PDNRM-1018GSM/WCDMA cellular device w/BT, BLE, WLAN

Quick GuideNokia Lumia 530 123123 Issue 1 EN RM-1018 Keys and parts Important: For important info on the safe use of your device and battery, read “Safety” and “Product and safety info” in the device user guide at www.nokia.com/support and in the in-device user guide before you take your device into use. Select Nokia Care. 1Earpiece 2Volume keys 3Power/Lock key 4Microphone 5Antenna areas 6Camera 7Audio connector 3.5 mm 8Micro-USB connector 9Loudspeaker Some of the accessories mentioned in this user guide, such as charger, headset, or data cable, may be sold separately. Avoid touching the antenna area while the antenna is in use. Contact with antennas affects the communication quality and may reduce battery life due to higher power level during operation. Get started Before you start using your phone, remove the back cover to insert the micro-SIM card (also known as the mini-UICC card). Remove the back cover Make sure the phone is switched off. 1. At the top of the phone, put your fingernails in the seam between the screen frame and the back cover. Do not use any sharp tools, as they may damage the phone. 2. Place your thumb in the middle of the back cover and bend the cover to remove it. 3. If the battery is in, lift it out from the upper right corner. Insert the SIM and memory cards 1. Carefully slide the micro-SIM card into the SIM slot with the metal contact area down. 2. Slide the memory card into the memory card slot. Important: Your device uses a micro-SIM card, also known as a mini-UICC SIM card. Use of incompatible SIM cards, or use of SIM card adapters, may damage the card or the device, and may corrupt data stored on the card. Tip: For best performance, it is recommended that you use a fast 4–128GB memory card by a well-known manufacturer. Replace the battery and back cover 1. Line up the battery contacts, and put the battery in. 2. Press the bottom edge of the back cover against the bottom edge of your phone, and snap the cover into place. 3. To switch your phone on, press the power key. Charge the battery Plug a compatible charger into a wall outlet, and connect the micro-USB end to your phone. You can also charge your phone from a computer with a USB cable. If the battery is completely discharged, it may need to charge for up to 20 minutes before you can use your device. The charging indicator may not be displayed in this time. Help and tips There's a user guide in your phone – it's always with you, available when needed. Check out videos, find answers to your questions, and get helpful tips. On the start screen, swipe left, and tap Nokia Care. If you’re new to Windows Phone, check out the section for new Windows Phone users. To transfer contacts and text messages from your old phone, on the start screen, swipe left, and tap Transfer my Data. For more info, see the Nokia Care app. For the online user guide, even more info, and troubleshooting help, go to www.nokia.com/ support. If your phone freezes To reset the phone without losing your data and settings, press and hold the power key for about 10 seconds. The phone vibrates and restarts. Product and safety information For info on Microsoft Mobile Service terms and Privacy policy, go to www.nokia.com/privacy. You can only use your device on the WCDMA 850, 900, 1900, 2100; and GSM 850, 900, 1800, 1900 MHz networks. Use your device only with an original BL-5J rechargeable battery. Do not dispose batteries as household waste. Charge your device with AC-18U charger. Charger plug type may vary. Microsoft Mobile may make additional battery or charger models available for this device. Do not drop, knock, or shake the device or the battery. Rough handling can break them. Third-party chargers that comply with the IEC/EN 62684 standard, and that can connect to your device micro USB connector, may also be compatible. To prevent possible hearing damage, do not listen at high volume levels for long periods. Exercise caution when holding your device near your ear while the loudspeaker is in use. When using this device, obey all laws and respect local customs, privacy and legitimate rights of others, including copyrights. Additional safety information Accessibility solutions Microsoft Mobile is committed to making mobile phones easy to use for all individuals, including those with disabilities. For more information, visit www.nokiaaccessibility.com. Hearing Warning: When you use the headset, your ability to hear outside sounds may be affected. Do not use the headset where it can endanger your safety. This device has been tested and rated for use with hearing aids for some of the wireless technologies used in this device. However, there may be some newer wireless technologies used in this device that have not yet been tested for use with hearing aids. It is important to try the different features of this device thoroughly and in different locations, using your hearing aid or cochlear implant, to determine if you hear any interference. Consult your service provider about its return and exchange policies and for information on hearing aid compatibility. Some wireless devices may interfere with some hearing aids. Your device complies with FCC rules on hearing aid compatibility. These rules require an M3 rating or higher. The M value of your device is marked on the device sales package. To determine the M-rating of your hearing aid and compatibility with this device, consult your hearing health professional. For more info about accessibility, go to www.nokiaaccessibility.com. Nickel The surface of this device is nickel-free. Information on health The U.S. Food and Drug Administration (FDA) and the U.S. Federal Communications Commission (FCC) published statements and questions and answers concerning cellular telephones and health. Microsoft Mobile encourages you to visit these websites for updated information. You can access the FDA website at www.fda.gov/ Radiation-EmittingProducts/ RadiationEmittingProductsandProcedures/ HomeBusinessandEnterta…

