P97JUNSUN0210Energy Saving Lamp

User’s Manual This device complies with part 18 of the FCC rules. 1 Use only on 120V/60Hz. 2 Never disassemble or modify-any changes could void the user’ authority to operate this device. 3 Not for use in totally enclosed recessed fixtures. 4 Risk of electric shock-do not use with where directly exposed to weather. 5 This device is not intended for use with emergency exit lights. 6 This product could produce interference when used near a TV, radio, wireless remote control or maritime safety communications or other critical navigation or communication equipment operating between 0.45-30 MHz. If interference should occur, move the lamp away from the appliance a distance of three feet or more. Or, plug the lamp or the appliance into a different outlet. 7 To prevent burns, do not touch the bulb burning operation or immediately after switching off. 8 Not for use with dimmers, electronic timer or photocell devices or occupancy sensor. 9 It does not start up when placed below -15°C. 10 “Added weight any cause instability of free-standing portable lamps. Use only with portable lamps in which the distance from the bottom of the base to the top of the lamp holder does not exceed three (3) times minimum base width. Use only with portable table lamps which are provided with lamp shades.”

F IGURE 1 E NERGY S AVING L AMP (M/N: SFCB-4W) G ENERAL A PPEARANCE F IGURE 2 E NERGY S AVING L AMP (M/N: SFCB-4W) G ENERAL A PPEARANCE (W ITHOUT L AMPSHADE ) F IGURE 3 E NERGY S AVING L AMP (M/N: SFCB-6W) G ENERAL A PPEARANCE F IGURE 4 E NERGY S AVING L AMP (M/N: SFCB-6W) G ENERAL A PPEARANCE (W ITHOUT L AMPSHADE ) F IGURE 5 E NERGY S AVING L AMP (M/N: SFCL-4W) G ENERAL A PPEARANCE F IGURE 6 E NERGY S AVING L AMP (M/N: SFCL-4W) G ENERAL A PPEARANCE (W ITHOUT L AMPSHADE ) F IGURE 7 E NERGY S AVING L AMP (M/N: SFCL-6W) G ENERAL A PPEARANCE F IGURE 8 E NERGY S AVING L AMP (M/N: SFCL-6W) G ENERAL A PPEARANCE (W ITHOUT L AMPSHADE ) F IGURE 9 E NERGY S AVING L AMP (M/N: SFGB-6W) G ENERAL A PPEARANCE F IGURE 10 E NERGY S AVING L AMP (M/N: SFGB-6W) G ENERAL A PPEARANCE (W ITHOUT L AMPSHADE ) F IGURE 11 E NERGY S AVING L AMP (M/N: SFGL-6W) G ENERAL A PPEARANCE F IGURE 12 E NERGY S AVING L AMP (M/N: SFGL-6W) G ENERAL A PPEARANCE (W ITHOUT L AMPSHADE )

Label Drawing 1. For example: Note:The blue words will be replaced as follows for each model. Model Label SFCB-4W SFCB-4W 120V 60Hz 70 mA SFCB-6W SFCB-6W 120V 60Hz 100 mA SFCL-4W SFCL-4W 120V 60Hz 70 mA SFCL-6W SFCL-6W 120V 60Hz 100 mA SFGB-6W SFGB-6W 120V 60Hz 100 mA SFGL-6W SFGL-6W 120V 60Hz 100 mA SFCB-4W 120V 60Hz 70mA Energy Saving Lamp FCC ID: P97JUNSUN0210 CAUTION: Risk of electric shock-Use in dry location only. Not for use with dimmers. Not for use in totally enclosed recessed fixtures. Not for use where exposed to the weather.

