 Report Number : ATE20073040 Date of Test : December 12, 2007 Date of Report : December 18, 2007 Page 2 of 18 FCC ID: P4SMTC9508 ACCURATE TECHNOLOGY CO. LTD REPORT NO. ATE20073040 TABLE OF CONTENTS Description Page Test Report Certification 1. GENERAL INFORMATION .......................................................................................................... 4 1.1. Description of Device (EUT)....................................................................................................................4 1.2. Description of Test Facility ......................................................................................................................4 1.3. Measurement Uncertainty.........................................................................................................................4 2. MEASURING DEVICE AND TEST EQUIPMENT ..................................................................... 5 3. RADIATED EMISSION FOR FCC PART 15 SECTION 15.227(B)........................................... 6 3.1. Block Diagram of Test Setup....................................................................................................................6 3.2. The Field Strength of Radiation Emission Measurement Limits..............................................................6 3.3. Configuration of EUT on Measurement ...................................................................................................7 3.4. Operating Condition of EUT ....................................................................................................................7 3.5. Test Procedure ..........................................................................................................................................7 3.6. The Field Strength of Radiation Emission Measurement Results ............................................................8 4. FUNDAMENTAL RADIATED EMISSION FOR FCC PART 15 SECTION 15.227(A) .......... 9 4.1. Block Diagram of Test Setup....................................................................................................................9 4.2. The Emission Limit For Section 15.227(a) ..............................................................................................9 4.3. EUT Configuration on Measurement .....................................................................................................10 4.4. Operating Condition of EUT ..................................................................................................................10 4.5. Test Procedure ........................................................................................................................................10 4.6. The Emission Measurement Result ........................................................................................................11 5. BAND EDGES ................................................................................................................................. 12 5.1. The Requirement ....................................................................................................................................12 5.2. EUT Configuration on Measurement .....................................................................................................12 5.3. Operating Condition of EUT ..................................................................................................................12 5.4. Test Procedure ........................................................................................................................................12 5.5. The Measurement Result ........................................................................................................................13 APPENDIX I ( TEST CURVES) (4pages) Page 3 of 18 FCC ID: P4SMTC9508 ACCURATE TECHNOLOGY CO. LTD REPORT NO. ATE20073040 Test Report Certification Applicant : Megatech International Inc. Manufacturer : Shanghai C.C.Lee Model Co., Ltd. EUT Description : Radio Control Helicopt (A) MODEL NO.: MTC9508 (B) SERIAL NO.: N/A (C) POWER SUPPLY: DC 12V (8דAA” batteries) Measurement Procedure Used: FCC Rules and Regulations Part 15 Subpart C Section 15.227: 2007 The device described above is tested by ACCURATE TECHNOLOGY CO. LTD to determine the maximum emission levels emanating from the device. The maximum emission levels are compared to the FCC Part 15 Subpart C Section 15.227 limits. The measurement results are contained in this test report and ACCURATE TECHNOLOGY CO. LTD is assumed full responsibility for the accuracy and completeness of these measurements. Also, this report shows that the Equipment Under Test (EUT) is to be technically compliant with the FCC requirements. This report applies to above tested sample only. This report shall not be reproduced in part without written approval of ACCURATE TECHNOLOGY CO. LTD. Date of Test : December 12, 2007 Prepared by : (Engineer) Reviewer : (Quality Manager) Approved & Authorized Signer : (Manager) Page 4 of 18 FCC ID: P4SMTC9508 ACCURATE TECHNOLOGY CO. LTD REPORT NO. ATE20073040 1. GENERAL INFORMATION 1.1. Description of Device (EUT) EUT : Radio Control Helicopt Model Number : MTC9508 Power Supply : DC 12V (8דAA” batteries) Operation Frequency : 27.145MHz Modulation Type : FM Applicant : Megatech International Inc. Address : 8300 Tonnelle Avenue, North Bergen, NJ 07047, USA Manufacturer : Shanghai C.C.Lee Model Co., Ltd. Address : No.1289#, Jiasong …
Text truncated - open the document above for the full version.
Contact Information
Applicant
Peter R Winston(President)
Test Firm
Shenzhen Academy of Metrology & Quality InspectionPeter Lin
Technical Specifications
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 27.145 MHz - 27.145 MHz | - |
