Test Report S/N: 15.201218649. FCC Part 15.247 Dates of Tests: January 3-4, 2001 Certification © 2001 PCTEST Lab CREWAVE FCC ID: PFTCW-1100 39 Wireless LAN Network Adapter Card (PCMCIA) Appendix E – Users Manual

March 26, 2001 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Mr. Joe Dichoso SUBJECT: Crewave Co., Ltd. FCC ID: PFTCW-1100 731 Confirmation No.: EA99775 Correspondence Reference No.: 18567 Request for Tech. Info.: 3/26/01 Dear Steve: Transmitted herewith, on behalf of Crewave Co., Ltd. is an amendment provided in response to the request for technical information dated March 26, 2001. 1. Schematics 2. Block Diagram 3. Operational Description We trust this information is sufficient for the immediate grant of this application. If you have any further questions, please do not hesitate to contact us. cc: Crewave Co., Ltd.

Test Report S/N: 15.201218649. FCC Part 15.247 Dates of Tests: January 3-4, 2001 Certification © 2001 PCTEST Lab CREWAVE FCC ID: PFTCW-1100 38 Wireless LAN Network Adapter Card (PCMCIA) Appendix D – EUT Photographs © 2001 PCTEST Lab CREWAVE FCC ID: PFTCW-1100 NVLAP Lab Code: 100431-0 Wireless LAN Network Adapter Card (PCMCIA) © 2001 PCTEST Lab CREWAVE FCC ID: PFTCW-1100 NVLAP Lab Code: 100431-0 Wireless LAN Network Adapter Card (PCMCIA) © 2001 PCTEST Lab CREWAVE FCC ID: PFTCW-1100 NVLAP Lab Code: 100431-0 Wireless LAN Network Adapter Card (PCMCIA) © 2001 PCTEST Lab CREWAVE FCC ID: PFTCW-1100 NVLAP Lab Code: 100431-0 Wireless LAN Network Adapter Card (PCMCIA) © 2001 PCTEST Lab CREWAVE FCC ID: PFTCW-1100 NVLAP Lab Code: 100431-0 Wireless LAN Network Adapter Card (PCMCIA) © 2001 PCTEST Lab CREWAVE FCC ID: PFTCW-1100 NVLAP Lab Code: 100431-0 Wireless LAN Network Adapter Card (PCMCIA)

Test Report S/N: 15.201218649. FCC Part 15.247 Dates of Tests: January 3-4, 2001 Certification © 2001 PCTEST Lab CREWAVE FCC ID: PFTCW-1100 34 Wireless LAN Network Adapter Card (PCMCIA) Appendix A: FCC ID Sample Label & Location LABELLING REQUIREMENTS PER § 2.925 & § 15.19 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. (SEE NEXT PAGE) Test Report S/N: 15.201218649. FCC Part 15.247 Dates of Tests: January 3-4, 2001 Certification © 2001 PCTEST Lab CREWAVE FCC ID: PFTCW-1100 35 Wireless LAN Network Adapter Card (PCMCIA) FCC ID: PFTCW-1100

Test Report S/N: 15.201218649. FCC Part 15.247 Dates of Tests: January 3-4, 2001 Certification © 2001 PCTEST Lab CREWAVE FCC ID: PFTCW-1100 38 Wireless LAN Network Adapter Card (PCMCIA) Appendix D – EUT Photographs © 2001 PCTEST Lab CREWAVE FCC ID: PFTCW-1100 NVLAP Lab Code: 100431-0 Wireless LAN Network Adapter Card (PCMCIA) © 2001 PCTEST Lab CREWAVE FCC ID: PFTCW-1100 NVLAP Lab Code: 100431-0 Wireless LAN Network Adapter Card (PCMCIA) © 2001 PCTEST Lab CREWAVE FCC ID: PFTCW-1100 NVLAP Lab Code: 100431-0 Wireless LAN Network Adapter Card (PCMCIA) © 2001 PCTEST Lab CREWAVE FCC ID: PFTCW-1100 NVLAP Lab Code: 100431-0 Wireless LAN Network Adapter Card (PCMCIA) © 2001 PCTEST Lab CREWAVE FCC ID: PFTCW-1100 NVLAP Lab Code: 100431-0 Wireless LAN Network Adapter Card (PCMCIA) © 2001 PCTEST Lab CREWAVE FCC ID: PFTCW-1100 NVLAP Lab Code: 100431-0 Wireless LAN Network Adapter Card (PCMCIA) © 2001 PCTEST Lab CREWAVE FCC ID: PFTCW-1100 NVLAP Lab Code: 100431-0 Wireless LAN Network Adapter Card (PCMCIA)

