PD9WM3B2915ABGIntel PRO/Wireless 2915ABG Network Connection

Contents Intel(R) PRO/Wireless 2915ABG Network Connection User Guide With your wireless network card, you can access wireless networks, share files or printers, or even share your Internet connection. All of these features can be explored using a wireless network in your home or office. This wireless LAN solution is designed for both home and business use. Additional users and features can be added as your networking needs grow and change. Your Intel(R) PROSet/Wireless 2915ABG Network Connection adapter is compatible with 802.11a, 802.11b or 802.11g wireless standards. Operating at 5 GHz or 2.4 GHz frequency at speeds of up to 54 Mbps you can now connect your computer to existing high-speed networks using multiple access points within large or small environments. Your wireless adapter maintains automatic data rate control according to access point location to achieve the fastest possible connection. provide enhanced security measures using 802.1x network authentication. All of your wireless networks connections can be easily managed by Intel PROSet/Wireless. Intel(R) PRO/Wireless profiles provide enhanced security measures using 802.1x network authentication. NOTE: The software is compatible with the Intel PROSet/Wireless 2915ABG Network Connection and the Intel PROSet Wireless 2200BG Network Connection. Table of Contents l Using Intel PROSet/Wireless l Using Profiles l Setting up Security l Security Overview l Introduction to Wireless Networking l Connecting to a Network l Specifications l Troubleshooting l Glossary l Customer Support l Safety and Regulatory Information l Warranty l Adapter Registration Information in this document is subject to change without notice. file:///C|/CX2%20Muroc%20UG/6-15-04/index.htm (1 of 2) [6/15/2004 3:40:01 PM] Contents © 2000–2004 Intel Corporation. All rights reserved. Intel Corporation, 5200 N.E. Elam Young Parkway, Hillsboro, OR 97124-6497 USA The copying or reproducing of any material in this document in any manner whatsoever without the written permission of Intel Corporation is strictly forbidden. Intel(R) is a trademark or registered trademark of Intel Corporation or its subsidiaries in the United States and other countries. Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Intel disclaims any proprietary interest in trademarks and trade names other than its own. Microsoft and Windows are registered trademarks of Microsoft Corporation. *Other names and brands may be claimed as the property of others. Intel Corporation assumes no responsibility for errors or omissions in this document. Nor does Intel make any commitment to update the information contained herein. June 2004 file:///C|/CX2%20Muroc%20UG/6-15-04/index.htm (2 of 2) [6/15/2004 3:40:01 PM] Using Intel(R)PROSet/Wireless Back to Contents Using Intel PROSet/Wireless Software: Intel(R) PRO/Wireless 2915ABG Network Connection User Guide l Using Intel(R) PROSet/Wireless as your Wireless Manager l Starting Intel PROSet/Wireless l Launch Intel PROSet/Wireless from the task tray l Task Tray Menu Options l Tool Tips and Balloon Message Prompts l Intel PROSet/Wireless Main Window l Connection Status Icons l Connection Details l Profile List l Available Networks l Menus (Tools and Profile menus) l Tools Menu m Application Settings m Adapter Settings m Use Microsoft Client m Advanced Statistics m Intel Wireless Troubleshooter m Administrator Tool l Profiles Menu m Import/Export m Manage Exclusions l Enabling and Disabling the Radio l Installing and Uninstalling the Software l Installing and Uninstalling Single Sign On Feature Using Intel(R) PROSet/Wireless as your Wireless Manager Intel PROSet/Wireless can be used to setup, edit and manage network profiles to connect to a network. It also includes advanced settings such as power management and channel selection for setting up ad-hoc networks. If you are using Windows XP as your wireless manager, you can disable it from the Wireless Network tab. To disable Windows XP as your wireless manager: 1. Double-click the Intel PROSet/Wireless icon in the desktop task tray or click Start ‡Settings ‡Control Panel and double-click on Network Connections. 2. Right-click Wireless Network Connection and click Properties. 3. Click on Wireless Networks tab on the Wireless Network Connection Properties. 4. Verify that the Use Windows to configure my wireless network settings box is not selected. If it is, deselect it. 5. Click OK. This confirms that the Intel PROSet/Wireless utility is configured to manage your network profiles. file:///C|/CX2%20Muroc%20UG/6-15-04/assist.htm (1 of 32) [6/15/2004 3:40:06 PM] Using Intel(R)PROSet/Wireless NOTE: Check that the Application Settings option Notify me when another application is using the wireless device is selected. This option prompts you when Windows XP starts to manage your network profiles. Starting Intel PROSet/Wireless Launch Intel PROSet/Wireless either from the task tray icon, the Windows Start button, or from the Windows Control Panel icon. To launch Intel PROSet/Wireless use either of the following methods: l Click Start > Programs > Intel Wireless > Intel PROSet/Wireless. l Right-click the task tray icon located in the lower right corner of your Windows Desktop, and click the menu option Open Intel PROSet/Wireless. l Double-click the task tray icon to open Intel PROSet/Wireless. Exit Intel PROSet/Wireless: l To exit Intel PROSet/Wireless and close the task tray icon, click Exit from the from the task tray menu or click the Close button on the Intel PROSet/Wireless main window. Launch Intel PROSet/Wireless from the task tray To launch Intel PROSet/Wireless, double-click the task tray icon located in the lower right corner of your Windows desktop or right-click the task tray icon and click Open Intel PROSet/Wireless. Exit Intel PROSet/Wireless To exit Intel PROSet/Wireless and hide the task tray icon, right-click the task tr…

