PDHGMRSWP1FRS/GMRS Combination

3. OPERATION 3.1 ICONS on LCD - Channel readout : Shows the current channel number. 3.2 Key Function 1) PTT switch : Push and hold to transmit ; release to receive. 2) Power Key : Turn on or off the Power 3) Channel Key : After pressing the Channel Key, the 2 Way Radio frequency channel can be changed by pressing the Up/Down Key. In a FM Radio Mode, the Channel Key is used as the FM frequency seek function. 4) Call Key : A call signal is transmitted by pressing the Call Key. 5) Monitor Key : This Key is used as a Squelch On/Off function when pressed short, and as a conversion Key of 2 Way Radio and FM Radio mode when pressed long. 6) Up/Down Key : Normally the Key is used to adjust the volume but this key is also used when setting a function. 7) Vox Level Switch : By pressing the Switch, a Vox Level ( High/Low/Off ) can be selected. 8) LCD (Liquid Crystal Display) : On the LCD, a Channel of the Radio is displayed. 9) Transmit indicator : When transmitting signals, a red light appears on the LCD. 3-3. SETTING AND OPERATION In order to communicate with other GMRS/FRS units, both you and the receiving party must be on the same channel. GMRSWP1 has 22channels indicated by the large digits on the LCD display panel. Before trying to transmit on the selected channel, you should press the Monitor Button to check the activity on that channel. If someone is already on the selected channel, you should try another channel that is clear 1) On/Off & Volume control Switch Radio ON : Press the power button at least for 2 seconds.You will hear confirming melody to indicated the unit is on. Radio OFF : Press the power button at least for 2 seconds. Volume setting : Press up[▲] or down[▼] button to adjust a level that is most comfortable for you while monitor is active. 2) Setting the Channel GMRSWP1 has 22 main channels * 22 Frequency channels ( indicated by CTC icon on the LCD ) To select the channel * Turn the radio on. * Press Channel button once, [XX] digit will blink on the LCD. XX is a channel. * Press up[▲] or down[▼] button to choose the channel. * Press the PTT button or Channel button to confirm. 3) VOX (Voice Operated Switching) You do not have to operate the PTT button each time when you want to transmit. You can also choose the VOX sensitivity so suit your environment of operation. ( Ex : noisy road, motor bike, factory etc. ) To Set the VOX level Vox Level can be selected by the Vox Level Switch. ìOffî means that the Vox function is disabled. ì Highî means that the Vox sensitivity is high. ì Lowî means that the Vox sensitivity is Low. 4) Call * Click the PTT button. 5) Monitoring the Channel It is used for listening the week signal or to here all activities on the channel by Manually overriding channel sub tone code setting. To activate the monitor feature * Press and hold the ìMONî(mointor) button quickly * When you hear the sound, release the ìMONî button. To disable the monitor feature * Press and hold the ìMONî(mointor) button quickly 6) Setting FM Radio Mode 2 Way Radio mode can be converted to FM Radio Mode and at a FM Radio Mode, when the 2 Way Radio signal comes in, the FM Radio Mode is converted to 2 Way Radio Mode. If there is no more signal coming at a 2 Way Radio Mode, the Radio gets back to the FM Radio Mode. To activate the FM Radio Mode By pressing the Monitor Button long, the 2 Way Radio Mode can be converted to FM Radio Mode. To get back to the 2 Way Radio Mode from FM Radio Mode, the Monitor button should be pressed long one more time. 7) FM Radio Frequency Scanning With the Frequency Scanning, a frequency of FM Radio can be selected. By pressing the scanning button, a desirable frequency can be chosen. To activate the Scan * Set the FM Radio Mode by pressing the Monitor Button long. * Scanning is initiated when the Channel Button is pressed. * If the Channel Button is pressed after a FM frequency was selected by scanning, the selected FM frequency is skipped and the scanning resumes. 