P8FCDPD-MON-02CDPD System Pager

Version 8.0 Quick Start Guide v 7.0 Digital Angel Corporation Page 2 Getting Started Step 1 Checking the Package Contents Make sure you have received the following items in the package. If any of these items are missing or damaged, contact the Digital Angel Product Support Line (see below): • Digital Angel monitor • Digital Angel ThermAlert watch • 115 volt AC adapter/wall charger • Car charger Digital Angel Product Support Line Telephone: 1-877-432-0830 Hours: 7:30 a.m. to 8:30 p.m. EST. After hours, you may leave a message and a Digital Angel Product Support Line specialist will return your call during business hours. In the event of an after hours emergency, you may leave an urgent message and your call will be returned as soon as possible. We can also be reached via email at [email protected] Quick Start Guide v 7.0 Digital Angel Corporation Page 3 Step 2 Getting Acquainted With Your Digital Angel Monitor Please take time to examine the diagram below and get acquainted with the components and features of your Digital Angel monitor. Emergency Button Enables the wearer to signal a distress call to the Digital Angel Operations Center. ON/OFF Switch—Slide up to turn ON, Slide down to turn OFF Antenna LED Status Lights The three LED status lights provide you with information about how your Digital Angel monitor is operating. • Power Status. A flashing red light means the monitor is powered up. A constant red light means the battery is low and requires charging. • Communication Status. A flashing green light means the monitor is in communication with the AT&T Wireless Network. • Battery Charging status. A constant red light appears while the battery is charging. A flashing red light (once every four seconds) indicates completion of the charging process. This device complies with Part 15 of the FCC Rules. Operation is subject to the condition that this device does not cause harmful interference. Step 3 Charging the Battery • You should charge the battery for a full six hours before beginning to use your Digital Angel monitor. Plug the AC adapter into your Digital Angel monitor, then into a 115V AC wall outlet to charge the battery. • The battery will supply adequate power for approximately 8 hours under normal use. The top LED light on the front of your Digital Angel monitor will show a constant red when the battery becomes low. Step 4 Getting Acquainted With Your Digital Angel ThermAlert Watch Please take time to examine the diagram below and get acquainted with the components and features of your Digital Angel watch. –INSERT: DIAGRAM OF THERMALERT WATCH- Quick Start Guide v 7.0 Digital Angel Corporation Page 4 LCD Digital Time Display The ThermAlert Watch features a fully functional digital clock that can be adjusted and reset. Time Adjustment/Reset Button ON/OFF Switch LCD RF Transmission Link Indicator When the temperature data transmission feature is activated, the indicator flashes at 18-second intervals, indicating active transmission of temperature data—via Radio Frequency (RF) link—from the ThermAlert Watch to the Digital Angel Monitor. The indicator does not appear when the temperature data transmission is deactivated or when the RF link is compromised. Mode Switch Switches between normal clock mode and stop-watch mode. Battery Compartment The ThermAlert Watch uses a non-replaceable battery that provides approximately two months of operation time when the temperature function enabled. This device complies with Part 15 of the FCC Rules. Operation is subject to the condition that this device does not cause harmful interference. Step 5 Turning on Your Digital Angel Monitor Once the battery is fully charged, turn on your Digital Angel monitor. When the communications status light begins blinking the monitor is properly communicating with the AT&T Wireless Network. This can take approximately 20 seconds after switching on your monitor although this varies by area. Move next to a window if the communications status light does not begin flashing. If the communications status light still does begin flashing this means that you do not have AT&T Wireless Network coverage in your area. Once the Digital Angel monitor is powered up, you should enable the temperature sensing function on the ThermAlert Watch and check the LCD Data Transmission Indicator to confirm (indicated by flashing at 18- second intervals) the RF link between the Watch and the Digital Angel monitor. Note: To maintain the integrity of the RF link, the distance between the ThermAlert Watch and Digital Angel monitor must be no more than 1.5 meters (approximately 4.9 feet). You are now ready to proceed with registering your Digital Angel monitor. Step 6 Registering Your Digital Angel Monitor In order to complete the registration process, you will need: • The EID of your Digital Angel monitor. The EID number is labeled on the back of the monitor. • Caregiver contact information including address, telephone number and email address. • Wearer information including address, telephone number, the established Temperature parameters and Location Boundary for the Wearer. • The User ID and Password of your choice required for access to all Digital Angel information requests via the Web site. • PIN number of your choice for telephone access to Digital Angel Alert Information Hotline Register your Digital Angel monitor by going to http://www.digitalangel.net and clicking the Beta Test button found in the upper right on the Digital Angel home page. You will be taken to the Digital Angel Registration page. Quick Start Guide v 7.0 Digital Angel Corporation Page 5 Now you’re ready to click the “REGISTER” button. This takes you to the Caregiver Profile page. Quick Start Guide v 7.0 Digital Angel Corporation Page 6 Enter all requested caregiver information; email address for receiving reports as well as alert notifications, portable email address (for receiving alert notifications), along with the User ID, Password, PIN number and Securi…

Text truncated - open the document above for the full version.

