PD9LEN4965AGClass B Computing Device Peripheral

Intel(R) Wireless WiFi Link 4965AGN User Guide With your wireless network card, you can access wireless networks, share files or printers, or even share your Internet connection. All of these features can be explored with a wireless network in your home or office. This wireless local area network (WLAN) solution is designed for both home and business use. Additional users and features can be added as your networking needs grow and change. Your Intel(R) Wireless WiFi Link 4965AGN adapter is compatible with 802.11a, 802.11b 802.11g and 802.11n wireless standards. Operating at 5 GHz or 2.4 GHz frequency at speeds of up to 54 Mbps you can now connect your computer to existing high-speed networks that use multiple access points within large or small environments. Your wireless adapter maintains automatic data rate control according to access point location to achieve the fastest possible connection. All of your wireless network connections are easily managed by Intel(R) PROSet/Wireless software. Profiles that are set up through the Intel PROSet/Wireless software provide enhanced security measures with 802.1x network authentication. NOTE: The software is compatible with the Intel(R) Wireless WiFi Link 4965AGN, Intel(R) Wireless WiFi Link 4965AG_, Intel(R) PRO/Wireless 3965ABG Network Connection, Intel(R) PRO/Wireless 3945ABG Network Connection, Intel(R) PRO/Wireless 3945BG Network Connection, Intel(R) PRO/Wireless 2915ABG Network Connection and the Intel(R) PRO/Wireless 2200BG Network Connection. Table of Contents Use Intel PROSet/Wireless Software Connect to a Network Use Profiles Set up Security Troubleshooting Administrator Tool Glossary Wireless Network Overview Security Overview Specifications Customer Support Safety and Regulatory Information Warranty Adapter Registration Information in this document is subject to change without notice. © 2004–2006 Intel Corporation. All rights reserved. Intel Corporation, 5200 N.E. Elam Young Parkway, Hillsboro, OR 97124-6497 USA The copying or reproducing of any material in this document in any manner whatsoever without the written permission of Intel Corporation is strictly forbidden. Intel(R) is a trademark or registered trademark of Intel Corporation or its subsidiaries in the United States and other countries. Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Intel disclaims any proprietary interest in trademarks and trade names other than its own. Microsoft and Windows are registered trademarks of Microsoft Corporation. Windows Vista is either a registered trademark or trademark of Microsoft Corporation in the United States and/or other countries. *Other names and brands may be claimed as the property of others. Intel Corporation assumes no responsibility for errors or omissions in this document. Nor does Intel make any commitment to update the information contained herein. "Important Notice FOR ALL USERS OR DISTRIBUTORS!!!! Intel wireless LAN adapters are engineered, manufactured, tested, and quality checked to ensure that they meet all necessary local and governmental regulatory agency requirements for the regions that they are designated and/or marked to ship into. Since wireless LANs are generally unlicensed devices that share spectrum with radars, satellites, and other licensed and unlicensed devices, it is sometimes necessary to dynamically detect, avoid, and limit usage to avoid interference with these devices. In many instances Intel is required to provide test data to prove regional and local compliance to regional and governmental regulations before certification or approval to use the product is granted. Intel's wireless LAN's EEPROM, firmware, and software driver are designed to carefully control parameters that affect radio operation and to ensure electromagnetic compliance (EMC). These parameters include, without limitation, RF power, spectrum usage, channel scanning, and human exposure. For these reasons Intel cannot permit any manipulation by third parties of the software provided in binary format with the wireless LAN adapters (e.g., the EEPROM and firmware). Furthermore, if you use any patches, utilities, or code with the Intel wireless LAN adapters that have been manipulated by an unauthorized party (i.e., patches, utilities, or code (including open source code modifications) which have not been validated by Intel), (i) you will be solely responsible for ensuring the regulatory compliance of the products, (ii) Intel will bear no liability, under any theory of liability for any issues associated with the modified products, including without limitation, claims under the warranty and/or issues arising from regulatory non-compliance, and (iii) Intel will not provide or be required to assist in providing support to any third parties for such modified products. Note: Many regulatory agencies consider Wireless LAN adapters to be "modules", and accordingly, condition system-level regulatory approval upon receipt and review of test data documenting that the antennas and system configuration do not cause the EMC and radio operation to be non-compliant." October 2006 Back to Contents Use Intel(R) PROSet/Wireless Software Use Intel PROSet/Wireless as your Wireless Manager Start Intel PROSet/Wireless Start Intel PROSet/Wireless from the Taskbar l Taskbar Icons l Tool Tips and Desktop Alerts Intel PROSet/Wireless Main Window l Wireless Networks List l Connection Status Icons l Network Properties l Connection Details l Profiles List Intel PROSet/Wireless Menus l Tools Menu m Application Settings m Intel Wireless Troubleshooter m Administrator Tool l Advanced Menu m Adapter Settings m Advanced Statistics m Use Windows to Manage Wi-Fi l Profiles Menu m Manage Profiles m Manage Exclusions Turn Wireless Radio On or Off Install and Uninstall the Software Use Intel PROSet/Wireless as your Wireless Manager Intel(R) PROSet/Wireless is used to setup, edit and ma…

