Operating Manual COMMPAK-900 900 MHz Spread Spectrum Transceiver Revision 1.00 March 6, 2001 Encom Wireless Data Solutions Inc. #7-640, 42 nd Ave. N.E. Calgary, Alberta T2E 7J9 Phone: (403) 230-1122 Fax: (403) 276-9575 www.encomrs.com COMMPAK-900 900 MHz Spread-Spectrum Radio Modem WARNING In order to comply with the FCC/IC adopted RF exposure requirements, this transmitter system will be installed by the manufacturer’s reseller professional. Installation of all antennas must be performed in a manner that will provide at least 23 cm clearance from the front radiating aperture, to any user or member of the public. EQUIPMENT LABELING The manufacturer, product name, and FCC and Industry Canada identifiers of this product must appear on the outside label of the end-user equipment. This manual contains information of proprietary interest to Encom Wireless Data Solutions Inc.. It has been supplied in confidence to purchasers and users of the COMMPAK-900, and by accepting this material the recipient agrees that the contents will not be copied o r reproduced, in whole or in part, without prior written consent of Encom Wireless Data Solutions Inc. Encom Wireless Data Solutions Inc.. has made ever y effort to assure that this document is accurate and complete. However, the company reserves the right to make changes or enhancements to the manual and/o r the product described herein at any time and without notice. Furthermore, Encom Wireless Data Solutions Inc. assumes no liability resulting from any omissions in this document, or out of the application or use of the device described herein. Encom ’ products are appropriate for home, office, o r industrial use, but are not authorized for utilization in applications where failure could result in damage to property or human injury or loss of life. The electronic equipment described in this manual generates, uses, and radiates radio frequency energy. Operation of this equipment in a residential area ma y cause radio interference, in which case the user, at his own expense, will be required to take whatever measures necessary to correct the interference. FCC Declaration of Conformity This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received including interference that may caused undesired operation. Encom Wireless Data Solutions Inc., products are warranted against all failures which occur as a result o f defective material or workmanship within 24 months of purchase by the user. This warranty does not extend to products that, in the opinion of Encom Wireless Data Solutions Inc.., have been subject to misuse, accidents, lightning strikes, improper installation or application, no r shall it extend to units which have, in Encom Wireless Data Solutions Inc.’s opinion, been opened, tampered with or repaired by an unauthorized facility. Encom Wireless Data Solutions Inc #7-640 42 nd Ave. N.E. Calgary, Alberta T2E 7J9 Phone: (403) 230-1122Fax: (403) 276-9575 www.encomrs.com All Rights Reserved. COMMPAK, ControlPAK are registered trademarks of Encom Wireless Data Solutions Inc. Microsoft and Windows are registered trademarks of Microsoft Corporation. pcANYWHERE and Symantec are registered trademarks of Symantec Corp. All other products mentioned in this document are trademarks or registered trademarks of their respective holders. Manual Revision 1.00, March 6, 2001. 1 1. INTRODUCTION..........................................................................................................................................................................2 1.0 Product Overview ..............................................................................................................................................................2 1.0.1 DC Characteristics ......................................................................................................................................4 2. P OWER CONNECTION.................................................................................................................................................................5 3. M ODES OF OPERATION..............................................................................................................................................................6 3.1 Data Mode..................................................................................................................................................................6 3.2 Command Mode.........................................................................................................................................................7 3.3 Diagnostics Mode.......................................................................................................................................................7 4. D ATA PORT 8 4.1 RS232 Configuration ..................................................................................................................................................8 4.1.1 Sleep Mode .................................................................................................................................................9 4.2 4 Wire RS485 Configuration .......................................................................................................................................9 4.3 2 Wire RS485 Configuration ..................................................................................................................................... 10 5. LED I NDICATORS..................................................................................................................................................................... 11 5.3.1 PWR (Red)................................................................................................................................................ 11 5.3.2 TXD (Red) .......…
Text truncated - open the document above for the full version.