Digital Angel CDPD Unit Block Diagrams GPS Module CDPD Module Local RF Receiver Module FallDown Sensor Module MCU --- DA CDPD System Micro-Controller Power supply / Mower Management System RF Transmitter Module Temperature Sensor Module Power Supply Watch Micro-controller DA Watch Unit DA Pager Unit

From: M. Flom Associates, Inc. [[email protected]] Sent: Friday, May 03, 2002 4:20 PM To: [email protected] Subject: Job #339XC2 DIGITAL ANTGEL CORP. ID; P8FCDPD-MON-02 Eric: Thanks for the email. The applicant has informed us, and we have measured, a pulse of 200 x l0 to the minus 6 secs. occurring every 30 seconds. Thus the duty cycle factor if D.C.F. = 200 X 10-6 OVER 30 = 6.667 X 10 -6 For a maximum R.F.Output Power: the theoretical power = 600 x l0 to the -3 W x D.C.F. = 4 X 10 TO THE -6 WATTS (AVERAGE POWER) WE REPORTED 1.48 MILLIWATTS AS MEASURED. We trust this is the information you need to issue both the Grant for the Watch and the Monitor. Personal regards, Mort - M. Flom Associates, Inc. Confidential - The information in this message is only intended for the person(s) or organization(s) to whom it is addressed. If you are not that person, please contact the sender, and destroy this copy.

From: M. Flom Associates, Inc. [[email protected]] Sent: Monday, May 06, 2002 7:04 PM To: [email protected] Subject: Digital Angel Corp FCC ID: P8FCDPD-MON-02 Job #339XC2 Follow Up Flag: Follow up Flag Status: Flagged Eric: Please see attached plot. The device uses an integral antenna - only radiated measurements available. Plot obtained with device wrapped tightly to 1/2 wave dipole connected to scope. E volts, measured = 30 mv P to P. Power Output = (E squared)/50 for 50 ohm system = 10 microwatts p-to-peak Plot shows approximately 50% Duty Cycle Regards, Mort Flom M. Flom Associates, Inc. Confidential - The information in this message is only intended for the person(s) or organization(s) to whom it is addressed. If you are not that person, please contact the sender, and destroy this copy.

