PIZXG220012.4 GHz Analog Cordless Phone

1 Safety Instructions ------------------------------------------------------------------------------------------- 3 Getting Started ------------------------------------------------------------------------------------------------ 5 Desk Mounting ------------------------------------------------------------------------------------------------ 8 Wall Mounting ------------------------------------------------------------------------------------------------- 9 Cordless Telephone Operation -------------------------------------------------------------------------- 11 Preparing for Use ---------------------------------------------------------------------------------------- 11 NO LINE Indicator --------------------------------------------------------------------------------------- 11 Receiving Calls ------------------------------------------------------------------------------------------ 11 Placing Calls --------------------------------------------------------------------------------------------- 12 Headset Feature ---------------------------------------------------------------------------------------- 13 Redial Feature ------------------------------------------------------------------------------------------- 13 Caller ID System Operation ------------------------------------------------------------------------------ 14 Caller ID System ---------------------------------------------------------------------------------------- 14 Viewing Caller Information During Incoming Calls ------------------------------------------ 14 MSG WAITING (Message Waiting) ------------------------------------------------------------ 14 Call Waiting ------------------------------------------------------------------------------------------ 15 Voice Mail Function -------------------------------------------------------------------------------- 15 C-F (Forwarded Call) ------------------------------------------------------------------------------ 15 L-D-C (Long Distance Call) ---------------------------------------------------------------------- 15 Caller List ------------------------------------------------------------------------------------------------- 15 Viewing the Caller List ----------------------------------------------------------------------------- 16 Placing a Call From the Caller List ------------------------------------------------------------- 16 Editing the Caller List before Dialing ----------------------------------------------------------- 16 Saving the Name and Number in the Caller List into the DIRECTORY--------------- 17 Deleting All Records in the Caller List --------------------------------------------------------- 17 Selective Deleting in the Caller List ------------------------------------------------------------ 17 Name and Telephone Number DIRECTORY----------------------------------------------------- 17 Viewing the DIRECTORY------------------------------------------------------------------------- 17 Speed Viewing the DIRECTORY--------------------------------------------------------------- 18 Saving in the DIRECTORY----------------------------------------------------------------------- 18 PREFERRED CALLS ----------------------------------------------------------------------------- 18 BLOCKED CALLS ---------------------------------------------------------------------------------- 18 Editing a Name and Number in the DIRECTORY------------------------------------------- 19 Contents 2 Editing the Number in the DIRECTORYbefore Dialing ----------------------------------- 20 Placing Calls from the DIRECTORY----------------------------------------------------------- 21 Deleting All Records in the DIRECTORY----------------------------------------------------- 21 Selective Deleting in the DIRECTORY-------------------------------------------------------- 21 Function Operation ------------------------------------------------------------------------------------- 22 A. Language ---------------------------------------------------------------------------------------- 23 B. Silent On/Off ------------------------------------------------------------------------------------- 23 C. Time Set ------------------------------------------------------------------------------------------ 23 D. Ringer Volume ---------------------------------------------------------------------------------- 24 E. LCD Contrast ------------------------------------------------------------------------------------ 24 F.PBX Number ------------------------------------------------------------------------------------ 24 G. Flash Time --------------------------------------------------------------------------------------- 25 H. Pause Time -------------------------------------------------------------------------------------- 25 I. Voice Mail ---------------------------------------------------------------------------------------- 26 J. MSG Waiting (Message Waiting) ----------------------------------------------------------- 26 Telephone Keypad Characters ----------------------------------------------------------------------- 27 Security ------------------------------------------------------------------------------------------------------- 28 Recharging the Battery Pack ---------------------------------------------------------------------------- 29 Changing the Battery Pack ------------------------------------------------------------------------------- 30 Problem Solving -------------------------------------------------------------------------------------------- 31 Technical Information -------------------------------------------------------------------------------------- 32 FCC Requirements ----------------------------------------------------------------------------------------- 33 Warranty ------------------------------------------------------------------------------------------------------ 35 Wall Mounting Template ---------------------------------------------------------------------------------- 41 Contents 3 IMPORTANT SAFETYINSTRUCTIONS To reduce the risk …

Text truncated - open the document above for the full version.

