M660 GPRS Module User Manual Shenzhen Neoway Technology Co.,Ltd. Enjoy your wireless life Shenzhen Neoway Technology Co., Ltd. Page 2 of 32 Copyright Copyright © 2008 Neoway Technology All rights reserved. is a trade mark of Shenzhen Neoway Technology Co., Ltd. Notice This document is intended for the customer engineers. This document is subject to change without any notice. No responsibility is assumed by Neoway Technology for the use of this document. Neoway Technology always provides the best supports. For pricing, ordering information and delivery please contact: [email protected] For any technical support requests please contact: [email protected] For further information please visit: http://www.neoway.com.cn Shenzhen Neoway Technology Co., Ltd. Page 3 of 32 Contents 1. Introduction ................................................................................................................................ 6 2. General Description ................................................................................................................... 6 3. Simplified Block Diagram ......................................................................................................... 6 4. Key Features ............................................................................................................................... 7 5. Product Specifications ............................................................................................................... 8 5.1 Variants ................................................................................................................................. 8 5.2 Dimension & Package ........................................................................................................... 8 5.3 Pin Description ...................................................................................................................... 9 5.4 PCB foot print ..................................................................................................................... 10 6. Application Interface ............................................................................................................... 11 6.1 Power Supply Requirements ............................................................................................... 11 6.1.1 Power Supply Basic Design Rules ........................................................................ 11 6.1.2 Extended Design Rules for Power Supply ............................................................ 13 6.2 ON/OFF Procedure ............................................................................................................. 15 6.2.1 Turning on the module .......................................................................................... 16 6.2.2 Turning off the module ......................................................................................... 16 6.2.3 RESET .................................................................................................................. 17 6.2.4 VCCIO .................................................................................................................. 17 6.3 UART .................................................................................................................................. 18 6.3.1 Basic Descriptions of UART ................................................................................. 18 6.3.2 Level Translators for UART .................................................................................. 18 6.4 Sleep mode .......................................................................................................................... 20 6.4.1 DTR ....................................................................................................................... 20 6.4.2 RING ..................................................................................................................... 21 6.5 SIM interface ...................................................................................................................... 21 6.6 Running LED Indicator ....................................................................................................... 23 6.7 Audio Interface ................................................................................................................... 24 6.8 Antenna Interface ................................................................................................................ 26 7. Mounting the Module onto the Application Board ............................................................... 28 8. Package ..................................................................................................................................... 29 Shenzhen Neoway Technology Co., Ltd. Page 4 of 32 9. Terms and Abbreviations ......................................................................................................... 29 Shenzhen Neoway Technology Co., Ltd. Page 5 of 32 Document History Revision History Version Remarks Date Issue V3.0 Modified Version 2013-9 V3.1 Change receive sensitivity index 2013-10 V3.2 Change 24pin definition 2013-11 Shenzhen Neoway Technology Co., Ltd. Page 6 of 32 1. Introduction This document describes the hardware features of M660, and guides for the relevant application design. 2. General Description With the ultra-compact design, M660 is intended to be used in a wide range of applications, including industrial and consumer devices. M660 is a GSM/GPRS module with EDGE of downlink. It features with voice, SMS, and data services. 3. Simplified Block Diagram Figure 1 M660 Block Diagram Shenzhen Neoway Technology Co., Ltd. Page 7 of 32 4. Key Features Table1 M660 Key Features Feature Implementation Frequency Bands 850/900/1800/1900 MHz Quad-band Compliant with GSM/GPRS Phase2/2+ Sensitivity < -107dBm Transmit Power 850/900 Class4(2W) 1800/1900 Class1(1W) AT GSM07.07 Extended AT commands Audio CODEC FR、…

Text truncated - open the document above for the full version.