Description of Circuitry of Digital Angel CDPD System The Digital Angel CDPD System consists of several function blocks, which perform various operations according to the system design: 1 The system operates on CDPD network. It uses GPS for position tracking purpose. It also has built-in fall down sensor and temperature sensor for bio-information purpose. The device communicates locally with the watch unit, which has the temperature sensor and RF transmitter to sense and send the temperature data wirelessly to the pager unit, which has the RF receiver to receive the information sent from the watch unit. The pager unit has a built-in fall down sensor, which can monitor the device carrier’s physical body state. It will trigger an alarm if the carrier falls down unexpectedly and in a harm way. The pager unit will trigger an alarm if the temperature runs out of pre-defined temperature range or if the carrier is out of the pre-defined geo-boundary. The carrier can trigger an alarm if he or she pushes the panic button, and the alarm will include the position data, body state data and temperature data. The monitor center can call the unit remotely and configure the unit remotely to get the updated information of the device carrier. 2 The all system function is controlled by its micro-controller. Under its control, CDPD module collects the data from output of the controller, and send the data to the monitor center via CDPD network. The CDPD module also receives the call from the monitor center and sends back to the micro-controller for further data processing. When the controller receives the call from CDPD, it starts searching for the desired information and then make decision according to result of the data processing. GPS module gets position data if it is turned on by the controller, and then sends back to the controller for further data processing. The falldown sensor constantly monitors the physical body state if it is turned on by the controller, and if the alarm condition is met, then it sends the alarm data back to the controller for further data processing. 3 The temperature monitoring function is done through local RF link between the pager unit and the watch unit. The watch monitors its temperature periodically if it is turned on by the carrier. If the alarm condition is met, it sends the alarm data back to the controller for further data processing. It also sends the temperature data back to the controller for normal data request from the monitor center or if the panic button is triggered. All these function is controller by its internal micro-controller. 4 The power management system is controlled by the system micro-controller. GPS receiver module is turned on only during data request. At the same time, CDPD module is turned off to save the power and to reduce the interference between CDPD module and GPS module.

