EV-128MRS User’s Guide 1 OPERATING INSTRUCTIONS BEDIENUNGSANLEITUNG MODE D’EMPLOI EV-128MRS MEMORY AUDIO PLAYER REPRODUCTOR DE AUDIO CON MEMORIA OWNER’S RECORD For your convenience, record the model number and the serial number (you will find them in the battery compartment of your set) in the space provided below. Please refer them when you contact your Evoluation dealer in case of difficulty. EV-128MRS User’s Guide 2 FCC NOTICE THIS DEVICE COMPLIES WITH PART 15 OF THE FCC FULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITION: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDERSIRED OPERATION. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communication. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures : - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit difference from that to which the receiver is connected. - Consult the dealer of an experienced radio/TV technician for help. NOTE : The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user’s authority to operate the equipment. EV-128MRS User’s Guide 3 NOTICE TO USERS WARNING TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. Copyright Notices Under the copyright laws, neither the documentation nor the software for this product may be copied, photocopied, reproduced, translated, or reduced to any electronic medium or machine-readable form, in whole or in part, without the prior written consent of Evolution Technologies, Inc.. Copyright © 2002 Evolution Technologies, Inc. All rights reserved. • Microsoft, Windows, Windows Media and the Windows Logo are trademarks or registered trademarks of Microsoft Corporation. • Intel and Pentium are registered trademarks of Intel Corporation. • MultiMediaCard is a trademark of Infineon Technologies AG. • The names of systems and products appearing in this manual may be registered trademarks or trademarks of their respective companies or organizations. In this manual, the TM or ® mark is not always explicitly described. EV-128MRS User’s Guide 4 Disclaimer Evolution Technologies, Inc. will not be responsible for any loss or damage of music files due to their transfer to the EV-128MRS player. About the supplied software • For using the supplied Audio Manager software, follow the terms of License Agreement that you can view during the installation of the software. • You need software upgrades in order to support emerging new compression methods other than WMA and MP3. Some software upgrades may not be free of charge. • For FAQs and downloading the new software for the EV-128MRS player, refer to http://www.nowevolution.com Warning You must be aware that distributing copies of WMA- or MP3-format music files to any other person without permission is against the copyright laws. You can use the software in the supplied installation CD-ROM for personal use only. COPYRIGHT Please check the laws on copyright relating to recordings from discs or external tapes for country in which the machine is being used. EV-128MRS User’s Guide 5 PRECAUTIONS The following are precautions that you should always keep in mind. Any violation of one or more of the following precautions may cause damage and will void the warranty. To maintain good performance • Avoid exposure to heat, moisture and static electricity. • Do not use the player in places that are extremely hot, cold, dusty, or humid. • In particular, do not keep the player in a high humidity area such as a bathroom, near a heater or in an area exposed to direct sunlight *e.g., inside a parked car). • When you carry the battery in your pocket, do not have other metal objects such as coins or keys in the same pocket. Friction caused by the metal and the battery rubbing together may cause a fire. • Make sure that pins or other foreign objects do not get inside the player. Caution of impact Do not drop the player or allow any sharp impact. This may cause serious damage to the player. Note on listening with the headphones • Listening to the player at full poser for extended periods of time can result in hearing damage. • Do not wear the headphones while driving or cycling. This may create a traffic hazard. • You should use extreme caution or temporarily discontinue use in potentially hazardous situations, such as walking, jogging, etc. • Wear them properly; L is left and R is right. • The in-ear type headphones should be worn with the longer cord behind your neck. To clean the cabinet Do not use chemicals to clean the cabinet. This may change the color of the player or damage the surface. Use a soft towel to clean the surface of the player. EV-128MRS User’s Guide 6 TABLE OF CONTENTS Chapter 1. Introduction ............................................................................7 Main features ..................................................................................................7 Accessories ....................................................................................................7 System requirements ...........................…

Text truncated - open the document above for the full version.

