PLJWS222Weather Station Receiver

BUTTON PLACEMENT 1 6 78 9 2 3 4 5 MIN/-/MIN: shows minimum temperature; adjusts clock, alarm, and temperature alarmvalues C/F: changes House Code and Channel Code; selects °C or °F SET: activates SET function Battery CompartmentLCD Screen ALARM /(°C/°F): toggles between °C and °F, 12 and 24 hour format, and alarm ON and OFF;disables temperature alarms CHN: scrolls through local and remote channels (1 to 4);HOUR/+/MAX: shows maximum temperature; adjusts clock, alarm, and temperature alarmvaluesMODE/SNOOZE: scrolls through the clock, alarm, and (upper & lower) temperaturealarm modes; snooze for alarm GETTING STARTED Remove battery cover Set up the transmitter(s) setting up the receiver before Remove battery cover 2 AA size batteries (included) 2 AA size batteries (included) setting up the transmitter 1 * 1 The temperature will appear on the LCD screen House code will blink for 8 seconds 22334 56789 10 Select House code (1-15) by pressing C/F Press SET Press SET Channel code will blink for 8 seconds Select Channel code (1-4) by pressing C/F * If you have multiple transmitters for a single receiver,set each transmitter to the House code same * If you have multiple transmitters for a single receiver,set each transmitter to a Channel code different Min and Max TemperatureTemperature Trend WS222 ReceiverWT440 Remote Transmitter TEMPERATURE DISPLAY A B * The trend indicator shows the trend of the temperaturein the past half-hour interval.Example:The following indicates that thetemperature is rising. Arrow Indicator Rising Steady Falling Trend WS222 + WT440 Wireless Weather Station OWNER’S MANUAL setting up the receiver Synchronized!!! 1 1 1 223 4 WIRELESS TRANSMISSION Automatic Learn Function: Manual Learn Function (Remote Signal Search): The learn function starts automatically and runs for approximately3 minutes when batteries are first installed in the receiver. Press and hold for 3 seconds to start. CHN If a new remote transmitter is added or if signal is lost (outdoor readouton the receiver is blinking), the learn function must be executed again. Within the 3 minutes, the receiver will pick up the temperaturesignal from the remote transmitter and display the reading. Unit will beep to indicate thatlearn function has started.Channel symbol will blink andunit will continue to beep aseach remote transmitter is detected. 1 Within 3 minutes, the temperature reading of the remote transmitterwill display on the receiver. WS222 receiver WT440 transmitter 10 Battery Cover 11 Wall Mount Bracket & Table Stand 11 SET C/F - AA 1 .5V + - AA 1 .5V + 5 9 4 7 6 8 10 11 2 Insert batteries into compartment,observing proper polarity Insert batteries into compartment,observing proper polarity; replace cover Select temperature display in C or F by pressing C/F °° Replace battery cover Congratulations on your purchase of thisweather station set, WS222+WT440.Please take the time to read andunderstand this manual so you can beginto enjoy the convenience and features thisproduct has to offer.Main Display Unit WS222:* clock and alarm clock function* local temperature display* receives and displays temperature readings from up to 4 remotetransmitters via RF technology of 433MHz * minimum/maximum temperature memory* temperature trend indicator* local/remote temperature alarms* day/night icon* user-selectable C or F* battery type :2xAA °° FEATURES Remote Transmitter WT440:* drip-proof design with LCD screen* temperature display in user-selectable Cor F * transmission range: up to 40 metres in open area * table stand or wall mountable* battery type :2xAA °° SET C/F - AA 1 .5V + - AA 1 .5V + 11 10 2 11 12 3 1 12 1 1 1 8 9 6 7 Press intheClockmodetodisplay the minimum temperatureThe MIN symbol will appear. MIN . To return to normal temperaturedisplay, press again. MIN To return to normal temperaturedisplay, press again. MAX Press inClockmodetodisplay the maximum temperature.The MAX symbol will appear. MAX NOTE: Min/Max readings are automatically cleared daily at 00:00 Press to view the minimum or maximum temperatures of the local and remote channels 1 to 4. CHN 1 1 LOW BATTERY INDICATION Replace the batteries when the Low Battery Indication lights up onthe LCD screen by the local (indoor) temperature display. NOTE: After replacing the batteries, you will need to perform the Setupand Learn Function procedures again. Refer to the GETTING STARTEDand WIRELESS TRANSMISSION sections. Replace the batteries when the Low Battery Indication lights up onthe bottom-left corner of the LCD screen on the WT440 transmitter.When the batteries are low on a transmitter, a Low Battery IndicationwillalsolightupontheLCDscreenoftheWS222receiverforthatparticular channel. MINIMUM MAXIMUM AB B C 3 4 B * A * * 2 2 3 3 4 4 1 1 2 123 * 4 TEMPERATURE ALARM The is an ideal feature to be used for greenhouses and wine cellars, or any place that you require controlled temperature.Once activated, the temperature alarm would sound when the room getstoo warm or too cold depending on your settings. temperature alarm You can set both an upper and lower temperature alarm for the localtemperature (main receiver unit) and/or for each of the remote(outdoor) channels of 1 to 4.Scroll to the Upper Temperature Alarm Setting mode by pressing . You should see the symbol and dotted lines ( ) or pre-existing setting blink. MODE --- Select the desired channel, local or remote channels (1 to 4) using . CHN Press to finish; or r MODE epeat steps for all other channels if desired.Press or key to set the desired value for the upper temperature limit. +- To disable the particular alarm, press . The dotted lines ( ) would reappear to indicate that the alarm has been disabled. ALARM --- Setting the Upper Temperature Alarm UPPER TEMPERATURE LIMIT: warm If the temperature gets too and reaches the upper temperature limit, the alarm would sound.LOWER TEMPERATURE LIMIT: cold If the temperature gets too and reaches the lower temperature limit, the alarm would sound. 123 * 4 TEMPERATURE …