Request for Modular Approval FCC ID: PJ7-123X Item Requirements EUT 1 Have its own RF shielding this module has its own RF shielding， see EUT photo. 2 Have buffered modulation/data inputs (if such inputs are provided) The module has buffered modulation / data inputs. it is integrated in chip MT6260SA（transceiver embedded) and RF7176(power IC embedded).. 3 Have its own power supply regulation The module has its own power supply regulation. it is integrated in chip MT6260SA. 4 Meet the antenna requirements of section 15.203 and 15.204(c). No applicable to the licensed module. 5 Demonstrate compliance in a stand-alone configuration The module has been testede in stand-alone configuration. The EUT was tested in a stand-alone configuration via a USB extender。please see section photographys of test configuration in the test report ，the EUT was plugged in this extender. 6 The licensed module must have a FCC ID label on the module itself. That FCC ID label must be visible through a window on the final device or it must be visible when an access panel, door or cover is easily removed. If not, a second label must be placed on the outside of the final device that contains the following text: Contains “FCC ID” The module is labeled with its own FCC ID. Please see exhibition Label Sample for the FCC ID of this module.And also in the exhibition Users Manual, there are instructions give to the OEM on how to label the end product. FCC ID: PJ7-123X 7 The module must comply with all specific rules applicable to the transmitter. The grantee must provide comprehensive instructions to explain compliance requirements. This module transmitter complies with applicable transmitter requirements. The required FCC rule has been fulfilled and all the instructions for maintain compliance has been clearly stated in the User Manual. 8 The module transmitter must comply with any applicable RF exposure requirements. The module transmitter complies with the applicable RF exposure requirements. Please refer to the exhibition RF Exposure for the requirements. Thank you for your attention to this matter. Xinhui Lin Technical Coordinator Certification

Shenzhen Neoway Technology Co.,Ltd. Dec. 16, 2013 Federal Communications Commission Authorization and Evaluation Division FCC ID：PJ7-123X Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the applicant hereby requests confidential treatment of information applied this application as outlined below: 1. Block Diagram CONF APPENDIX PJ7-123X _Block Diagram.pdf 2. Circuit Diagram CONF APPENDIX PJ7-123X _Schematics.pdf 3. Operational Description CONF APPENDIX PJ7-123X _Operational description.pdf 4. Tune up procedure CONF APPENDIX PJ7-123X _Tune up procedure.pdf 5. BOM List CONF APPENDIX PJ7-123X_BOM List.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application Sincerely, Signature Name/Title: Xinhui Lin / Hardware Testing Manager Applicant: Shenzhen Neoway Technology Co.,Ltd. ADDRESS: 4F-2#,Lianjian Science & Industry Park,Huarong Road,Dalang,Bao'an District,Shenzhen.P.R.C. TEL: +86 18719287694 FAX: +86 755-2967256 Email: [email protected]