Operating Manual COMMPAK-900 900 MHz Spread Spectrum Transceiver Revision 1.00 March 6, 2001 Encom Wireless Data Solutions Inc. #7-640, 42 nd Ave. N.E. Calgary, Alberta T2E 7J9 Phone: (403) 230-1122 Fax: (403) 276-9575 www.encomrs.com COMMPAK-900 900 MHz Spread-Spectrum Radio Modem WARNING In order to comply with the FCC/IC adopted RF exposure requirements, this transmitter system will be installed by the manufacturer’s reseller professional. Installation of all antennas must be performed in a manner that will provide at least 23 cm clearance from the front radiating aperture, to any user or member of the public. EQUIPMENT LABELING The manufacturer, product name, and FCC and Industry Canada identifiers of this product must appear on the outside label of the end-user equipment. This manual contains information of proprietary interest to Encom Wireless Data Solutions Inc.. It has been supplied in confidence to purchasers and users of the COMMPAK-900 , and by accepting this material the recipient agrees that the contents will not be copied or reproduced, in whole or in part, without prior written consent of Encom Wireless Data Solutions Inc. Encom Wireless Data Solutions Inc.. has made every effort to assure that this document is accurate and complete. However, the company reserves the right to make changes or enhancements to the manual and/or the product described herein at any time and without notice. Furthermore, Encom Wireless Data Solutions Inc. assumes no liability resulting from any omissions in this document, or out of the application or use of the device described herein. Encom ’ products are appropriate for home, office, or industrial use, but are not authorized for utilization in applications where failure could result in damage to property or human injury or loss of life. The electronic equipment described in this manual generates, uses, and radiates radio frequency energy. Operation of this equipment in a residential area may cause radio interference, in which case the user, at his own expense, will be required to take whatever measures necessary to correct the interference. FCC Declaration of Conformity This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received including interference that may caused undesired operation. Encom Wireless Data Solutions Inc., products are warranted against all failures which occur as a result of defective material or workmanship within 24 months of purc hase by the user. This w arranty does not exte nd to products that, in the opinion of Encom Wireless Data Solutions Inc.., have been subject to misuse, accidents, lightning strikes, improper installation or application, nor shall it extend to units which have, in Encom Wireless Data Solutions Inc.’s opinion, been opened, tampered with or repaired by an unaut horized facility. Encom Wireless Data Solut ions Inc #7-640 42 nd Ave. N.E. Calgary, Alberta T2E 7J9 Phone: (403) 230-1122Fax: (403) 276-9575 www.encomrs.com All Rights Reserved. COMMPAK , ControlPAK are registered trademarks of Encom Wireless Data Solutions Inc. Microsoft and Windows are registered trademarks of Microsoft Corporation. pcANYWHERE and Symantec are registered trademarks of Symantec Corp. All other products mentioned i n this document are trademarks or registered trademarks of their respective holders. Manual Revision 1.00, March 6, 2001. 1 1.I NTRODUCTION .................................................................................................................................................................................................2 1.0 Produc t Over view.............................................................................................................................................. 2 1.0.1DC Char acteristics......................................................................................................................... 4 2.P OWER C ONNECTION .....................................................................................................................................................................................5 3.M ODES OF O PER ATION ..................................................................................................................................................................................6 3.1Master Mode............................................................................................................................................... 6 3.2Repeater Mode........................................................................................................................................... 6 3.3Slave Mode................................................................................................................................................. 6 3.4Network Topologies..................................................................................................................................... 7 4.D ATA P ORT .......................................................................................................................................................................................................2 4.1RS232 Configuration................................................................................................................................... 2 4.1.1Sleep Mode................................................................................................................................... 3 4.24 Wire RS485 Configuration........................................................................................................................ 3 4.32 Wire RS485 Configuration........................................................................................................................ 4 5.LED I NDICATORS ....................................................…