Text truncated - open the document above for the full version.

Contents Intel(R) PRO/Wireless 2915ABG Network Connection User Guide With your wireless network card, you can access wireless networks, share files or printers, or even share your Internet connection. All of these features can be explored using a wireless network in your home or office. This wireless LAN solution is designed for both home and business use. Additional users and features can be added as your networking needs grow and change. Your Intel(R) PROSet/Wireless 2915ABG Network Connection adapter is compatible with 802.11a, 802.11b or 802.11g wireless standards. Operating at 5 GHz or 2.4 GHz frequency at speeds of up to 54 Mbps you can now connect your computer to existing high-speed networks using multiple access points within large or small environments. Your wireless adapter maintains automatic data rate control according to access point location to achieve the fastest possible connection. provide enhanced security measures using 802.1x network authentication. All of your wireless networks connections can be easily managed by Intel PROSet/Wireless. Intel(R) PRO/Wireless profiles provide enhanced security measures using 802.1x network authentication. NOTE: The software is compatible with the Intel PROSet/Wireless 2915ABG Network Connection and the Intel PROSet Wireless 2200BG Network Connection. Table of Contents l Using Intel PROSet/Wireless l Using Profiles l Setting up Security l Security Overview l Introduction to Wireless Networking l Connecting to a Network l Specifications l Troubleshooting l Glossary l Customer Support l Safety and Regulatory Information l Warranty l Adapter Registration Information in this document is subject to change without notice. file:///C|/CX2%20Muroc%20UG/6-15-04/index.htm (1 of 2) [6/15/2004 3:40:01 PM] Contents © 2000–2004 Intel Corporation. All rights reserved. Intel Corporation, 5200 N.E. Elam Young Parkway, Hillsboro, OR 97124-6497 USA The copying or reproducing of any material in this document in any manner whatsoever without the written permission of Intel Corporation is strictly forbidden. Intel(R) is a trademark or registered trademark of Intel Corporation or its subsidiaries in the United States and other countries. Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Intel disclaims any proprietary interest in trademarks and trade names other than its own. Microsoft and Windows are registered trademarks of Microsoft Corporation. *Other names and brands may be claimed as the property of others. Intel Corporation assumes no responsibility for errors or omissions in this document. Nor does Intel make any commitment to update the information contained herein. June 2004 file:///C|/CX2%20Muroc%20UG/6-15-04/index.htm (2 of 2) [6/15/2004 3:40:01 PM] Using Intel(R)PROSet/Wireless Back to Contents Using Intel PROSet/Wireless Software: Intel(R) PRO/Wireless 2915ABG Network Connection User Guide l Using Intel(R) PROSet/Wireless as your Wireless Manager l Starting Intel PROSet/Wireless l Launch Intel PROSet/Wireless from the task tray l Task Tray Menu Options l Tool Tips and Balloon Message Prompts l Intel PROSet/Wireless Main Window l Connection Status Icons l Connection Details l Profile List l Available Networks l Menus (Tools and Profile menus) l Tools Menu m Application Settings m Adapter Settings m Use Microsoft Client m Advanced Statistics m Intel Wireless Troubleshooter m Administrator Tool l Profiles Menu m Import/Export m Manage Exclusions l Enabling and Disabling the Radio l Installing and Uninstalling the Software l Installing and Uninstalling Single Sign On Feature Using Intel(R) PROSet/Wireless as your Wireless Manager Intel PROSet/Wireless can be used to setup, edit and manage network profiles to connect to a network. It also includes advanced settings such as power management and channel selection for setting up ad-hoc networks. If you are using Windows XP as your wireless manager, you can disable it from the Wireless Network tab. To disable Windows XP as your wireless manager: 1. Double-click the Intel PROSet/Wireless icon in the desktop task tray or click Start ‡Settings ‡Control Panel and double-click on Network Connections. 2. Right-click Wireless Network Connection and click Properties. 3. Click on Wireless Networks tab on the Wireless Network Connection Properties. 4. Verify that the Use Windows to configure my wireless network settings box is not selected. If it is, deselect it. 5. Click OK. This confirms that the Intel PROSet/Wireless utility is configured to manage your network profiles. file:///C|/CX2%20Muroc%20UG/6-15-04/assist.htm (1 of 32) [6/15/2004 3:40:06 PM] Using Intel(R)PROSet/Wireless NOTE: Check that the Application Settings option Notify me when another application is using the wireless device is selected. This option prompts you when Windows XP starts to manage your network profiles. Starting Intel PROSet/Wireless Launch Intel PROSet/Wireless either from the task tray icon, the Windows Start button, or from the Windows Control Panel icon. To launch Intel PROSet/Wireless use either of the following methods: l Click Start > Programs > Intel Wireless > Intel PROSet/Wireless. l Right-click the task tray icon located in the lower right corner of your Windows Desktop, and click the menu option Open Intel PROSet/Wireless. l Double-click the task tray icon to open Intel PROSet/Wireless. Exit Intel PROSet/Wireless: l To exit Intel PROSet/Wireless and close the task tray icon, click Exit from the from the task tray menu or click the Close button on the Intel PROSet/Wireless main window. Launch Intel PROSet/Wireless from the task tray To launch Intel PROSet/Wireless, double-click the task tray icon located in the lower right corner of your Windows desktop or right-click the task tray icon and click Open Intel PROSet/Wireless. Exit Intel PROSet/Wireless To exit Intel PROSet/Wireless and hide the task tray icon, right-click the task tr…

