P6CFSLXULI236Energy Saving Lamp

Foshan Electrical And Lighting Co., Ltd.

Click to zoom

Application Details

Equipment Class: 8CC - Part 18 Consumer Device
Date of Grant: Feb 07, 2002
Application Purpose: Original Equipment
Date of Application: Feb 07, 2002
Equipment Note: Energy Saving Lamp
Frequency Range: 0.04000000 - 0.05000000
Company: Foshan Electrical And Lighting Co., Ltd.
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Page 1 Foshan Electrical And Lighting Co., Ltd. Energy Saving Lamp FCC ID: P6CFSLXULI236 EXHIBIT 5 User’s Manual CAUTIONS AND INSTRUCTION Page 2 Foshan Electrical And Lighting Co., Ltd. Energy Saving Lamp FCC ID: P6CFSLXULI236 1. Use only on 110-120V, 60Hz. 2. Never disassemble or modify the lamp. 3. To prevent risk of fire, never install this device in the following fixtures: a. Fixture on dimming circuits. b. Emergency exit lights powered by direct current (DC). 4. To avoid risk of electronic shock----use only in dry locations. 5. This product may produce interference when using a T.V., radio or a wireless remote control. If interference should occur, move the lamp away form such equipment three feet or more, otherwise, plug the lamp or the receiver into a different outlet. 6. To prevent burns and avoid electric shock, please do not touch the bulb or cap during operation or immediately after switching off. 7. COMPLIANCE INFORMATION STATEMENT Product Name: Energy Saving Lamp Model Number: F205, F207, F209, F211, F213; F315, F318, F322, F324, F326; F 615, F618, F622, F624, F626. This device complies with part 18 of FCC Rules operation is subject to the following two conditions: 1) This device may not cause harmful interference. 2) This device must accept any interference received, including interference that may cause undesired operation. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment.