Text truncated - open the document above for the full version.
#110, 1144 - 29th Avenue N.E. Calgary, Alberta T2E 7P1 Tel: (403) 248-0028 Fax: (403) 248-2762 Website: http://www.microhardcorp.com April 19, 2001 Federal Communications Commission OET Laboratory Division 7435 Oakland Mills Rd. Columbia, MD 21046 Re: Request for Confidentiality. Pursuant to the Commission’s Rules Microhard Systems Inc. requests confidential treatment of the Schematics and Bill of Materials for the PLQCOMMPAK900. This product is Microhard Systems Inc.’s MHX-920E (FCC ID: NS901P6), which Microhard Systems Inc. owns and manufactures. Microhard Systems Inc. requests that you hold his information confidential from public and from the applicant Encom Wireless Data Solutions Inc. These documents contain trade secrets and proprietary information, which is not released to the public. Extensive research and development efforts have provided us with spread spectrum radio technology that significantly outperforms much of our competition. The public disclosure of these materials would be harmful to Microhard Systems Inc. and would give our competitors unfair benefits. Thank you in advance. Hany H. Shenouda President
#110, 1144 - 29th Avenue N.E. Calgary, Alberta T2E 7P1 Tel: (403) 248-0028 Fax: (403) 248-2762 Website: http://www.microhardcorp.com July 9, 2001 Federal Communications Commission OET Laboratory Division 7435 Oakland Mills Rd. Columbia, MD 21046 Re: Request for Third Party Confidentiality. This letter supercedes all previous requests for confidentiality. Pursuant to the Commission’s Rules Microhard Systems Inc. requests confidential treatment of the Microhard Systems’ Schematics and Bill of Materials. Microhard Systems Inc. requests confidentiality for the following exhibits and any other exhibits which are marked confidential. Digital_SCH.pdf Radio_SCH.pdf BOM.pdf These exhibits are the confidential and proprietary property of Microhard Systems Inc. The applicant (Encom Wireless Data Solutions Inc.) has filed for a grant under FCC ID: PLQCOMMPAK900, however, the applicant does not own nor have access to the listed exhibits herein or any other confidential exhibits. This product is Microhard Systems Inc.’s MHX-920E (FCC ID: NS901P6), which Microhard Systems Inc. owns and manufactures and sells to the applicant. Microhard Systems Inc. requests that FCC holds his information confidential from public and from the applicant Encom Wireless Data Solutions Inc. These documents contain trade secrets and proprietary information, which is not released to the public or the applicant. Extensive research and development efforts have provided us with spread spectrum radio technology that significantly outperforms much of our competition. The public disclosure of these materials would be harmful to Microhard Systems Inc. and would give our competitors unfair benefits. Thank you in advance. Hany H. Shenouda President
COMMPAK-900 Transceiver External Photographs COMMPAK-900 Transceiver External Photographs COMMPAK-900 Transceiver External Photographs COMMPAK-900 Transceiver External Photographs COMMPAK-900 Transceiver External Photographs
FCC ID LABEL FORMAT AND LOCATION TOP VIEW FCCID: PLQCOMMPAK900 This device complies with Part 15 of the FCC Rules. Operation of this device is subject to the following conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference which may cause undesired operation. COMMPAK 900 MHZ RF
Top View Microhard Systems Inc. MHX-920E NS901P6
Bottom View Microhard Systems Inc. MHX-920E NS901P6
RF Shield View Microhard Systems Inc. MHX-920E NS901P6
Microhard Systems Inc. MHX-920E Operational Description MHX-920E Operational Description1 1.0 Operational Description The MHX-920E is a high-performance embedded spread spectrum data transceiver. Users communicate with this module via an asynchronous RS-232 interface. All data that users send to the module is buffered in banks of SRAM memory, packetized with the appropriate header information, and sent over the air at a fixed bit rate. The microprocessor inside the module precisely controls the bit-width, packet size, and hopping algorithm, to ensure that the RF occupied bandwidth and channel dwell-times remain constant. Users have no ability to modify the occupied bandwidth of the transmitted data. Users power the module from a 5 - 5.5V source. Linear regulators and biasing ensure that increases to the supply voltage will not increase the transmitted power, which is limited to 1W, or in the case that the module is sold with high gain antennas, the transmitted power is factory-limited to 100mW. The MHX-920E modem can be configured for a wide range of applications. The module is designed such that all communication is through one serial port (Pins 21 to 28 on the module). This port has two functions: 1. It provides the asynchronous interface with the host equipment for data that is sent/received on the RF channel. When operating in this fashion, the module is said to be in data mode. 2. It is also used for configuring and programming the module. When operating in this fashion, the module is said to be in command mode. The functionality of any particular MHX-920E can be configured as follows: nMaster Point-to-Point: The modem is configured to communicate with a single Slave, either directly, or through one or more Repeaters. nMaster Point-to-Multipoint: The modem is configured to communicate with one or more Slaves and/or Repeaters. nSlave: The modem is configured