Security System Your cordless telephone uses a digital coding security system to prevent unauthorized use of your telephone line by another nearby cordless telephone. The system has its own identifying signal created by microcomputers in both the BASE UNITand the HANDSET. Security Code This telephone has an internal security code with 65,536 possible combinations. Resetting Security Code and Channel Information Communication between the HANDSETand the BASE UNITmay not be possible in any of the following situations: 1.After a power failure. 2.After relocating the BASE UNITby disconnecting the AC ADAPTER. 3.After replacing the HANDSETBATTERYPACK. To reset, place the HANDSETon the BASE UNITfor 2 to 5 seconds. Multi-Channel Access Your cordless telephone lets you select a channel from the 40 frequencies available to transmit signals between the BASE UNITand HANDSET. When you notice interference from other cordless telephones, change to another channel by pressing the button on the HANDSET. DELETE SCAN 28 Security Battery Type Use the following type and size of BATTERYPACK: Cordless Telephone BATTERYPACK 3.6V, 600mAh U.S. Electronics Inc. Ni-MH Battery Pack: Model B655 This BATTERYPACK is available through: U.S. Electronics Service Center 105 Madison Avenue New York, NY10016 1-800-825-5208 NOTES:1.During a power interruption, the BASE UNIT does not operate, and a phone conversation cannot be made on the HANDSET. 2.A“beep” will be heard when the HANDSET is properly positioned in the BASE UNIT CHARGE CRADLE and charging. Securely positioning the HANDSET,KEYPAD face up,in the BASE UNIT will also prevent the HANDSET from failing. Recharging the Battery Pack The nickel metal hydride (Ni-MH) BATTERYPACK in the HANDSETcan be recharged many times using the built-in charger in the BASE UNIT. When the BATTLOW symbol appears on the LCD Screen, a “beep” sound will be heard every 10 seconds. This indicates that the BATTERYPACK needs to be recharged. Charge the BATTERYPACK at least once every 90 days of non-use to avoid battery failure. When the BATTERYPACK can no longer be charged, replacement of the BATTERYPACK will be necessary. The BATTERYPACK used in your telephone may develop a condition known as “MEMORY”. Once subjected to a regular short discharging routine, the BATTERYPACK assumes the discharging pattern it was subjected to. This is known as a “MEMORY” condition which causes rapid discharging thereby shortening the BATTERYPACK charge span. If you believe your BATTERYPACK has developed a “MEMORY” condition, do not charge the HANDSETuntil the BATTLOW symbol appears on the LCD Screen. When the BATTLOW symbol appears on the LCD Screen, charge the HANDSETfully for 12 hours. 29 Recharging the BATTERYPACK IMPORTANT In order to get maximum life from the HANDSET BATTERYPACK, be sure to charge the HANDSET for 12 hours before initial use. Changing the Battery Pack The BATTERYPACK provides power for the HANDSETof your cordless telephone. To Replace BATTERYPACK: 1.Remove the HANDSETBATTERYCOMPARTMENTCOVER by sliding it down. 2.Pull out the BATTERYPACK PLUG and remove the BATTERYPACK. 3.Plug the new BATTERYPACK into the BATTERYCONNECTOR. 4.Slide the HANDSETBATTERYCOMPARTMENTCOVER firmly into place in its closed position. 5.Before use, charge the new BATTERYPACK for 12 hours. ATTENTION: The telephone that you have purchased contains a rechargeable BATTERYPACK. The BATTERYPACK is recyclable. At the end of its useful life, under various state and local laws, it may be illegal to dispose of this BATTERYPACK into the municipal waste stream. Check with your local solid waste officials for details in your area for recycling options or proper disposal. 30 Changing the BATTERYPACK IMPORTANT In order to get maximum life from the HANDSET BATTERYPACK, be sure to charge the HANDSET for 12 hours before initial use. Problem Solving Section For your assistance, we have listed below a few common problems. Phone does not work, check the following: 1.BASE UNITis plugged into a power source. 2.HANDSETis charged. 3.TONE/PULSE Select switch is in the right position. 4.TELEPHONE LINE CORD is plugged into the TELEPHONE JACK. Range of phone limited, check the following: 1.BASE UNITis centrally located in your residence. 2.BASE UNITis not located near appliances. No dial tone, check the following: 1.TELEPHONE LINE CORD plugs are connected to the TELEPHONE JACK and TELEPHONE LINE CONNECTION JACK. 2.BASE UNITis plugged into a power source. 3.If you had a power failure or had unplugged the BASE UNIT, replace the HANDSETon the BASE UNITfor 2 to 5 seconds to reset the system. Received signal flutters or fades, check the following: 1.BATTERYPACK in the HANDSETis fully charged. 2.HANDSETis not too far from the BASE UNIT. Interference on reception, check the following: 1.Noise may be picked up from electrical products in the home or electrical storms. Generally, this noise is a minor annoyance and should not be interpreted as a defect in your system. (See Technical Information on page 32.) 2.Choose an alternate channel using the button on the HANDSET. 3.Do not use this telephone within 20 ft. of a microwave oven while it is working, as you may experience interference. This is a normal occurrence with 2.4 GHz phones and should not be interpreted as a defect in the product. Long Distance “L-D-C” indicator is not ON when receiving a long distance call, check the following: 1.Your local telephone company can provide the Area Code on an incoming long distance call. Excess static, check the following: 1.Check to see that the ANTENNAis not touching another metal object. If after pressing the button, you receive three “beeps” and no dial tone, check the following: 1.BASE UNITis plugged into a power source. 2.If you had a power failure or had unplugged the BASE UNIT, replace the HANDSETon the BASE UNITfor 2 to 5 seconds to reset the system. NOTE:If none of telephones in the house are working, disconnect one set at a time to verify that none of the phone…

