Quick GuideNokia Lumia 635 2014-05-06 Issue 1.0 (draft) EN RM-975 Psst... This guide isn't all there is... There's a user guide in your phone – it's always with you, available when needed. Check out videos, find answers to your questions, and get helpful tips. On the start screen, swipe left, and tap Nokia Care. If you’re new to Windows Phone, check out the section for new Windows Phone users. For the online user guide, even more info, and troubleshooting help, go to www.nokia.com/support. Check out the videos at www.youtube.com/ NokiaSupportVideos. For info on Microsoft Mobile Service terms and Privacy policy, go to www.nokia.com/privacy. First start-up Your new phone comes with great features that are installed when you start your phone for the first time. Allow some minutes while your phone sets up. 2 Quick Guide Nokia Lumia 635 Contents Safety 4 Keys and parts 6 Get started 8 Try out the touch screen 11 Get the basics 12 Take your friends with you 13 Help and tips 14 Feature-specific information 15 Find your model number and serial number (IMEI) 15 Product and safety information 15 3 Safety Read these simple guidelines. Not following them may be dangerous or illegal. For further info, read the complete user guide. SWITCH OFF IN RESTRICTED AREAS Switch the device off when mobile phone use is not allowed or when it may cause interference or danger, for example, in aircraft, in hospitals or near medical equipment, fuel, chemicals, or blasting areas. Obey all instructions in restricted areas. ROAD SAFETY COMES FIRST Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety. INTERFERENCE All wireless devices may be susceptible to interference, which could affect performance. QUALIFIED SERVICE Only qualified personnel may install or repair this product. BATTERIES, CHARGERS, AND OTHER ACCESSORIES Use only batteries, chargers, and other accessories approved by Microsoft Mobile for use with this device. Third-party chargers that comply with the IEC/EN 62684 standard, and that can connect to your device micro USB connector, may be compatible. Do not connect incompatible products. KEEP YOUR DEVICE DRY Your device is not water-resistant. Keep it dry. GLASS PARTS The device screen is made of glass. This glass can break if the device is dropped on a hard surface or receives a substantial impact. If the 4 glass breaks, do not touch the glass parts of the device or attempt to remove the broken glass from the device. Stop using the device until the glass is replaced by qualified service personnel. PROTECT YOUR HEARING To prevent possible hearing damage, do not listen at high volume levels for long periods. Exercise caution when holding your device near your ear while the loudspeaker is in use. SAR This device meets RF exposure guidelines when used either in the normal use position against the ear or when positioned at least 5/8 inch (1.5 centimetres) away from the body. The specific maximum SAR values can be found in the Certification Information (SAR) section of this user guide. For more info, go to www.sar-tick.com. When a carry case, belt clip or other form of device holder is used for body-worn operation, it should not contain metal and should provide at least the above-stated separation distance from the body. Note that mobile devices may be transmitting even if you are not making a voice call. 5 Keys and parts 1Audio connector AHJ 3.5 mm 2Earpiece 3Volume keys 4Power/Lock key 5Microphone 6Antenna area 7Camera 8Loudspeaker 9Micro-USB connector Some of the accessories mentioned in this user guide, such as charger, headset, or data cable, may be sold separately. Avoid touching the antenna area while the antenna is in use. Contact with antennas affects the communication quality and may reduce battery life due to higher power level during operation. 6 7 Get started Before you start using your phone, remove the back cover to insert the micro-SIM card (also known as the mini-UICC card). Remove the back cover Make sure the phone is switched off. 1. At the top corner of the phone, put your index finger in the seam between the screen frame and the back cover. Do not use any sharp tools, as they may damage the phone. 2. Press the middle of the back cover, bend the cover open, and remove it. 8 Insert the SIM and memory card 1. If the battery is in, lift it out. 2. Slide the micro-SIM card into the SIM slot with the metal contact area down. 3. If you have a memory card, slide the card into the memory card slot. It is recommended that you use a fast microSD card from a well-known manufacturer. Important: Your device uses a mini-UICC SIM card, also known as a micro-SIM card. Use of incompatible SIM cards, or use of SIM card adapters, may damage the card or the device, and may corrupt data stored on the card. 9 Replace the battery and back cover 1. Line up the battery contacts, and put the battery in. 2. Press the bottom edge of the back cover against the bottom edge of your phone, and snap the cover into place. 3. To switch your phone on, press and hold the power key. Charge the battery Plug a compatible charger into a wall outlet, and connect the micro-USB end to your phone. You can also charge your phone from a computer with a USB cable. If the battery is completely discharged, it may need to charge for up to 20 minutes before you can use your device. The charging indicator may not be displayed in this time. 10 Try out the touch screen To use your phone, simply tap or tap and hold the touch screen. Swipe To, for example, open the action centre, place a finger at the top of the screen, and slide it down. Zoom in or out Place 2 fingers on an item, such as a photo, and slide your fingers apart or together. Tap and hold to open a menu Place your finger on an item, until the menu opens. 11 Get the basics Make a call 1. Tap > , type in the phone number, and tap call. To type in the + character, used for international calls, …
Text truncated - open the document above for the full version.