© 2001 PCTEST Engineering Lab., Inc. 6660-B Dobbin Road • Columbia, MD 21045 • U.S.A. TEL (410) 290-6652 • FAX (410) 290-6654 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE (SAR EVALUATION) CREWAVE Co., Ltd. Dates of Tests: January 3-4, 2001 F7, Pureun Bldg. 28-1 Jamwon-dong, Seocho-gu Test Report S/N: SAR.201218648.PFT Seoul, KOREA 137-030 Test Site: PCTEST Lab, Columbia, MD USA Attn: Charlie Park FCC ID PFTCW-1100 APPLICANT CREWAVE Co., Ltd. EUT Type: Wireless LAN Network Adapter Card (PCMCIA) Tx Frequency: 2412 – 2472 MHz Max. RF Output Power 0.086 W EIRP (19.33 dBm) Trade Name/Model: CREWAVE CW-1100 FCC Classification: Spread Spectrum Transceiver (DSS) Application Type: Certification FCC Rule Part(s): § 2.1093; ET Docket 96.326 0.6510 W/kg Body SAR Maximum SAR: This wireless portable device has been shown to be compliant for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in ANSI/IEEE Std. C95.3-1992. (See Test Report) I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. NVLAP accreditation does not constitute any product endorsement by NVLAP or any agency of the United States Government. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. 201218648.PFT Test Report S/N: SAR.201218648.PFT SAR Measurement Report Test Dates: January 3-4, 2001 FCC Part 15.247 Certification © 2001 PCTEST CREWAVE FCC ID: PFTCW-1100 Wireless LAN PCMCIA Network Adapter Card Table of Contents 1.1 SCOPE...........................................................................................................1 2.1 INTRODUCTION...........................................................................................2 2.2 SAR Definition...................................................................................................2 3.1 SAR MEASUREMENT SET-UP.....................................................................3 4.1 ISOTROPIC E-FIELD PROBE SYSTEM.......................................................4 5.1 E-field PROBE CALIBRATION PROCESS..................................................5 6.1 PHANTOM AND EQUIVALENT TISSUES....................................................7 7.1 SYSTEM SPECIFICATIONS..........................................................................8 8.1 MEASUREMENT PROCESS.........................................................................9 9.1 TEST POSITION OF THE PHONE...............................................................10 10.1 ANSI/IEEE C95.1 - 1992 RF EXPOSURE LIMITS......................................11 11.1 MEASUREMENT UNCERTAINTIES..........................................................12 12.1 SAR TEST DATA SUMMARY...................................................................13 13.1 SAR TEST