Oct 28, 2000NT 332 588 Rev 1.5 AUTOMATISMES & TELECOMMUNICATIONS ARTEMA Mobile Installation guide ² DASSAULT AT NT 332 588 Rev.1.5ARTEMA Mobile1 Installation guide THIS INFORMATION IS PROPRIETARY INFORMATION OF DASSAULT A. T. AND MAY NOT BE USED, COPIED, DISCLOSED OR DIVULGED, IN WHOLE OR IN PART, FOR ANY PURPOSE BY ANY PERSON WITHOUT THE WRITTEN APPROVAL OF DASSAULT A.T. DASSAULT A.T. Table of contents 1Artema presentation............................................................................................. 2 2Installation and connections................................................................................. 3 2.1Warning........................................................................................................ 3 2.2Lithium batteries............................................................................................ 3 2.3Environment.................................................................................................. 3 2.4Battery pack installation................................................................................. 4 2.5Installing the paper roll.................................................................................. 4 2.6Connecting to the mains supply..................................................................... 6 2.7Charging ARTEMA........................................................................................ 6 3Trouble shooting & spare sparts........................................................................... 7 4Technical specifications....................................................................................... 8 4.1Handset specifications................................................................................... 8 4.2Power supply base specifications.................................................................. 8 NT 332 588 Rev.1.5ARTEMA Mobile2 Installation guide THIS INFORMATION IS PROPRIETARY INFORMATION OF DASSAULT A. T. AND MAY NOT BE USED, COPIED, DISCLOSED OR DIVULGED, IN WHOLE OR IN PART, FOR ANY PURPOSE BY ANY PERSON WITHOUT THE WRITTEN APPROVAL OF DASSAULT A.T. DASSAULT A.T. 1 ARTEMA PRESENTATION Smart card reader* "Power on" key Pin Pad* To phone line** * depending on configuration Paper cover Magnetic stripe card reader Printer Paper output NT 332 588 Rev.1.5ARTEMA Mobile3 Installation guide THIS INFORMATION IS PROPRIETARY INFORMATION OF DASSAULT A. T. AND MAY NOT BE USED, COPIED, DISCLOSED OR DIVULGED, IN WHOLE OR IN PART, FOR ANY PURPOSE BY ANY PERSON WITHOUT THE WRITTEN APPROVAL OF DASSAULT A.T. DASSAULT A.T. 2 INSTALLATION AND CONNECTIONS 2.1 Warning Artema is an electrical device. It must be used in normal conditions as described in this manual. DASSAULT A.T. cannot be held responsible for : - Damages due to using or servicing Artema other than in the conditions described in this guide. - Damages or Failures due to external causes . 2.2 Lithium batteries In addition to the battery pack of the handset, Artema uses Lithium batteries in order to backup internal data. The Lithium batteries in normal usage conditions have 6 years life expectancy. These batteries should only be replaced by an approved servicing center. CAUTION Danger of explosion if battery is incorrectly replaced Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer’s instructions. 2.3 Environment In order to use Artema in optimal conditions - Place the base on a clear, flat, leveled surface, close to the mains. - Place the terminal away from excessive heat sources, vibrations, dust, water and strong radio sources. Environmental conditions MinimumMaximum Operating temperature+5 °C+40°C Storage temperature-25 °C+55 °C Relative humidity50%90% NT 332 588 Rev.1.5ARTEMA Mobile4 Installation guide THIS INFORMATION IS PROPRIETARY INFORMATION OF DASSAULT A. T. AND MAY NOT BE USED, COPIED, DISCLOSED OR DIVULGED, IN WHOLE OR IN PART, FOR ANY PURPOSE BY ANY PERSON WITHOUT THE WRITTEN APPROVAL OF DASSAULT A.T. DASSAULT A.T. 2.4 Battery pack installation - It is important to switch off the terminal before changing the battery pack. - Position the battery pack in the back of the handset. - Press on the upper part of the battery until a "click" noise is heard. - The terminal is ready for the charging cycle (see installation and connection). 2.5 Installing the paper roll To obtain the highest printing quality, and to ensure maximum printer life span, only use recommended paper rolls 2 1/4 x 7/8 x 80 Ft. - Open the printer casing by pressing simultaneously on both sides, and by pulling upwards. NT 332 588 Rev.1.5ARTEMA Mobile5 Installation guide THIS INFORMATION IS PROPRIETARY INFORMATION OF DASSAULT A. T. AND MAY NOT BE USED, COPIED, DISCLOSED OR DIVULGED, IN WHOLE OR IN PART, FOR ANY PURPOSE BY ANY PERSON WITHOUT THE WRITTEN APPROVAL OF DASSAULT A.T. DASSAULT A.T. - Place the roll of paper in the casing, paper output towards the pin pad. Leave a few inches of paper outside. - Close the printer casing. You will hear a "click" sound to confirm the casing is closed. NT 332 588 Rev.1.5ARTEMA Mobile6 Installation guide THIS INFORMATION IS PROPRIETARY INFORMATION OF DASSAULT A. T. AND MAY NOT BE USED, COPIED, DISCLOSED OR DIVULGED, IN WHOLE OR IN PART, FOR ANY PURPOSE BY ANY PERSON WITHOUT THE WRITTEN APPROVAL OF DASSAULT A.T. DASSAULT A.T. - The printer will work only if the casing is closed and battery is charged. - Switch on the terminal, by pressing the "power on" key, and draw an inch of paper to check the roll is correctly placed in its casing. - Cut the exceeding paper. 2.6 Connecting to the mains supply - Connect the power supply line to the mains supply (115V), and check that the green indicator on the base in on. The mains outlet needs to be close to the terminal, within reach, in order to quickly disconnect the terminal if necessary. 2.7 Charging ARTEMA Before using Artema for the first time, leave the handset to charge fo…