8) Receiving The Coding feature reduce the possibility of interference and provide enhanced Communication. You can only listen to a call that has correct matching code. Important : Before transmitting or receiving to the other parties * Correct channel is selected (1 to 22) 9) Transmitting * Press and hold the PTT button * Speak slowly and clearly * To Stop the transmisstion, release the PTT button. * if there are no more receiving signal for 5 seconds, the unit will go into power save mode. [RF EXPOSURE STATEMENT : PDHGMRSWP1 / TTI TECH CO., LTD.] - CAUTION! - IMPORTANT SAFETY INFORMATION Your wireless hand-held portable transceiver contains a radio frequency transmitter. When the PTT button is pushed, the transmitter sends out RF signals. The device is authorized to operate at a transmit duty factor not exceeding 50% using alkaline “AAA” size batteries to comply with Federal Communications Commissions (FCC) RF exposure safety level guidelines for hand-held wireless devices. This device has been tested for SAR (SPECIFIC ABSORBTION RATE) and has been found to meet the requirements for body-worn transceiver. If you wear the radio, always use the manufacturer-supplied belt clip. Use of non- manufacturer-approved accessories may exceed the FCC RF exposure guidelines. Unauthorized antennas, modifications, or attachments could damage the transceiver and may violate FCC regulations. GMRS License : Use of GRMS radios within the United States requires a FCC GMRS license. An individual of 18 years of age or older, who is not a representative of a foreign government is eligible to apply for a GMRS system license. You will need two forms from the FCC - FCC FORM 159 and FCC Form 605 Main Form and Schedule F. You can find the forms online at http://www.fcc.gov/formpage.html or call 1-800- 418-3676.

0000000000 FCC LABEL LOCATION E.K.LIM MAR. 3. 2003 GMRSWP1 1 1 00 DRAWING. PART NO NAME OR TITAL FIRST USED IN ASSEMBLY DRAWNSCALEREV DATE : MAR 3,2003 G MR SWP 1 F C C L A B E L L O C A T I O N LABEL

VCO circuit problem. -. Squelch does not work IF IC U8 problem. Control logic circuit problem. 5. DESCRIPTION OF RADIO CIRCUIT 5-1. Frequency synthesizer Frequency synthesizer consists of VCO,PLL IC(built in PRESCALER) and loop filter. a) VCO VCO is composed of One VCO. Oscillation circuit takes colpitts circuit using variable Diode. And VCO is composed R46,D5,C66,C67,L17,C70,C71,C57, R29,R28,C47,C36,R23,Q14,Q15,R22,L14,L15,C22. VCO control voltage through loop filter adjusts frequency and Microphone Signal through Modulation terminal makes modulation. b) PLL IC PLL IC is adjustable IC to produce the wished frequency which VCO provides through loop filter. It has internal counter using 10.25Mhz reference frequency to make 6.25kHz as reference Signal. VCO frequency from prescaled input is divided signal is compared with Reference signal phase in phase comparator. Built-in charger pump changes voltage (until two signals are in phase) and charged voltage supplies VCO through loop filter to produce the desired frequency. Frequency data associated with channel goes to PLL IC by CPU through CLOCK , DATA. PLL IC enables by strobe line of CPU. c) Loop Filter Loop filter is composed of C34, R11, C31,R13, C33 and changes pulse from pin U9.14 to DC . And eliminates harmonic component in pulse. It helps VCO oscillate clearly as DC voltage is supplied into Varicap. 