PLQENC11AC49ENC-11AC49

1 ENC-11AC49 Features Qualcomm-Atheros QCA9880 chipset Support 4.9GHz 2x2 MIMOTechnology, Mini PCI Express edgeconnector RoHS compliance ensure a high level protection of human health and the environment from risks that can be posed by chemicals Supports Spatial Multiplexing,Cyclic-Delay Diversity (C DD),Low-Density Parity Check(LDPC) Codes, Maximal Ratio Combining (MRC), Space Time Block Code (STBC) Cards are individually calibrated for Quality Assurance Applications Security Surveillance Commercial radio coverage Hotel Wireless application  Country coverage Forest fire protection engineering Some special scene application Product Description ENC-11AC49 based on QCA9880 chipset is an enterprise wireless module integrated with 2x2 4.9G high power Radio module specifically to provide users with mobile access to high-bandwidth video streaming, voice, and data transmission for office and challenging RF environment in factories, warehouses establishment. 2 Symbol Parameter Chipset QCA9880 Host Interface Mini PCI Express 1.1 Standard Antenna Connector 2 x UF.L Frequency Range 4940~4990MHz Operating Voltage 3.3V DC Power Consumption Modulation Techniques OFDM:BPSK, QPSK, DQPSK, 16-QAM, 64-QAM, 256-QAM Environmental Temperature Operating: -40°C to 70°C, Storage: -40°C to 90°C Environmental Humidity, non-condensing Operating: 5% to 95%, Storage: Max. 90% ROHS Compliance YES Dimensions (W×H×D) 30.0mm × 50.9mm × 3.2mm Specifications 3 GPIO Pin Mapping GPIO Pin Function GPIO0 WLAN_DIS GPIO1 WLAN_LED GPIO2 MCI_CLK_IN GPIO3 MCI_CLK_OUT GPIO4 MCI_DATA_OUT GPIO5 MCI_DATA_IN GPIO12 TMS 13 TCK 14 TDI 15 TDO 16 CPU_WARM_RESET / JTEG RESET 17 GPIO17_BT_LED 19 ANT_A 20 ANT_B 21 FEM_BS 22 FEM_MODE RF Performance Table Operating Mode Data Rate Max Tune-up Output Power 1 Chain 2 Chains 4.9 GHz 6Mbps / 22.20dBm Operating Mode Data Rate RX Sensitivity 4.9 GHz 6Mbps -94dBm 4 MiniPCIe Slot Pin Assignment TOP Side Bottom Side 1 PCIE_WAKE_L 2 VCC_3V3 3 NC 4 GND 5 NC 6 NC 7 PCIE_CLKREQ_L 8 NC 9 GND 10 NC 11 PCIE_REFCLK_N 12 NC 13 PCIE_REFCLK_P 14 NC 15 GND 16 NC Mechanical key 17 NC 18 GND 19 NC 20 GPIO0_WLAN_DIS 21 GND 22 PCIE_RST_L 23 PCIE_TX_N 24 VCC_3V3 25 PCIE_TX_P 26 GND 27 GND 28 NC 29 GND 30 NC 31 PCIE_RX_P 32 NC 33 PCIE_RX_N 34 GND 35 GND 36 NC 37 GND 38 NC 39 VCC_3V3 (RESERVED) 40 GND 41 VCC_3V3 (RESERVED) 42 NC 43 GND 44 GPIO1_WLAN_LED 45 NC 46 GPIO17_BT_LED 47 NC 48 NC 49 NC 50 GND 51 NC 52 VCC_3V3 5 1） the picture show us the Pin 1 and the pin51，the pin numbers are increasing by odd numbers on the topside； 2） and increasing by even numbers from Pin2 to Pin52 on the bottom side；the pin2 is on the bottom of the pin1 Version Version CPU Feature ENC-11AC49 QCA9880 Support 4.9G Warning: 1.0 This module has been tested and found to comply with PART90Y requirements for Modular Approval. This module can work with 4.9G . 1.1. Summarize the specific operational use conditions: This module can be used in Commercial radio coverage and other equipment. The input voltage to the module should be nominally 3.3VDC ,the ambient temperature of the module is - 40°~70°.And the antenna needs to be changed, the certification should be re-applied. 1.2. Limited module procedures NA Pin1 Pin51 6 1.3.Trace antenna designs NA 1.4.RF exposure considerations This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment .This equipment should be installed and operated with minimum distance 20cm between the radiator& your body. If the device built into a host as a portable usage, the additional RF exposure evaluation may be required as specified by 2.1093. 1.5.Antennas Antenna type :External fixed omni antenna 4.9GHz band Peak Gain：2(dBi) 1.6.Label and compliance information Whe n the module is installed in the host device, the FCC ID label must be visible through a window on the final device or it must be visible when an access panel, door or cover is easily re-moved. If not, a second label must be placed on the outside of the final device that contains the following text: “Contains FCC ID: PLQENC11AC49”. The FCC ID can be used only when all FCC ID compliance requirements are met. 1.7.Information on test modes and additional testing requirements a) The modular transmitter has been fully tested by the module grantee on the required number of channels,modulation types, and modes, it should not be necessary for the host installer to re-test all the available transmitter modes or settings. It is recommended that the host product manufacturer, installing the modular transmitter,perform some investigative measurements to confirm that the resulting composite system does not exceed the spurious emissions limits or band edge limits(e.g.,where a different antenna may be causing additional emissions). b)The testing should check for emissions that may occur due to the intermixing of emissions with the other transmitters, digital circuitry, or due to physical properties of the host product (enclosure). This investigation is especially important when integrating multiple modular transmitters where the certification is based on testing each of them in a stand-alone configuration. It is important to note that host product manufacturers should not assume that because the modular transmitter is certified that they do not have any responsibility for final product compliance. 7 c) If the investigation indicates a compliance concern the host product manufacturer is obligated to mitigate the issue.Host products using a modular transmitter are subject to all the applicable individual technical rules as well as to the general conditions of operation in Sections15.5,15.15,and15.29 to not cause interference.The operator of the host product will be obligated to stop operating the device until the interference have been corrected. 1.8.Additional testing,Part15 Sub part B dis claimer The final host / module combination need to be evaluated against the FCC Part 15B criteria for unintentional radiator…