EQUIPMENT............................................................................14 14.1 CONCLUSION...........................................................................................15 APPENDIX A – SAR TEST PLOTS....................................................................16 APPENDIX B – SAR TEST SETUP PHOTOGRAPHS.......................................17 Test Report S/N: SAR.201218648.PFT SAR Measurement Report Test Dates: January 3-4, 2001 FCC Part 15.247 Certification © 2001 PCTEST CREWAVE FCC ID: PFTCW-1100 1 Wireless LAN Network Adapter Card (PCMCIA) SAR MEASUREMENT REPORT 1.1 SCOPE Environmental evaluation measurements of specific absorption rate 1 (SAR) distributions in simulated human tissues exposed to radiofrequency (RF) radiation from wireless portable devices for compliance with the rules and regulations of the U.S. Federal Communications Commission (FCC) and Industry Canada (IC). 2 Applicant Name: CREWAVE CO., LTD. Address: F7, Pureun Bldg. 28-1 Jamwon-dong, Seocho-gu Seoul, KOREA 137-030 Attention: Charlie Park • EUT Type: Wireless LAN Network Adapter Card (PCMCIA) • Trade Name: CREWAVE • Model(s): CW-1100 • FCC IDENTIFIER: PFTCW-1100 • Tx/Rx Frequency: 2412 – 2472 MHz • Application Type: Certification • FCC Classification: Spread Spectrum Transceiver (DSS) • FCC Rule Part(s): § 2.1093, Docket 96-326 • Modulation(s): Direct Sequence System (DSS) • Max. Output Power: 0.086 W EIRP (19.33 dBm) • Date(s) of Tests: January 3-4, 2001 • Place of Tests: PCTEST Engineering Lab. Columbia, MD, U.S.A. • Report Serial No.: SAR.201218648.PFT 1 Specific Absorption Rate (SAR) is a measure of the rate of energy absorption due to exposure to an RF transmitting source (wireless portable device). 2 IEEE/ANSI Std. C95.1-1992 limits are used to determine compliance with FCC ET-Docket 93-62. Fig. 1 SAR Test Setup Test Report S/N: SAR.201218648.PFT SAR Measurement Report Test Dates: January 3-4, 2001 FCC Part 15.247 Certification © 2001 PCTEST CREWAVE FCC ID: PFTCW-1100 2 Wireless LAN Network Adapter Card (PCMCIA) 2.1 INTRODUCTION The FCC has adopted the guidelines for evaluating the environmental effects of radio frequency radiation in ET Docket 93-62 on Aug. 6, 1996 to protect the public and workers from the potential hazards of RF emissions due to FCC-regulated portable devices.[1] The safety limits used for the environmental evaluation measurements are based on the criteria published by the American National Standards Institute (ANSI) for localized specific absorption rate (SAR) in IEEE/ANSI C95.1-1992 Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. (c) 1992 by the Institute of Electrical and Electronics Engineers, Inc., New York, New York…