5-2. Receiver This is composed of Dual Conversion Super Heterodyne. First IF is 10.7Mhz. Local oscillator frequency is lower in 1’st IF than Rx frequency. It is called low side injection. Second IF is 450kHz . 2’nd local oscillator Frequency comes to 10.25MHz. a) Rx / Tx Conversion Circuit Rx signal goes to Rx / Tx conversion circuit through FIXED antenna connector, low pass filter (L1,L2,C1,C2,C113,C5) and receiver resonance circuit composed of L3,C15. When transmitting, Voltage through R1,D1 supplies,D2 of receive input is short and Tx is on condition. When PIN diode is off in condition of Rx, C18 resonate serially and make impedance matching at receiver bandpass filter. b) Front End Front-end has Q6 to provide a high sensitivity and low noise feature. It employs band pass filter to eliminate image frequency and to produce enough pass band by Q6 input and output. c) Mixer The receiver which has been amplifier in the RF front-end is provided to the base of the 1 st mixer Q7. The 1 st L/O signal provide from the VCO is supplied to the emitter of Q7 and Converted to the 1 st IF 10.7 MHz It has RF signal through Q6 and Band Pass Filter ,L14 and RF signal from Local Oscillator mixed. It develops 1’st IF 10.7MHz. 1’st IF goes to 1’st IF amplifier Q20 base through Ceramic filter FL2. If of mixing signals is selected and taken into Ceramic filter. impedance of mixer is direct matched with input impedance of Ceramic filter. Matching of filter satisfies pass bandwidth of filter, ripple elimination with in pass band, and attenuation characteristic of stop band. Ceramic filter is composed of two pole monolithic Ceramic filter, 8kHz of IF Bandwidth. R24 is used as impedance matching with 1’st IF Amp Q20. d) IF AMP and Detection 1’st IF AMP Q20 supplies IF IC (U8) mixer input pin16 through output resistor R24 and C95 to need gain in insertion loss of Ceramic filter and last stage circuit. Multi-use IF IC makes up of mixer IF AMP. 2’nd local frequency enter to IF IC pin1. It supplies mixer of internal IF IC. Mixer output of IF IC through pin3 passes 450kHz ceramic filter, supplies 2’nd IF amplifier and limits. After 2’nd IF AMP has a process of enough gain and AMP rejection, it comes to quadrature detection. Demodulated audio signal by X1 is amplified and comes out to pin9. Detected audio signal through R1,C46,C49,C145,R69,R19 C146,U3,R32,Q21,C50 and input in audio amp. Audio IC U10 through C51. e) Squelch Circuit Noise component of detected outputs has amplification squelch threshold Is controlled by Resistor C680,R311, R305. f) Audio Amplifier Demodulated audio signal enters to pin3 of AF IC (U10). It comes out to pin5 then, it reaches at speaker. 5-3. Transmitt When Tx develops with pressing PTT switch, VCO output amplifies through Q13,Q2,Q1,Q3,28 transmits by antenna through low pass filter. Tx RF signal produced from Tx VCO is amplified by Buffer Q28, Driver Q3 through C12 and entered Q1,Q2,Q13 Power Transistor input terminal with final amplification. After this stage, the signal is emitted at antenna through 50?matching circuit to low pass filter (L2,L1,C1,C2,C113,C5,) to eliminate harmonic. a) Audio Modulation and Audio Amplification Audio signal produced by external microphone, limits amplification, low pass filter by IC U3. Max. Frequency modulation deviation is adjusted by VR1 keeps noise and audio from entering to VCO at time of Tx. Audio modulation and Audio Amplification has characteristic of 6/OCT pre-emphasis by U3. 