Text truncated - open the document above for the full version.

Company Name: Encom Wireless Data Solutions Inc. Add: #7, 640 42nd Avenue N.E. Calgary, Alberta, T2E 7J9 Canada Tel: (403) 230-1122 Fax: (403) 276-9575 Date: 2020-03-03 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Attestation Letter Dear Sir or Madam: Our product ENC-11AC49 (model name:ENC-11AC49, FCC ID: PLQENC11AC49), use the chip QCA9880-BR4A only activates 4.9GHz(4940~4990MHz,20MHz bandwidth) function. The other bands and functions had been blocked by the firmware. Please contact me if there is need for any additional clarification or information. Sincerely Yours, Signature: Typed or Printed Name: Mike Kwan Title: VP-Engineering

QA-FR-170-B Company Name: Encom Wireless Data Solutions Inc. Add: #7, 640 42nd Avenue N.E. Calgary, Alberta, T2E 7J9 Canada Tel: (403) 230-1122 Fax: (403) 276-95 75 FCC Authorization Date: 2020-01-07 FE DERAL COMM UNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization To whom it may concern: We, Encom Wireless Data Solutions Inc., the undersigned, Hereby authorizes Bay Area Compliance Laboratories Corporation to act on its behalf in all matters relating to application for Equipment authorization, including the signing of all documents relating to these matters. All acts carried out by Bay Area Compliance Laboratories Corp. on our behalf shall hav e the same effect as our own action. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. This authorization is valid until further written notice from the applicant. Sincerely Yours, Signature: Typed or Printed Name: Mike Kwan Title:VP-Engineering

Company Name : Encom Wireless Data Solutions Inc. Add: #7, 640 42nd Avenue N.E. Calgary, Alberta, T2E 7J9 Canada Tel: (403) 230-1122 Fax: (403) 276-9575 FCC Confidential Authorization Date: 2020-01-07 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request regarding application for certification of FCC ID: PLQENC11AC49 To: whom it may concern, In accordance with Sections 0.457 and 0.459 of the Commission’s Rules, Encom Wireless Data Solutions Inc. hereby requests long-term confidential treatment of information accompanying this application as outlined below: Block Diagram Schematics Operation Description BOM Tune-up The above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Sin cerely Yours, Signature: Typed or Printed Name: Mike Kwan Title: VP-Engineering