Text truncated - open the document above for the full version.

Test Report S/N: SAR.201218648.PFT SAR Measurement Report Test Dates: January 3-4, 2001 FCC Part 15.247 Certification © 2001 PCTEST CREWAVE FCC ID: PFTCW-1100 16 Wireless LAN Network Adapter Card (PCMCIA) APPENDIX A – SAR TEST PLOTS Peak SAR Location © 2001 PCTEST Lab CREWAVE FCC ID: PFTCW-1100 (Model: CW-1000) NVLAP Lab Code: 100431-0 Wireless LAN PCMCIA Network Adapter Card (DSS) Body SAR File : c:/idx3/SYSTEM/SARMEAS3/data/Normal/00122802_ZOOM.VLT Start : 28-Dec-100 10:38:08 am End : 28-Dec-100 10:50:00 am Radio Type : CREWAVE Model Number : CW-1100 Serial Number : 1 Frequency : 2412 MHz Peak Trans. Pwr : 0.100 W Start Trans. Pwr: 0.100 W Antenna Type : Helical Antenna Posn. : Internal Phantom Type : Body Phantom Posn. : Abdomen Scan Type : ZOOM/SAR Probe Name : PCTEST Field Type : E Field Orientation : 0 Degrees Mixture Type = Muscle Mixture Dielectric Constant = 52.200 Mixture Conductivity = 2.850 Comment : CREWAVE WIRELESS DSS LAN CHANNEL 01 CREWAVE WIRELESS DSS LAN Robot : PCTEST Probe Offset = 0.25 cm Sensor Factor = 0.0108 Conversion Factor = 0.983 PCTEST Amplifier Channel Settings : 0.172 0.187 0.220 Max Location : X = -0.750, Y = 0.500, Z = 0.000 (cm) Value = 7.756 Measured Values (volts) = 6.836E-003 4.817E-003 2.811E-003 2.019E-003 1.456E-003 1.106E-003 9.056E-004 7.698E-004 7.583E-004 6.059E-004 6.067E-004 6.709E-004 7.242E-004 6.306E-004 6.445E-004 6.273E-004 6.359E-004 5.792E-004 6.282E-004 6.765E-004 6.021E-004 Calc. Voltage @ Surface (Vs) = 0.0107 Voltage @ 1.00 cm (Vt) = 0.0020 Ave. Voltage (Vs+Vt)/2 = 0.0064 Ave. SAR over 1 g (mW/g) = 0.5792 0.0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0 mW/g -1012345 Z centimeters SAR Scan File : 00122802_ZOOM Start : 28-Dec-100 10:38:08 am End : 28-Dec-100 10:50:00 am CREWAVE/CW-1100/1;2412MHz;W;Helical/Internal; Body/Abdomen;ZOOM/SAR;PCTEST/E Field/0 DegreesMuscle/52.200/2.850 File : 00122802_ZOOM Start : 28-Dec-100 10:38:08 am End : 28-Dec-100 10:50:00 am CREWAVE/CW-1100/1;2412MHz;W;Helical/Internal; Body/Abdomen;ZOOM/SAR;PCTEST/E Field/0 DegreesMuscle/52.200/2.850 0.706 0.636 0.565 0.495 0.425 0.354 0.284 0.214 0.144 0.073 File : 00122802_ZOOM Start : 28-Dec-100 10:38:08 am End : 28-Dec-100 10:50:00 am CREWAVE/CW-1100/1;2412MHz;W;Helical/Internal; Body/Abdomen;ZOOM/SAR;PCTEST/E Field/0 DegreesMuscle/52.200/2.850 0.706 0.636 0.565 0.495 0.425 0.354 0.284 0.214 0.144 0.073 File : c:/idx3/SYSTEM/SARMEAS3/data/Normal/00122803_ZOOM.VLT Start : 28-Dec-100 11:00:58 am End : 28-Dec-100 11:08:32 am Radio Type : CREWAVE Model Number : CW-1100 Serial Number : 1 Frequency : 2442 MHz Peak Trans. Pwr : 0.100 W Start Trans. Pwr: 0.100 W Antenna Type : Helical Antenna Posn. : Internal Phantom Type : Body Phantom Posn. : Abdomen Scan Type : ZOOM/SAR Probe Name : PCTEST Field Type : E Field Orientation : 0 Degrees Mixture Type = Muscle Mixture Dielectric Constant = 52.200 Mixture Conductivity = 2.850 Comment : CREWAVE WIRELESS DSS LAN CHANNEL 07 CREWAVE WIRELESS DSS LAN Robot : PCTEST