Text truncated - open the document above for the full version.

BIS Microsoft Date I July 3, 2014 Microsoft IVIobile OY Visiokatu 6 FIN-33720 TAMPERE FINLAND Tel.+358 7180 08000 Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD. 21046 Attention: Equipment Authorization Branch REQUEST FOR CONFIDENTIALITY Pursuant to Sections 0.457 (d) (I) (ii) and 0.459 of the Commission's Rules, the Applicant hereby requests confidential treatment of some of the information accompanying this Application of FCC ID: PDNRM-1018 and as outlined below: Exhibit 4: Block Diagram Exhibit 5: Schematic Diagrams Exhibit 10: List of Active Devices and Tune-Up Procedure Exhibit 12: Theory of Operation / Description of Circuitry FCC ID: PDNRM-1018 Exhibitl3a_Request_for_Confidentiality_15_22_24_27 Applicant: Microsoft Mobile Oy Copyright © 2014 Microsoft Mobile. All Rights Reserved. 2" Microsoft These materials contain trade secrets and proprietary information not customarily released to the public and the public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457 (d) (I) (ii) disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this Application. Microsoft Mobile OY yianne llkka Product Certification Officer SD/NLQ FCC ID: PDNRM-1018 Exhibitl3a_Request_for_Confidentiality_15_22_24_27 Applicant: Microsoft Mobile Oy ( Copyright © 2014 Microsoft Mobile. All Rights Reserved.

Microsoft Mobile Oy Tel +358 *(0) 7180 08000 Keilalahdentie 4 02150 ESPOO www.microsoft.com Finland Microsoft Corporation is an equal opportunity employer. Page 1 of 1 June 13, 2014 Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD. 21046 Attention: Equipment Authorization Branch This letter will authorize the appointment of Janne Ilkka to act as our agent in all FCC matters for grantee code PDN. Yours Sincerely, Microsoft Mobile Oy Antero Koivisto Senior Specialist, Regulatory

Microsoft Mobile OY Visiokatu 6 FIN-33720 Tampere FINLAND Tel. +358 7180 08000 July 3, 2014 - Attention: Equipment Authorization Branch REQUEST FOR SHORT TERM CONFIDENTIALITY Pursuant to Section 0.459 of the Commission's Rules and Public Notice DA 04-1705 of June 15, 2004, the Applicant hereby requests for 45 days short term confidential treatment of some of the information accompanying this application of FCC ID: PDNRM-1018 and as outlined below: External photos Test setup photos User's manual Internal photos - Exhibit 3: - Exhibit 7: - Exhibit 8: - Exhibit 9: These materials contain proprietary information not yet released to the public and the public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. Microsoft Mobile OY Product Certification Officer SD/NLO

FCC ID: PDNRM-1018 Exhibit 03 External photos Applicant: Microsoft Mobile Oy Copyright © 2014 Microsoft Mobile. All Rights Reserved. Date| Jul 3, 2014 FCC ID: PDNRM-1018 Exhibit 03 External photos Applicant: Microsoft Mobile Oy Copyright © 2014 Microsoft Mobile. All Rights Reserved. FCC ID: PDNRM-1018 Exhibit 03 External photos Applicant: Microsoft Mobile Oy Copyright © 2014 Microsoft Mobile. All Rights Reserved.