NOKIA NOKIA CORPORATION Visiokatu 6 FIN-33720 TAMPERE FINLAND Tel. +358 7180 08000 April 25, 2014 Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD. 21046 Attention: Equipment Authorization Branch REQUEST FOR CONFIDENTIALITY Pursuant to Sections 0.457 (d) (I) (ii) and 0.459 of the Commission's Rules, the Applicant hereby requests confidential treatment of some of the information accompanying this Application of FCC ID: PDNRM-975 and as outlined below: Exhibit 4: Block Diagram - Exhibit 5: Schematic Diagrams - Exhibit 10: List of Active Devices and Tune-Up Procedure Exhibit 12: Theory of Operation / Description of Circuitry These materials contain trade secrets and proprietary Information not customarily released to the public and the public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457 (d) (I) (11) disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this Application. NOKIA CORPORATION Janne Ilkka Product Certification Officer SD/NLQ
09 Apr 2014 External Photographs External Photographs FCC ID: PDNRM-975 Exhibit 3 IC: 661R-RM975 Applicant: Nokia Corporation Copyright © 2014 Nokia. All rights reserved. 09 Apr 2014 External Photographs External Photographs FCC ID: PDNRM-975 Exhibit 3 IC: 661R-RM975 Applicant: Nokia Corporation Copyright © 2014 Nokia. All rights reserved. 09 Apr 2014 External Photographs External Photographs FCC ID: PDNRM-975 Exhibit 3 IC: 661R-RM975 Applicant: Nokia Corporation Copyright © 2014 Nokia. All rights reserved. 09 Apr 2014 External Photographs External Photographs FCC ID: PDNRM-975 Exhibit 3 IC: 661R-RM975 Applicant: Nokia Corporation Copyright © 2014 Nokia. All rights reserved.
Page | 1 Label FCC ID: PDNRM‐975 Exhibit 1 IC: 661R‐RM975 Applicant: Nokia Corporation Copyright © 2014 Nokia. All Rights Reserved. Date| Apr 7, 2014
9 Apr 2014 Internal Photographs Internal Photographs FCC ID: PDNRM-975 IC: 661R-RM975 Exhibit 9 Applicant: Nokia Corporation Copyright © 2014 Nokia. All rights reserved. 9 Apr 2014 Internal Photographs Internal Photographs FCC ID: PDNRM-975 IC: 661R-RM975 Exhibit 9 Applicant: Nokia Corporation Copyright © 2014 Nokia. All rights reserved. 9 Apr 2014 Internal Photographs Internal Photographs FCC ID: PDNRM-975 IC: 661R-RM975 Exhibit 9 Applicant: Nokia Corporation Copyright © 2014 Nokia. All rights reserved. 9 Apr 2014 Internal Photographs Internal Photographs FCC ID: PDNRM-975 IC: 661R-RM975 Exhibit 9 Applicant: Nokia Corporation Copyright © 2014 Nokia. All rights reserved. 9 Apr 2014 Internal Photographs Internal Photographs FCC ID: PDNRM-975 IC: 661R-RM975 Exhibit 9 Applicant: Nokia Corporation Copyright © 2014 Nokia. All rights reserved. 9 Apr 2014 Internal Photographs Internal Photographs FCC ID: PDNRM-975 IC: 661R-RM975 Exhibit 9 Applicant: Nokia Corporation Copyright © 2014 Nokia. All rights reserved.