to communicate with one Master either directly or through one or more Repeaters.. nRepeater: The modem is configured to pass information from either a Master or another Repeater onto subsequent Repeaters and/or Slaves and vice versa. The Repeater also acts as a Slave in the sense that, like a Slave, it passes information to/from its serial port. The MHX-920E is a frequency hopping transceiver, meaning that it “hops” to a new frequency after a predetermined time interval. This time interval is a fixed time set by the user, and can range from 8ms to 120ms. The MHX-920E hops according to a pseudorandom pattern of 50 different channels. Each of the 50 channels is used once in the pseudorandom pattern, and the dwell time is equal among channels. There are 64 available channels with spacing of 400 kHz starting at 902.4 MHz and going up to 927.6 MHz. The system receiver input bandwidth is 350 kHz The RF connector on the module is an MCX straight PC mount jack. The manufacturer's part no. is: Johnson # 133-3701-211
8.0 RF Exposure Statement: Notice in Installation Manual: FCC Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment, when installed as directed. This equipment should be installed and operated with fix-mounted antennas that are installed with a minimum of 2 meters of separation distance between the antenna and all persons’ body during normal operation. RF Exposure Calculations: The following information provides the minimum separation distance for the highest gain antenna provided with the EUT, as calculated from FCC OET 65 Appendix B, Table 1B Guidelines for General Population/Uncontrolled Exposure. This calculation is based on the highest EIRP possible from the system, considering maximum power and antenna gain, and considering a 0.6 mW/cm^2 uncontrolled exposure limit. The Friss formula used was: S = (Po*G) / (4*Pi*r^2)orr =(Po*G) / (4*Pi*S) WhereS = 0.6 mW/cm^2 for 902 MHz (902 / 1500) WherePo = 100 mW Peak for Yagi antennas, and 1000 mW for Omni Antennas WhereG= Isotropic antenna gain (numeric) Wherer= Minimum Safe Distance from antenna (cm) For:8.5 dB Yagi Antennar = 10 cm 2.5 dB Omni Antennar = 16 cm 6 .0 dB Omni Antennar = 23 cm RF Exposure Table For Antennas Used With This Equipment Antenna Type Gain (dBi) Numeric Gain ChannelPeak Output Power (mW) Calculated Distance (cm) Minimum RF Exposure Separation Distance (cm) Yagi8.5711001020 Omni6.04110002323 Omni2.51.8110001620
COMMPAK-900 900 MHz Spread-Spectrum Radio Modem WARNING In order to comply with the FCC/IC adopted RF exposure requirements, this transmitter system will be installed by the manufacturer’s reseller professional. Installation of all antennas must be performed in a manner that will provide at least 23 cm clearance from the front radiating aperture, to any user or member of the public. EQUIPMENT LABELING The manufacturer, product name, and FCC and Industry Canada identifiers of this product must appear on the outside label of the end-user equipment. This manual contains information of proprietary interest to Encom Wireless Data Solutions Inc.. It has been supplied in confidence to purchasers and users of the COMMPAK-900, and by accepting this material the recipient agrees that the contents will not be copied or reproduced, in whole or in part, without prior written consent of Encom Wireless Data Solutions Inc. Encom Wireless Data Solutions Inc.. has made every effort to assure that this document is accurate and complete. However, the company reserves the right to make changes or enhancements to the manual and/or the product described herein at any time and without notice. Furthermore, Encom Wireless Data Solutions Inc. assumes no liability resulting from any omissions in this document, or out of the application or use of the device described herein. Encom ’ products are appropriate for home, office, or industrial use, but are not authorized for utilization in applications where failure could result in damage to property or human injury or loss of life. The electronic equipment described in this manual generates, uses, and radiates radio frequency energy. Operation of this equipment in a residential area may cause radio interference, in which case the user, at his own expense, will be required to take whatever measures necessary to correct the interference. FCC Declaration of Conformity This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this de vice may not ca use harmf ul i nte rfe re nce , and (2) this device must accept any interference received including interference that may caused undesired operation. Encom Wireless Data Solutions Inc., products are warranted against all failures which occur as a result of defective material or workmanship within 24 months of purchase by the user. This warranty does not extend to products that, in the opinion of Encom Wireless Data Solutions Inc.., have been subject to misuse, accidents, lightning strikes, improper installation or application, nor shall it extend to units which have, in Encom Wireless Data Solutions Inc.’s opinion, been opened, tampered with or repaired by an unauthorized facility. Encom Wireless Data Solut ions Inc #7-640 42 nd Ave. N.E. Calgary, Alberta T2E 7J9 Phone: (403) 230-1122Fax: (403) 276-9575 www.encomrs.com All Rights Reserved. COMMPAK , ControlPAK are registered trademarks of Encom Wireless Data Solutions Inc. Microsoft and Windows are registered trademarks of Microsoft Corporation. pcANYWHERE and Symantec are registered trademarks of Symantec Corp. All other products mentioned i n this document are trademarks or registered trademarks of their respective holders. Manual Revision 1.00, March 6, 2001.