9. EXPLODED VIEW 10. CHANNEL DATA 1) 2 way Radio Frequency Chart Channel Frequency (MHz) Channel Frequency (MHz) 1 462.5625 12 467.6625 2 462.5875 13 467.6875 3 462.6125 14 467.7125 4 462.6375 15 462.5500 5 462.6625 16 462.5750 6 462.6875 17 462.6000 7 462.7125 18 462.6250 8 467.5625 19 462.6500 9 467.5875 20 462.6750 10 467.6125 21 462.7000 11 467.6375 22 462.7250 NOTE: Channels 1 through 7 are shared between GMRS and FRS radios. The channel number 20 is used for emergency channel. 2) FM Radio Frequency 87.5 Mhz ~ 108 Mhz

HYUNDAI CALIBRATION & CERTIFICATION TECH. CO., LTD. PRODUCT COMPLIANCE DIVISION SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 CERTIFICATE OF COMPLIANCE (SAR EVALUATION) EUT Type: GMRS(General Mobile Radio Service) and FRS(Family Radio Service) Bands. Prototype Model(s): GMRSWP1 Tx Frequency: 462.5500 MHz – 462.7250 MHz (GMRS) 467.5625 MHz – 467.7125 MHz (FRS) Max. SAR Measurement(s): 0.099mW/g(1g) GMRS Body SAR Max. RF Output Power: 0.225W ERP(23.5dBm) GMRS ; 0.218W ERP(23.4dBm) FRS Conducted Power: 0.787W (29.0dBm) GMRS ; 0.753W (28.8dBm) FRS Emission Designator: 10K5F3E Channel Capacity: 22 Application Type: Certification Trade Name(s): TTI FCC Rule Part(s): §95(A)(B), 2(J) This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled Environment Occupational exposure limits specified in ANSI/ IEEE Std. C95.1- 1992 and had been tested in accordance with the measurement procedures specified in ANSI/ IEEE Std. C95.3- 1992. (See Test Report). I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Hyundai C-Tech Co., Ltd. Certifies that no party to this application has been denied FCC benefits pursuant to section 5301 of the Anti- Drug Abuse Act of 1998, 21 U.S. C. 853(a) Report prepared by : Ki-Soo Kim Manager of Product Compliance Team This report only responds to the tested sample and may not be reproduced, except in full, without written approval of the HCT Co., Ltd. Manufacture; TTI TECH CO., LTD. Eundo Bldg. Room 402, 737-19 Banpo-1dong, Seocho-ku, Seoul, Korea, 137-041 FRN: 0005-8660-25 Date of Issue: February 10, 2003 Test Report No.: HCT-SAR03-0201 Test Site: HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. FRN: 0005-8642- 21 FCC ID : APPLICANT : PDHGMRSWP1 TTI TECH CO., LTD. Report No.: HCT-SAR03-0201 FCC ID : PDHGMRSWP1 DATE : February 10, 2003 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hctec.co.kr ２ ２２ ２ of 17 Table of Contents 1.1 SCOPE ---------------------------------------------------------------------------------------------------------- 2.1 INTRODUCTION / SAR DEFINITION --------------------------------------------------------------------- 3.1 SAR MEASUREMENT SET-UP --------------------------------------------------------------------------- 4.1 E-FIELD PROBE SYSTEM --------------------------------------------------------------------------------- 5.1 E-FIELD PROBE CALIBRATION PROCESS -------------------------------------------------------- 6.1 PHANTOM, HOLDER, & EQUIVALENT TISSUE --------------------------------------------------- 7.1 SYSTEM SPECIFICATIONS ------------------------------------------------------------------------------ 8.1 MEASUREMENT PROCESS ------------------------------------------------------------------------------ 9.1 ANSI/ IEEE C95.1 - 1992 RF EXPOSURE LIMITS -------------------------------------------------------- 10.1 MEASUREMENT UNCERTAINTIES ------------------------------------------------------------------- 11.1 TEST DATA SUMMARY ---------------------------------------------------------------------------------- 12.1 SAR TEST EQUIPMENT LIST --------------------------------------------------------------------------- 13.1 CONCLUSION ------------------------------------------------------------------------------------------------ 14.1 REFERENCES -------------------------------------------------------------------------------------------- APPENDIX A – SAR TEST PLOTS APPENDIX B – TEST SETUP PHOTOGRAPHS APPENDIX C – EUT PROFILE PHOTOGRAPHS APPENDIX D – DIPOLE VALIDATION PLOTS APPENDIX E – PROBE CALIBRATION DATA APPENDIX F – DIPOLE CALIBRATION DATA 3 4 5 6-7 8 9 10 11 12 13 14 15 16 17 Report No.: HCT-SAR03-0201 FCC ID : PDHGMRSWP1 DATE : February 10, 2003 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hctec.co.kr ３ ３３ ３ of 17 SAR MEASUREMENT REPORT 1.1 SCOPE Environmental evaluation measurements of specific absorption rate 1 (SAR) distributions in emulated human head and body tissues exposed to radio frequency(RF) radiation from wireless portable devices for compliance with the rules and regulations of the U.S. Federal Communications Commission (FCC). 2 1. 2 Applicant • FCC ID: PDHGMRSWP1 • EUT Type: GMRS(General Mobile Radio Service) and FRS(Family Radio Service) Bands. • Trade Name: TTI • Model(s): GMRSWP1 • Tx Frequency: 462.5500 MHz – 462.7250 MHz (GMRS) 467.5625MHz – 467.7125 MHz (FRS) • Application Type: Certification • Classification: Licensed Portable Transmitter • Modulation(s): FM • Max SAR Measurement: 0.099mW/g(1g) GMRS Body SAR • Max. RF Output Power: 0.225W ERP(23.5dBm) GMRS ; 0.218W ERP(23.4dBm) FRS Figure 1. SAR System • Conducted Power: 0.787W (29.0dBm) GMRS ; 0.753W (28.8dBm) FRS • Power Supply: (x4) AAA Alkaline batteries (1.5VDC) Manufacture(•: Rocket / •: Cencell / •: Energizer) • Place of Test(s): Hyundai C- TECH. EMC Lab. • Date(s) of Tests: February 7, 2003 • Report No.: HCT-SAR03-0201 1 Specific Absorption Rate (SAR) is a measure of the rate of energy absorption due to exposure to an RF transmitting source (wireless portable device). 2 IEEE/ANSI Std. C95.1-1992 limits are used to determine compliance with FCC ET Docket 93-62 Company Name: TTI TECH CO., LTD. Address: Eundo Bldg. Room 402, 737-19 Banpo-1dong, Seocho-ku, Seoul, Korea Attention: Mr. Hun-Joo Lee Senior –Manager Tel. / Fax : 82- 2-518-2417 / 82- 2-31-518-2419 E-Mail : [email protected] Report No.: HCT-SAR03-0201 FCC…

Text truncated - open the document above for the full version.

Report No.: HCT-SAR03-0201 FCC ID : PDHGMRSWP1 DATE : February 10, 2003 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hctec.co.kr 17 of 17 15.1 REFERENCES: [1] Federal Communications Commission, ET Docket 93-62, Guidelines for Evaluating the Environmental Effects of Radio frequency Radiation, Aug. 1996. [2] ANSI/IEEE C95.1 - 1991, American National Standard safety levels with respect to human exposure to radio frequency electromagnetic fields, 300kHz to 100GHz, New York: IEEE, Aug. 1992 [3] ANSI/IEEE C95.3 - 1991, IEEE Recommended Practice for the Measurement of Potentially Hazardous Electromagnetic Fields - RF and Microwave, New York: IEEE, 1992. [4] NCRP, National Council on Radiation Protection and Measurements, Biological Effects and Exposure Criteria for Radio Frequency Electromagnetic Fields, NCRP Report No. 86, 1986. Reprinted Feb. 1995. [5] T. Schmid, O. Egger, N. Kuster, Automated E-field scanning system for dosimetric assessments, IEEE Transaction on Microwave Theory and Techniques, vol. 44, Jan. 1996, pp. 105-113. [6] K. Pokovic, T. Schmid, N. Kuster, Robust setup for precise calibration of E-field probes