Text truncated - open the document above for the full version.

Declaration of Compliance June 24, 2004 Chief, Certification and Engineering Bureau Industry Canada 1241 Clyde Avenue Ottawa, Ontario Canada K2C 1Y3 Dear Certification Officer: On behalf of Intel Corporation, Aegis Labs, Inc. (an authorized agent for preparations of applications) attest that the radio device tested (IC: 1000M-B2915ABG) has been evaluated and found to comply with the RF exposure limits for humans, as specified in Health Canada’s Safety Code 6 and reproduced in RSS-102. Please refer to the MPE Calculations attached to this application for any assumptions used in the SAR evaluation concerning user-control parameters. If there are any additional questions or if further information is needed, please contact me at your earliest convenience. Sincerely, Rick Candelas Aegis Labs, Inc. Lab Manager

AEGIS LABS, INC 22431 Antonio Parkway B160-417, Rancho Santa Margarita, CA 92688 949-459-7886 TEL 949-459-7869 FAX www.aegislabsinc.com TRANSMITTER MODULAR APPROVAL ATTESTATION June 23, 2004 Federal Communications Commission Re: Application Modular Approval Certification for FCC ID: PD9WM3B2915ABG Gentlemen: The following attestation addresses the eight requirements to support modular approval as required by the FCC Public Notice DA00-1407 “Part 15 Unlicensed Modular Transmitter Approval” 1 The modular transmitter has its own RF shielding and does not rely upon the shielding provided by the device into which it is installed in order to comply with Part 15 limits. 2 The modular transmitter has buffered modulation/data inputs. All inputs to the modules are buffered through the radio circuitry. 3 The modular transmitter has its own power supply regulator. 4 The modular transmitter has an antenna that complies with section 15.203 and 15.204(c) of the FCC rules. It has a UFL type of connector at the transmitter end and is soldered to the antenna (depending on OEM configuration). Also the antenna will be internal in the OEM host equipment and inaccessible to the user. 5 The modular transmitter was tested outside of a host desktop computer using a PCI extender card. The PCI extender card allows the transmitter to be placed outside of the chassis of the host desktop computer. 6 The modular transmitter will be labeled with its own FCC ID. Also, the OEM host computer manufacturer will be informed to display a label referring to the enclosed module. The exterior label will read as follows: “Contains Transmitter Module FCC ID” or “Contains TXFCCID”. 7 The modular transmitter is manufactured so that the user cannot influence the operation of the transmitter that will operate outside of the scope of the regulations. 8 The modular transmitter meets the MPE calculations of 47 CFR 1.1307(b)(1). Also, SAR data is available if necessary. If there are any additional questions or if further information is needed, please contact us at your earliest convenience at (949) 459-7886. Sincerely, Rick Candelas Aegis Labs, Inc. Lab Manager