Text truncated - open the document above for the full version.

CIDMATE International Technology IMPORTANT TO ENSURE YOUR PHONE CHARGES PROPERLY ALWAYS CHARGE WITH THE KEYPAD FACE UP MODEL NO.: XG2200 FCC ID: PIZXG22001 THIS DEVICE COMPLIES WITH PART 15 OF FCC RULES. OPERATION IS SUBJECTED TO THE FOLLOWING CONDITIONS:1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. TELEPHONE EQUIPMENT FOR SERVICE PLEASE CALL 1-866-466-9228 MODEL NO. XG2200 0307000001 S/NO.: R 2002627 CONFORMS TOANSI/UL STD, 1950 US CM QC 1A ACC HAC Licensed under U.S. Patent No. 5,263,084 FCC ID:PIZXG22001 COMPLIES WITH PART 68 FCC RULES, FCC REG. NO.: US: 6RUW900BXG2200 USOC: RJ11C REN: 0.0B PRIVACY OF COMMUNICATIONS MAY NOT BE ENSURED WHEN USING THIS PHONE MADE IN CHINA MODEL NO. XG2200 CHARGEIN USE PAGE NOTE PRIOR TO INITIAL USE OR WHEN YOU HEAR A BEEP SOUND WHILE THE BATT LOW SYMBOL APPEARS, RECHARGE THE HANDSET BY PLACING IT IN ITS CRADLE IN THE BASE UNIT OVERNIGHT. IF HANDSET LOSES DIAL TONE, PLACE HANDSET IN BASE FOR 5 SECONDS. THIS WILL RESET SECURITY CODE AND RESTORE DIAL TONE. TO ALLOW PROPER CHARGING, CLEAN THE BATTERY CONTACTS ON BOTH THE HANDSET AND THE BASE UNIT ONCE A MONTH. XG2200 LABELS' LOCATION DESIGNED BY: DENG LING DATE: Feb./24/03

2400bfcc.SCH-1 - Sat Jan 26 09:23:48 2002 2400hfcc.SCH-1 - Sat Jan 26 09:21:12 2002 XG2200B1A0 ECO-00.sch-1 - Wed Feb 12 16:23:22 2003 XG2200H1K0 ECO-00.sch-1 - Wed Feb 12 16:27:50 2003