Probe Offset = 0.25 cm Sensor Factor = 0.0108 Conversion Factor = 0.983 PCTEST Amplifier Channel Settings : 0.172 0.187 0.220 Max Location : X = 0.000, Y = 0.750, Z = 0.000 (cm) Value = 9.752 Measured Values (volts) = 7.676E-003 4.782E-003 3.083E-003 2.191E-003 1.671E-003 1.255E-003 1.085E-003 9.150E-004 8.194E-004 7.583E-004 7.963E-004 7.424E-004 7.230E-004 6.548E-004 6.779E-004 6.612E-004 7.822E-004 7.248E-004 7.370E-004 6.566E-004 6.405E-004 Calc. Voltage @ Surface (Vs) = 0.0121 Voltage @ 1.00 cm (Vt) = 0.0022 Ave. Voltage (Vs+Vt)/2 = 0.0072 Ave. SAR over 1 g (mW/g) = 0.6510 0.0 0.2 0.4 0.6 0.8 1.0 1.2 mW/g -1012345 Z centimeters SAR Scan File : 00122803_ZOOM Start : 28-Dec-100 11:00:58 am End : 28-Dec-100 11:08:32 am CREWAVE/CW-1100/1;2442MHz;W;Helical/Internal; Body/Abdomen;ZOOM/SAR;PCTEST/E Field/0 DegreesMuscle/52.200/2.850 File : 00122803_ZOOM Start : 28-Dec-100 11:00:58 am End : 28-Dec-100 11:08:32 am CREWAVE/CW-1100/1;2442MHz;W;Helical/Internal; Body/Abdomen;ZOOM/SAR;PCTEST/E Field/0 DegreesMuscle/52.200/2.850 0.888 0.800 0.712 0.624 0.536 0.449 0.361 0.273 0.185 0.097 File : 00122803_ZOOM Start : 28-Dec-100 11:00:58 am End : 28-Dec-100 11:08:32 am CREWAVE/CW-1100/1;2442MHz;W;Helical/Internal; Body/Abdomen;ZOOM/SAR;PCTEST/E Field/0 DegreesMuscle/52.200/2.850 0.888 0.800 0.712 0.624 0.536 0.449 0.361 0.273 0.185 0.097 File : c:/idx3/SYSTEM/SARMEAS3/data/Normal/00122804_ZOOM.VLT Start : 28-Dec-100 11:22:48 am End : 28-Dec-100 11:30:22 am Radio Type : CREWAVE Model Number : CW-1100 Serial Number : 1 Frequency : 2472 MHz Peak Trans. Pwr : 0.100 W Start Trans. Pwr: 0.100 W Antenna Type : Helical Antenna Posn. : Internal Phantom Type : Body Phantom Posn. : Abdomen Scan Type : ZOOM/SAR Probe Name : PCTEST Field Type : E Field Orientation : 0 Degrees Mixture Type = Muscle Mixture Dielectric Constant = 52.200 Mixture Conductivity = 2.850 Comment : CREWAVE WIRELESS DSS LAN CHANNEL 13 CREWAVE WIRELESS DSS LAN Robot : PCTEST Probe Offset = 0.25 cm Sensor Factor = 0.0108 Conversion Factor = 0.983 PCTEST Amplifier Channel Settings : 0.172 0.187 0.220 Max Location : X = -0.250, Y = 0.250, Z = 0.000 (cm) Value = 5.577 Measured Values (volts) = 4.777E-003 3.491E-003 2.232E-003 1.559E-003 1.245E-003 1.013E-003 8.009E-004 7.886E-004 7.945E-004 7.724E-004 7.143E-004 6.746E-004 6.766E-004 5.961E-004 6.223E-004 6.396E-004 6.985E-004 6.550E-004 6.081E-004 5.749E-004 6.252E-004 Calc. Voltage @ Surface (Vs) = 0.0070 Voltage @ 1.00 cm (Vt) = 0.0016 Ave. Voltage (Vs+Vt)/2 = 0.0043 Ave. SAR over 1 g (mW/g) = 0.3897 0.0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 mW/g -1012345 Z centimeters SAR Scan File : 00122804_ZOOM Start : 28-Dec-100 11:22:48 am End : 28-Dec-100 11:30:22 am CREWAVE/CW-1100/1;2472MHz;W;Helical/Internal; Body/Abdomen;ZOOM/SAR;PCTEST/E Field/0 DegreesMuscle/52.200/2.850 File : 00122804_ZOOM Start : 28-Dec-100 11:22:48 am End : 28-Dec-100 11:30:22 am CREWAVE/CW-1100/1;2472MHz;W;Helical/Internal; Body/Abdomen;ZOOM/SAR;PCTEST/E Field/0 DegreesMuscle/52.200/2.850 0.508 0.461 0.414 0.366 0.…