Text truncated - open the document above for the full version.

Statement of differences between Remote Receiver Clock WS222 and WS220 Below is the comparison between the new model WS222 and the approved (PLJWS220) model WS220. Similarities • Both models share the identical plastic housing, keys • Both models utilize the same RF receiver module, located in the same orientation and location inside the plastic housing • Both models has the same construction of the internal receiver antenna • The operation duty cycle, operation frequency and modulation / bit rate are identical • The main processor circuit board has similar size and component layout • Both models operate on the same power source (2 x AA size battery) Differences • Minor differences in the pattern of LCD display due to different features • Different colour of plastic housing / keys

Size : 30 x 17mm 1:1 2:1 FCC LABEL OF WEATHER STATION, MODEL WS222 MODEL: WS 222 MODEL: WS 222 FCC ID: PLJWS222/ IC: 3981A-WS222 FCC ID: PLJWS222/ IC: 3981A-WS222 Made in China Made in China This device complies with Part 15 of the FCC Rules and with RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Serial No.: This device complies with Part 15 of the FCC Rules and with RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Serial No.:

CETECOM ICT Services GmbH Radio Satellite Communication Untertürkheimer Straße 6-10 . D-66117 SaarbrückenTelefon: +49 (0)681 598-0Telefax: -9075 RSC14issue test report consist of 33 PagesPage 1 (33) Test report no.: 5-3355-A/01 FCC Part 15.231 MANDOLYN Thermostation WS 260,WS 220, WS 240 and WS 410 Accredited Testing Laboratory DAR-Registration number: TTI-P-G 166/98-00 CETECOM ICT Services GmbH Test report nr.: 5-3355-A/01Issue date:19.03.01Page 2 (33) Table of Contents 1 General information 1.1 Notes 1.2 Testing laboratory 1.3 Details of applicant 1.4 Application details 1.5 Test item 1.6 Test standards 2 Technical test 2.1 Summary of test results 2.2 Test report 1 General information 1.1 Notes The test results of this test report relate exclusively to the test item specified in 1.5. The CETECOM ICT Services GmbH does not assume responsibility for any conclusions and generalisations drawn from the test results with regard to other specimens or samples of the type of the equipment represented by the test item. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of the CETECOM ICT Services GmbH. 1.2Testing laboratory CETECOM ICT Services GmbH Untertürkheimer Straße 6 - 10 66117 Saarbrücken Germany Telefone: + 49 681 598 - 0 Telefax : + 49 681 598 - 9075 E-mail: [email protected] Internet: www.cetecom.de Accredited testing laboratory DAR-registration number : TTI-P-G 166/98-00 CETECOM ICT Services GmbH Test report nr.: 5-3355-A/01Issue date:19.03.01Page 3 (33) 1.3Details of applicant Name :Mandolyn Electronic Technology Inc. Street :108-250 Shields CRT. City :Markham, Ontario, L3R 9W7 Country :CANADA Telephone:+905 305 0923 Telefax :+905 305 0924 Contact :Mr. CM Yip Telephone:+905 305 0923 1.4Application details Date of receipt of application : 07.03.2001 Date of receipt of test item : 07.03.2001 Date of test : 09.03.- 19.03.2001 1.5Test item Type of equipment : Wireless Thermostation Type designation: WS 260, WS 220, WS 240, WS 410 Manufacturer:applicant Street: City: Country: Serial number: Additional informations:: Frequency:433,925 MHz Type of modulation:20K0A1D Number of channels :1 Antenna:integral print antenna Power supply:TX: 3V DC, RX: 3V DC Output power:max 68 dBμV/m at 3m Type of equipment:Temperature range : -20°C - +55°C 1.6Test standards: FCC Part 15 §15.231 CETECOM ICT Services GmbH Test report nr.: 5-3355-A/01Issue date:19.03.01Page 4 (33) 2 Technical test 2.1Summary of test results The thermostation family consists of one transmitter and three