Technical Specifications
| # | Rule Parts | Frequency Range | Power Output |
|---|
| 14 | 15E | 6.67 GHz - 6.67 GHz | 573.00 mW |
Modular TypeSingle Modular ApprovalConfidentialityLong Term Grant NotesPower Output listed is EIRP. The first five rows reported above are for LPI mode and the remaining rows are for Standard mode. Modular Approval filing. Device is a 2 x 2 MIMO configuration, enabled for 6 GHz operations as described in this filing. The antenna(s) used for this transmitter must not transmit simultaneously with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedures. Grantee must provide installation and operating instructions for complying with FCC multi-transmitter product procedures. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. End-users and installers must be provided with transmitter operating conditions for satisfying RF exposure compliance. The highest reported Body and Simultaneous SAR values are 0.63 W/kg and 1.59 W/kg respectively.
This device supports 20, 40, 80,160, and 320 MHz BW modes.
This module is approved in portable configurations with PIFA reference antenna (4.88 to 5.02 dBi) at 45mm minimum test separation distance. Power Density and SAR testing was performed to demonstrate RF exposure compliance.
This filing meets MPE requirements of KDB 447498 and can be used in mobile configurations for the following reference antennas: PIFA reference antenna (4.88 to 5.02 dBi), Dipole reference antenna (4.49 to 5.02 dBi) and Monopole reference antenna (4.79 to 4.91 dBi). The minimum gain approved with the UNII-5 to UNII-8 bands is -2.0 dBi.