Text truncated - open the document above for the full version.

January 9, 2007 American TCB 6731 Whittier Ave., Suite C110 McLean, VA 22101 Gentlemen: The attached documentation is provided in support of a formal submission to your organization for a modular approval of an intentional unlicensed transmitter. On behalf of our client, Aegis Labs has included an application for a Grant of Equipment Authorization pursuant to Subpart C of part 15 of FCC Rules (47 CFR) regarding intentional radiators. The data within the test report demonstrates the equipment was tested in a manner described under Part 2 and 15 of the Code of Federal Regulations. This is a modular approval of the Intel Wireless WiFi Link 4965AGN (MN: 4965AG_, FCC ID: PD9LEN4965AG), which is a WLAN adapter (802.11a, 802.11b, & 802.11g). It was tested externally to a computer chassis with a set of Ethertronics Antennas continuously transmitting and receiving form Chain A, B, and C antenna ports. If there are any additional questions or if further information is needed, please contact us at your earliest convenience. Sincerely, Johnny Candelas Aegis Labs, Inc. Test Technician Enclosure (1 Emissions Test Report + Exhibits)

Top View Bottom View

D7390502 rev01 4965AGN/AG Generic M1 Pre-printed Artwork 1. ALL DIMENSIONS PER D5978901 CURRENT REV 2. ALL TEXT/GRAPHICS TO BE BLACK UNLESS OTHERWISE INDICATED 3. LABEL MATERIAL PER D5978901 CURRENT REV 2111 NE 25th Ave Hillsboro, OR 97124 1 3 2 D73905-002 Pb N232 Complies with IDA Standards DB 02941 Regulatory approvals apply only to Intel authorized components, software and antenna solutions. Unauthorized installations or modifications will void regulatory approvals and product warranties. FCC ID: PD9LEN4965AG IC: 1000M-L4965AG (11S) PN SN: PPPPPPPZHHHHHYMDXXX Made in Xxxxxxxx FRU: XXXXXXX (23S) 802.11A/G MAC: XX XX XX XX XX XX EC: XXXXXX Model: 4965AG_ MM1 TR1 RO TR2 CCAH06LP0070T6 Label Location

Top View “Insulation removed” Bottom View “Insulation removed” Top View “Shielding removed”