receivers that use all the same RX-board. The same TX (WS260) is sold either with WS220 , WS240 or WS410. The radiated measurements were performed vertical, horizontal results are about 5 dB lower over the whole frequency range. All measurement settings are according to FCC 15.35, 15.205, 15.207, 15.209 and 15.231. Measurements below 1 GHz were performed with a CISPR Quasi Peak Adapter, over 1 GHz we used peak measurements. At peaks we did an second, average measurement. ResBW and VBW were according FCC requirements. No deviations from the technical specification(s) were ascertained in the course of the tests performed. Technical responsibility for area of testing : 23.03.01RSC 8414Ames H. DateSectionNameSignature Technical responsibility for area of testing : 23.03.01RSC8411Berg M. DateSectionNameSignature CETECOM ICT Services GmbH Test report nr.: 5-3355-A/01Issue date:19.03.01Page 5 (33) 2.2Testreport TEST REPORT Testreport no. : 5-3355-A/01 CETECOM ICT Services GmbH Test report nr.: 5-3355-A/01Issue date:19.03.01Page 6 (33) TEST REPORT REFERENCE LIST OF MEASUREMENTS ParagraphPARAMETER TO BE MEASUREDPAGE Transmitter parameters §15.231 (a) (2) Automatic deactivation7 § 15.231 (e)Time of occupancy8 § 15.231 (c) Bandwidth of emission9 § 15.231 (e) Restricted field stregth for periodic TX 10 § 15.231 (e) Restricted field stregth for spurious 10 Receiver parameters § 15.209Spurious radiations - Radiated11 Test equipment listing15 Photographs of the equipment17 CETECOM ICT Services GmbH Test report nr..: 5-3355-A/01Issue Date:19.03.01Page 7 (33) Equipment under test : WS 260, WS 220, WS 240 and WS 410 Ambient temperature: 20°C Relative humidity : 31% REFERENCE NUMBER(S) OF TEST EQUIPMENT USED (for reference numbers see test equipment listing) - Automatic deactivationSUBCLAUSE §15.231 (a) (2) SUBCLAUSE §15.231 (e) The transmitter is activated automatically every 60 seconds for a duration of 210.9 ms. Encoding:2 pulses of 0.976 ms for low, 0.976 ms high for logic 1 1 pulse of 1.952 ms low, 1.952 ms high for logic 0 Word format: 36 bits/word (70.3 ms) Operating period: One transmission of 3 words (3*70.3 ms) every 60 s. So we have 3*70.3 ms = 210.9 ms every 60 s. CETECOM ICT Services GmbH Test report nr..: 5-3355-A/01Issue Date:19.03.01Page 8 (33) Equipment under test : WS 260, WS 220, WS 240 and WS 410 Ambient temperature: 20°C Relative humidity : 31% REFERENCE NUMBER(S) OF TEST EQUIPMENT USED (for reference numbers see test equipment listing) 64 Time of occupancy§ 15.231 (e) Cursor 1 to cursor 2 ~60.1 s; cursor 2 to cursor 3 ~60.1 s etc. Ref Lvl -20 dBm Ref Lvl -20 dBm RBW 100 kHz VBW 100 kHz RF Att 10 dB A UnitdBmSWT 300 s Center 433.9 MHz30 s/ 1VIEW1AP -120 -110 -100 -90 -80 -70 -60 -50 -40 -30 -20 1 1 23 Delta 1 [T1] -4.06 dB 60.120240 s 1 [T1] -48.71 dBm 3.006012 s 1 [T1] -4.06 dB 60.120240 s 2 [T1] 0.88 dB 120.240481 s 3 [T1] 0.79 dB 180.360721 s Date: 13.MAR.2001 08:19:06 CETECOM ICT Services GmbH Test report nr..: 5-3355-A/01Issue Date:19.03.01Page 9 (33) Equipment under test : WS 260, WS 220, WS 240 and WS 410 Ambient temperature: 20°C Relative humidity : 31% REFERENCE NUMBER(S) OF TEST EQUIPMENT USED (for reference numbers see test equipment listing) 64 Bandwidth of Emission§ 15.231 (c) The red threshold line shows the relative maximum peak output power. The red reference line is –20 dBc. Both cursors are at the crossin…

Text truncated - open the document above for the full version.

CETECOM ICT Services GmbH Test report nr..: 5-3355-A/01Issue Date: 19.03.01Page 14 (33) Test site RADIATED EMISSIONS CETECOM ICT Services GmbH Test report nr..: 5-3355-A/01Issue Date: 19.03.01Page 15 (33) Test site RADIATED EMISSIONS CETECOM ICT Services GmbH Test report nr..: 5-3355-A/01Issue Date: 19.03.01Page 16 (33) Test site RADIATED EMISSIONS