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 July 14, 2004 RE: FCC ID: PD9WM3B2915ABG_ATCB001467 Attention: Rick Candelas I have a few comments on this Application. Please note that further comments may arise in response to answers provided to the questions below. FCC 1. Please note that the 731 shows 550mW as the power for 2412MHz. Please note that the proper frequency bands for a WLN device in the 2.4GHz range is 2412 to 2462MHz. Please correct the 731 form to show the actual measured maximum power and frequency ranges for the various frequency bands. 2. Please note that the tune up procedure and other documentation indicates that this device operates on non-US frequencies. Please provide information explaining how non-US frequencies are prevented from being accessed by the user and how these non-US frequencies are disabled so the OEM integrator cannot enable them. If this information has been provided, please give the location of this information. 3. Please note that page 8 of the report states that the typical transmit power of the device for 802.11g is significantly different than the transmit powers listed on the 731 and in the table on page 6. Please explain. 4. FYI – No action needed. Please note that on page 33 of the report you show 11.649GHz as needing only to be -20dB from the peak. Please note that 11.649GHz is in the restricted bands and the limits are 54dBuV average and 74dBuV peak. While the device is compliant, the report should reflect the proper limits. 5. In the note on page 119 of the manual it states,” To avoid the possibility of exceeding the FCC radio frequency exposure limits, you should keep a distance of at least 2 cm between you (or any other person in the vicinity) and the antenna that is built into the computer.” As this can only be in stalled with a mandatory 20cm separation requirement, shouldn’t this statement also indicate 20cm? Please verify and correct as necessary. 6. Please note that there does not appear to be OEM instructions to place a label on the host as follows or similar, “Contains FCC ID: PD9WM3B2915ABG”. Please explain. Industry Canada 7. Please note that in the FCB process the company numbers of both the applicant and the Existing Canadian representative need to be provided. Please provide the IC company number for the Existing Canadian representative for this application. If this is not known, or if this is not an existing contanct, please advise if this is to be listed as a New Contact. If this is an existing contact and you do not know the IC company number you may email [email protected] with the name address and contact person name for this information. Dennis Ward mailto:[email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. z Page 2 July 14, 2004 Any questions about the content of this correspondence should be directed to the sender.

July 16, 2004 RE: Intel Corporation FCC ID: PD9WM3B2915ABG Answers to the ATCB comments on the above referenced Application. FCC 1. Please note that the 731 shows 550mW as the power for 2412MHz. Please note that the proper frequency bands for a WLN device in the 2.4GHz range is 2412 to 2462MHz. Please correct the 731 form to show the actual measured maximum power and frequency ranges for the various frequency bands. Refer to “Form 731 (DTS) – Rev. A, 07-16-04” exhibit. 2. Please note that the tune up procedure and other documentation indicates that this device operates on non-US frequencies. Please provide information explaining how non-US frequencies are prevented from being accessed by the user and how these non-US frequencies are disabled so the OEM integrator cannot enable them. If this information has been provided, please give the location of this information. Refer to “WM3B2915ABG Channel Attestation.pdf” exhibit. 3. Please note that page 8 of the report states that the typical transmit power of the device for 802.11g is significantly different than the transmit powers listed on the 731 and in the table on page 6. Please explain. Refer to “Form 731 (DTS) – Rev. A, 07-16-04” exhibit. Page 8 of the test report only states typical values with the actual values listed on page 6 and in Appendix A of the test report. 5. In the note on page 119 of the manual it states,” To avoid the possibility of exceeding the FCC radio frequency exposure limits, you should keep a distance of at least 2 cm between you (or any other person in the vicinity) and the antenna that is built into the computer.” As this can only be in stalled with a mandatory 20cm separation requirement, shouldn’t this statement also indicate 20cm? Please verify and correct as necessary. Per Intel: The user’s guide is concerning various models/products this part of the manual on page 119 is specified for the 2200BG Network Connection, due to this information being incorrect we have gone forward with updating the manual on this page. Refer to “WM3B2915ABG User Manual eng a1.pdf” exhibit. 6. Please note that there does not appear to be OEM instructions to place a label on the host as follows or similar, “Contains FCC ID: PD9WM3B2915ABG”. Please explain. The user’s manual has been updated on page 109 concerning the label requirements. Refer to “WM3B2915ABG User Manual eng a1.pdf” exhibit. Industry Canada 7. Please note that in the FCB process the company numbers of both the applicant and the Existing Canadian representative need to be provided. Please provide the IC company number for the Existing Canadian representative for this application. If this is not known, or if this is not an existing contanct, please advise if this is to be listed as a New Contact. If this is an existing contact and you do not know the IC company number you may email [email protected] with the name address and contact person name for this information. This item will be responded to in a later response.

