P4XKB778cordless mouse

APPENDIX C - EUT EXTERNAL PHOTOGRAPHS Transmitter Chassis - Top View Transmitter Chassis - Bottom View

APPENDIX A - FCC PRODUCT LABELING AND WARNING STATEMENT FCC ID Label Specifications: Text is black in color and is left justified. Labels are printed in indelible ink on permanent adhesive backing and shall be affixed at a conspicuous location on the EUT. Proposed Label Location on EUT Bottom Side of EUT/FCC ID Label Proposed Location FCC Warning Statement If the EUT is too small, the FCC statement could be presented in the user manual. The following is one sample of the FCC Statement: “ This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.” FCC ID: P4XKB778 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 2.1875" 1.0"

APPENDIX C - EUT PHOTOGRAPHS Transmitter - Cover Off View Transmitter Main Board - Component View Transmitter Main Board - Solder View Antenna Board - Circuit View Antenna Board – Component View

Note: This test report is specially limited to the above client company and product model only. It may not be duplicated without prior written consent of Bay Area Compliance Laboratory Corporation. This report must not be used by the client to claim product endorsement by NVLAP or any agency of the U.S. Government. FCC ID PER PART 15.227 EMI MEASUREMENT AND TEST REPORT For Dynapoint (Dong Guan) Electronics Co. Ltd Hua Guo Shan Industry Park, Jie Kou. Chang An. Dong Guan Guan Dong, China FCC ID: P4XKB778 January 20, 2003 This Report Concerns: Original Report Equipment Type: Cordless Mouse, ITE Test Engineer: Benjamin Jing Report No.: R0301102 Test Date: January 14, 2003 Reviewed By: Hans Mellberg Prepared By: Bay Area Compliance Laboratory Corporation 230 Commercial Street Sunnyvale, CA 94085 Tel: (408) 732-9162 Fax: (408) 732-9164 DynaPoint (Dong Guan) Inc. FCC ID: P4XKB778 Report # R0301102 Page 2 of 8 FCC ID Per 15.227 Report TABLE OF CONTENTS 1 - GENERAL INFORMATION.................................................................................................................................................3 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT)........................................................................................3 1.2 OBJECTIVE................................................................................................................................................................................3 1.3 RELATED SUBMITTAL(S)/GRANT(S).....................................................................................................................................3 1.4 TEST METHODOLOGY..............................................................................................................................................................3 1.5 TEST FACILITY.........................................................................................................................................................................3 1.6 TEST EQUIPMENT LIST............................................................................................................................................................4 1.7 LOCAL SUPPORT EQUIPMENT LIST AND DETAILS...............................................................................................................4 1.8 EXTERNAL I/O CABLES LIST AND DETAILS.........................................................................................................................4 2 - SYSTEM TEST CONFIGURATION..................................................................................................................................5 2.1 JUSTIFICATION..........................................................................................................................................................................5 2.2 SCHEMATICS AND BLOCK DIAGRAM....................................................................................................................................5 2.3 EQUIPMENT MODIFICATIONS.................................................................................................................................................5 2.4 TEST SETUP CONFIGURATION................................................................................................................................................5 3 - SUMMARY OF TEST RESULTS........................................................................................................................................6 4 - RADIATED EMISSIONS TEST...........................................................................................................................................7 4.1 MEASUREMENT UNCERTAINTY.............................................................................................................................................7 4.2 EUT SETUP...............................................................................................................................................................................7 4.3 SPECTRUM ANALYZER SETUP................................................................................................................................................7 4.4 TEST PROCEDURE....................................................................................................................................................................7 4.5 CORRECTED AMPLITUDE & MARGIN CALCULATION.........................................................................................................8 4.6 SUMMARY OF TEST RESULTS.................................................................................................................................................8 4.7 RADIATED EMISSIONS TEST RESULT DATA.........................................................................................................................8 DynaPoint (Dong Guan) Inc. FCC ID: P4XKB778 Report # R0301102 Page 3 of 8 FCC ID Per 15.227 Report 1 - GENERAL INFORMATION 1.1 Product Description for Equipment Under Test (EUT) The Dynapoint (Dong Guan) Electronics Co. Ltd. ’s product, model KB778 or the "EUT" as referred to in this report is a wireless mouse. EUT measures approximately 4.8” L x 2.2” W x 1.5” H . 1.2 Objective This Type approval report is prepared on behalf of Dynapoint (Dong Guan) Electronics Co. Ltd. in accordance with Part 2, Subpart J, and Part 15, Subparts A and B of the Federal Communication Commissions rules. The objective of the manufacturer is to demonstrate compliance with FCC rules, sec 15.209 and sec 15.227. 1.3 Related Submittal(s)/Grant(s) No Related Submittals. 1.4 Test Methodology All measurements contained in this report were conducted with ANSI C63.4-1992, American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the range of 9 kHz to 40 GHz. All radiated and conducted emissions measurement was performed at Bay Area Com…

Text truncated - open the document above for the full version.

APPENDIX B - TEST SETUP PHOTOGRAPHS Radiated Emission