SK TECH CO., LTD. Page 1 of 2 SKT SKTOS-02033 FCC ID : PAREV-128MRS External Photographs of EUT SK TECH CO., LTD. Page 2 of 2 SKT SKTOS-02033 FCC ID : PAREV-128MRS

SK TECH CO., LTD. Page 1 of 1 SKT SKTOS-02033 FCC ID : PAREV-128MRS FCC ID Label Sample

SK TECH CO., LTD. Page 1 of 1 SKT SKTOS-02033 FCC ID : PAREV-128MRS FCC ID Sample Label & Location Information LABELLING REQUIREMENTS PER 2.928 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. FCC ID : PAREV-128MRS

SK TECH CO., LTD. Page 1 of 5 SKT SKTOS-02033 FCC ID : PAREV-128MRS Internal Photographs of EUT SK TECH CO., LTD. Page 2 of 5 SKT SKTOS-02033 FCC ID : PAREV-128MRS SK TECH CO., LTD. Page 3 of 5 SKT SKTOS-02033 FCC ID : PAREV-128MRS SK TECH CO., LTD. Page 4 of 5 SKT SKTOS-02033 FCC ID : PAREV-128MRS SK TECH CO., LTD. Page 5 of 5 SKT SKTOS-02033 FCC ID : PAREV-128MRS