Nokia ____________________________________________________________________________ SAR Compliance Test Report Test report no.: FCC_RM-975_03 Date of report: 2014-04-28 Template version: 19.6 Number of pages: 124 Testing laboratory: TCC Nokia San Diego Laboratory 16620 West Bernardo Drive SAN DIEGO CA. 92127 USA Tel. +1 858 831 5000 Fax. +1 858 831 6500 Client: Nokia Corporation P.O. Box 68 Sinitaival 5 FIN-33721 TAMPERE, FINLAND Tel. +358 (0) 7180 08000 Fax. +358 (0) 7180 46880 Responsible test engineer: Jose Gomez Product contact person: Juha Paukku Measurements made by: Ray Ventura, Angelina Belden, Guy Abadilla, Jose Gomez, Jani Tuomela Tested device: RM-975 FCC ID: PDNRM-975 IC: 661R-RM975 Supplement reports: SAR_Photo_RM-975_04 Testing has been carried out in accordance with: 47CFR §2.1093 Radiofrequency Radiation Exposure Evaluation: Portable Devices FCC published RF exposure KDB procedures RSS-102, Issue 4 Evaluation Procedure for Mobile and Portable Radio Transmitters with Respect to Health Canada’s Safety Code 6 for Exposure of Humans to Radio Frequency Fields IEEE 1528 - 2013 IEEE Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Technique Documentation: The documentation of the testing performed on the tested devices is archived for 15 years at TCC Nokia. Test results: The tested device complies with the requirements in respect of all parameters subject to the test. The test results and statements relate only to the items tested. The test report shall not be reproduced except in full, without written approval of the laboratory. Date and signatures: For the contents: SAR Report FCC_RM-975_03 Applicant: Nokia Corporation Type: RM-975 Copyright 2014 TCC Nokia 1/124 Nokia ____________________________________________________________________________ CONTENTS 1. SUMMARY OF SAR TEST REPORT ........................................................................................................................................ 4 1.1 TEST DETAILS ........................................................................................................................................................................... 4 1.2 MAXIMUM RESULTS ................................................................................................................................................................... 4 1.2.1 Head Configuration ...................................................................................................................................................... 4 1.2.2 Body Worn Configuration .......................................................................................................................................... 6 1.2.3 Wireless Router Configuration ................................................................................................................................. 7 1.2.4 Summary SAR data ....................................................................................................................................................... 9 1.2.5 Maximum Drift ........................................................................................................................................................... 10 1.2.6 Measurement Uncertainty ...................................................................................................................................... 10 2. DESCRIPTION OF THE DEVICE UNDER TEST .................................................................................................................... 11 2.1 POWER REDUCTIONS IN WIRELESS ROUTER CONFIGURATIONS ................................................................................................ 14 2.2 DESCRIPTION OF THE ANTENNA .............................................................................................................................................. 14 3. TEST CONDITIONS ............................................................................................................................................................. 16 3.1 TEMPERATURE AND HUMIDITY ................................................................................................................................................ 16 3.2 TEST SIGNAL, FREQUENCIES AND OUTPUT POWER .................................................................................................................. 16 4. DESCRIPTION OF THE TEST EQUIPMENT ......................................................................................................................... 18 4.1 MEASUREMENT SYSTEM AND COMPONENTS ............................................................................................................................ 18 4.1.1 Isotropic E-field Probe Type ES3DV3 ................................................................................................................... 20 4.1.2 Isotropic E-field Probe Type EX3DV4 ................................................................................................................... 20 4.2 PHANTOMS ............................................................................................................................................................................ 21 4.3 TISSUE SIMULANTS ................................................................................................................................................................ 21 4.3.1 Tissue Simulant Recipes .......................................................................................................................................... 21 4.4 SYSTEM VALIDATION AND SYSTEM CHECKING ........................................................................................................................... 22 4.4.1 System validation status .................................................................................................…
Text truncated - open the document above for the full version.