in tissue simulating liquids at mobile communications frequencies, ICECOM97, Oct. 1997, pp. 120-124. [7]K. Pokoviº, T. Schmid, and N. Kuster, E-field Probe with improved isotropy in brain simulating liquids, Proceedings of the ELMAR, Zadar, Croatia, June 23-25, 1996, pp. 172-175. [8] Schmid & Partner Engineering AG, Application Note: Data Storage and Evaluation, June 1998, p2. [9] V. Hombach, K. Meier, M. Burkhardt, E. Kuhn, N. Kuster, The Dependence of EM Energy Absorption upon Human Head Modeling at 900 MHz, IEEE Transaction on Microwave Theory and Techniques, vol. 44 no. 10, Oct. 1996, pp. 1865-1873. [10] N. Kuster and Q. Balzano, Energy absorption mechanism by biological bodies in the near field of dipole antennas above 300MHz, IEEE Transaction on Vehicular Technology, vol. 41, no. 1, Feb. 1992, pp. 17-23. [11] G. Hartsgrove, A. Kraszewski, A. Surowiec, Simulated Biological Materials for Electromagnetic Radiation Absorption Studies, University of Ottawa, Bioelectro magnetics, Canada: 1987, pp. 29-36. [12] Q. Balzano, O. Garay, T. Manning Jr., Electromagnetic Energy Exposure of Simulated Users of Portable Cellular Telephones, IEEE Transactions on Vehicular Technology, vol. 44, no.3, Aug. 1995. [13] W. Gander, Computer mathematick, Birkhaeuser, Basel, 1992. [14] W.H. Press, S.A. Teukolsky, W.T. Vetterling, and B.P. Flannery, Numerical Recepies in C, The Art of Scientific Computing, Second edition, Cambridge University Press, 1992. [15] Federal Communications Commission, OET Bulletin 65, Evaluating Compliance with FCC Guidelines for Human Exposure to Radiofrequency Electromagnetic Fields. Supplement C, Dec. 1997. [16] N. Kuster, R. Kastle, T. Schmid, Dosimetric evaluation of mobile communications equipment with known precision, IEEE Transaction on Communications, vol. E80-B, no. 5, May 1997, pp. 645-652. [17] CENELEC CLC/SC111B, European Prestandard (prENV 50166-2), Human Exposure to Electromagnetic Fields High-frequency: 10kHz-300GHz, Jan. 1995. [18] Prof. Dr. Niels Kuster, ETH, EidgenØssische Technische Hoschschule Zòrich, Dosimetric Evaluation of the Cellular Phone. Report No.: HCT-SAR03-0201 FCC ID : PDHGMRSWP1 DATE : February 10, 2003 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hctec.co.kr APPENDIX A – SAR TEST PLOTS Report No.: HCT-SAR03-0201 FCC ID : PDHGMRSWP1 DATE : February 10, 2003 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hctec.co.kr Report No.: HCT-SAR03-0201 FCC ID : PDHGMRSWP1 DATE : February 10, 2003 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hctec.co.kr Report No.: HCT-SAR03-0201 FCC ID : PDHGMRSWP1 DATE : February 10, 2003 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hctec.co.kr Report No.: HCT-SAR03-0201 FCC ID : PDHGMRSWP1 DATE : February 10, 2003 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hctec.co.kr Report No.: HCT-SAR03-0201 FCC ID : PDHGMRSWP1 DATE : February 10, 2003 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hctec.co.kr Report No.: HCT-SAR03-0201 FCC ID : PDHGMRSWP1 DATE : February 10, 2003 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hctec.co.kr Report No.: HCT-SAR03-0201 FCC ID : PDHGMRSWP1 DATE : February 10, 2003 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hctec.co.kr Report No.: HCT-SAR03-0201 FCC ID : PDHGMRSWP1 DATE : February 10, 2003 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hctec.co.kr Report No.: HCT-SAR03-0201 FCC ID : PDHGMRSWP1 DATE : February 10, 2003 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hctec.co.kr Report No.: HCT-SAR03-0…

Text truncated - open the document above for the full version.