Index of CDPD 2 Piece (Watch & Pager) Bill of Material Status Report For any questions or comments contact: Michael Dunn Production ManagerDigital Angel Systems909-276-7180 Ext 231Section 1CASE SUBASSEMBLY - List of all items that pertain to the outer pager style case, on off switches and Consisting of 13 items. Row 59 thru 71Missing Lead times, Part Numbers, Symbol in Schematic, and Supplier Infor m to be provided by Dr. Chen and Dex. Section 2MOTHER BOARD SUBASSEMBLY -List of all surface mount componets and the circuit board. Consisting of 46 items. Row 78 thru 1235 Intergrated Circuits delayed due to payment issues. 4 due in 5 days. Last o 868 RX Chips awaiting payment. Production will start without waiting for the s Missing Lead times, Part Numbers, Qty in Subassembly, Symbol in Schemat i to be provided by Dr. Chen and Dex. Section 3BATTERY SUBASSEMBLY - List of all the charging and battery systems components. Consisting of 5 items. Row 115 thru 120Missing Lead times, Part Numbers, Symbol in Schematic, and Supplier Infor m provided by Dr. Chen and Dex. Section 4GPS SUBASSEMBLY - List of all GPS componets. Consisting of 6 items. Row 129 thru 134Need pricing and manfacturer of some items from Dex. Section 5CDPD SUBASSEMBLY - List of all CDPD compnents. Consisting of 4 items. Row 140 thru 143No open issues. Section 6WATCH ASSEMBLY - List of case, populated PCBA , and sensors that are the components of the wat c Consisting of 3 items. Row 148 thru 150No open issues. Section 6Packaging - List of blister pack, shipping & return boxes, manuels, packaging material To be supplied by Michael, Pat, & David. Note: FCC Approval process begins 2/25/02. Dex will hand carry samples. This status report will be updated each Wednesday. All blank lead times will be supplied by Dex.The ORDER PRICE is in China RNB$ or US$. If there is no currency designator it is RNB$. A single $ The PIECE PRICE has been converted to US Dollars. THE BILLS OF MATERIAL FOR DA CDPD 2 PIECE CASE SUBASSEMBL Y COMPONENT ITEM P/N QUANTITY ORDERED ORDER PRICE LEAD TIME OTY IN SUBASSY PIECE PRICE MATERIA L CASE (STD-VI ) 1200 12,000.00 1 $1.2195 BOLT(FIX GPS MODULE) 2400 180.00 2 $0.0091 BOLT(FIX PCB) 3600 160.00 3 $0.0054 BOLT(FIX CASE) 2400 120.00 2 $0.0061 BOLT(FIX ANTENNA ) 2400 400.00 2 $0.0203 INSULATOR BAND 55*67mm 1200 200.00 1 $0.0203 INSULATOR PAD 10*25mm 2400 240.00 2 $0.0122 INSULATOR TUBE 10mm 2400 200.00 2 $0.0102 LED ( GREEN ) 5000 1,100.00 1 $0.0268 IN4148 LL4148 5000 1,500.00 2 $0.0366 IN5817 1N5817 5000 4,000.00 1 $0.0976 SWITCH BUTTON 1050 420.00 1 $0.0488 CLICK 1050 630.00 1 $0.0732 MOTHER BOARD SUBASSEMBLY COMPONENT ITEM P/N QUANTITY ORDERED ORDER PRICE LEAD TIME OTY IN SUBASSY PIECE PRICE NARROW RS232 CONN 1050 21,000.00 1 $2.4390 ACCELEROMETER SENSOR ADXL202JE 1050 $13,125.00 4 - 6 wks 1 $12.50 FALLDOWN PLUG2.0mm*4 3000 3,600.00 $0.1463 DIODE&LED LED ( RED ) 5000 1,100.00 2 $0.0268 CAP. 30P ( 0603 ) GRM39U2J300 5000 180.00 4 $0.0044 47P ( 0603 ) GRM39U2J470 5000 180.00 1 $0.0044 102P ( 0603 ) CL10B102KBNC 5000 180.00 3 $0.0044 103P ( 0603 ) CS1608Y5V103Z 20000 720.00 9 $0.0044 104P ( 0603 ) CS1608Y5V104Z 10000 360.00 $0.0044 1UF ( 1206 ) TAJA105M016R 5000 3,000.00 1 $0.0732 1UF ( 0805 ) CS1612Y5V105Z 5000 3,000.00 $0.0732 10UF ( 1206 ) TAJA106M016R 10000 5,500.00 7 $0.0671 33UF ( 16V ) TAJA336M016R 5000 9,000.00 1 $0.2195 RES. (0603) 1K RC-03K102JT 5000 40.00 2 $0.0010 2K2 RC-03K222JT 5000 40.00 1 $0.0010 6K8 RC-03K682JT 5000 40.00 1 $0.0010 10K ( 1% ) RC-03K103FT 5000 80.00 2 $0.0020 10K RC-03K103JT 10000 80.00 8 $0.0010 15K RC-03K153JT 5000 40.00 1 $0.0010 22K ( 1% ) RC-03K223FT 5000 80.00 4 $0.0020 22K RC-03K223JT 5000 40.00 3 $0.0010 100K RC-03K104JT 20000 160.00 5 $0.0010 120K RC-03K124JT 5000 