Text truncated - open the document above for the full version.

Test Report S/N: SAR.201218648.PFT SAR Measurement Report Test Dates: January 3-4, 2001 FCC Part 15.247 Certification © 2001 PCTEST CREWAVE FCC ID: PFTCW-1100 17 Wireless LAN Network Adapter Card (PCMCIA) APPENDIX B – SAR TEST SETUP PHOTOGRAPHS © 2001 PCTEST Lab CREWAVE FCC ID: PFTCW-1100 NVLAP Lab Code: 100431-0 Wireless LAN Network Adapter Card (PCMCIA) © 2001 PCTEST Lab CREWAVE FCC ID: PFTCW-1100 NVLAP Lab Code: 100431-0 Wireless LAN Network Adapter Card (PCMCIA) © 2001 PCTEST Lab CREWAVE FCC ID: PFTCW-1100 NVLAP Lab Code: 100431-0 Wireless LAN Network Adapter Card (PCMCIA)

© 2001 PCTEST Engineering Lab., Inc. PCTEST Engineering Laboratory, Inc. 66606660--B Dobbin Road B Dobbin Road •• Columbia, MD 21045 Columbia, MD 21045 •• U.S.A. U.S.A. TEL (410) 290TEL (410) 290--6652 6652 •• FAX (410) 290 FAX (410) 290--66546654 http://www.pctestlab.comhttp://www.pctestlab.com CERTIFICATE OF COMPLIANCE CREWAVE Co., Ltd. Dates of Tests: January 3-4, 2001 F7, Pureun Bldg. 28-1 Jamwon-dong, Seocho-gu Test Report S/N: 15.201218649. Seoul, KOREA 137-030 Test Site: PCTEST Lab, Columbia MD Attention: Charlie Park FCC ID PFTCW-1100 APPLICANT CREWAVE Co., Ltd. FCC Rule Part(s): § 15.247; ANSI C-63.4 (1992) Classification: Spread Spectrum Transceiver (DSS) Method/System: Direct Sequence System Equipment Type: Wireless LAN Network Adapter Card (PCMCIA) Max Output Power: 0.086 Watts Frequency Range: 2412 – 2472 MHz Trade/Model No(s).: CREWAVE CW-1100 This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C-63-4. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. 201218649.PFT FCC Part 15.247 Certification © 2001 PCTEST Engineering Laboratory, Inc. FCC Part 15.247 TABLE OF CONTENTS SCOPE 1 INTRODUCTION (SITE DESCRIPTION) 2 PRODUCT INFORMATION 3 DESCRIPTION OF TESTS A. CONDUCTED EMISSIONS 4 B. RADIATED EMISSIONS 5 C. RESTRICTED BANDS 6 D. ANTENNA REQUIREMENT 7 E. DIRECT SEQUENCE BANDWIDTH 8 F. MAXIMUM PEAK POWER OUTPUT 9 G. POWER DENSITY 10 RADIATED MEASUREMENTS (FUNDAMENTAL & HARMONICS) 11-13 FREQUENCY MEASUREMENTS (SPURIOUS) 14 PROCESSING GAIN 15-31 LIST OF TEST EQUIPMENT 32 CONCLUSION 33 APPENDIX A - LABELLING REQUIREMENTS 34-35 APPENDIX B - PLOTS OF EMISSIONS 36 APPENDIX C - PHOTOGRAPHS OF TEST SET-UP 37 APPENDIX D - EUT PHOTOGRAPHS 38 APPENDIX E - USER’S MANUAL 39 Test Report S/N: 15.201218649. FCC Part 15.247 Dates of Tests: January 3-4, 2001 Certification © 2001 PCTEST Lab CREWAVE FCC ID: PFTCW-1100 1 Wireless LAN Network Adapter Card (PCMCIA) MEASUREMENT REPORT Scope - Measurement and determination of electromagnetic emissions (EME) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission. §2.983(a) General Information Applicant Name: CREWAVE Co., Ltd. Address: F7, Pureun Bldg. 28-1 Jamwon-dong, Seocho-gu Seoul, KOREA 137-030 Attention: Charlie Park • FCC ID: PFTCW-1100 • Class: Spread Spectrum Transceiver (DSS) • Type: Wireless LAN Network Adapter Card (PCMCIA) • Freq. Range: 2412 – 2472 MHz • Method/System: Direct Sequence System (DSS) • Model No(s): CW-1100 • Max. RF Output Power: 0.086 W • Power Supply: 3.3VDC from PC • Rule Part(s): § 15.247 • Dates of Tests: January 3-4, 2001 • Place of Tests: PCTEST Lab, Columbia, MD U.S.A. • Test Report S/N: 15.201218649. Test Report S/N: 15.201218649. FCC Part 15.247 Dates of Tests: January 3-4, 2001 Certification © 2001 