Dipole D750V3 – SN: 1010 Antenna Parameters measured: 2014-03-20. Antenna Parameters with Head TSL Calibration certificate Annual measurement Impedance, transformed to feed point 54.9 Ω + 1.7 jΩ 52.5 Ω + 0.5 jΩ Return loss -26.2 dB -32.0 dB Antenna Parameters with Body TSL Calibration certificate Annual measurement Impedance, transformed to feed point 49.7 Ω - 1.5 jΩ 49.3 Ω - 1.8 jΩ Return loss -36.0 dB -34.2 dB Head TSL Body TSL Dipole D835V2 – SN: 4d040 Antenna Parameters measured: 2014-02-21. Antenna Parameters with Head TSL Calibration certificate Annual measurement Impedance, transformed to feed point 50.7 Ω - 3.8 jΩ 49.2 Ω - 3.2 jΩ Return loss -28.3 dB -29.5 dB Antenna Parameters with Body TSL Calibration certificate Annual measurement Impedance, transformed to feed point 47.1 Ω - 5.0 jΩ 46.3 Ω -5.8 jΩ Return loss -24.5 dB -22.9 dB Head TSL Body TSL Dipole D1750V2 – SN: 1081 Antenna Parameters measured: 2014-02-21. Antenna Parameters with Head TSL Calibration certificate Annual measurement Impedance, transformed to feed point 49.4 Ω - 0.2 jΩ 50.5 Ω +2.1 jΩ Return loss -44.2 dB -33.5 dB Antenna Parameters with Body TSL Calibration certificate Annual measurement Impedance, transformed to feed point 45.6 Ω + 0.2 jΩ 45.0 Ω + 0.3 jΩ Return loss -26.8 dB -25.6 dB Head TSL Body TSL Dipole D1900V2 – SN: 5d099 Antenna Parameters measured: 2014-02-14. Antenna Parameters with Head TSL Calibration certificate Annual measurement Impedance, transformed to feed point 50.9 Ω + 6.4 jΩ 48.8 Ω +4.3 jΩ Return loss -23.9 dB -26.8 dB Antenna Parameters with Body TSL Calibration certificate Annual measurement Impedance, transformed to feed point 46.3 Ω + 6.8 jΩ 45.7 Ω + 7.0 jΩ Return loss -22.0 dB -21.3 dB Head TSL Body TSL Dipole D2450V2 – SN: 800 Antenna Parameters measured: 2013-10-10. Antenna Parameters with Head TSL Calibration certificate 2-year measurement Impedance, transformed to feed point 54.9Ω + 2.2 jΩ 52.7 Ω + 3.8 jΩ Return loss -25.7 dB -26.9 dB Antenna Parameters with Body TSL Calibration certificate 2-year measurement Impedance, transformed to feed point 51.4 Ω + 3.7 jΩ 49.5 Ω + 5.6 jΩ Return loss -28.1 dB -24.9 dB Head TSL Body TSL
FCC Part 15C Compliance Test Report / Template Version 15.0 FCC15CWLAN_RM‐975_11.docx Copyright © TCC Nokia 1 (10) TCC Nokia Salo Laboratory P.O.Box(86) Joensuunkatu 7H / Kiila 1B FIN‐24101 SALO, FINLAND Tel. +358 (0) 7180 08000 Fax. +358 (0) 7180 45220 FCC Part 15C Compliance Test Report Test Report no.: FCC15CWLAN_RM-975_11.docx Date of Report: 20-May-2014 Number of pages: 10 Customer’s Contact person: Juha Paukku Testing laboratory: TCC Nokia Salo Laboratory P.O.Box(86) Joensuunkatu 7H / Kiila 1B FIN-24101 SALO, FINLAND Tel. +358 (0) 7180 08000 Fax. +358 (0) 7180 45220 Customer: Nokia Corporation P.O. Box 68 Sinitaival 5 FIN-33720 TAMPERE, FINLAND Tel. +358 (0) 7180 46800 Fax. +358 (0) 7180 46880 FCC listing no.: IC recognition no.: 533467 661V-1 Tested devices/ accessories: Phone RM-975 / Battery BL-5H / Headset WH-108 / AC-Charger AC-20E FCC ID: PDNRM-975 IC: 661R-RM975 Supplement reports: - Testing has been carried out in accordance with: CFR 47, FCC rules Part 15 Subpart C, ANSI C63.4 (2003), DTS procedures KDB 558074, IC standards. Deviations, modifications or clarifications (if any) to above mentioned documents are written in each section under "Test method and limit". Documentation: The test report must always be reproduced in full; reproduction of an excerpt only is subject to written approval of the testing laboratory. The documentation of the testing performed on the tested devices is archived for 15 years at TCC Nokia. Test Results: The EUT complies with the requirements in respect of all parameters subject to the test. The test results relate only to devices specified in this document Date and signature for the contents: Kalle Hannila, System Manager, EMC FCC Part 15C Compliance Test Report / Template Version 15.0 FCC15CWLAN_RM‐975_11.docx Copyright © TCC Nokia 2 (10) TCC Nokia Salo Laboratory P.O.Box(86) Joensuunkatu 7H / Kiila 1B FIN‐24101 SALO, FINLAND Tel. +358 (0) 7180 08000 Fax. +358 (0) 7180 