External Photo

Internal photo

Report No. :SET2013-08559 CCIC-SET/T (00) Page 1 of 9 RF Exposure Evaluation Report Report No.: SET2013-08559 Product: GPRS Module FCC ID: PJ7-123X Brand Name: neoway Applicant: Shenzhen Neoway Technology Co.,Ltd. Address： 4F-2#,Lianjian Science & Industry Park,Huarong Park, Futian District, Shenzhen, China District, Shenzhen Road,Dalang,Bao'an District,Shenzhen.P.R.C. Issued by: CCIC-SET Lab Location: Electronic Testing Building, Shahe Road, Xili, Nanshan District, Shenzhen, 518055, P. R. China Tel: 86 755 26627338 Fax: 86 755 26627238 This test report consists of 9 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CCIC-SET. The test results in the report only apply to the tested sample. The test report shall be invalid without all the signatures of testing engineers, reviewer and approver. Any objections must be raised to CCIC-SET within 15 days since the date when the report is received. It will not be taken into consideration beyond this limit. Report No. :SET2013-08559 CCIC-SET/T (00) Page 2 of 9 Test Report Product ................................. : GPRS Module Model No. ............................ : M660 Applicant .............................. : Shenzhen Neoway Technology Co.,Ltd. Applicant Address ............... : 4F-2#,Lianjian Science & Industry Park,Huarong Road,Dalang,Bao'an District,Shenzhen.P.R.C. Manufacturer ........................ : Shenzhen Eternity Technology Co.,Ltd Manufacturer Address ......... : Block A2,Yingzhan Industrial Zone, Longtian Community, KengziOffice,Pingshan New District,Shenzhen,Guangdong Province,P.R.China Test Standards ..................... : ANSI Std C95.1-1992: Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3KHz-300GHz.(IEEE Std C95.1-1992) RSS-102: Radio Frequency Exposure Compliance of Radiocommunication Apparatus （All Frequency Bands （Issue 4 of March 2010）） Test Result ............................ : Pass Tested by ............................. : 2013.12.11 Lu Lei, Test Engineer Reviewed by ......................... : 2013.12.11 Shuangwen Zhang, Senior Engineer Approved by ......................... : 2013.12.11 Wu Li’an, Manager Report No. :SET2013-08559 CCIC-SET/T (00) Page 3 of 9 Table of Contents Test Report ................................................................................................................................. 2 1 .General Information ................................................................................................................. 4 1.1 Description of EUT ............................................................................................................... 4 1.2 Test specifications ................................................................................................................. 4 2 RF Exposure Limit Introduction ........................................................................................... 5 3 Conducted RF Output Power（Unit：dBm） ..................................................................... 7 4 RF Exposure Evaluation ....................................................................................................... 8 Report No. :SET2013-08559 CCIC-SET/T (00) Page 4 of 9 1 .General Information 1.1 Description of EUT Product Feature & Specification DUT Type GPRS Module Model Name M660 FCC ID PJ7-123X Tx Frequency GSM850: 824.2 MHz ~ 848.8 MHz GSM1900: 1850.2 MHz ~ 1909.8MHz Rx Frequency GSM850: 869.2 MHz ~ 893.8 MHz GSM1900: 1930.2 MHz ~ 1989.8 MHz Antenna Type Refer to Remark 2 and 3 HW Version 1230 V1.0 SW Version M660_1230_LQS13000_V009B Test of Modulation GMSK Remark 1: The above DUT's information was declared by manufacturer. Please refer to the specifications or user's manual for more detailed description. Remark 2: The external antenna must be matched properly to achieve best performance regarding radiated power, DC-power consumption, modulation accuracy and harmonic suppression. Antenna matching networks are not included on the M660 Module PCB and should be placed in the host application. Remark 3: An antenna was used via a UHL Type Connector, whose maximum antenna gain was 2dBi for Band 850 and 2dBi for Band 1900. 1.2 Test specifications ANSI Std C95.1-1992 Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3KHz-300GHz.(IEEE Std C95.1-1992) Report No. :SET2013-08559 CCIC-SET/T (00) Page 5 of 9 RSS-102 Radio Frequency Exposure Compliance of Radiocommunication Apparatus （All Frequency Bands （Issue 4 of March 2010）） KDB 447498 D01V05 General RF Exposure Guidance 2 RF Exposure Limit Introduction An estimation of MPE in this application for product is used to ensure if it complies to the rules of the standard in the regulation list above. Maximum permissible exposure (MPE) refers to the RF energy that is acceptable for human exposure. It is broken down into two categories, Occupational/controlled and General population/uncontrolled. Occupational/controlled limits apply in situations in which persons are exposed as a consequence of their employment provided those persons are fully aware of the potential for exposure and can exercise control over their exposure. Limits for occupational/controlled exposure also apply in situations when an individual is transient through a location where occupational/controlled limits apply provided he or she is made aware of the potential for exposure. General population/uncontrolled exposures apply in situations in which the general public may be exposed, or in which persons that are exposed as a consequence of their employment may not be fully aware of the potential for exposure or can not exercise control over their exposure. We analysis if it comply with the limits for General population/uncontrolled exposure. The FCC’s MPE limits for f…

Text truncated - open the document above for the full version.