Report No.: HCT-SAR03-0201 FCC ID : PDHGMRSWP1 DATE : February 10, 2003 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hctec.co.kr Report No.: HCT-SAR03-0201 FCC ID : PDHGMRSWP1 DATE : February 10, 2003 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hctec.co.kr Date : February 5, 2003 Federal Communications Commission Authorization and Evaluation Division 7435 Oskland Mills Road Columbia, MD21046 Subject : GMRSWP1 Battery Type To whom it may concern Here we would like to confirm that the ‘AAA’ type batteries only should be used For this subject model GMRSWP1.(FCC ID: PDHGMRSWP1) Sincerely Yours, TTI tech Co., Ltd. President / W. K. You Report No.: HCT-SAR03-0201 FCC ID : PDHGMRSWP1 DATE : February 10, 2003 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hctec.co.kr APPENDIX C – EUT PROFILE PHOTOGRAPHS Report No.: HCT-SAR03-0201 FCC ID : PDHGMRSWP1 DATE : February 10, 2003 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hctec.co.kr Report No.: HCT-SAR03-0201 FCC ID : PDHGMRSWP1 DATE : February 10, 2003 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hctec.co.kr Report No.: HCT-SAR03-0201 FCC ID : PDHGMRSWP1 DATE : February 10, 2003 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hctec.co.kr Report No.: HCT-SAR03-0201 FCC ID : PDHGMRSWP1 DATE : February 10, 2003 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hctec.co.kr APPENDIX D – DIPOLE VALIDATION PLOTS Report No.: HCT-SAR03-0201 FCC ID : PDHGMRSWP1 DATE : February 10, 2003 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hctec.co.kr Report No.: HCT-SAR03-0201 FCC ID : PDHGMRSWP1 DATE : February 10, 2003 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hctec.co.kr Report No.: HCT-SAR03-0201 FCC ID : PDHGMRSWP1 DATE : February 10, 2003 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hctec.co.kr Report No.: HCT-SAR03-0201 FCC ID : PDHGMRSWP1 DATE : February 10, 2003 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hctec.co.kr Report No.: HCT-SAR03-0201 FCC ID : PDHGMRSWP1 DATE : February 10, 2003 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hctec.co.kr APPENDIX E – PROBE CALIBRATION DATA Report No.: HCT-SAR03-0201 FCC ID : PDHGMRSWP1 DATE : February 10, 2003 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hctec.co.kr Report No.: HCT-SAR03-0201 FCC ID : PDHGMRSWP1 DATE : February 10, 2003 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hctec.co.kr Report No.: HCT-SAR03-0201 FCC ID : PDHGMRSWP1 DATE : February 10, 2003 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hctec.co.kr Report No.: HCT-SAR03-0201 FCC ID : PDHGMRSWP1 DATE : February 10, 2003 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hctec.co.kr

Report No.: HCT-SAR03-0201 FCC ID : PDHGMRSWP1 DATE : February 10, 2003 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hctec.co.kr Report No.: HCT-SAR03-0201 FCC ID : PDHGMRSWP1 DATE : February 10, 2003 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hctec.co.kr Report No.: HCT-SAR03-0201 FCC ID : PDHGMRSWP1 DATE : February 10, 2003 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hctec.co.kr Report No.: HCT-SAR03-0201 FCC ID : PDHGMRSWP1 DATE : February 10, 2003 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hctec.co.kr Report No.: HCT-SAR03-0201 FCC ID : PDHGMRSWP1 DATE : February 10, 2003 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hctec.co.kr Report No.: HCT-SAR03-0201 FCC ID : PDHGMRSWP1 DATE : February 10, 2003 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hctec.co.kr Report No.: HCT-SAR03-0201 FCC ID : PDHGMRSWP1 DATE : February 10, 2003 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hctec.co.kr Report No.: HCT-SAR03-0201 FCC ID : PDHGMRSWP1 DATE : February 10, 2003 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL …
