PE3DOYAK12-T2.4GHZ BT WIRELESS MOUSE

ULTRA eXo Mouse 2.4GHz Bluetooth Wireless Mouse User Guide The eXo mouse is designed for Windows OS (Window XP or higher), Mac OS and Linux OS. It features as a 2.4 GHz Bluetooth Wireless and a laser pointer which can be used for presentations. Contact and Support ULTRA Products 8300 West Flagler St. Suite #121-106 Miami, FL 33144 TEL : 1-888-222-5487 Website : www.ultraproducts.com I. Setup Options: Depending if you have a computer with a built-in Bluetooth® transceiver, there are two methods of connecting with the eXo Mouse: Transceiver –Free (PC & Mac) This method requires a computer with built-in Bluetooth®. Using the Bluetooth® USB Dongle Adaptor (PC Only) For PCs without Bluetooth®connectivity, ULTRA includes a Bluetooth®USB dongle. II. Package Contents 1. eXo Mouse 2. Charging Cable 3. Pen Stand 3. User’s Manual 4. Mouse Pad 5. Bluetooth USB Adapter 6. Installation CD Page1Page2 Mminimum System Requirements: For Windows®-based PCs Windows® XP Windows® 7 Windows Vista® For Apple-based Computers: Mac OS X v.10.2.6 higher* *Built-in Bluetooth®is required for operation ⑦ ⑧ ④ ① ② ③ ⑤ ⑥ ⑪ ⑫ ⑬ III. Features: Page3Page4 ①Page Up Button ②Charging & Laser Pointer Indicators ③Page Down Button ④Laser Pointer Button ⑤Low Battery Indicator ⑥Motion Indicator ⑦Right Mouse Button ⑧Scroll Wheel ⑨Left Mouse Button (Pen Tip) ⑩Charger Jack ⑪Laser Pointer ⑫DPI Switch ⑬Power Switch ⑨ ⑩ •When the battery is drained, ⑤on the eXo will blink every 2 seconds. •We recommend fully charging the battery for 3 hours prior to initial use. •When the charging cable is connected,②will illuminate red while charging and Switch to green when charging is complete. •Charging is possible even when the device is powered off. VI. Paring the eXo with a PC that Already has a Bluetooth® Transmitter: 1. Click on the Bluetooth® icon in the Control Panel window. 2. Click on the DEVICE Tab. If the eXo is displayed, registration has already been completed and no further steps are necessary. If the eXo is not listed, click on Add.... 3. Ensure the eXo is in paring mode by follow the steps above entitled Paring 4. Next, check the box for “My device is set up and ready to be found.” and click Next. Page5 IV. Paring : •Pairing varies depending on the type of Bluetooth®connection used. Ensure first that your Bluetooth® computer supports the HID function before paring. •For computers that are already paired with the eXo, the paring process is not necessary after restarting your computer. Reconnection is automatically made when the eXo is powered and the computer is ready to receive a Bluetooth® signal. Also, when the eXo is powered off, is out of range, or has radio interference, the device can loose its connection to the PC. Reconnection is made by turning the eXo OFF then back ON. •In order to pair your device, turn the eXo OFF then back ON and then press both ①③ simultaneously for 5 seconds . To indicate the device is in pairing mode, the green and red LEDs will flash. •If you are not able to enter pairing mode, repeat this procedure. V. Charging: In order to charge your eXo, connect it to the charging cable via the port on the top and connect the cable to any available USB port on your computer. USB Page6 ① ③ 7. Installation is now complete and the below window should appear. Clicking on Finishwill allow you to use the eXo. 8. When the registration is completed, the eXo will appear listed in the Bluetooth® devices list. Page7 5. Turn on the eXo and press both the Page Up and Page Down buttons (①③) simultaneously for 5 seconds. The eXo will now be in pairing mode. If the eXo is not found, confirm if it is in the pairing mode by ensuring the device is in paring mode and press the Search Againbutton. 6. You will then be asked for a passkey to register the device. Click on the 3 rd Pass Key option “Let me choose my own pair key:” and input the following code: 0000. Click on Next to continue. Page8 Page9 VII. Pairing the eXo with your MAC (with built in Bluetooth®): 1. Click on the Apple Menuand choose System Preferences. 2. Click on the Bluetooth®icon. Page10 3. In the Bluetooth®window ensure the following boxes are selected: Onand Discoverable. 4. Click the checkbox next to Show Bluetooth status in the menu bar. 5. Ensure the eXo is in paring mode by follow the steps above entitled Paring 6. Click the Set Up New Device....button and OS X will attempt to connect to the mouse. 7. When the computer is paired with the eXo, it will list it under Deviceson the Bluetooth®Setup Assistantwindow. When this occurs, click on Continue. Page11 8. The computer will finish pairing the eXo and will indicate when the connection has been made. 9. Re-opening the Bluetooth®preferences window, will show a list of all of the connected devices. Page12 VIII. Paring the eXo with a PC that does not have a Bluetooth®Transmitter (PC Only): 1.Insert the included CD to your system. Click on the Setup icon. 2.Select your language. 3. Accept terms of license agreement. 4. After installation, connect the Bluetooth®USB dongle to your system. 5. Click on the Launch Blue Manager Suite Icon located on your desktop (shown below). The Blue Manager application will launch. Page13 6. Under Bluetooth®Neighborhood, select Peripheral Devicesand double click the indicated area to perform device discovery. 7. A search for Bluetooth®devices will start. In order to become discoverable, the eXo must be in pairing mode. See section entitled Paring for instructions on how get the eXo in paring mode. Page14 8. When the Bluetooth®is enabled, the window below will display “Pointing in range” and “Connectable Mode.” Click OKto proceed The Bluetooth®mouse driver will be installed. 9. Once the device is properly installed, the Bluetooth®icon on the system tray Will turn from Blue to Green. IX. LED Indicators: Status ⑤RED LED⑥GREEN LED Standby modeOFF OFF Power onOFF Blinks Once When pairingBlinks Alternate RED & GREEN Until Paring is Complete In-useOFF ON When Device is Being Used Text Size OFF…

Text truncated - open the document above for the full version.

ISV Co., Ltd. E-Mail : [email protected] Tel. : 82-32-329-8921Fax. : 82-32-327-1125 August 20, 2010 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: PE3doyak12-T Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Part List CONF APPENDIX – DOYAK12-T - Part List.PDF Schematics Diagram(s) CONF APPENDIX - DOYAK12-T – Schemetics.PDF Block diagram CONF APPENDIX - DOYAK12-T– Block diagram.PDF The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely,

www.kes.co.kr FCC ID: U5MWPM-2400R Page 1 of 1 EUT External Photographs

www.kes.co.kr FCC ID label and Location Label

www.kes.co.kr EUT Internal Photographs www.kes.co.kr

DOYAK12-T Antenna Electrical specifications •Frequency range : 2402 ~ 2480MHz •Gain : -5.1dBi •V.S.W.R : 1.004 •Polarization: Vertical •Radiation pattern : Omni directional •Impedance : 50ohm Normalizer Mechanical specifications •Connector type : Solder •Material : Wrapping wire •Temperature Range : -40°C ~ + 80°C ØVSWR & Gain

TOD3003 Bluetooth ® Single Chip for HID (Product Data Sheet) Copyright © Terax Communication Technologies Inc. All rights reserved. Terax Confidential & Proprietary. All the descriptions and information in this material, in whole or in part, are provided by Terax “AS IS”, without warranty of any kind, and Terax reserves the right to make changes to this specification and its products at any time without notice. Customers are advised to obtain the latest version of this device specification as finally confirmed by Terax, before relying on any published information and before placing orders for products. Terax Communication www.terax.com.tw Version 1.04 Technologies Inc. Page 1 of 28 02/17/2009 General Description The TOD3003 is a highly integrated single chip Bluetooth device with a stand-alone baseband processor and integrated 2.4 GHz transceiver and is compliant to Bluetooth 2.0. This chip is specifically designed for applications in wireless input devices including keyboards, mice, presenters and gaming controllers. Built-in firmware is fully compliant to Bluetooth ® Human Interface Device (HID) profile. Application − Wireless mouse − Wireless keyboard − Game controllers − Presenters − Remote controls − GPS mouse (G-mouse) RF-Transceiver − Clean, fast hopping synthesizer − 0 dBm, 1 Mbps GFSK transmitter − Analog and Digital filtered receiver − Internal VCO resonator and PLL filter − 50 ohm ant. port eliminates most external RF parts Features − Compliant with Bluetooth ® Specification V2.0 − Compliant with Bluetooth ® HID profile version 1.0 − Support AFH − Embedded 8-bits ’C51 compatible Micro-Controller − Internal 128 kB mask ROM and 8 kB SRAM − On chip support for common mouse sensor interface eliminates external processor − On chip support for Serial Peripheral Interface (SPI) (mater/slave mode) − Optional I 2 C compatible interface − Built-in Power On Reset (POR) − Built-in 8-bit accuracy/10-bit resolution ADC with 4 input channels for detecting low power of battery and reading various analog sensors such as 3-axis accelerometer, etc. − Low Power 1.8V core operation − Integrated Switch-mode Regulators (1 BUCK and 1 BOOST) to support external sensor, LED/Laser and MCU to reduce external BOM cost. − Crystal oscillator with built-in digital trimming − Power management includes digital shutdown and wake up commands with an integrated low power oscillator for sniff mode − Support MCP option with 4 Megabit Flash − Support COB (Chip on Board) option − 56-Pin QFN package available (8 x 8 x 0.9 mm) UART GPIO Battery Antenna 12MHz XTAL Baseband MCUROMRAM 2.4Ghz Radio Boost 8 bit ADC POR SPI Buck Figure 1 – Functional Block Diagram TOD3003 Bluetooth ® Single Chip for HID (Product Data Sheet) Copyright © Terax Communication Technologies Inc. All rights reserved. Terax Confidential & Proprietary. All the descriptions and information in this material, in whole or in part, are provided by Terax “AS IS”, without warranty of any kind, and Terax reserves the right to make changes to this specification and its products at any time without notice. Customers are advised to obtain the latest version of this device specification as finally confirmed by Terax, before relying on any published information and before placing orders for products. Terax Communication www.terax.com.tw Version 1.04 Technologies Inc. Page 2 of 28 02/17/2009 1. Scope The document is a specification of TOD3003. 1.1 Document Information Document No.： Version： 1.04 Total Page: 28 Date: 2009/02/17 Title： ASIC Data Sheet Product Name： TOD3003 1.2 Update History Version Date/name Description 0.0 2008/01/24 Established -- -- (status= Preliminary) 1.0 2008/12/03 Change status from Preliminary to Product. Minor updates throughout. Indicate Buck regulator output as 1.83V, not 1.8V, wherever applicable. Add Key Features page. Add vendor list for xtal. Add Buck converter output filter values. 1.01 2009/02/02 Fix spelling on all page headers. Page 25: change Rr to Effective Series Resistance Rs. 1.02 2009/02/09 P. 1, 13, 18: Update accuracy of ADC to 8-bit. P. 3: Update T.O.C. P. 6: RF Interface: Add pin 57 to table. Clarify pins that are Test Pts. P. 10: Redraw module schematic to eliminate multiple net names. Last page: Remove leading ‘0’ from phone number. 1.03 2009/02/10 P. 5: Fix formatting of Fig. 2. Show pin 57. P. 9: Remove multiple net names on schematic. Correct spelling. P. 10: Additional schematic clean-up. Annotate photo. 1.04 2009/02/17 P. 10: Add/clarify annotations to photo. P. 16: Update Fig. 3 Bluetooth Software Stack. P. 19: Clarify first paragraph; add “optional” for Boost reg. TOD3003 Bluetooth ® Single Chip for HID (Product Data Sheet) Copyright © Terax Communication Technologies Inc. All rights reserved. Terax Confidential & Proprietary. All the descriptions and information in this material, in whole or in part, are provided by Terax “AS IS”, without warranty of any kind, and Terax reserves the right to make changes to this specification and its products at any time without notice. Customers are advised to obtain the latest version of this device specification as finally confirmed by Terax, before relying on any published information and before placing orders for products. Terax Communication www.terax.com.tw Version 1.04 Technologies Inc. Page 3 of 28 02/17/2009 Contents KEY FEATURES ............................................................................................................................................................. 4 PINOUT INFORMATION .............................................................................................................................................. 5 PIN ASSIGNMENT DIAGRAM........................................................................................................................................... 5 PIN DEFINITION..................................................................................................................................................…

Text truncated - open the document above for the full version.