Text truncated - open the document above for the full version.

127510 Artema CDPD “Mobile” P4432-909 & P4432-959 block diagram Hand held unit P4432-051 & -053 From base unit Base unit P4432-160 To hand held unit Mains AC P Radio module Keyboard PCB* *secured for -053 Printer Smart Card reader Magnetic Card reader Power supply NiCd Battery Pack LCDisplay Power supply AC/DC Antenna PCB

FCC ID: PB8P4432-051

Antenna Location Side View In Place On Terminal Antenna Reverse Angle – Relation to PCB

CELLTECH RESEARCH INC. Test Report S/N: 101700-33DAS 1955 Moss Court, Kelowna, Date(s) of Tests: October 24, 2000 B.C. CANADA V1Y 9L3 _________________________________________________________________________________________________________ © 2000 Celltech Research Inc. CERTIFICATE OF COMPLIANCE SAR EVALUATION This wireless mobile and/or portable device has been shown to be compliant for localized specific absorption rate (SAR) for uncontrolled environment/general exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in ANSI/IEEE Std. C95.3-1999. (See test report). I attest to the accuracy of data. All measurements were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Celltech Research Inc. certifies that no party to this application has been denied FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Shawn McMillen General Manager Celltech Research Inc. Test Lab: CELLTECH RESEARCH INC. Testing and Engineering Lab 1955 Moss Court Kelowna, B.C. Canada V1Y 9L3 Phone: 250 - 860-3130 Fax: 250 - 860-3110 Toll Free: 1-877-545-6287 e-mail: [email protected] web site: www.globuswireless.com Applicant Name: DASSAULT Automatismes & Telecommunications 9, rue Elsa TRIOLET - Z.I. des Gatines - BP 13 78 373 PLAISIR Cedex FRANCE Attn: Mr. Olivier POITRENAUD R & D Engineer Tel.: (33) 1 30 81 26 95 Fax: (33) 1 30 81 23 45 Trade Name: ARTEMA US MOBILE Model No.: P4432-909 Equipment Type: E.F.T./P.O.S. Terminal with CDPD Modem Card Equipment Classification: Licensed Non-Broadcast Station Transmitter (TNB) Tx Frequency Range: 824-849 MHz Rx Frequency Range: 869-894 MHz Max. RF Output Power: 0.6 Watts (ERP) FCC Rule Part(s): 2.1093; ET Docket 96.326 CELLTECH RESEARCH INC. Test Report S/N: 101700-33DAS 1955 Moss Court, Kelowna, Date(s) of Tests: October 24, 2000 B.C. CANADA V1Y 9L3 _________________________________________________________________________________________________________ © 2000 Celltech Research Inc. TABLE OF CONTENTS 1.0 INTRODUCTION.................................................................. 1 2.0 DESCRIPTION OF EUT.......................................................... 1 3.0 SAR MEASUREMENT SYSTEM ............................................. 2 4.0 MEASUREMENT SUMMARY.................................................. 3 5.0 SAR LIMITS........................................................................ 3 6.0 DETAILS OF SAR EVALUATION........................................... 4 7.0 EVALUATION PROCEDURES................................................. 5 8.0 SYSTEM VALIDATION.......................................................... 