Applicant Encom Wireless Data Solutions Inc. FCC ID: PLQENC11AC49 Section 15.212 Modular Transmitters Request for Modular Approval  Request for Limited Modular Approval   RequirementsEUT ConditionsComply(Y/N) Single Modular Approval Requirements 1 The radio elements of the modular transmitter must have their own shielding. The physical crystal and tuning capacitors may be located external to the shielded radio elements. Refer to external photos. This module does have shield cover. Y 2 The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with part 15 requirements under conditions of excessive data rates or over‐modulation. All inputs to the modules are buffered through logic or microprocessor inputs. Refer to Schematics. Y 3 The modular transmitter must have its own power supply regulation. The Module uses the chip QCA 9880 with built-in power management components, the module reted power is 3.3V power, Refer to schematics. Y 4 The modular transmitter must comply with the antenna and transmission system requirements of §§15.203, 15.204(b) and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). The “professional installation” provision of §15.203 is not applicable to modules but can apply to limited modular approvals under paragraph (b) of this section. The EUT has been tested with two external antennas and each antenna gain is 2dBi with IPEX connector, which use a unique type of connector to attach to the EUT. Refer to external photo. Y Company: Encom Wireless Data Solutions Inc. Add: #7, 640 42nd Avenue N.E. Calgary, Alberta, T2E 7J9 Canada Tel: (403) 230-1122 Fax: (403) 276-9575 E-mail: [email protected] 5 The modular transmitter must be tested in a stand‐alone configuration, i.e., the module must not be inside another device during testing for compliance with part 15 requirements. Unless the transmitter module will be battery powered, it must comply with the AC line conducted requirements found in §15.207. AC or DC power lines and data input/output lines connected to the module must not contain ferrites, unless they will be marketed with the module (see §15.27(a)). The length of these lines shall be the length typical of actual use or, if that length is unknown, at least 10 centimeters to insure that there is no coupling between the case of the module and supporting equipment. Any accessories, peripherals, or support equipment connected to the module during testing shall be unmodified and commercially available (see §15.31(i)). The modular transmitter is tested in a stand-alone configuration, i.e., the module is not be inside another device when testing. Please refer to setup photo. Y 6 The modular transmitter must be equipped with either a permanently affixed label or must be capable of electronically displaying its FCC identification number The device Uses a permanently affixed label, refer Label .when the module is installed inside a nother device, then the outside of the device into which the module is installed,this exterior label must use wording such as the following: “Contains Transmitter Module FCC ID: PLQENC11AC49 ” or “Contains FCC ID: PLQENC11AC49 ”. Y 7 The modular transmitter must comply with any specific rules or operating requirements that ordinarily apply to a complete transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. Refer to manual Y 8 The modular transmitter must comply with any applicable RF exposure requirements in its final configuration. The EUT comply with RF exposure requirements § 2.1091.If the device built into a host as a portable usage, t he RF exposure evaluation may be required as specified by§ 2.1093. Y Sincerely, Signature: Typed or Prin ted Name: Mike Kwan Title: VP-Engineering

EXHIBIT A - EUT EXTERNAL PHOTOGRAPHS Antenna 1 Antenna 2 ANT port 1 ANT port 2

ENC-11AC49 ENC-11AC49 PLQENC11AC49 ENC-11AC49 ENC-11AC49 PLQENC11AC49

EXHIBIT B - EUT INTERNAL PHOTOGRAPHS

Bay Area Compliance Laboratories Corp. (Kunshan) Report No.: RKSA200107001-00A FCC Part 90Y Page 10 of 49 FCC §1.1310 & §2.1091- MAXIMUM PERMISSIBLE EXPOSURE (MPE) Applicable Standard According to §2.1091and §1.1310, systems operating under the provisions of this section shall be operated in a manner that ensure that the public is not exposed to radio frequency energy level in excess of the Commission’s guideline. Limits for Maximum Permissible Exposure (MPE) (§1.1310, §2.1091) f = frequency in MHz; * = Plane-wave equivalent power density; According to §1.1310 and §2.1091 RF exposure is calculated. Calculated Formulary: Predication of MPE limit at a given distance S = PG/4πR² = power density (in appropriate units, e.g. mW/cm 2 ); P = power input to the antenna (in appropriate units, e.g., mW); G = power gain of the antenna in the direction of interest relative to an isotropic radiator, the power gain factor, is normally numeric gain; R = distance to the center of radiation of the antenna (appropriate units, e.g., cm); Calculated Data: Mode Frequency Range (MHz) Antenna Gain Tune-up Output Power Evaluation Distance (cm) Power Density (mW/cm 2 ) MPE Limit (mW/cm 2 ) (dBi) (numeric)(dBm)(mW) 20MHz 4950-4980 2.0 1.58 22.50117.83 20 0.0559 1.0 Note: The tune-up output power was declared by the manufacturer. Conclusion: The EUT meets exemption requirement - RF exposure evaluation greater than 20cm distance specified in § 2.1091. If the device built into a host as a portable usage, the additional RF exposure evaluation may be required as specified by§ 2.1093.

Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in part without prior written consent from Bay Area Compliance Laboratories Corp. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. FCC PART 90 TEST REPORT For Encom Wireless Data Solutions Inc. #7, 640 42nd Avenue N.E. Calgary, Alberta, T2E 7J9 Canada Report Type: Original Report Product Type: ENC-11AC49 Test Engineer: Stone Zhang Re port Number: RKSA200107001-00A Re port Date: 2020-03-03 Reviewed B y: Oscar Ye EMC Mana ger Prepared By: Bay Area Compliance Laboratories Corp. (Kunshan) No.248 Chenghu Road, Kunshan, Jiangsu province, China Tel: +86-0512-86175000 Fax: +86-0512-88934268 www.baclcorp.com.cn FCC ID: PLQENC11AC49 Bay Area Compliance Laboratories Corp. (Kunshan) Report No.: RKSA200107001-00A FCC Part 90Y Page 2 of 49 TABLE OF CONTENTS GENERAL INFORMATION ....................................................................................................................................... 4 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ..................................................................................... 4 OBJECTIVE ................................................................................................................................................................... 4 RELATED SUBMITTAL(S)/GRANT(S) ............................................................................................................................. 4 TEST METHODOLOGY .................................................................................................................................................. 5 MEASUREMENT UNCERTAINTY .................................................................................................................................... 5 TEST FACILITY ............................................................................................................................................................. 5 SYSTEM TEST CONFIGURATION .......................................................................................................................... 6 DESCRIPTION OF TEST CONFIGURATION ...................................................................................................................... 6 EUT EXERCISE SOFTWARE .......................................................................................................................................... 6 SPECIAL ACCESSORIES ................................................................................................................................................. 6 EQUIPMENT MODIFICATIONS ....................................................................................................................................... 6 SUPPORT EQUIPMENT LIST AND DETAILS .................................................................................................................... 6 EXTERNAL I/O CABLE .................................................................................................................................................. 6 BLOCK DIAGRAM OF TEST SETUP ................................................................................................................................ 7 SUMMARY OF TEST RESULTS ............................................................................................................................... 8 TEST EQUIPMENT LIST ........................................................................................................................................... 9 FCC §1.1310 & §2.1091- MAXIMUM PERMISSIBLE EXPOSURE (MPE) ........................................................ 10 APPLICABLE STANDARD ............................................................................................................................................ 10 FCC §2.1049 - OCCUPIED BANDWIDTH .............................................................................................................. 11 APPLICABLE STANDARD ............................................................................................................................................ 11 TEST PROCEDURE ...................................................................................................................................................... 11 TEST DATA ................................................................................................................................................................ 12 FCC §2.1046, §90.205(p), §90.1215(a)(1) - POWER OUTPUT ............................................................................... 19 APPLICABLE STANDARD ............................................................................................................................................ 19 TEST PROCEDURE ...................................................................................................................................................... 19 TEST DATA ................................................................................................................................................................ 19 FCC §2.1046 ,§90.205(p), §90.1215(a)(2) - POWER SPECTRAL DENSITY ........................................................ 21 APPLICABLE STANDARD ............................................................................................................................................ 21 TEST PROCEDURE ...................................................................................................................................................... 21 TEST DATA ................................................................................................................................................................ 21 FCC §90.1215(e) - PEAK EXCURSION ...........................................…

Text truncated - open the document above for the full version.

EXHIBIT C - TEST SETUP PHOTOGRAPHS Radiated Emissions (Below 1GHz) Radiated Emissions (1GHz-18 GHz) Radiated Emissions (18GHz-40GHz)