45220 1. Summary for FCC Part 15C Compliance Test Report Date of receipt 04-Apr-2014 Testing completed 20-May-2014 The customer's contact person Juha Paukku Test Plan referred to T:\Projects\RM-975\TestPlan\RS_testplan_RM-975.xlsm Notes - Document name T:\Projects\RM-975\EMC\FCC15CWLAN_RM-975_11.docx 1.1. EUT and Accessory Information The EUT is a mobile phone with following features: GSM/WCDMA/WLAN/Bluetooth The EUT is tested with maximum rated TX power. Devices under tests Product Type SN HW MV SW DUT Phone RM-975 004402478049996 2020 - 010601.00014.14112.00000 18152 Battery BL-5H 4955403494010105474ö0670699 - - - 17993 Headset WH-108 2376171 - - - 17990 AC-Charger AC-20E 4090493271550402507ö0675628 - - - 17995 1.2. Summary of Test Results WLAN: Section in CFR 47 Section in RSS-GEN or RSS-210 Name of the test Result 15.247(b)(1) A8(0.4(4)) Conducted peak output power - 15.247(d), 15.205(b) A8(0.5) Band edge compliance of RF emissions PASSED 15.247(d) A8(0.5) Spurious RF conducted emissions - 15.247(d), 15.209 A8(0.5) Spurious radiated emissions - 15.207 7.2.2 AC powerline conducted emissions - 15.247(a)(2) A8(0.1(1)) 6dB(bandwidth) - 15.247(e) A8(0.1(2)) Power spectral density - PASSED The EUT complies with the essential requirements in the standard. FAILED The EUT does not comply with the essential requirements in the standard. NP The test was not performed by the TCC Nokia Laboratory. FCC Part 15C Compliance Test Report / Template Version 15.0 FCC15CWLAN_RM‐975_11.docx Copyright © TCC Nokia 3 (10) TCC Nokia Salo Laboratory P.O.Box(86) Joensuunkatu 7H / Kiila 1B FIN‐24101 SALO, FINLAND Tel. +358 (0) 7180 08000 Fax. +358 (0) 7180 45220 CONTENTS 1. Summary for FCC Part 15C Compliance Test Report ............................................... 2 1.1. EUT and Accessory Information ........................................................................................................ 2 1.2. Summary of Test Results .................................................................................................................. 2 2. Band edge compliance of RF emissions (FCC 15.247(d), 15.205(b), RSS-210 A8(0.5)) .................................................................... 4 2.2. Test method and limit ........................................................................................................................ 4 2.3. WLAN test results ............................................................................................................................. 5 3. Test Equipment ............................................................................................................. 9 3.1. Conducted measurements ................................................................................................................ 9 3.2. Radiated measurements ................................................................................................................... 9 FCC Part 15C Compliance Test Report / Template Version 15.0 FCC15CWLAN_RM‐975_11.docx Copyright © TCC Nokia 4 (10) TCC Nokia Salo Laboratory P.O.Box(86) Joensuunkatu 7H / Kiila 1B FIN‐24101 SALO, FINLAND Tel. +358 (0) 7180 08000 Fax. +358 (0) 7180 45220 2. Band edge compliance of RF emissions (FCC 15.247(d), 15.205(b), RSS-210 A8(0.5)) EUT with DUT number RM-975, DUT 18152 Accessories with DUT numbers BL-5H, DUT 17993 ; WH-108, DUT 17990 ; AC-20E, DUT 17995 Operation Voltage [V] / [Hz] Nominal Results PASSED Remarks - Temp [ o C] / Humidity [%RH] / Air Pressure [kPa] 20 / 43 / 101.4 Date of measurements 20-May-2014 Measured by Kalle Hannila 2.1.1 Test setup Tower / table controller Communication Tester Receiver EUT 2.2. Test method and limit The measurement is made according to DTS procedures KDB 558074 and IC standard RSS-210. The measurement results are obtained as described below: E [dBμV/m] = U RX + A TOT Where U RX is receiver reading and A TOT is total correction factor including cable loss, antenna factor and preamplifier gain (A TOT = L CABLES + A F - G PREAMP ). Limits for band edge compli…
Text truncated - open the document above for the full version.
