Technical Specifications
| # | Rule Parts | Frequency Range | Power Output |
|---|
| 3 | 15C | 2.42 GHz - 2.46 GHz | 494.00 mW |
Modular TypeSingle Modular ApprovalConfidentialityLong Term Grant NotesPower Output listed is conducted. Modular Approval. Power output has been reduced at the upper
bandedge channels as shown in filings under this FCC ID. The antenna(s) used for this transmitter
must not transmit simultaneously with any other antenna or transmitter, except in accordance with
FCC multitransmitter product procedures. Grantee must provide installation and operating instructions
for complying with FCC multi-transmitter product procedures. This module is approved in
mobile/portable configurations. Only those antenna(s) tested with the device or similar antenna(s) with
equal or lesser gain may be used with this transmitter. Grantee must coordinate with OEM integrator
to determine applicable host configurations to ensure RF exposure compliance, including
simultaneous transmission SAR requirements according to published KDB 616217 Supplement
documentation. When all conditions of this filing cannot be met installation of this device into specific
final products may require the submission of a permissive change application, containing appropriate
data demonstrating compliance, or a new application. OEM/Host integrator must be provided with
antenna installation instructions and transmitter operating conditions to satisfy RF exposure
compliance. Device is a client only device containing a 2 x 2 MIMO configuration, enabled for either
2.4 or 5 GHz band operations as described in this filing. OEM/Host integrator is responsible for
complying with the instructions and requirements for each transmitter they choose to integrate into a host product. The highest reported Body and Simultaneous SAR values are 0.30W/kg and 1.52W/kg respectively.
This module is approved in portable/mobile configurations with antenna SkyCross reference Antenna, Type PIFA at 18mm minimum test separation distance.
SAR testing was performed to demonstrate RF compliance.