Top View Bottom View

IC: 1000M-3B2915 FCC ID: PD9WM3B2915ABG

Top View “Insulation removed” Bottom View “Insulation removed” Top View “Shielding removed”

MPE Calculations Systems operating under the provision of 47 CFR 1.1307(b)(1) shall be operated in a manor that ensures that the public is not exposed to radio frequency energy levels in excess of the FCC guidelines. The EUT will only be used with a separation of 20 centimeters or greater between the antenna and the body of the user or nearby persons and can therefore be considered a mobile transmitter per 47 CFR 2.1091(b). The MPE calculation for this exposure is shown below. Using the Ethertronics Antennas @ 5 GHz Range with highest output power: The peak radiated output power (EIRP) is calculated as follows: EIRP = P + G EIRP = 23.20 dBm + 5.00 dBi EIRP = 28.20 dBm (660.69 mW) Where P = Power input to the antenna (mW). G = Power gain of the antenna (dBi) Power density at the specific separation: S = PG/(4R 2 ð) S = (208.93 x 3.162) / (4 x 20 2 x ð) S = 0.131 mW/cm 2 Where S = Maximum power density (mW/cm 2 ) P = Power input to the antenna (mW). G = Numeric power gain of the antenna R = Distance to the center of the radiation of the antenna (20cm = limit for MPE) The maximum permissible exposure (MPE) for the general population is 1mW/cm 2 . The power density at 20cm does not exceed the 1mW/cm 2 limit. Therefore, the exposure condition is compliant with FCC rules. Estimated safe separation: R = PG/4ð R = (208.93 x 3.162) / 4ð R = 7.25 cm Where P = Power input to the antenna (mW). G = Numeric power gain of the antenna R = The safe estimated separation that the user must maintain from the antenna (cm) The numeric gain (G) of the antenna with a gain specified in dB is determined by: G = Log -1 (dB antenna gain/10) G = Log -1 (5.00 dBi/10) G = 3.162 Using the Ethertronics Antennas @ 2.4 GHz Range with highest output power: The peak radiated output power (EIRP) is calculated as follows: EIRP = P + G EIRP = 23.90 dBm + 3.00 dBi EIRP = 26.90 dBm (489.78 mW) Where P = Power input to the antenna (mW). G = Power gain of the antenna (dBi) Power density at the specific separation: S = PG/(4R 2 ð) S = (245.47 x 1.995) / (4 x 20 2 x ð) S = 0.097 mW/cm 2 Where S = Maximum power density (mW/cm 2 ) P = Power input to the antenna (mW). G = Numeric power gain of the antenna R = Distance to the center of the radiation of the antenna (20cm = limit for MPE) The maximum permissible exposure (MPE) for the general population is 1mW/cm 2 . The power density at 20cm does not exceed the 1mW/cm 2 limit. Therefore, the exposure condition is compliant with FCC rules. Estimated safe separation: R = PG/4ð R = (245.47 x 1.995) / 4ð R = 6.24 cm Where P = Power input to the antenna (mW). G = Numeric power gain of the antenna R = The safe estimated separation that the user must maintain from the antenna (cm) The numeric gain (G) of the antenna with a gain specified in dB is determined by: G = Log -1 (dB antenna gain/10) G = Log -1 (3.00 dBi/10) G = 1.995