FCC Part 15C Compliance Test Report / Template Version 15.0 FCC15CWLAN_RM‐975_12.docx Copyright © TCC Nokia 1 (10) TCC Nokia Salo Laboratory P.O.Box(86) Joensuunkatu 7H / Kiila 1B FIN‐24101 SALO, FINLAND Tel. +358 (0) 7180 08000 Fax. +358 (0) 7180 45220 FCC Part 15C Compliance Test Report Test Report no.: FCC15CWLAN_RM-975_12.docx Date of Report: 21-May-2014 Number of pages: 10 Customer’s Contact person: Juha Paukku Testing laboratory: TCC Nokia Salo Laboratory P.O.Box(86) Joensuunkatu 7H / Kiila 1B FIN-24101 SALO, FINLAND Tel. +358 (0) 7180 08000 Fax. +358 (0) 7180 45220 Customer: Nokia Corporation P.O. Box 68 Sinitaival 5 FIN-33720 TAMPERE, FINLAND Tel. +358 (0) 7180 46800 Fax. +358 (0) 7180 46880 FCC listing no.: IC recognition no.: 533467 661V-1 Tested devices/ accessories: Phone RM-975 / Battery BL-5H / Headset WH-108 / AC-Charger AC-20E FCC ID: PDNRM-975 IC: 661R-RM975 Supplement reports: - Testing has been carried out in accordance with: CFR 47, FCC rules Part 15 Subpart C, ANSI C63.4 (2003), DTS procedures KDB 558074, IC standards. Deviations, modifications or clarifications (if any) to above mentioned documents are written in each section under "Test method and limit". Documentation: The test report must always be reproduced in full; reproduction of an excerpt only is subject to written approval of the testing laboratory. The documentation of the testing performed on the tested devices is archived for 15 years at TCC Nokia. Test Results: The EUT complies with the requirements in respect of all parameters subject to the test. The test results relate only to devices specified in this document Date and signature for the contents: Sami Lehtonen, Specialist, EMC FCC Part 15C Compliance Test Report / Template Version 15.0 FCC15CWLAN_RM‐975_12.docx Copyright © TCC Nokia 2 (10) TCC Nokia Salo Laboratory P.O.Box(86) Joensuunkatu 7H / Kiila 1B FIN‐24101 SALO, FINLAND Tel. +358 (0) 7180 08000 Fax. +358 (0) 7180 45220 1. Summary for FCC Part 15C Compliance Test Report Date of receipt 04-Apr-2014 Testing completed 21-May-2014 The customer's contact person Juha Paukku Test Plan referred to T:\Projects\RM-975\TestPlan\RS_testplan_RM-975.xlsm Notes - Document name T:\Projects\RM-975\EMC\FCC15CWLAN_RM-975_12.docx 1.1. EUT and Accessory Information The EUT is a mobile phone with following features: GSM/WCDMA/WLAN/Bluetooth The EUT is tested with maximum rated TX power. Devices under tests Product Type SN HW MV SW DUT Phone RM-975 004402478049996 2020 - 010601.00014.14112.00000 18152 Battery BL-5H 4955403494010105474ö0670699 - - - 17993 Headset WH-108 2376171 - - - 17990 AC-Charger AC-20E 4090493271550402507ö0675628 - - - 17995 1.2. Summary of Test Results WLAN: Section in CFR 47 Section in RSS-GEN or RSS-210 Name of the test Result 15.247(b)(1) A8(0.4(4)) Conducted peak output power NP 15.247(d), 15.205(b) A8(0.5) Band edge compliance of RF emissions NP 15.247(d) A8(0.5) Spurious RF conducted emissions NP 15.247(d), 15.209 A8(0.5) Spurious radiated emissions PASSED 15.207 7.2.2 AC powerline conducted emissions NP 15.247(a)(2) A8(0.1(1)) 6dB(bandwidth) NP 15.247(e) A8(0.1(2)) Power spectral density NP PASSED The EUT complies with the essential requirements in the standard. FAILED The EUT does not comply with the essential requirements in the standard. NP The test was not performed by the TCC Nokia Laboratory. FCC Part 15C Compliance Test Report / Template Version 15.0 FCC15CWLAN_RM‐975_12.docx Copyright © TCC Nokia 3 (10) TCC Nokia Salo Laboratory P.O.Box(86) Joensuunkatu 7H / Kiila 1B FIN‐24101 SALO, FINLAND Tel. +358 (0) 7180 08000 Fax. +358 (0) 7180 45220 CONTENTS 1. Summary for FCC Part 15C Compliance Test Report ............................................... 