PNF-PC3200PWIRELESS PCMCIA CDMA DATA MODEM

User Manual for the AirPrime PC3200P- version 0.4 (07/17/02) ************************************************************ Getting the Most Out of Your Reception Keeping Tabs on Signal Strength The quality of each call you make or receive depends on the signal strength in your area. Your PC card used with a laptop computer informs you of the current signal strength by displaying a number of bars next to the signal strength icon. The more bars displayed, the stronger the signal. If you’re inside a building, being near a window may give you better reception. Understanding the Power Save Feature If your PC card is unable to find a signal after 15 minutes of searching, a Power Save feature is automatically activated. If your PC card is active, it periodically rechecks service availability or you can check it yourself by pressing any key. Anytime the Power Save feature is activated, a message displays on the screen. When a signal is found, your PC card returns to Standby mode. Understanding How Your PC card Operates Your PC card is basically a radio transmitter and receiver. When it’s turned on, it receives and transmits radio frequency (RF) signals. When you use your PC card, the system handling your call controls the power level. This power can range from 0.006 watts to 1 watts in digital mode. Knowing Radio frequency Safety The design of your PCS PC card complies with updated NCRP standards described below. In 1991-92, the Institute of Electrical and Electronics Engineers (IEEE) and the American National Standards Institute (ANSI) joined in updating ANSI’s 1982 standard for safety levels with respect to human exposure to RF signals. More than 120 scientists, engineers and physicians from universities, government health agencies and industries developed this updated standard after reviewing the available body of research. In 1993, the Federal Communications Commission (FCC) adopted this updated standard in a regulation. In August 1996, the FCC adopted hybrid standard consisting of the existing ANSI/IEEE standard and the guidelines published by the National Council of Radiation Protection and Measurements (NCRP). Maintaining Your PC card’s Peak Performance There are several simple guidelines to operating your PC card properly and maintaining safe, satisfactory service. • • Use your PC card with the antenna raised, fully-extended pointing up. Try not to hold, bend or twist the PC card’s antenna. • • Don’t use the PC card if the antenna is damaged. • • Avoid exposing your PC card to rain or liquid spills. If your PC card does get wet, immediately turn the power off. If it’s inoperable, return it to a Sprint Store or call PCS Customer Solutions for service. Note: For the best care of your PC card, only Sprint authorized personnel should service your PC card. Faulty service may void the warranty. Maintaining Safe Use of and Access to Your PC Card FAILURE TO FOLLOW THE INSTRUCTIONS OUTLINED MAY LEAD TO SERIOUS PERSONAL INJURY AND POSSIBLE PROPERTY DAMAGE Using Your PC card While Driving • • Using your PC card while driving is not recommended and is prohibited in some jurisdictions. Laws vary as to specific restrictions. Remember that safety always comes first. • • When using your PC card in the car, pull over to the side of the road and park safely before utilizing your PC card. Following Safety Guidelines To operate your PC card safely and efficiently, always follow any special regulations in a given area. Turn your PC card off in areas where use is forbidden or when it may cause interference or danger. Using Your PC card Near Other Electronic Devices • • Most modern electronic equipment is shielded from radio frequency (RF) signals. However, RF signals from wireless PC cards may affect inadequately shielded electronic equipment. • • RF signals may affect improperly installed or inadequately shielded electronic operating systems and/or entertainment systems in motor vehicles. Check with the manufacturer or their representative to determine if these systems are adequately shielded from external RF signals. Also check with the manufacturer regarding any equipment that has been added to your vehicle. • • Consult the manufacturer of any personal medical devices, such as pacemakers and hearing aids, to determine if they are adequately shielded from external RF signals. Note: Always turn off the PC card in health care facilities and request permission before using the PC card near medical equipment. Turning Off Your PC card Before Flying • • Turn off your PC card before boarding any aircraft. To prevent possible interference with aircraft systems, the U.S. Federal Aviation Administration (FAA) regulations require you to have permission from a crewmember to use your PC card while the plane is on the ground. To prevent any risk of interference, FCC regulations prohibit using your PC card while the plane is in the air. Turning Off Your PC card in Dangerous Areas • • To avoid interfering with blasting operations, turn off your PC card when in a blasting area or in other areas with signs indicating that two-way radios should be turned off. Construction crews often use remote-control RF devices to set off explosives. • • Turn off your PC card when you’re in any area that has a potentially explosive atmosphere. Although it’s rare, your PC card or its accessories could generate sparks. Sparks could cause an explosion or a fire resulting in bodily injury or even death. These areas are often, but not always, clearly marked. They include: • • Fueling areas such as gas stations. • • Below deck on boats. • • Fuel or chemical transfer or storage facilities. • • Areas where the air contains chemicals or particles such as grain, just or metal powders. • • Any other area where you would normally be advised to turn off your vehicle’s engine. Vehicles using liquefied petroleum gas (such as propane or butane) must comply with the National Fire Protection Standard (NFPA-58). For a copy of this standard, contact the Nationa…

Text truncated - open the document above for the full version.

