FCC ID: P9Y00000723391 Technical Description : The brief circuit description is listed as follows : Reader - C14, C14A and associated circuit act as Antenna. - R2, Jum1 and Jum2 act as RF Filter. - U1, Y1 and associated circuit act as RFID Reader and 13.56 MHz Oscillator. - U2 acts as Micro-Controller with Voice Synthesizer. - Q1 and associated circuit act as Audio Amplifier. - Q2 and associatd circuit act as Power Supply Control Circuit. - SW Bear, SW Bottle and Metal Plate act as Control Inputs. Tag s - C1, C2 and associated circuit act as Antenna. - U3 acts as RFID Transponder. Antenna Used : A loop antenna has been used.