2 1.1. EUT and Accessory Information ........................................................................................................ 2 1.2. Summary of Test Results .................................................................................................................. 2 2. Radiated emissions (FCC 15.247(e), RSS-210 WLAN) ........................................................................................ 4 2.2. Test method and limit ........................................................................................................................ 4 2.3. WLAN test results ............................................................................................................................. 6 3. Test Equipment ............................................................................................................. 9 3.1. Conducted measurements ................................................................................................................ 9 3.2. Radiated measurements ................................................................................................................... 9 FCC Part 15C Compliance Test Report / Template Version 15.0 FCC15CWLAN_RM‐975_12.docx Copyright © TCC Nokia 4 (10) TCC Nokia Salo Laboratory P.O.Box(86) Joensuunkatu 7H / Kiila 1B FIN‐24101 SALO, FINLAND Tel. +358 (0) 7180 08000 Fax. +358 (0) 7180 45220 2. Radiated emissions (FCC 15.247(e), RSS-210 WLAN) EUT with DUT number RM-975, DUT 18152 Accessories with DUT numbers BL-5H, DUT 17993 ; WH-108, DUT 17990 ; AC-20E, DUT 17995 Operation Voltage [V] / [Hz] Nominal Results PASSED Remarks - Temp [ o C] / Humidity [%RH] / Air Pressure [kPa] 21 / 42 / 101.5 Date of measurements 21-May-2014 Measured by Sami Lehtonen 2.1.1 Test setup Tower / table controller Communication Tester Receiver EUT 2.2. Test method and limit The measurement is made according to DTS procedures KDB 558074 and IC standard RSS-210 as follows: The measurement is divided into the Preliminary Measurement and the Final Measurement. The suspected frequencies are searched for in Preliminary Measurement with absorbers on the floor and measuring antenna at fixed height using 2-axis EUT position system. The Final Measurement is performed in the Semi-An…
Text truncated - open the document above for the full version.
FCC Part 15C Compliance Test Report / Template Version 15.0 FCC15BTLE_RM‐975_13.docx Copyright © TCC Microsoft 1 (8) TCC Microsoft Salo Laboratory P.O.Box(86) Joensuunkatu 7E FIN‐24101 SALO, FINLAND Tel. +358 (0) 7180 08000 Fax. +358 71 804 5220 FCC Part 15C Compliance Test Report Test Report no.: FCC15BTLE_RM-975_13.docx Date of Report: 27-May-2014 Number of pages: 8 Customer’s Contact person: Juha Paukku Testing laboratory: TCC Microsoft Salo Laboratory P.O.Box(86) Joensuunkatu 7E FIN-24101 SALO, FINLAND Tel. +358 (0) 7180 08000 Fax. +358 71 80 44122 Customer: Microsoft Tampere P.O.Box 403 Visiokatu 4 FIN-33720 TAMPERE, FINLAND Tel. +358 (0) 7180 46800 Fax. +358 (0) 7180 46880 FCC listing no.: IC recognition no.: 533467 661V-1 Tested devices/ accessories: Phone RM-975 / Batt…