SK TECH CO., LTD. Page 1 of 13 SKT SKTOS-02033 FCC ID : PAREV-128MRS Certificate of Compliance Test Report No.: SKTOS-02033 NVLAP CODE : 200220-0 Applicant: mpman.com, Inc. Applicant Address: 2 nd Floor, ASEM Tower 159-1, Samsung-Dong, Kangnam-Ku, Seoul, Korea Product: MP3 Player FCC ID: PAREV-128MRS Model No.: EV-128MRS Receipt No.: SKE20020321-190 Date of receipt: Mar. 21, 2002 Date of Issue: Apr. 11, 2002 Testing location: SK TECH CO., LTD. 820-2, Wolmoon-Ri, Wabu-Up, Namyangju-Si, Kyunggi-Do, Korea Test Standards: ANSI C63.4 / 2000 Rule Parts: FCC part 15 Subpart B Equipment Class : Class B Digital Device Peripheral Test Result: The above mentioned product has been tested and passed. Prepared by:Y.H.Kang Tested by:Y.B.Kim/Engineer Approved by: K.S.Kim/Manager & Chief Engineer Signature Date Signature Date Signature Date Other Aspects : Abbreviations : · OK, Pass = passed · Fail = failed · N/A = not applicable •This test report is not permitted to copy partly without our permission. •This test result is dependent on only equipment to be used. •This test result is based on a single evaluation of one sample of the above mentioned. •This test report must not be used by the client to claim product endorsement by NVLAP or any agency of the U.S Government. • We certify that this test report has been based on the measurement standards that is traceable to the national or International standards. NVLAP Lab. Code: 200220-0 SK TECH CO., LTD. Page 2 of 13 SKT SKTOS-02033 FCC ID : PAREV-128MRS Contents Contents 2 List of Tables 2 List of Figures 2 1. General 3 2. Test Site 3 2.1 Location 3 2.2 List of Test and Measurement Instruments 4 2.3 Test Date 4 2.4 Test Environment 4 3. Description of the tested samples 5 3.1 Rating and Physical Characteristics 5 3.2 Submitted Documents 5 4. Measurement Conditions 6 4.1 Modes of Operation 6 4.2 List of Peripherals 6 4.3 Type of Used cables 7 4.4 Test Setup 7 4.5 Uncertainty 7 5. EMISSION Test 8 5.1 Conducted Emissions 8 5.2 Radiated Emissions 12 List of Tables Table 1 List of test and measurement Equipment 4 Table 2 Test Data, Conducted Emissions 11 Table 3 Test Data, Radiated Emissions 13 List of Figures Figure 1 Spectral Diagram, LINE-PE 9 Figure 2 Spectral Diagram, Neutral-PE 10 SK TECH CO., LTD. Page 3 of 13 SKT SKTOS-02033 FCC ID : PAREV-128MRS 1. General This equipment has been shown to be capable of compliance with the applicable technical standards and was tested in accordance with the measurement procedures as indicated in this report. We attest to the accuracy of data. All measurements reported herein were performed by SK Tech Co., Ltd. and were made under Chief Engineer’s supervision. We assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. 2. Test Site SK TECH Co., Ltd. 2.1 Location 820-2, Wolmoon Ri, Wabu-Up, Namyangju-Si, Kyunggi-Do, Korea The test site is in compliance with ISO/IEC 17025 for general requirements for the competence of testing and calibration laboratories. This laboratory is accredited by NVLAP for NVLAP Lab. Code : 200220-0 and DATech for DAR-Registration No.:TTI-P-G155/97-10 SK TECH CO., LTD. Page 4 of 13 SKT SKTOS-02033 FCC ID : PAREV-128MRS 2.2 List of Test and Measurement Instruments Table 1 : List of Test and Measurement Equipment l Conducted Disturbance Kind of Equipment Type S/N Calibrated until EMI Receiver ESHS10 862970/019 02.2003 Artificial Mains Network ESH3-Z5 834549/001 10.2002 EMI Receiver ESHS10 835871/002 10.2002 Artificial Mains Network ESH3-Z5 836679/018 10.2002 Conducted Cable N/A N/A N/A l Radiated Disturbance Kind of Equipment Type S/N Calibrated until EMI Receiver ESVS 10 825120/013 02.2003 EMI Receiver ESVS 10 834468/008 11.2002 Spectrum Analyzer R3361A 11730187 06.2002 Amplifier 8447F 3113A05153 05.2002 Log Periodic Antenna UHALP9107 1819 02.2003 Biconical Antenna BBA9106 91031626 02.2003 Antenna Mast 5907 N/A N/A Antenna & Turntable controller 5906 N/A N/A Amp & Receiver connection cables N/A N/A N/A 50 Switcher MP59B 6100214538 N/A 2.3 Test Date Date of Application : Mar. 21, 2002 Date of Test : Apr. 10, 2002 2.4 Test Environment See each test item’s description. SK TECH CO., LTD. Page 5 of 13 SKT SKTOS-02033 FCC ID : PAREV-128MRS 3. Description of the tested samples The EUT is the MP3 Player. 3.1 Rating and Physical Characteristics Hardware requirements • Intel Pentium 233 MMX or faster • 64MB RAM or more • Free hard-disk space 32MB or more for software installation 150MB or more for music-file storage • CD-ROM drive that supports digital audio extraction • 1 available USB port • Sound card • 256-color display (16-bit color display is recommended) and 16-bit color video card • 28.8-kbps modem or faster required for Internet access (ISDN or LAN connection recommended) 3.2 Submitted Documents N/A SK TECH CO., LTD. Page 6 of 13 SKT SKTOS-02033 FCC ID : PAREV-128MRS 4. Measurement Conditions The operating voltage of EUT DC 1.5V by batteries. 4.1 Modes of Operation The EUT was in the following operation mode during all testing; The EUT was connected with the PC with USB cable. The test was made on the mode of uploading, downloading and playing MP3 files. 4.2 List of Peripherals Description Manufacturer Model Name Serial No. FCC ID Personal Computer LG IBM W8S 202KI10585 DoC Monitor Comtec CT-151B N/A DoC Keyboard Jing Mold LKB-0107 102009670 N/A Mouse Logitech M-S69 HCA14910006 JNE211443 Printer H.P. 2225C 3245S12493 DSI6XU2225 Adapter 1 (for Monitor) ILAN Elec. F1650K N/A N/A Adapter 2 (for Printer) Dream Electronics DR-05600U N/A N/A SK TECH CO., LTD. Page 7 of 13 SKT SKTOS-02033 FCC ID : PAREV-128MRS 4.3 Type of Used Cables Description Length Type of shield Manufacturer Remark PC Power cable 1.6m Non-Shield None AC/DC Adapter cable 1.8m Non-Shield None For Monitor AC/DC Adapter cable 1.9m Non-Shield None For Printer VGA cable 1.8m Shield None Printer Interface cable 1.7m Shield None USB cable 1.2m Shield None For EUT Keyboar…

Text truncated - open the document above for the full version.

SK TECH CO., LTD. Page 1 of 2 SKT SKTOS-02033 FCC ID : PAREV-128MRS Test set up photos Photograph 1: Setup for Conducted Emissions SK TECH CO., LTD. Page 2 of 2 SKT SKTOS-02033 FCC ID : PAREV-128MRS Photograph 2: Setup for Radiated Emissions