Page 1 of 12 Report Number: INTEL-070110F Revision Number: NONE TEST REPORT PERTAINING TO: Equipment Under Test Model Number(s) Intel Wireless WiFi Link 4965AGN 4965AG_ CONFIGURATION 802.11a / 802.11b / 802.11g with a set of Ethertronics Antennas MEASUREMENTS PERFORMED IN ACCORDANCE WITH THE FOLLOWING STANDARD (S) Regulatory Standard(s) FCC CFR 47, PART 15 SUBPART B CLASS B PREPARED FOR: PREPARED BY: Intel Corporation Aegis Labs, Inc. 2111 NE 25 th Avenue 22431 Antonio Parkway B160-417 Hillsboro, Oregon 97124 Rancho S. Margarita, CA 92688 Contact(s): Mr. Robert Paxman Agent(s): Mr. Rick Candelas Mr. Johnny Candelas Test Report #: INTEL-070110F Test Report Revision: NONE APPENDICES REPORT BODY A B C D TOTAL PAGES PAGES 12 6 5 1 4 28 The contents of this report shall not be reproduced except in full, without the written approval of Aegis Labs, Inc. The Intel Corporation logo is used for identification purposes only and is a registered trademark of Intel Corporation Certificate Number: 1111.01 Page 2 of 12 Report Number: INTEL-070110F Revision Number: NONE TABLE OF CONTENTS SECTION TITLE PAGE COVER SHEET......................................................................................................... 01 TABLE OF CONTENTS.................................................................................................................... 02 1.0 REGULATORY COMPLIANCE GUIDELINES................................................................ 03 1.1 Guidelines For Testing To Emissions Standards..................................................................... 03 2.0 SUMMARY OF REGULATORY LIMITS.................................................................................. 04 3.0 ADMINISTRATIVE DATA AND TEST DESCRIPTION..................................................... 05 4.0 DESCRIPTION OF EUT CONFIGURATION....................................................................... 06 4.1 Arrangement and Location of EUT and Host Equipment........................................................... 06 4.2 EUT Description and Configuration..................................................................................................... 07 4.2.1 Product Description............................................................................................................................ 07 4.2.2 EUT Configuration.............................................................................................................................. 07 4.3 List of EUT Sub-Assemblies and Host Equipment.......................................................................... 08 4.4 Signal Line Cable Description And Connection Location.......................................................... 09 4.5 EMC Test Hardware and Software Measurement Equipment.............................................................. 10 5.0 CONDITIONS DURING EMISSIONS MEASUREMENTS................................................... 11 5.1 General..................................................................................................................... 11 5.2 Conducted Emissions Test Setup.......................................................................................................... 11 5.3 Radiated Emissions Test Setup......................................................................................... 12 APPENDICES A Test Data B Photographs – Test Setups C Modifications Required D Accreditation Certificate Page 3 of 12 Report Number: INTEL-070110F Revision Number: NONE 1.0 REGULATORY COMPLIANCE GUIDELINES Aegis Labs, Inc. operates as both a Nevada and California Corporation with no organizational or financial relationship with any company, institution, or private individual. Testing and engineering functions provided by Aegis Labs were furnished by RF technicians and engineers with accredited qualifications and training credentials to carry out their duties. The object of this report was to publish verifiable test results of an EUT subjected to the tests outlined in the standard listed on the cover page of this report. 1.1 Guidelines For Testing To Emissions Standards These global standards for EMC emission requirements apply to electrical equipment for Information Technology Equipment (ITE). Compliance to these standards and in combination with the other standards listed in this test report can be used to demonstrate presumption of compliance with the protection requirements of the appropriate agency standard. The purpose of these standards is to specify minimum requirements for emissions regarding electromagnetic compatibility (EMC) and protect the radio frequency spectrum 9 kHz. – 400 GHz. from unwanted interference generated from electrical/digital systems that intentionally or unintentionally generated RF energy. The emissions standards, normative documents and/or publications were used to conduct all tests performed on the equipment herein referred to as “Equipment Under Test”. Page 4 of 12 Report Number: INTEL-070110F Revision Number: NONE 2.0 SUMMARY OF TEST RESULTS Emissions Index Standard Test Limits / Levels Results FCC PART 15 A.C. Mains Port; Conducted Emissions; 0.150 MHz to 30 MHz Frequency Q-P Limit AVG Limit 0.150 – 0.5 MHz 66 dBuV 56 dBuV 0.5 – 5 56 dBuV 46 dBuV 5 – 30 60 dBuV 50 dBuV PASSED 1 FCC PART 15 R.F. Electromagnetic Fields, 30 to 1000 MHz Frequency Limit Distance 30 – 230 MHz 30 dBuV/m 10m 230 – 1000 MHz 37 dBuV/m 10m PASSED ANALYSIS AND CONCLUSIONS Based upon the measurement results we find that this equipment is within the limits of the global standards listed on the cover page of this test report. All results are based on a test of one sample. If any significant changes are made to the unit, the changes shall be evaluated and a retest may be required. Approval Signatories Test and Report Completed By: 01/09/07 Johnny Candelas Date: Test Technician Aegis Labs, Inc. Report Approved By: 01/09/07 Rick Candelas Date: Quality Assurance Manager Aegis Labs, Inc. Page 5 of 12 R…