Report No.：SET2013-07917 CCIC-SET/T（00） Page 1 of 58 RF TEST REPORT Report No.： SET2013-07917 Product： GPRS Module FCC ID: PJ7-123X Model No.： M660 Applicant： Shenzhen Neoway Technology Co.,Ltd. Address： 4F-2#,Lianjian Science & Industry Park,Huarong Road,Dalang,Bao'an District,Shenzhen.P.R.C. Issued by： CCIC-SET Lab Location： Electronic Testing Building, Shahe Road，Xili, Nanshan District, Shenzhen China Tel：86 755 26627338 Fax：86 755 26627238 This test report consists of 58 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CCIC-SET. The test results in the report only apply to the tested sample. The test report shall be invalid without all the signatures of testing engineers, reviewer and approver. Any objections must be raised to CCIC-SET within 15 days since the date when the report is received. It will not be taken into consideration beyond this limit. Report No.：SET2013-07917 CCIC-SET/T（00） Page 2 of 58 Test Report Product ................................. : GPRS Module Brand Name .......................... : neoway Trade Name ........................... : neoway Applicant ............................... : Shenzhen Neoway Technology Co.,Ltd. Applicant Address ............... : 4F-2#,Lianjian Science & Industry Park,Huarong Road,Dalang,Bao'an District,Shenzhen.P.R.C. Manufacturer ........................ : Shenzhen Eternity Technology Co.,Ltd Manufacturer Address ......... : Block A2,Yingzhan Industrial Zone, Longtian Community, KengziOffice,Pingshan New District,Shenzhen,Guangdong Province,P.R.China Test Standards ..................... : 47 CFR Part 2(10-1-12 Edition) Frequency Allocations and Radio Treaty Matters; General Rules and Regulations 47 CFR Part 22(10-1-12 Edition) Public Mobile Services 47 CFR Part 24(10-1-12 Edition)Personal Communications Services Test Result ............................ : PASS Tested by ............................. : 2013.12.11 Lu Lei，Test Engineer Reviewed by ......................... : 2013.12.11 Shuangwen Zhang, Senior Egineer Product.............................: 2013.12.11 Wu Li’an，Manager Report No.：SET2013-07917 CCIC-SET/T（00） Page 3 of 58 Table of Contents 1. GENERAL INFORMATION .................................................................................................... 4 1.1 EUT Description ......................................................................................................................... 4 1.2 Test Standards and Results ........................................................................................................ 5 1.3 Facilities and Accreditations ...................................................................................................... 6 2. 47 CFR PART 2, PART 22H & 24E REQUIREMENTS ........................................................ 7 2.1 Conducted RF Output Power .................................................................................................... 7 2.2 Peak to Average Radio ............................................................................................................. 15 2.3 99% Occupied Bandwidth ....................................................................................................... 17 2.4 Frequency Stability ................................................................................................................... 22 2.5 Conducted Out of Band Emissions ......................................................................................... 25 2.6 Band Edge ................................................................................................................................. 32 2.7 Transmitter Radiated Power (EIRP/ERP) ............................................................................. 35 2.8 Radiated Out of Band Emissions ............................................................................................ 40 ANNEX A ACCREDITATION CERTIFICATE ........................................................................ 54 ANNEX B PHOTOGRAPHS OF THE EUT .............................................................................. 55 ANNEX C PHOTOGRAPHS OF THE TEST SETUP .............................................................. 57 Change History Issue Date Reason for change 1.0 Dec.11, 2013 First edition Report No.：SET2013-07917 CCIC-SET/T（00） Page 4 of 58 1. GENERAL INFORMATION 1.1 EUT Description EUT Type.............................. : GPRS Module Serial No. .............................. : (n.a, marked #1 by test site) Hardware Version ................. : 1230 V1.0 Software Version ................... M660_1230_LQS13000_V009B Frequency Range .................. : GSM 850MHz: Tx: 824.20 - 848.80MHz (at intervals of 200kHz); Rx: 869.20 - 893.80MHz (at intervals of 200kHz) GSM 1900MHz: Tx: 1850.20 - 1909.80MHz (at intervals of 200kHz); Rx: 1930.20 - 1989.80MHz (at intervals of 200kHz) Modulation Type ................... : GSM,GPRS Mode with GMSK Modulation Multislot Class ...................... : GPRS: Multislot Class12 Antenna Type ........................ : GSM glue stick antenna Emission Designators ........... : GSM 850:244KGXW,GSM 1900:244KGXW GPRS850:240KGXW,GPRS1900:244KGXW Note 1: The transmitter (Tx) frequency arrangement of the Cellular 850MHz band used by the EUT can be represented with the formula F(nq)=824.2+0.2*(n-128), 128<=n<=251; the lowest, middle, highest channel numbers (ARFCHs) used and tested in this report are separately 128 (824.2MHz), 190 (836.6MHz) and 251 (848.8MHz). Note 2: The transmitter (Tx) frequency arrangement of the PCS 1900MHz band used by the EUT can be represented with the formula F(n)=1850.2+0.2*(n-512), 512<=n<=810; the lowest, middle and highest channel numbers (ARFCHs) used and tested in this report are separately 512 (1850.2MHz), 661 (1880.0MHz) and 810 (1909.…

Text truncated - open the document above for the full version.

Radiated Emission Test setup photos 30M~18G 18G~20G Conducted Test setup photo
