PD9-R900531Wireless Access Point

Intel® Wireless Gateway User's Guide July 9, 2001 ii Intel® Wireless Gateway User's Guide Copyright Copyright © 2000, 2001, Intel Corporation. All rights reserved. Intel Corporation, 5200 N.E. Elam Young Parkway, Hillsboro, OR 97124-6497 Intel Corporation assumes no responsibility for errors or omissions in this document. Nor does Intel make any commitment to update the information contained herein. Intel® Wireless Gateway is a registered trademark of Intel Corporation. † Other product and corporate names may be trademarks of other companies and are used only for explanation and to the owners’ benefit, without intent to infringe. Patents This product is covered by one or more of the following U.S. and foreign patents: U.S. Patent No. 4,360,798; 4,369,361; 4,387,297; 4,460,120; 4,496,831; 4,593,186; 4,603,262; 4,607,156; 4,652,750; 4,673,805; 4,736,095; 4,758,717; 4,816,660; 4,845,350; 4,896,026; 4,897,532; 4,923,281; 4,933,538; 4,992,717; 5,015,833; 5,017,765; 5,021,641; 5,029,183; 5,047,617; 5,103,461; 5,113,445; 5,130,520; 5,140,144; 5,142,550; 5,149,950; 5,157,687; 5,168,148; 5,168,149; 5,180,904; 5,216,232; 5,229,591; 5,230,088; 5,235,167; 5,243,655; 5,247,162; 5,250,791; 5,250,792; 5,260,553; 5,262,627; 5,262,628; 5,266,787; 5,278,398; 5,280,162; 5,280,163; 5,280,164; 5,280,498; 5,304,786; 5,304,788; 5,306,900; 5,321,246; 5,324,924; 5,337,361; 5,367,151; 5,373,148; 5,378,882; 5,396,053; 5,396,055; 5,399,846; 5,408,081; 5,410,139; 5,410,140; 5,412,198; 5,418,812; 5,420,411; 5,436,440; 5,444,231; 5,449,891; 5,449,893; 5,468,949; 5,471,042; 5,478,998; 5,479,000; 5,479,002; 5,479,441; 5,504,322; 5,519,577; 5,528,621; 5,532,469; 5,543,610; 5,545,889; 5,552,592; 5,557,093; 5,578,810; 5,581,070; 5,589,679; 5,589,680; 5,608,202; 5,612,531; 5,619,028; 5,627,359; 5,637,852; 5,664,229; 5,668,803; 5,675,139; 5,693,929; 5,698,835; 5,705,800; 5,714,746; 5,723,851; 5,734,152; 5,734,153; 5,742,043; 5,745,794; 5,754,587; 5,762,516; 5,763,863; 5,767,500; 5,789,728; 5,789,731; 5,808,287; 5,811,785; 5,811,787; 5,815,811; 5,821,519; 5,821,520; 5,823,812; 5,828,050; 5,850,078; 5,861,615; 5,874,720; 5,875,415; 5,900,617; 5,902,989; 5,907,146; 5,912,450; 5,914,478; 5,917,173; 5,920,059; 5,923,025; 5,929,420; 5,945,658; 5,945,659; 5,946,194; 5,959,285; D305,885; D341,584; D344,501; D359,483; D362,453; D363,700; D363,918; D370,478; D383,124; D391,250; D405,077; D406,581; D414,171; D414,172 Invention No. 55,358; 62,539; 69,060; 69,187 (Taiwan); No. 1,601,796; 1,907,875; 1,955,269 (Japan); European Patent 367,298; 367,299; 367,300; 414,281; UK 2,072,832; France 81/03938; Italy 1,138,713 A63132-001 About This Document Intel® Wireless Gateway User's Guide iii About This Document Reference Documents This guide refers to the following documents: Part Number Document Title A63132-001 Intel® Wireless Gateway Quick Install Guide A63132-001 Intel® Wireless Gateway Regulatory Approval Guide A63132-001 Internet Service Provider (ISP) Worksheet Conventions Keystrokes are indicated as follows: ENTER identifies a key. FUNC, CTRL, C identifies a key sequence. Press and release each key in turn. Press A+B press the indicated keys simultaneously. Hold A+B press and hold the indicated keys while performing or waiting for another function. Used in combination with another keystroke. Typeface conventions used include: <angles> indicates mandatory parameters in syntax. [brackets] for command line, indicates available parameters; in configuration files, brackets act as separators for options. GUI Screen text indicates the name of a control in a GUI-based application. Italics indicates the first use of a term, book title, variable or menu title. Bold indicates important user information, license provisions or warranty conditions. Screen dialog indicates screen dialog and user input options, and the exact syntax of items. Screen text indicates text and data displayed in an application screen on a computer monitor. Ter TerTer Terminal text minal textminal text minal text indicates text shown in a radio terminal LCD screen. URL indicates a Uniform Resource Locator, such as a Web page address. About This Document iv Intel® Wireless Gateway User's Guide This document uses the following for certain conditions or information: indicates tips or special requirements. indicates conditions that can cause equipment damage or data loss. indicates a potentially dangerous condition or procedure that only product-trained personnel should attempt to correct or perform. Intel® Wireless Gateway User's Guide v Contents Copyright................................................................................................................................ii Patents.................................................................................................................................... ii About This Document.........................................................................................iii Reference Documents.........................................................................................................iii Conventions..........................................................................................................................iii Chapter 1. Introduction............................................................................................................ 1 1.1 Infrastructure Mode: A WLAN with Access Points................................... 1 1.2 Peer-to-Peer Mode (Ad Hoc): A WLAN without Access Points............. 1 1.3 Identifying a WLAN....................................................................................... 1 Chapter 2. About the Intel® Wireless Gateway................................................................... 3 2.1 Features.......................................................................................................... 3 2.1.1 Security...................................................................................................................... 3 2.1.2 Roaming.......…