E E N N C C O O M M W W I I R R E E L L E E S S S S D D A A T T A A S S O O L L U U T T I I O O N N S S F F C C C C I I N N F F O O R R M M A A T T I I O O N N FCC ID: PLQCOMMPAK900Page 2 of 49 R R R F F F M M M e e e a a a s s s u u u r r r e e e m m m e e e n n n t t t R R R e e e p p p o o o r r r t t t P P P r r r e e e p p p a a a r r r e e e d d d b b b y y y : : : N N N a a a t t t i i i o o o n n n a a a l l l C C C e e e r r r t t t i i i f f f i i i c c c a a a t t t i i i o o o n n n L L L a a a b b b o o o r r r a a a t t t o o o r r r y y y 8370 Court Avenue, Suite B-1 Ellicott City, Maryland 21043 (410) 461-5548 I I I n n n S S S u u u p p p p p p o o o r r r t t t o o o f f f : : : F F F o o o r r r : : : Encom Wireless Data Solutions #7, 640 42 nd Avenue, NE Calgary Alberta, Canada T2E 7J9 Model: Commpak-900 FCCID: PLQCOMMPAK900 Demonstration of Compliance with FCC Rules Part 15.247 No part of this report may be reproduced without written approval of National Certification Laboratory March 22, 2001 FCC APPLICATION FOR CERTIFICATION FCC ID: PLQCOMMPAK900Page 3 of 49 TABLE OF CONTENTS 1.0General Information.................................................................................................................................5 1.1Summary5 1.2Test Methodology...................................................................................................................................5 1.3Test Facility.............................................................................................................................................5 2.0Description of Equipment Under Test (EUT).........................................................................................6 2.1EMI Countermeasure..............................................................................................................................7 3.0Test Program7 4.0Test Configuration For Antenna Terminal Conducted.........................................................................8 4.1Peak Power Test Results.........................................................................................................................9 4.1.1Peak Power Modulated Carrier (1 MHz Res. BW) Low Channel Plot.........................................10 4.1.2Peak Power Modulated Carrier (1 MHz Res. BW) Mid Channel Plot.........................................11 4.1.3Peak Power Modulated Carrier (1 MHz Res. BW) High Channel Plot........................................12 4.220 dB Emission Bandwidth Test Results..............................................................................................13 4.2.120 dB Bandwidth Emissions (3 kHz Res. BW) Low Channel Plot..............................................14 4.2.220 dB Bandwidth Emissions (3 kHz Res. BW) Mid Channel Plot...............................................15 4.2.320 dB Bandwidth Emissions (3 kHz Res. BW) High Channel Plot..............................................16 4.3RF Antenna Conducted Spurious/Harmonics Emissions......................................................................17 4.3.1FCC Part 15.247(c) Conducted Spurious, 902.47 MHz Frequency Of Carrier............................18 4.3.2FCC Part 15.247(c) Conducted Spurious, 914.8 MHz Frequency of Carrier...............................19 4.3.3FCC Part 15.247(c) Conducted Spurious,927.6 MHz Frequency of Carrier................................20 4.3.4Conducted Harmonics Emissions (100kHz Res. BW) Low Cannel Plot......................................21 4.3.5Conducted Harmonics Emissions (100kHz Res. BW) Mid Cannel Plot......................................22 4.3.6Conducted Harmonics Emissions (100kHz Res. BW) High Cannel Plot.....................................23 4.4Conducted Bandedge Emissions Test Results......................................................................................24 4.4.1Low Channel Conducted Bandedge Emissions Plot.....................................................................24 4.4.2High Channel Conducted Bandedge Emissions Plot....................................................................25 4.5Channel Occupancy Test Results..........................................................................................................26 FCC ID: PLQCOMMPAK900Page 4 of 49 4.6UT Average Time of Channel Occupancy and Dwell Time.................................................................28 4.7Hopping Dwell Time.............................................................................................................................29 5.0Test Configuration For Conducted And Radiated Emissions............................................................30 6.0A.C. Conducted Emissions Scheme.......................................................................................................30 6.1AC Conducted Emissions Data Table...................................................................................................31 7.0Radiated Emissions Scheme...................................................................................................................32 7.1Yagi Antenna, 902.47 MHz, 100mW Radiated Emissions Data Table................................................33 7.2Yagi Antenna, 914.83 MHz, 100mW Radiated Emissions Data Table................................................34 7.3Yagi Antenna, 927.61 MHz,100mW Radiated Emissions Data Table.................................................35 7.46 dBi Omni Antenna, 902.47 MHz, 1000mW Radiated Emissions Data Table...................................36 7.56 dBi Omni Antenna, 914.83 MHz, 1000mW Radiated Emissions Data Table...................................37 7.66 dBi Omni Antenna, 927.61 MHz, 1000mW Radiated Emissions Data Table...................................38 7.7Receiver, 915 MHz Radiated Emissions Data Table............................................................................39 8.0RF Exposure Statement.............................................................…
Text truncated - open the document above for the full version.
8370 Court Avenue · Ellicott City, Maryland · United States
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 902.47 MHz - 927.61 MHz | 1 W |

ENC-11AC49
Equipment Class
TNB - Licensed Non-Broadcast Station Transmitter
Transmitter Module
Equipment Class
DSS - Part 15 Spread Spectrum Transmitter