PCTEST Lab CREWAVE FCC ID: PFTCW-1100 2 Wireless LAN Network Adapter Card (PCMCIA) INTRODUCTION The measurement procedure described in American National Standard for Methods of Measurement of Radio- Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9kHz to 40GHz (ANSI C63.4-1992) and FCC Public Notice dated July 12, 1995 entitled “Guidance on Measurement for Direct Sequence Spread Spectrum Systems” were used in the measurement of CREWAVE Spread Spectrum wireless LAN network adapter card. These measurement tests were conducted at PCTEST Engineering Laboratory, Inc. facility in New Concept Business Park, Guilford Industrial Park, Columbia, Maryland. The site address is 6660-B Dobbin Road, Columbia, MD 21045. The test site is one of the highest points in the Columbia area with an elevation of 390 feet above mean sea level. The site coordinates are 39° 11'15" N latitude and 76° 49'38" W longitude. The facility is 1.5 miles North of the FCC laboratory, and the ambient signal and ambient signal strength are approximately equal to those of the FCC laboratory. There are no FM or TV transmitters within 15 miles of the site. The detailed description of the measurement facility was found to be in compliance with the requirements of § 2.948 according to ANSI C63.4 on October 19, 1992. PCTEST Location The map at right shows the location of the PCTEST Lab, its proximity to the FCC Lab, the Columbia vicinity area, the Baltimore- Washington International (BWI) airport, and the city of Baltimore, and the Washington, D.C. area. (see Figure1). Figure 1. Map of the Greater Baltimore and Metropolitan Washington, D.C. area. Test Report S/N: 15.201218649. FCC Part 15.247 Dates of Tests: January 3-4, 2001 Certification © 2001 PCTEST Lab CREWAVE FCC ID: PFTCW-1100 3 Wireless LAN Network Adapter Card (PCMCIA) PRODUCT INFORMATION Equipment Description: The Equipment under test (EUT) is the Crewave CW-1100 wireless LAN PCMCIA Card using spread spectrum direct sequence and time division duplex techniques. Frequency Range: 2412 – 2472 MHz Channels: 3 Channel Separation: 30.0 MHz Spread Spectrum Method: Direct Sequence (DBPSK modulation) Max RF Output Power: 0.086 Watts Antenna: Omni-directional Power Consumption: 3.3VDC from PC CH Rx/Tx Freq. (MHz) 01 2412 06 2442 11 2472 Test Report S/N: 15.201218649. FCC Part 15.247 Dates of Tests: January 3-4, 2001 Certification © 2001 PCTEST Lab CREWAVE FCC ID: PFTCW-1100 4 Wireless LAN Network Adapter Card (PCMCIA) Description of Tests Conducted Emissions The line-conducted facility is…

Text truncated - open the document above for the full version.

Test Report S/N: 15.201218649. FCC Part 15.247 Dates of Tests: January 3-4, 2001 Certification © 2001 PCTEST Lab CREWAVE FCC ID: PFTCW-1100 36 Wireless LAN Network Adapter Card (PCMCIA) Appendix B – Plots of Emissions

Test Report S/N: 15.201218649. FCC Part 15.247 Dates of Tests: January 3-4, 2001 Certification © 2001 PCTEST Lab CREWAVE FCC ID: PFTCW-1100 37 Wireless LAN Network Adapter Card (PCMCIA) Appendix C – Test Photographs © 2001 PCTEST Lab CREWAVE FCC ID: PFTCW-1100 NVLAP Lab Code: 100431-0 Wireless LAN Network Adapter Card (PCMCIA) © 2001 PCTEST Lab CREWAVE FCC ID: PFTCW-1100 NVLAP Lab Code: 100431-0 Wireless LAN Network Adapter Card (PCMCIA) © 2001 PCTEST Lab CREWAVE FCC ID: PFTCW-1100 NVLAP Lab Code: 100431-0 Wireless LAN Network Adapter Card (PCMCIA)