Test Report ------------------------------------------------------------------------------ 1/30 Report No.: C5015310, 2.4GHz Analog Cordless Phone, FCC Part 15 Class B Training Research Co., Ltd. TEL:886-2-26935155, Fax:886-2-26934440 MEASUREMENT REPORT of CORDLESS TELEPHONE Applicant : CIDMATE International Technology Inc. Model No. : XG2200xx, XG2201xx (x could be numbers or alphabets) EUT : 2.4GHz Analog Cordless Phone FCC ID : PIZXG22001 Report No. : C5015310 Test by : Training Research Co., Ltd. TEL : 886-2-26935155 FAX : 886-2-26934440 No. 255, Nan-yang Street, Shijr, Taipei Hsien 221, Taiwan, R.O.C. Test Report ------------------------------------------------------------------------------ 2/30 Report No.: C5015310, 2.4GHz Analog Cordless Phone, FCC Part 15 Class B Training Research Co., Ltd. TEL:886-2-26935155, Fax:886-2-26934440 CERTIFICATION We here by verify that: The test data, data evaluation, test procedures and equipment configurations shown in this report were made mainly in accordance with the procedures given in ANSI C63.4 (1992) as a reference. All test were conducted by Training Research Co., Ltd., No. 255, Nan-yang Street, Shijr, Taipei Hsien 221, Taiwan, R.O.C. Also, we attest to the accuracy of each. We further submit that the energy emitted by the sample EUT tested as described in the report is in compliance with the technical requirements set forth in the FCC Rules Part 15 Subpart C Section 15.249. Applicant : CIDMATE International Technology Inc. Product Name : 2.4Hz Analog Cordless Phone Model No. : XG2200xx, XG2201xx FCC ID : PIZXG22001 Report No. : C5015310 Test Date : January 29, 2003 Prepared by: Approved by: JACK TSAI FRANK TSAI Test by : Training Research Co., Ltd. TEL : 886-2-26935155 FAX : 886-2-26934440 No. 255, Nan-yang Street, Shijr, Taipei Hsien 221, Taiwan, R.O.C. Test Report ------------------------------------------------------------------------------ 3/30 Report No.: C5015310, 2.4GHz Analog Cordless Phone, FCC Part 15 Class B Training Research Co., Ltd. TEL:886-2-26935155, Fax:886-2-26934440 Tables of Contents I. GENERAL 1.1 Introduction .................................................................................................................. 5 1.2 Description of EUT ...................................................................................................... 5 1.3 Description of Support Equipment ................................................................................ 6 1.4 Configuration of System Under Test .............................................................................. 7 1.5 Test Procedure ............................................................................................................. 8 1.6 Location of the Test Site ............................................................................................... 8 1.7 General Test Condition ................................................................................................. 8 II. Conducted Emissions Measurements 2.1 Test Condition & Setup ............................................................................................... 9 2.2 List of Test Instruments ................................................................................................ 9 2.3 Test Result of Conducted Emissions ............................................................................ 10 III. Radiated Emissions Measurements 3.1 Test Condition & Setup .............................................................................................. 13 3.2 List of Test Instruments ............................................................................................... 13 3.3 Test Result of Radiated Emissions ............................................................................... 15 3.4 Test Result of Spurious Radiated Emissions ................................................................. 16 IV. Verify Frequencies and Channels ............................................................................... 24 Appendix A .......................................................................................................................... 25 Appendix B .......................................................................................................................... 28 Test Report ------------------------------------------------------------------------------ 4/30 Report No.: C5015310, 2.4GHz Analog Cordless Phone, FCC Part 15 Class B Training Research Co., Ltd. TEL:886-2-26935155, Fax:886-2-26934440 TABLES Table 1 Power Line Conducted Emissions [Channel 01]................................................... 10 Table 2 Power Line Conducted Emissions [Channel 40]................................................... 11 Table 3 Power Line Conducted Emissions [Charging mode]............................................. 12 Table 4 Fundamental Emissions ...................................................................................... 15 Table 5 Radiated Emissions [Base Channel 01 Horizontal 30MHz to1GHz]...................... 16 Table 6 Radiated Emissions [Base Channel 01 Vertical 30MHz to1GHz] ...................... 16 Table 7 Radiated Emissions [Base Channel 01 Horizontal 1GHz to 25GHz] .................... 17 Table 8 Radiated Emissions [Base Channel 01 Vertical 1GHz to 25GHz] ....................... 17 Table 9 Radiated Emissions [Base Channel 40 Horizontal 30MHz to 1GHz] .................. 18 Table 10 Radiated Emissions [Base Channel 40 Vertical 30MHz to 1GHz]........................ 18 Table 11 Radiated Emissions [Base Channel 40 Horizontal 1GHz to 25GHz] ................... 19 Table 12 Radiated Emissions [Base Channel 40 Vertical 1GHz to 25GHz] ...................... 19 Table 13 Radiated Emissions [Handset Channel 01 Horizontal 30MHz to 1GHz]............... 20 Table 14 Radiated Emissions [Handset Channel 01 Vertical 30MHz to 1GHz]................... 20 Table 15 Radiated Emissions [Handset Channel 01 Horizontal 1GHz to 2…