5 9.0 SIMULATED EQUIVALENT TISSUES...................................... 6 10.0 TISSUE PARAMETERS......................................................... 6 11.0 SYSTEM SPECIFICATIONS.................................................... 7 12.0 TEST EQUIPMENT LIST........................................................ 8 13.0 MEASUREMENT UNCERTAINTIES........................................ 9 14.0 REFERENCES...................................................................... 10 APPENDIX A - SAR MEASUREMENT DATA........................................ 11 APPENDIX B - DIPOLE VALIDATION................................................ 12 APPENDIX C - PROBE CALIBRATION............................................... 13 APPENDIX D - TEST SETUP PHOTOGRAPHS..................................... 14 CELLTECH RESEARCH INC. Test Report S/N: 101700-33DAS 1955 Moss Court, Kelowna, Date(s) of Tests: October 24, 2000 B.C. CANADA V1Y 9L3 _________________________________________________________________________________________________________ © 2000 Celltech Research Inc. DASSAULT ARTEMA US MOBILE Model: P4432-909 1 E.F.T./P.O.S. Terminal with CDPD Modem Card (824-849 MHz) 1.0 INTRODUCTION This measurement report shows compliance of the DASSAULT Artema US Mobile Model: P4432-909 Portable E.F.T./P.O.S. Terminal with internal CDPD Modem Card with FCC Part 2.1093, ET Docket 96-326 Rules for mobile and portable devices. The test procedures, as described in American National Standards Institute C95.1 - 1992 (1), FCC OET Bulletin 65– 1997 were employed. A description of the product and operating configuration, detailed summary of the test results, methodology and procedures used in the evaluation, equipment used, and the various provisions of the rules are included within this test report. 2.0 DESCRIPTION of Equipment Under Test (EUT) Fig. 1. Front of EUT Fig. 2. Rear of EUT Fig. 3. Antenna Side Fig. 4. CDPD Modem EUT Type Portable E.F.T./P.O.S. Terminal with internal CDPD Modem Card Equipment Class Licensed Non-Broadcast Station Transmitter (TNB) Trade Name ARTEMA US MOBILE Model No. P4432-909 Tx Frequency Range (MHz) 824-849 S/N No. Pre-production Rx Frequency Range (MHz) 869-894 Max. RF Output Power 0.6 Watts Power Supply Ni-Cad Battery Pack Signal Modulation(s) GMSK FM CELLTECH RESEARCH INC. Test Report S/N: 101700-33DAS 1955 Moss Court, Kelowna, Date(s) of Tests: October 24, 2000 B.C. CANADA V1Y 9L3 _________________________________________________________________________________________________________ © 2000 Celltech Research Inc. DASSAULT ARTEMA US MOBILE Model: P4432-909 2 E.F.T./P.O.S. Terminal with CDPD Modem Card (824-849 MHz) 3.0 SAR MEASUREMENT SYSTEM Celltech Research SAR measurement facility utilizes the Dosimetric Assessment System (DASY™) manufactured by Schmid & Partner Engineering AG (SPEAG™) of Zurich, Switzerland. The DASY system is comprised of the robot controller, computer, near-field probe, probe alignment sensor, and the generic twin phantom containing brain or muscle equivalent material (see Figure 6). The robot is a six-axis industrial robot…