40.00 1 $0.0010 150K ( 0603 ) RC-03K154JT 5000 40.00 $0.0010 200K RC-03K204JT 5000 40.00 1 $0.0010 220K ( 1% ) RC-03K204FT 5000 80.00 1 $0.0020 24.9K ( 1% ) RC-03K2492FT 5000 80.00 1 $0.0020 470K ( 0603 ) RC-03K474JT 5000 40.00 $0.0010 IC MAX3243EAI MAX3243EAI 1050 46,200.00 1 $5.3659 MAX1679EUA MAX1679EAI 1050 22,050.00 1 $2.5610 MAX1692EUB MAX1692EUB 1050 25,725.00 1 $2.9878 SMD10P06 SMD10P06 1050 1,050.00 1 $0.1220 XC61CC3402PR XC61CC3402PR 1050 3,675.00 1 $0.4268 MAX3100CEE MAX3100CEE 1050 29,400.00 1 $3.4146 MAX890L MAX890LESA 1050 15,750.00 1 $1.8293 AT89LS53-12AI AT89LS53-12AI 1050 30,990.00 1 $3.5993 MICROCONTROLLER AT15L 1050 $1,050.00 4 wks 1 $1.00 MICROCONTROLLER AT15L 1050 $1,050.00 4 wks 1 $1.00 TC CHIP RFM RT5001 1050 $12,600.00 4 wks 1 $12.00 RX CHIP RFM RX5001 1050 $8,400.00 4 wks 1 $8.00 HT7027A HT7027A 1050 1,785.00 1 $0.2073 XC6204B332MR XC6204B332MR 1050 4,410.00 1 $0.5122 INDUCTOR 33uH SMD4033 5000 9,000.00 1 $0.2195 TRANS. 2N3904 2N3904 5000 500.00 1 $0.0122 2N3906 2N3906 5000 3,000.00 3 $0.0732 PCB PCB ( STD-VI-10.PCB) 1050 7,307.00 1 $0.8487 BATTERY SUBASSEMBLY COMPONENT ITEM P/N QUANTITY ORDERED ORDER PRICE LEAD TIME OTY IN SUBASSY PIECE PRICE BATTERY CONNECTOR 5000 2,500.00 1 $0.0610 CHARGER CONNECTOR 5000 2,500.00 1 $0.0610 BATTERY (1400mAH) B103448 1050 36,750.00 1 $4.2683 CAR CHARGER ( 12-24/5/1A ) 1050 26,250.00 1 $3.0488 POWER LINE 3.0*1.1 1050 1,800.00 1 $0.2091 CHARGER(110/5V,1A) 1050 31,500.00 1 $3.6585 GPS SUBASSEMBLY COMPONENT ITEM P/N QUANTITY ORDERED ORDER PRICE LEAD TIME OTY IN SUBASSY PIECE PRICE GPS PLUG USA 1 USA GPS Receiver 3B2WT4NM- 05S4AX 1050 $61,950.00 3 wks 1 $59.00 GPS CONNECTOR USA 1200 USA GPS ANTENNA VLA01B3MXC 1050 $14,700.00 3 wks 1 $14.00 CDPD SUBASSEMBLY COMPONENT ITEM P/N QUANTITY ORDERED ORDER PRICE LEAD TIME OTY IN SUBASSY PIECE PRICE CDPD MODULE 649496 004613 1050 $113,400.00 4 wks 1 $108.00 CDPD ANTENA 1050 MANUFACTURED IN HOUSE 1 #VALUE! CDPD CONNECTOR 1050 1,386.00 $0.1610 WATCH ASSEMBLY COMPONENT ITEM P/N QUANTITY ORDERED ORDER PRICE LEAD TIME OTY IN SUBASSY PIECE PRICE PIN PIN 2.0mm*4 3000 3,600.00 $0.1463 CRYSTAL 11.0592MHZ 1050 1,785.00 $0.2073 3.6864MHZ 1050 1,890.00 $0.2195 SENSOR THERMISTOR WM303E 1050 $840.00 4 wks 1 $0.80 WATCH CASE ( STD-VI …

Text truncated - open the document above for the full version.

The Tune Up Procedures for Digital Angel CDPD System The pager unit tune up Configure the CDPD module so the device operates in UDP mode. Configure the IP address so the device works in a point to point mode; Configure the falldown sensor so the device works in a reliable way to give the right alarm according to the system design. The falldown module has the standard procedures for its tune up: Affix the unit with falldown sensor on top of a 4’ long pole or stick, the other end is pivoted. Let the pole fall from vertical position to horizontal position in various speeds. The falldown sensor should alarm when the fall takes 0.35 to 0.65 seconds. After fall, it should remain motionless for 30 seconds. The falldown sensor should not alarm when the fall takes less than 0.35 seconds or more than 0.65 seconds. Test is carried out in two orientations: 0 degree and 90 degree from the surface of the device. The falldown sensor should not alarm when the unit is vibrated arbitrarily.