FCC ID: PDNRM-1018 Exhibit 01 Type Label and location Applicant: Microsoft Mobile Oy Copyright © 2014 Microsoft Mobile. All Rights Reserved. Date| July 1, 2014

FCC ID: PDNRM-1018 Exhibit 09 Internal Photos Applicant: Microsoft Mobile Oy Copyright © 2014 Microsoft Mobile. All Rights Reserved. Date| Jul 3, 2014 FCC ID: PDNRM-1018 Exhibit 09 Internal Photos Applicant: Microsoft Mobile Oy Copyright © 2014 Microsoft Mobile. All Rights Reserved. FCC ID: PDNRM-1018 Exhibit 09 Internal Photos Applicant: Microsoft Mobile Oy Copyright © 2014 Microsoft Mobile. All Rights Reserved. FCC ID: PDNRM-1018 Exhibit 09 Internal Photos Applicant: Microsoft Mobile Oy Copyright © 2014 Microsoft Mobile. All Rights Reserved.

FCC Part 15C Compliance Test Report / Template Version 15.0 FCC15CBT_RM-1018_05.docx Copyright © TCC Microsoft 1 (42) TCC Microsoft Tampere Laboratory P.O. Box 68 Sinitaival 5 FIN-33720 TAMPERE, FINLAND Tel. +358 (0) 7180 46800 Fax. +358 (0) 7180 46880 FCC Part 15C Compliance Test Report Test Report no.: FCC15CBT_RM-1018_05.docx Date of Report: 05-Jun-2014 Number of pages: 42 Customer’s Contact person: Tero Huhtala Testing laboratory: TCC Microsoft Tampere Laboratory P.O.Box 403 Visiokatu 3 FIN-33101 TAMPERE, FINLAND Tel. +358 71 800 8000 Fax. +358 71 804 6880 Customer: Microsoft Tampere P.O.Box 403 Visiokatu 4 FIN-33720 TAMPERE, FINLAND Tel. +358 (0) 7180 46800 Fax. +358 (0) 7180 46880 FCC listing no.: IC recognition no.: 94436 661AK-1 Tested devices/ accessories: Phone RM-1018 / Battery BL-5J / AC Charger AC-18E / Headset WH-108 / Dummy Battery SD-130 FCC ID: PDNRM-1018 IC: 661R-RM1018 Supplement reports: - Testing has been carried out in accordance with: CFR 47, FCC rules Part 15 Subpart C, ANSI C63.4 (2003), Public Notice DA 00-705, DTS procedures KDB 558074, IC standards. Deviations, modifications or clarifications (if any) to above mentioned documents are written in each section under "Test method and limit". Documentation: The test report must always be reproduced in full; reproduction of an excerpt only is subject to written approval of the testing laboratory. The documentation of the testing performed on the tested devices is archived for 15 years at TCC Microsoft. Test Results: The EUT complies with the requirements in respect of all parameters subject to the test. The test results relate only to devices specified in this document Date and signature for the contents: Hannu Söderholm, Specialist, EMC FCC Part 15C Compliance Test Report / Template Version 15.0 FCC15CBT_RM-1018_05.docx Copyright © TCC Microsoft 2 (42) TCC Microsoft Tampere Laboratory P.O. Box 68 Sinitaival 5 FIN-33720 TAMPERE, FINLAND Tel. +358 (0) 7180 46800 Fax. +358 (0) 7180 46880 1. Summary for FCC Part 15C Compliance Test Report Date of receipt Check Date Testing completed 27-May-2014 The customer's contact person Tero Huhtala Test Plan referred to T:\Projects\RM-1018\TestPlan\RS_testplan_RM-1018.xlsm Notes - Document name T:\Projects\RM-1018\EMC\FCC15CBT_RM-1018_05.docx 1.1. EUT and Accessory Information The EUT is a mobile phone with following features: GSM/WCDMA/WLAN/Bluetooth The EUT is tested with maximum rated TX power. Devices under tests Product Type SN HW MV SW DUT Phone RM-1018 004402478273679 1500 - 01068.00004.14182.20000 43170 Phone RM-1018 004402478273646 1500 - 01068.00004.14182.20000 43171 Phone RM-1018 004402478273562 1500 - 01068.00004.14182.04000 43175 Battery BL-5J 4175354134B12507230;0670573 - - - 43173 AC Charger AC-18E 4090493442750400944;0675695 - - - 43172 Headset WH-108 2376171 - - - 43142 Dummy battery SD-130 06.05.2014/03618 V.1 - - 