Text truncated - open the document above for the full version.

FCC ID:PD9-R900531 Report No.: RF900626R04 1 Issued: July 27, 2001 ANNEX PHOTOGRAPHS OF EUT FCC ID:PD9-R900531 Report No.: RF900626R04 2 Issued: July 27, 2001 FCC ID:PD9-R900531 Report No.: RF900626R04 3 Issued: July 27, 2001 FCC ID:PD9-R900531 Report No.: RF900626R04 4 Issued: July 27, 2001 FCC ID:PD9-R900531 Report No.: RF900626R04 5 Issued: July 27, 2001

FCC ID:PD9-R900531 Report No.: RF900626R04 6 Issued: July 27, 2001 FCC ID:PD9-R900531 Report No.: RF900626R04 7 Issued: July 27, 2001 FCC ID:PD9-R900531 Report No.: RF900626R04 8 Issued: July 27, 2001 FCC ID:PD9-R900531 Report No.: RF900626R04 9 Issued: July 27, 2001 FCC ID:PD9-R900531 Report No.: RF900626R04 10 Issued: July 27, 2001 FCC ID:PD9-R900531 Report No.: RF900626R04 11 Issued: July 27, 2001 FCC ID:PD9-R900531 Report No.: RF900626R04 12 Issued: July 27, 2001

FCC ID: PD9-R900531 ADT Number: 900626R04 1 FCC TEST REPORT REPORT NO.: RF900626R04 MODEL NO.: WLGW2011BAK ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT:Intel Corporation ADDRESS: 15250 Avenue of Science, SN1-02, San Diego, CA 92128 ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14th Ling, Chia Pau Tsuen, Linkou Hsiang, Taipei, Taiwan, R.O.C. 0528 Lab Code: 200102-0 FCC ID: PD9-R900531 ADT Number: 900626R04 2 RF Exposure Measurement 1. Introduction 2.4 GHz frequency band is regarded specially as a dangerous band for its heating harmfulness to the human body. That’s why microwave oven is operating in this frequency band. The manufacturer whose product is working in this frequency band is obligatory to prove the harmfulness of his product. In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC) calibrated for antenna measurement in ADT, and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis transmission formula is a far field assumption, the calculated result of that is an over-prediction for near field power density. We will take that as the worst case to specify the safety range. 2. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 300-1500......F/3006 1500-100,000......56 (B)Limits For General Population / Uncontrolled Exposure 300-1500......F/15006 1500-100,000......1.030 F = Frequency in MHz FCC ID: PD9-R900531 ADT Number: 900626R04 3 3. Friis Formula Friis transmission formula : Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd is the limit of MPE, 1 mW/cm 2 . If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Ref. : David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 4 EUT Operating condition The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 5 Climate Condition The temperature and related humidity: 30 deg. C and 60 % RH 6. Classification This device is not fixed inside the host equipment, it is connected with host through wire. So it is easy to be re-located in the place where at least 20 cm far away from the body of the user. Warning statement to the user for keeping at least 20cm or more separation distance with the antenna should be included in users manual. So, this device is classified as Mobile Device. FCC ID: PD9-R900531 ADT Number: 900626R04 4 7 Test Results 7.1 Antenna Gain The maximum Gain measured in Fully Anechoic Chamber is 1dBi or 1.26 (numeric). 7.2 Output Power Into Antenna & RF Exposure Distance : CHANNEL CHANNEL FREQUENCY (MHz) EIRP OUTPUT POWER TO ANTENNA (mW) MINIMUM ALLOWABLE DISTANCE ( r ) FROM SKIN (Centi-Meter) 124127.110.84 6243710.591.01 11246211.431.03 The minimum allowable distance is very close to the enclosure of the antenna. So, the user has no need to worry about the harmfulness of radiation. But it is recommended to always keep, at least, 20 cm separation distance with the antenna.

FCC ID: PD9-R900531 Report No.: RF900626R04 1 Issued: July 27, 2001 FCC TEST REPORT REPORT NO.: RF900626R04 MODEL NO.: WLGW2011BAK RECEIVED: June 26, 2001 TESTED: July 4 ~ July 13, 2001 APPLICANT:INTEL CORPORATION ADDRESS:15250 Avenue of Science, SN1-02, San Diego, CA 92128 ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14th Ling, Chia Pau Tsuen, Linkou Hsiang, Taipei, Taiwan, R.O.C. This test report consists of 49 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, NVLAP or any government agencies. The test results in the report only apply to the tested sample. 0528 Lab Code: 200102-0 FCC ID: PD9-R900531 Report No.: RF900626R04 2 Issued: July 27, 2001 Table of Contents 1CERTIFICATION........................................................................................... 4 2SUMMARY OF TEST RESULTS .................................................................. 5 3GENERAL INFORMATION ........................................................................... 6 3.1GENERAL DESCRIPTION OF EUT ............................................................. 6 3.2DESCRIPTION OF TEST MODES ............................................................... 7 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS .............................. 7 3.4DESCRIPTION OF SUPPORT UNITS ......................................................... 8 4TEST TYPES AND RESULTS ...................................................................... 9 4.1CONDUCTED EMISSION MEASUREMENT................................................ 9 4.1.1LIMITS OF CONDUCTED EMISSION MEASUREMENT ...................................................... 9 4.1.2TEST INSTRUMENTS ...........................................................................................................9 4.1.3TEST PROCEDURES .......................................................................................................... 10 4.1.4TEST SETUP ....................................................................................................................... 10 4.1.5EUT OPERATING CONDITIONS......................................................................................... 11 4.1.6TEST RESULTS ................................................................................................................... 12 4.2RADIATED EMISSION MEASUREMENT................................................... 18 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT ......................................................... 18 4.2.2TEST INSTRUMENTS ......................................................................................................... 19 4.2.3TEST PROCEDURES .......................................................................................................... 20 4.2.4TEST SETUP ....................................................................................................................... 21 4.2.5EUT OPERATING CONDITIONS......................................................................................... 21 4.2.6TEST RESULTS ................................................................................................................... 22 4.36DB BANDWIDTH MEASUREMENT ......................................................... 27 4.3.1LIMITS OF 6dB BANDWIDTH MEASUREMENT ................................................................ 27 4.3.2TEST INSTRUMENTS ......................................................................................................... 27 4.3.3TEST PROCEDURE ............................................................................................................28 4.3.4TEST SETUP ....................................................................................................................... 28 4.3.5EUT OPERATING CONDITIONS......................................................................................... 28 4.3.6TEST RESULTS ................................................................................................................... 29 4.4MAXIMUM PEAK OUTPUT POWER.......................................................... 33 4.4.1LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT ................................... 33 4.4.2INSTRUMENTS.................................................................................................................... 33 4.4.3TEST PROCEDURES .......................................................................................................... 34 4.4.4TEST SETUP ....................................................................................................................... 34 4.4.5EUT OPERATING CONDITIONS......................................................................................... 34 4.4.6TEST RESULTS ................................................................................................................... 35 4.5POWER SPECTRAL DENSITY MEASUREMENT ..................................... 36 4.5.1LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT ........................................... 36 4.5.2TEST INSTRUMENTS ......................................................................................................... 36 4.5.3TEST PROCEDURE ............................................................................................................37 4.5.4TEST SETUP ....................................................................................................................... 37 4.5.5EUT OPERATING CONDITION ........................................................................................... 37 4.5.6TEST RESULTS ................................................................................................................... 38 4.6BAND EDGES MEASUREMENT ............................................................... 42 FCC ID: …