FCC ID: P8FCDPD-MON-02 MFA p0220007, d0230050 REVISED TRANSMITTERCERTIFICATION of FCC ID: P8FCDPD-MON-02 MODEL: CDPD-MON-02 to FEDERAL COMMUNICATIONS COMMISSION Rule Part(s) 22H, 22.901(d) DATE OF REPORT: March 13, 2002 ON THE BEHALF OF THE APPLICANT: Digital Angel Corporation AT THE REQUEST OF: P.O. #2 and #1018 Digital Angel Systems 1451 Research Park Drive Riverside, CA 92507 Attention of: Michael P. Dunn, Production Manager (909) 276-7180 ext. 231; FAX: -7191 email: [email protected] Dexing Pang, Ph. D., Director R&D (909) 276-7180 ext. 216; FAX: -7191 email: [email protected] SUPERVISED BY: Morton Flom, P. Eng. FCC ID: P8FCDPD-MON-02 MFA p0220007, d0230050 LIST OF EXHIBITS (FCCCERTIFICATION(CELLULAR TRANSMITTERS) - REVISED 9/28/98) APPLICANT: Digital Angel Corporation FCC ID: P8FCDPD-MON-02 BY APPLICANT: 1. LETTER OF AUTHORIZATION x 2. IDENTIFICATION DRAWINGS, 2.1033(c)(11) xLABEL xLOCATION OF LABEL xCOMPLIANCE STATEMENT xLOCATION OF COMPLIANCE STATEMENT 3. PHOTOGRAPHS, 2.1033(c)(12) x 4. CONFIDENTIALITY REQUEST: 0.457 and 0.459 N/A 5. DOCUMENTATION: 2.1033(c) (3) USER MANUAL x (9) TUNE UP INFO x (10) SCHEMATIC DIAGRAM x (10) CIRCUIT DESCRIPTION x BLOCK DIAGRAM x PARTS LIST x ACTIVE DEVICES x BY M.F.A. INC. A. TESTIMONIAL & STATEMENT OF CERTIFICATION B. STATEMENT OF QUALIFICATIONS FCC ID: P8FCDPD-MON-02 MFA p0220007, d0230050 THE APPLICANT HAS BEEN CAUTIONED AS TO THE FOLLOWING: 15.21 INFORMATION TO USER. The users manual or instruction manual for an intentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. 15.27(a) SPECIAL ACCESSORIES. Equipment marketed to a consumer must be capable of complying with the necessary regulations in the configuration in which the equipment is marketed. Where special accessories, such as shielded cables and/or special connectors are required to enable an unintentional or intentional radiator to comply with the emission limits in this part, the equipment must be marketed with, i.e. shipped and sold with, those special accessories. However, in lieu of shipping or packaging the special accessories with the unintentional or intentional radiator, the responsible party may employ other methods of ensuring that the special accessories are provided to the consumer, without additional charge. Information detailing any alternative method used to supply the special accessories for a grant of equipment authorization or retained in the verification records, as appropriate. The party responsible for the equipment, as detailed in § 2.909 of this chapter, shall ensure that these special accessories are provided with the equipment. The instruction manual for such devices shall include appropriate instructions on the first page of text concerned with the installation of the device that these special accessories must be used with the device. It is the responsibility of the user to use the needed special accessories supplied with the equipment. FCC ID: P8FCDPD-MON-02 MFA p0220007, d0230050 TABLE OF CONTENTS RULE DESCRIPTION PAGE . Test Report 1 2.1033(c) General Information Required 2 2.1033(c)(14) Rule Summary 5 Description Of Product 6 . Standard Test Conditions and Engineering Practices 7 2.1046(a) ERP Carrier Power (Radiated) 8 2.1046(a) R. F. Power Output (Radiated) 9 2.1049(c)(1), 22 Emission Masks (Occupied Bandwidth) 11 2.1053(a) Field Strength of Spurious Radiation 13 2.1055(a)(1) Frequency Stability (Temperature Variation) 17 2.1055(b)(1) Frequency Stability (Voltage Variation) 20 FCC ID: P8FCDPD-MON-02 MFA p0220007, d0230050 PAGE NO.1of20. Required information per ISO/IEC Guide 25-1990, paragraph 13.2: a) TEST REPORT b) Laboratory: (FCC: 31040/SIT) (Canada: IC 2044) M. Flom Associates, Inc. 3356 N. San Marcos Place, Suite 107 Chandler, AZ 85225 c) Report Number: d0230050 d) Client: Digital Angel Systems 1451 Research Park Drive Riverside, CA 92507 e) Identification: CDPD-MON-02 FCC ID: P8FCDPD-MON-02 Description: UHF FM Portable Transceiver f) EUT Condition: Not required unless specified in individual tests. g) Report Date: March 13, 2002 EUT Received: February 26, 2002 h, j, k): As indicated in individual tests. i) Sampling method: No sampling procedure used. l) Uncertainty: In accordance with MFA internal quality manual. m) Supervised by: Morton Flom, P. Eng. n) Results: The results presented in this report relate only to the item tested. o) Reproduction: This report must not be reproduced, except in full, without written permission from this laboratory. FCC ID: P8FCDPD-MON-02 MFA p0220007, d0230050 PAGE NO.2of20. LIST OF GENERAL INFORMATION REQUIRED FOR CERTIFICATION IN ACCORDANCE WITH FCC RULES AND REGULATIONS, VOLUME II, PART 2 AND TO 22H, 22.901(d) Sub-part 2.1033 (c)(1): NAME AND ADDRESS OF APPLICANT: Digital Angel Corporation 490 Villaume Avenue South St. Paul, MN 55075-2445 MANUFACTURER: Digital Angel Systems, Shenzhen Branch 1 Dong – 6H Xiangjing Da Sha, 2034 Lianhua Road, Futian District Shenzhen, P.R. China 518037 (c)(2): FCC ID: P8FCDPD-MON-02 MODEL NO: CDPD-MON-02 (c)(3): INSTRUCTION MANUAL(S): PLEASE SEE ATTACHED EXHIBITS (c)(4): TYPE OF EMISSION: 28K8FXW (c)(5): FREQUENCY RANGE, MHz : 824 to 849 (c)(6): POWER RATING, Watts: 1.48 x 10 -3 W ERP Switchable Variable x N/A (c)(7): MAXIMUM POWER RATING, Watts: 7 (FCC Limit) FCC ID: P8FCDPD-MON-02 MFA p0220007, d0230050 PAGE NO.3of20. Subpart 2.1033(continued) (c)(8): VOLTAGES & CURRENTS IN ALL ELEMENTS IN FINAL R. F. STAGE, INCLUDING FINAL TRANSISTOR OR SOLID STATE DEVICE: COLLECTOR CURRENT, A = 0.0005 COLLECTOR VOLTAGE, Vdc = per manual SUPPLY VOLTAGE, Vdc = 3.6 (c)(9): TUNE-UP PROCEDURE: PLEASE SEE ATTACHED EXHIBITS (c)(10): CIRCUIT DIAGRAM/CIRCUIT DESCRIPTION: Including description of circuitry & devices provided for determining and stabilizing frequency, for suppression of spurious radiation, for limiting modulation and limiting power. PLEASE SEE ATTACH…

Text truncated - open the document above for the full version.

FCC ID: P8FCDPD-MON-02 MFA p0220007, d0230051 PAGE NO.12 of 27. PHOTOGRAPH(S) OF TEST SETUP FOR HIGHEST EMISSIONS TEST SETUP: Radiated Emissions g0220117: 2002-Feb-27 Wed 10:41:30 STATE: 0:General TEST SETUP: Radiated Emissions g0220118: 2002-Feb-27 Wed 10:41:30 STATE: 0:General