Page 1 of 18 Report Number: INTEL-040412F FCC ID: PD9WM3B2915ABG Modular Approval Test Report And Application for Grant of Equipment Authorization Pertaining To: EUT FCC ID: Intel PRO/Wireless 2915ABG Network Connection, MN: WM3B2915ABG PD9WM3B2915ABG Configuration 802.11a / 802.11b / 802.11g with a set of Ethertronics Antennas MEASUREMENTS PERFORMED IN ACCORDANCE WITH Regulatory Standard(s) 47 CFR Part 15, Subpart C Section 15.247 Test Method: ANSI C63.4: 1992 American National Standard for Methods of Measurement of Radio-Noise Emissions from Low- Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz Certificate Number: 1111.01 APPLICANT: PREPARED BY: Intel Corporation Aegis Labs, Inc. EC2-02 13280 Evening Creek Drive 22431 Antonio Parkway B160-417 San Diego, California 92128 Rancho S. Margarita, CA 92688 Contact(s): Mr. Robert Paxman Agent(s): Mr. Steve Kuiper Mr. Rick Candelas Mr. Johnny Candelas Test Report #: INTEL-040412F APPENDICES REPORT BODY A TOTAL PAGES PAGES 18 73 91 Test Report Revision: None The contents of this report shall not be reproduced except in full, without the written approval of Aegis Labs, Inc. Page 2 of 18 Report Number: INTEL-040412F FCC ID: PD9WM3B2915ABG TABLE OF CONTENTS SECTION TITLE PAGE COVER SHEET.................................................................................... 01 TABLE OF CONTENTS............................................................................................... 02 1.0 CERTIFICATION OF TEST DATA............................................................................. 03 2.0 SUMMARY OF TEST RESULTS.............................................................. 06 3.0 ADMINISTRATIVE DATA AND TEST DESCRIPTION.......................................... 07 4.0 DESCRIPTION OF EUT..................................................................................... 08 4.1 EUT Description..................................................................................... 08 4.1.1 Channel Number and Frequencies................................................................ 09 4.2 EUT Configuration.................................................................................. 10 4.3 List of EUT Sub-Assemblies and Host Equipment...................................................... 11 4.4 I/O Cabling Diagram and Description............................................................................. 12 5.0 TEST EQUIPMENT AND TEST SETUPS............................................................... 13 5.1 AC Power Line Conducted Emissions............................................................ 13 5.2 Spurious Radiated Emissions...................................................................... 14 5.3 Conducted Emissions At The Antenna Port.................................................................... 14 5.4 Test and Measurement Equipment Used......................................................... 15 6.0 SAMPLE CALCULATIONS.......................................................................................... 16 7.0 MODIFICATIONS AND RECOMMENDATIONS........................................ 18 APPENDICES A Test Data Page 3 of 18 Report Number: INTEL-040412F FCC ID: PD9WM3B2915ABG 1.0 CERTIFICATION OF TEST DATA Aegis Labs, Inc. operates as both a Nevada and California Corporation with no organizational or financial relationship with any company, institution, or private individual. Testing and engineering functions provided by Aegis Labs are furnished through the use of part-time, full-time or consulting engineers with the appropriate qualifications to carry out their duties. The intended purpose of this test report is to describe the measurement procedure and to determine whether the equipment under test “EUT” complies with both the conducted and radiated limits. Limits for emissions testing are described under Subpart C of Part 15 of the FCC rules. The data, data evaluation and equipment configuration represented herein are a true and accurate representation of the Equipment Under Test (EUT) under the requirements specified in the emissions standard as described below. The test results contained in this report are only representative of the test sample tested as described in Section 3.0 of this report. Certification of the EUT is required as a prerequisite to marketing as defined in Part 2 of the FCC Rules. Prepared By: ________________________06/24/04 Rick Candelas Date: Staff Engineer Aegis Labs, Inc. Report Approved By: ________________________06/24/04 Steve J. Kuiper Date: Quality Assurance Manager Aegis Labs, Inc. Page 4 of 18 Report Number: INTEL-040412F FCC ID: PD9WM3B2915ABG 2.0 SUMMARY OF TEST RESULTS The test results provided within this report, indicate that the EUT has been found to be in COMPLIANCE with the test specifications based upon the following RF compliance standards: Pass/Fail determination is based upon the nominal values of the test data. 802.11a Mode (5725-5850 MHz) EMISSIONS STANDARD FCC Part 15 Section Description Results Comments 15.247(a)(2) The minimum 6dB bandwidth shall be at least 500 kHz. PASSED 5745 MHz = 16.58 MHz 5785 MHz = 16.67 MHz 5825 MHz = 16.67 MHz 15.247(b)(1) The maximum peak output power of the intentional radiator shall not exceed 1 watt. PASSED 5745 MHz = 22.9 dBm = 194.98 mW 5785 MHz = 23.10 dBm = 204.17 mW 5825 MHz = 23.20 dBm = 208.93 mW 15.247(b)(4) The intentional radiator shall be operated in a manner that ensures that the public is not exposed to radio …