www.kes.co.kr Test Report No.: TK-FR10037 Model No: DOYAK12-T Page 1 of 30 This Report shall not be reproduced except in full without the written approval of THRU-KES CO.,LTD. TEST REPORT For FCC Test Report No. : TK-FR10037 Date of Issue : 09/13/2010 FCC ID : PE3DOYAK12-T Description of Product : 2.4GHz Bluetooth Wireless Mouse Model No. : DOYAK12-T Applicant : ISV Co., Ltd. 102-705, Pucheon Technopark 364 Samjung-Dong, Ojun-Gu, Pucheon-Si, Korea Manufacturer : ISV Co., Ltd. 102-705, Pucheon Technopark 364 Samjung-Dong, Ojun-Gu, Pucheon-Si, Korea Standards : FCC Part 15.247 Test Date : 08/20/2010 – 09/13/2010 Test Results : PASS FAIL The test results relate only to the items tested. Tested by: Reviewed by: Kyu-Chul Shin KT Kang Test Engineer Technical Manager Date:09/13/2010 Date: 09/13/2010 THRU-KES CO.,LTD. 477-6, Hager-Ri, Yoju-Up, Yoju-Gun Kyunggi-Do,469-803, Korea Tel: +82-31-425-6200 / Fax: +82-31-424-0450 www.kes.co.kr Test Report No.: TK-FR10037 Model No: DOYAK12-T Page 2 of 30 This Report shall not be reproduced except in full without the written approval of THRU-KES CO.,LTD. TABLE OF CONTENTS 1.0 General Product Description ...............................................................................3 1.1 Tested Frequency .............................................................................................3 1.2 Tested Mode ....................................................................................................3 1.3 Model Differences .............................................................................................4 1.4 Device Modifications .........................................................................................4 1.5 Peripheral Devices ............................................................................................4 1.6 Calibration Details of Equipment Used for Measurement .........................................5 1.7 Test Facility......................................................................................................5 1.8 Laboratory Accreditations and Listings .................................................................5 2.0 Summary of tests .............................................................................................6 2.1 Technical Characteristic Test...............................................................................7 2.1.1 Carrier Frequency Separation .......................................................................7 2.1.2 Number of Hopping Frequencies ...................................................................9 2.1.3 20 dB bandwidth ...................................................................................... 11 2.1.4 Time of Occupancy (Dwell Time) ................................................................. 13 2.1.5 Maximum peak Conducted Output Power...................................................... 15 2.1.6 Band-edge............................................................................................... 18 2.1.7 Field Strength of Emissions ........................................................................ 24 2.1.8 AC Conducted Emissions............................................................................ 29 *Not Applicable, as it’s power was supplied from DC Power Supply ..오류! 책갈피가 정의되어 있지 않습니다. APPENDIX A – Test Equipment Used For Tests ................................................................ 32 www.kes.co.kr Test Report No.: TK-FR10037 Model No: DOYAK12-T Page 3 of 30 This Report shall not be reproduced except in full without the written approval of THRU-KES CO.,LTD. 1.0 General Product Description Equipment model name : DOYAK12-T Serial number : Prototype EUT condition : Pre-production, not damaged Antenna type : PCB antenna Gain -5.1dBi Frequency Range : 2402 ~ 2480 MHz RF output power : -4.43 dBm Peak Conducted Number of channels : 79 Type of Modulation(Data Rate) : GFSK Power Source : DC 3.7V 1.1 Tested Frequency LOW MID HIGH Frequency (MHz) 2402 2441 2480 1.2 Tested Mode - Pre-Scan has been conducted to determine the worst-case mode from all possible combinations between available modulations, data rates and antenna ports (if EUT with antenna diversity architecture). - Following channel(s) was (were) selected for the final test as listed below. Tested Ch Modulation Technology Modulation Type Low,Mid, High FHSS GFSK www.kes.co.kr Test Report No.: TK-FR10037 Model No: DOYAK12-T Page 4 of 30 This Report shall not be reproduced except in full without the written approval of THRU-KES CO.,LTD. 1.3 Model Differences Not applicable 1.4 Device Modifications The following modifications were necessary for compliance: Not applicable 1.5 Peripheral Devices Device Manufacturer Model No. Serial No. FCC ID or DoC EUT ISV Co., Ltd. DOYAK12-T - - Notebook F U J I T S U L T D LIFEBOOK S-5582 434230343466 DoC www.kes.co.kr Test Report No.: TK-FR10037 Model No: DOYAK12-T Page 5 of 30 This Report shall not be reproduced except in full without the written approval of THRU-KES CO.,LTD. 1.6 Calibration Details of Equipment Used for Measurement Test equipment and test accessories are calibrated on regular basis. The maximum time between calibrations is one year or what is recommended by the manufacturer, whichever is less. All test equipment calibrations are traceable to the Korea Research Institute of Standards and Science (KRISS), therefore, all test data recorded in this report is traceable to KRISS. 1.7 Test Facility The measurement facility is located at 477-6, Hager-Ri, Yoju-Up, Yoju-Gun Kyunggi- Do,469-803, Korea. Tel: +82-31-883-5092/Fax: +82-31-883-5169. The sites are constructed in conformance with the requirements of ANSI C63.7, ANSI C63.4 and CISPR Publication 22. 1.8 Laboratory Accreditations and Listings Country Agency Scope of Accreditation Logo USA FCC 3 & 10 meter Open Area Test Sites and one conducted site to perform FCC Part 15/18 measurements. 343818 KOREA KCC EMI (10 meter Open Area Test Site and two c…

Text truncated - open the document above for the full version.

www.kes.co.kr Test Setup Photos and Configuration Conducted Voltage Emissions www.kes.co.kr Radiated Electric Field Emissions