43176 1.2. Summary of Test Results Bluetooth: Section in CFR 47 Section in RSS-GEN or RSS-210 Name of the test Result 15.247(b)(1) A8(0.4(2)) Conducted peak output power PASSED 15.247(d), 15.205(b) A8(0.5) Band edge compliance of RF emissions PASSED 15.247(d) A8(0.5) Spurious RF conducted emissions PASSED 15.247(d), 15.209 A8(0.5) Spurious radiated emissions PASSED 15.207 7.2.2 AC powerline conducted emissions PASSED 15.247(a)(1) A8(0.1(1)) 20dB(bandwidth) PASSED 15.247(a)(1) A8(0.1(2)) Carrier frequency separation PASSED 15.247(a)(1)(iii) A8(0.1(4)) Number of hopping frequencies PASSED 15.247(a)(1)(iii) A8(0.1(4)) Time of occupancy PASSED PASSED The EUT complies with the essential requirements in the standard. FAILED The EUT does not comply with the essential requirements in the standard. NP The test was not performed by the TCC Microsoft Laboratory. FCC Part 15C Compliance Test Report / Template Version 15.0 FCC15CBT_RM-1018_05.docx Copyright © TCC Microsoft 3 (42) TCC Microsoft Tampere Laboratory P.O. Box 68 Sinitaival 5 FIN-33720 TAMPERE, FINLAND Tel. +358 (0) 7180 46800 Fax. +358 (0) 7180 46880 CONTENTS 1. Summary for FCC Part 15C Compliance Test Report .............................................. 2 1.1. EUT and Accessory Information ...........................................................................................................2 1.2. Summary of Test Results .....................................................................................................................2 2. Conducted peak output power (FCC §15.247(b)(1), RSS-210 A8(0.4(2))) .......................................................................... 5 2.1. Test Setup ............................................................................................................................................5 2.2. Test method and limit ...........................................................................................................................5 2.3. Bluetooth Test results ...........................................................................................................................6 3. Band edge compliance of RF emissions (FCC 15.247(d), 15.205(b), RSS-210 A8(0.5)) ................................................................... 9 3.2. Test method and limit ...........................................................................................................................9 3.3. Bluetooth test results ......................................................................................................................... 10 4. Spurious RF conducted emissions (FCC §15.247(d), RSS-210 A8(0.5)) ................................................................................. 18 4.1. Test Setup ......................................................................................................................................... 18 4.2. Test method and limit ........................................................................................................................ 18 4.3. Bluetooth Test results ...............................…

Text truncated - open the document above for the full version.

EMC Test Setup Photos / Template Version 1.0 EMC_Photo_RM-1018_09.docx Copyright © TCC Microsoft 1 (2) RM-1018 Test Setups Picture 1. FCC Part 15C Radiated emissions Picture 2. FCC Part 15B Radiated emissions EMC Test Setup Photos / Template Version 1.0 EMC_Photo_RM-1018_09.docx Copyright © TCC Microsoft 2 (2) Picture 3. FCC Part 15C AC powerline conducted emissions Picture 4. FCC Part 15B AC powerline conducted emissions