Label Location Information Refer to the below red arrow: (for example) SFCB-4W 120V 60Hz 70mA

F IGURE 1 E NERGY S AVING L AMP (M/N: SFCB-4W) C OVER R EMOVED F IGURE 2 E NERGY S AVING L AMP (M/N: SFCB-4W) M AIN B OARD (C OMPONENT S IDE ) F IGURE 3 E NERGY S AVING L AMP (M/N: SFCB-4W) M AIN B OARD (S OLDERED S IDE ) F IGURE 4 E NERGY S AVING L AMP (M/N: SFCB-6W) C OVER R EMOVED F IGURE 5 E NERGY S AVING L AMP (M/N: SFCB-6W) M AIN B OARD (C OMPONENT S IDE ) F IGURE 6 E NERGY S AVING L AMP (M/N: SFCB-6W) M AIN B OARD (S OLDERED S IDE ) F IGURE 7 E NERGY S AVING L AMP (M/N: SFCL-4W) C OVER R EMOVED F IGURE 8 E NERGY S AVING L AMP (M/N: SFCL-4W) M AIN B OARD (C OMPONENT S IDE ) F IGURE 9 E NERGY S AVING L AMP (M/N: SFCL-4W) M AIN B OARD (S OLDERED S IDE ) F IGURE 10 E NERGY S AVING L AMP (M/N: SFCL-6W) C OVER R EMOVED F IGURE 11 E NERGY S AVING L AMP (M/N: SFCL-6W) M AIN B OARD (C OMPONENT S IDE ) F IGURE 12 E NERGY S AVING L AMP (M/N: SFCL-6W) M AIN B OARD (S OLDERED S IDE ) F IGURE 13 E NERGY S AVING L AMP (M/N: SFGB-6W) C OVER R EMOVED F IGURE 14 E NERGY S AVING L AMP (M/N: SFGB-6W) M AIN B OARD (C OMPONENT S IDE ) F IGURE 15 E NERGY S AVING L AMP (M/N: SFGB-6W) M AIN B OARD (S OLDERED S IDE ) F IGURE 16 E NERGY S AVING L AMP (M/N: SFGL-6W) C OVER R EMOVED F IGURE 17 E NERGY S AVING L AMP (M/N: SFGL-6W) M AIN B OARD (C OMPONENT S IDE ) F IGURE 18 E NERGY S AVING L AMP (M/N: SFGL-6W) M AIN B OARD (S OLDERED S IDE )

Schematics

Shanghai Junsun Lighting Co., Ltd. FCC ID: P97JUNSUN0210 Page 1 of 32 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F02098 Application for FCC Certificate On Behalf of Shanghai Junsun Lighting Co., Ltd. Energy Saving Lamp Model No.: SFCB-4W SFCB-6W SFCL-4W SFCL-6W SFGB-6W SFGL-6W FCC ID: P97JUNSUN0210 Prepared For : Shanghai Junsun Lighting Co., Ltd. Beiguan, Malu town, Jiading, Shanghai, China. Prepared By : Audix Technology (Shanghai) Co., Ltd. 3F 34Bldg 680 Guiping Rd, Caohejing Hi-Tech Park, Shanghai, China 200233. Tel : +86-21-64955500 Fax : +86-21-64955491 Report No. : ACI-F02098 Date of Test : Sep 17, 2002 Date of Report : Sep 23, 2002 Shanghai Junsun Lighting Co., Ltd. FCC ID: P97JUNSUN0210 Page 2 of 32 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F02098 TABLE OF CONTENTS Page 1 GENERAL INFORMATION.......................................................................................................... 4 1.1 Description of Equipment Under Test........................................................................................4 1.2 Description of Test Facility ........................................................................................................ 4 1.3 Measurement Uncertainty .......................................................................................................... 4 2 AC POWERLINE CONDUCTED EMISSION TEST ................................................................. 5 2.1 Test Equipment........................................................................................................................... 5 2.2 Block Diagram of Test Setup ..................................................................................................... 5 2.3 Conducted Emission Limits ....................................................................................................... 5 2.4 Test Configuration...................................................................................................................... 6 2.5 Operating Condition of EUT ...................................................................................................... 6 2.6 Test Procedures .......................................................................................................................... 6 2.7 Test Results ................................................................................................................................ 7 3 FIELDSTRENGTH TEST ............................................................................................................ 13 3.1 Test Equipment......................................................................................................................... 13 3.2 Block Diagram of Test Setup ................................................................................................... 13 3.3 Test Configuration.................................................................................................................... 13 3.4 Operating Condition of EUT .................................................................................................... 13 3.5 Test Procedure .......................................................................................................................... 14 3.6 Test Result ................................................................................................................................ 14 Shanghai Junsun Lighting Co., Ltd. FCC ID: P97JUNSUN0210 Page 3 of 32 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F02098 TEST REPORT FOR FCC CERTIFICATE Applicant : Shanghai Junsun Lighting Co., Ltd. Manufacturer : Shanghai Junsun Lighting Co., Ltd. EUT Description : Energy Saving Lamp (A) Model No.: SFCB-4W; SFCB-6W; SFCL-4W; SFCL-6W SFGB-6W; SFGL-6W (B) Power Supply: 120V/60Hz Test Procedure Used: FCC RULES AND REGULATIONS PART 18 CONSUMER DEVICES (2000) AND MP-5/1986 The device described above is tested by Audix Technology (Shanghai) Co., Ltd. to determine the maximum emission levels emanating from the device. The maximum emission levels are compared to the FCC Part 18 RF Lighting Device limits both conducted emissions and field strength. The test results are contained in this test report and Audix Technology (Shanghai) Co., Ltd. is assumed full responsibility for the accuracy and completeness of these measurements. Also, this report shows that the EUT to be technically compliant with the FCC official limits. This report applies to above tested sample only. This report shall not be reproduced in part without written approval of Audix Technology (Shanghai) Co., Ltd. This report must not be used by the applicant to claim product endorsement by NVLAP or any agency of the U.S. Government. Date of Test : Sep 17, 2002 Prepared by : Test Engineer : CATHRIN YIN (Assistant) PAUL CHU (Engineer) Reviewer : Approved Signatory : BYRON KWO (Supervisor) JASON CHEN (Deputy Manager) Shanghai Junsun Lighting Co., Ltd. FCC ID: P97JUNSUN0210 Page 4 of 32 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F02098 1 GENERAL INFORMATION 1.1 Description of Equipment Under Test Description : Energy Saving Lamp Type of EUT : ; Production … Pre-product … Pro-type Model Number : SFCB-4W; SFCB-6W SFCL-4W; SFCL-6W SFGB-6W; SFGL-6W Applicant : Shanghai Junsun Lighting Co., Ltd. Beiguan, Malu town, Jiading, Shanghai,China. Manufacturer : Shanghai Junsun Lighting Co., Ltd. Beiguan, Malu town, Jiading, Shanghai, China. Test Model Apparent Power (V ̇ A) Real Power (W) SFCB-4W 8.79 4.66 SFCB-6W 11.21 6.29 SFCL-4W 8.29 4.28 SFCL-6W 10.91 6.14 SFGB-6W 11.31 6.46 SFGL-6W 10.74 6.07 1.2 Description of Test Facility Site Description : Sept. 17, 1998 file on (Semi-Anechoic Chamber) Federal Communications Commission FCC Engineering Laboratory 7435 Oakland Mills Road Columbia, MD 21046, USA Name of Firm : Audix Technology (Shanghai) Co., Ltd. Site Location : 3F 34Bldg 680 Guiping Rd, Caohejing Hi-Tech Park, Shanghai, China 200233. NVLAP Lab Code : 200371-0 1.3 M…

Text truncated - open the document above for the full version.

Test Set-Up Photos 1. Conducted Emission Test (M/N: SFCB-4W) (M/N: SFCB-6W) (M/N: SFCL-4W) (M/N: SFCL-6W) (M/N: SFGB-6W) (M/N: SFGL-6W) 2. Field strength Test (M/N: SFCB-4W) (M/N: SFCB-6W) (M/N: SFCL-4W) (M/N: SFCL-6W) (M/N: SFGB-6W) (M/N: SFGL-6W)