Text truncated - open the document above for the full version.

FCC ID: PD9-R900531 Report No.: RF900626R04 1 Issued: July 27, 2001 ANNEX 1 PROCESSING GAIN OF DIRECT SEQUENCE SPREAD SPECTRUM MEASUREMENT 1. 1.1. 1. LIMITS OF PROCESSING GAIN OF A DIRECT SEQUENCE SPREAD SPECTRUM MEASUREMENT The limit of processing gain is 10dB 1.1 TEST INSTRUMENTS & SUPPORT UNIT Description & ManufacturerModel No.Serial No. Anritsu Spectrum Analyzer, 9kHz to 30GHz MS2667CM10281 Anritsu Signal Generator, 10kHz to 20GHz 68247B984703 Hewlett Packard Power Meter,HP438A2743A04416 Hewlett Packard Power Sensor, -30 to 20dBm 8485A2942A08387 Hewlett Packard Step Attenuator, 10dB steps HP8496B3247A18505 Mini-Circuits Power SplitterZN2PD-9GNA DELL Laptop ComputerInspiron 5000eNA Campaq Laptop ComputerPPX99125 FCC ID: PD9-R900531 Report No.: RF900626R04 2 Issued: July 27, 2001 1.2 METHOD OF MEASUREMENT The processing gain may be measured using the CW jamming margin method. Section 4.7.4 shows the test configuration. The test consists of stepping a signal generator in 50 kHz increments across the passband of the system. At each point, the generator level required to produce the recommended Bit Error Rate (BER) is recorded. This level is jammer level. The output power of the transmitting unit is measured at the same point. The jammer to Signal (J/S) ratio is then calculated. Discard the worst 20% of the J/S data points. The lowest remaining J/S ratio is used when calculating the Process Gain. The reference PER is specified as 8%. The corresponding Es/No (signal to noise ratio per symbol) is 16.4 dB. The curve is attached as below. This value and the measured J/S ratio are used in the following equation to calculate the Process Gain (Gp) of the system. Where: (S/N) o : Signal to noise ratio for the chosen BER. Gp = (S/N)+Mj+Lsys FCC ID: PD9-R900531 Report No.: RF900626R04 3 Issued: July 27, 2001 Mj : Maximum jammer to Signal Ratio recorded at the detected BER. Lsys : System losses . For the purpose of this processing gain calculation, we assume Lsys at its minimum value of 2 dB. TEST SETUP 7 NOTEBOOK EUT ANRITSU SIGNAL GENERATOR EUT NOTEBOOK PWR SENSOR 8485A Power meter HP 438A Mini-Circuits 15542 ZNZPD-9G HP8496D STEP ATTN 110dB (10dB steps) Matched Cables RECEIVER Transmitter FCC ID: PD9-R900531 Report No.: RF900626R04 4 Issued: July 27, 2001 1.3 TEST PROCEDURES Obtain the simplex link shown. Perform all independent instrumentation calibrations prior to this procedure. Set operating power levels using fixed and variable attenuators in system to meet the following objectives: Signal Power at receiver approximately –55dBm (above thermal sensitivity such that thermal noise does not cause bit errors. Signal Power at power meter between –20 and –30dBm for optimal linearity. Use spectrum analyzer to monitor test. Ensure that CW Jammer generator RF output is disabled and measure the power at the power meter port using the power meter. This is the relative signal power, Sr. Disable Transmitter, and set CW Jammer generator RF output frequency equal to the carrier frequency and enable generator output. Set reference CW Jammer power level at power meter