Text truncated - open the document above for the full version.

Test Report ------------------------------------------------------------------------------ 25/30 Report No.: C5015310, 2.4GHz Analog Cordless Phone, FCC Part 15 Class B Training Research Co., Ltd. TEL:886-2-26935155, Fax:886-2-26934440 Appendix A The antenna of the device is screwed inside the device. The user can not remove it freely without any tools from outside the device. This is comply with the FCC rules part 15.203 Test Report ------------------------------------------------------------------------------ 26/30 Report No.: C5015310, 2.4GHz Analog Cordless Phone, FCC Part 15 Class B Training Research Co., Ltd. TEL:886-2-26935155, Fax:886-2-26934440 Test Report ------------------------------------------------------------------------------ 27/30 Report No.: C5015310, 2.4GHz Analog Cordless Phone, FCC Part 15 Class B Training Research Co., Ltd. TEL:886-2-26935155, Fax:886-2-26934440 Test Report ------------------------------------------------------------------------------ 28/30 Report No.: C5015310, 2.4GHz Analog Cordless Phone, FCC Part 15 Class B Training Research Co., Ltd. TEL:886-2-26935155, Fax:886-2-26934440 Appendix B § 15.245 (b)(3) Emissions radiated outside of the specified frequency bands, except for harmonics, shall be attenuated by at least 50dB below the level of the fundamental or to the general radiated emission limits in §15.209, whichever is the lesser attenuation. See as next page. Test Report ------------------------------------------------------------------------------ 29/30 Report No.: C5015310, 2.4GHz Analog Cordless Phone, FCC Part 15 Class B Training Research Co., Ltd. TEL:886-2-26935155, Fax:886-2-26934440 Base Channel 1 Band edge: 79.65dBV/m (Peak Amplitude) – 31.83dB = 47.82dBV/m < 53.94dBV/m Test Report ------------------------------------------------------------------------------ 30/30 Report No.: C5015310, 2.4GHz Analog Cordless Phone, FCC Part 15 Class B Training Research Co., Ltd. TEL:886-2-26935155, Fax:886-2-26934440 Handset Channel 40 Band edge: 75.37dBV/m (Peak Amplitude) – 26.67dB = 48.70dBV/m < 53.94dBV/m

Test Setup Photos ------------------------------------------------------------------------- 1/3 FCC ID: PIZXG22001 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Conducted Test Setup Placement: (Operating mode) Front View of the Test Configuration Rear View of the Test Configuration Test Setup Photos ------------------------------------------------------------------------- 2/3 FCC ID: PIZXG22001 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Radiated Test Setup Placement: (BASE) Front View of the Test Configuration of Base Rear View of the Test Configuration of Base Test Setup Photos ------------------------------------------------------------------------- 3/3 FCC ID: PIZXG22001 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Radiated Test Setup Placement: (Handset) Front View of the Test Configuration of X-axis Front View of the Test Configuration of Y-axis