port 8.4dB below Sr (minimum J/S, or 10dB processing gain reference level). Note the power level setting on the generator, this is the reference CW Jammer power setting, Jr. Disable CW Jammer, re-establish link. PER test should be operating essentially error -free. Enable CW Jammer at the reference power level and verify that the PER test indicates a PER of less than 8%. Alternatively, adjust the CW Jammer level to that which causes 8% PER and verify that the S/J is less than 8.4dB. Repeat step 7 for uniform steps in frequency increments of 50 kHz across the receiver passband with the CW Jammer. In this case the receiver passband is +/- 8.5 MHz. The numerical data associated with the following radio channel is tabulated and presented for Channel 1,6, and 11. Note:Since the jamming signal will be blocked by the IF filter if the jamming frequency is far form the center of the carrier frequency. So, only those frequencies around carrier frequency are shown here. FCC ID: PD9-R900531 Report No.: RF900626R04 5 Issued: July 27, 2001 1.4 EUT OPERATING CONDITION The software provided by client to set the EUT to transmit at lowest, middle and highest channel. 1.5 TEST RESULTS EUT11Mbps Wireless LAN CardModelWL-216C Environmental Conditions24°C, 70%RHTe s t e d B ySteven Lu Although the theoretical processing gain is lower than 10 dB, but the CCK coding provides an extra coding gain of 2.2dB. 11Mbps CHANNEL 1 Processing Gain FrequencyGp(S/N)Mj = J/SLsys (GHz)(dB)(dB)(dB)(dB) 2.4070011.816.4-6.92 2.4070511.416.4-6.92 2.4071011.516.4-6.92 2.4071511.616.4-6.92 2.4072011.316.4-6.82 2.4072511.516.4-6.92 2.4073011.516.4-6.92 2.4073511.516.4-6.92 2.4074011.416.4-7.02 2.4074511.316.4-7.12 2.4075011.516.4-7.12 2.4075511.316.4-7.12 2.4076011.116.4-7.22 2.4076511.216.4-7.22 2.4077011.416.4-7.12 2.4077511.416.4-7.12 2.4078011.216.4-7.22 2.4078511.316.4-7.22 2.4079011.016.4-7.12 2.4079511.216.4-7.22 2.4080011.116.4-7.32 2.4080511.316.4-7.32 FCC ID: PD9-R900531 Report No.: RF900626R04 6 Issued: July 27, 2001 11Mbps CHANNEL 1 Processing Gain FrequencyGp(S/N)Mj = J/SLsys (GHz)(dB)(dB)(dB)(dB) 2.4081011.216.4-7.22 2.4081511.416.4-7.22 2.4082011.316.4-7.12 2.4082511.216.4-7.22 2.4083011.116.4-7.22 2.4083511.316.4-7.12 2.4084011.316.4-7.12 2.4084511.516.4-7.32 2.4085011.216.4-7.42 2.4085511.216.4-7.22 2.4086011.116.4-7.32 2.4086511.416.4-7.32 2.4087011.316.4-7.22 2.4087511.216.4-7.22 2.4088011.316.4-7.12 2.4088511.416.4-7.12 2.4089011.116.4-7.32 2.4089511.016.4-7.42 2.4090011.016.4-7.42 2.4090511.316.4-7.32 2.4091011.116.4-7.32 2.4091511.416.4-7.32 2.4092011.116.4-7.32 2.4092511.216.4-7.32 2.4093011.016.4-7.42 2.4093511.216.4-7.22 2.4094011.216.4-7.32 2.4094511.116.4-7.32 2.4345011.016.4-7.42 2.4345511.216.4-7.22 2.4346011.316.4-7.32 2.4346511.116.4-7.32 2.4347011.216.4-7.22 2.4347511.416.4-7.22 FCC ID: PD9-R900531 Report No.: RF900626R04 7 Issued: July 27, 2001 11Mbps CHAN…

Text truncated - open the document above for the full version.

FCC ID: PD9-R900531 Report No.: RF900626R04 47 Issued: July 27, 2001 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: PD9-R900531 Report No.: RF900626R04 48 Issued: July 27, 2001 RADIATED EMISSION TEST