Section 5B Regulatory InformationIn This Section

Warning (EMI) - US FCC Information

Warning (EMI) - Canada T his section outlines important regulatory notices concerning your newPCS Connection Card TM . Regulatory Notices This device is compliant with Parts 15 and 24 of the FCC Rules. Operationof this device is subject to the following two conditions:1. This device may not cause harmful interference, and 2. This device must accept any interference received, includinginterference that may cause undesirable operations. FCC guidelines stipulate that the antenna should be more than 2.5 cm(1”) from by-standers and 1.0 cm (0.39”) from the user. When in use, theantenna should be fully extended upward at a 90 degree angle. The highest reported SAR values of the PCS Connection Card - ModelPC3200 are: 1. Separation distance of 2.5 cm (1”) to nearby persons (0.85 W/kg). 2. Direct contact to user's lap with PCS Connection Card inserted intothe top PC Card slot of the laptop computer with antenna fullyextended upward (0.17 W/kg). FCC ID: PNF-PC3200P CAUTION Unauthorized modifications or changes not expressly approved by Sprint Communications Company L.P. could void compliance withregulatory rules and thereby your authority to use this equipment. WARNING (EMI) - United States FCC Information - This equipment has been tested and found to comply with the limits pursuant to Part 15 & 24of the FCC Rules. These limits are designed to provide reasonableprotection against harmful interference in an appropriate installation.This equipment generates, uses, and can radiate radio frequency energyand, if not installed and used in accordance with the instructions, maycause harmful interference to radio communication. However, there is noguarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or televisionreception, which can be determined by turning the equipment off and on,the user is encouraged to try to correct the interference by one or more ofthe following measures:
Reorient or relocate the receiving antenna
Increase the separation between the equipment and receiver
Connect the equipment into an outlet on a circuit different from that towhich the receiver is connected
Consult the dealer or an experienced radio/TV technician for help Safety Information and Terms & Conditions Section 6 Section 6A Safety and NoticesIn This Section
Important Notice
Safety and Hazards T his section outlines important liability and safety guidelines concerningyour new PCS Connection Card TM . Important Notice Because of the nature of wireless communications, transmission andreception of data can never be guaranteed. Data may be delayed, corrupted(i.e., have errors) or be totally lost. Although significant delays or losses ofdata are rare when wireless devices such as the PCS Connection Card -Model PC3200 CDMA modem are used in a normal manner with a well-constructed network, they should not be used in situations where failure totransmit or receive data could result in damage of any kind to the user orany other party, including but not limited to personal injury, death, or lossof property. SPRINT SPECTRUM L.P. accepts no responsibility for damagesof any kind resulting from delays or errors in data transmitted or receivedusing the PCS Connection Card - Model PC3200 CDMA modem, or forfailure of the PCS Connection Card - Model PC3200 to transmit or receivesuch data. Safety and Hazards Do not operate the PCS Connection Card -Model PC3200 in areas whereblasting is in progress, where explosive atmospheres may be present, nearmedical equipment, life support equipment, or any equipment whichmay be susceptible to any form of radio interference. In such areas, thePCS Connection Card - Model PC3200 MUST BE POWERED OFF . It can transmit signals that could interfere with this equipment.Do not operate the PCS Connection Card - Model PC3200 in any aircraft,whether the aircraft is on the ground or in flight. In aircraft, the PCSConnection Card - Model PC3200 MUST BE POWERED OFF . When operating, it can transmit signals that could interfere with variousonboard systems.The driver or operator of any vehicle should not operate the PCS ConnectionCard - Model PC3200 while in control of a vehicle. Doing so will detractfrom the driver or operator's control and operation of that vehicle. In some jurisdictions, operating such communications devices while in control of a vehicle is an offense.

18 Basics 6.Click Finishto complete the installation. 7.Reboot your computer. 8.Insert the PCS Connection Card into your computer’s uuppppeerr PPCCMMCCIIAA ccaarrddsslloott (Sprint label facing up). Then raise the antenna so that it is fully extended and pointed up. Use in any other configuration may exceed FCC RF Exposure limits.

Section 5B Regulatory InformationIn This Section

Warning (EMI) - US FCC Information

Warning (EMI) - Canada T his section outlines important regulatory notices concerning your newPCS Connection Card TM . Regulatory Notices This device is compliant with Parts 15 and 24 of the FCC Rules. This PCcard has been tested with the typical laptop computer with the side loadingPCMCIA bay. This PC card must not be co-located or operated inconjunction with any other antenna or transmitter. Use of this device inany other configuration may exceed the FCC RF Exposure compliancelimit. Operation of this device is subject to the following two conditions:1. This device may not cause harmful interference, and 2. This device must accept any interference received, includinginterference that may cause undesirable operations. FCC guidelines stipulate that the antenna should be more than 2.5 cm(1”) from by-standers and 1.0 cm (0.39”) from the user. When in use, theantenna should be fully extended upward at a 90 degree angle. The highest reported SAR values of the PCS Connection Card - ModelPC3200 are: 1. Separation distance of 2.5 cm (1”) to nearby persons (0.85 W/kg). 2. Direct contact to user's lap with PCS Connection Card inserted intothe top PC Card slot of the laptop computer with antenna fullyextended upward (0.17 W/kg). FCC ID: PNF-PC3200P CAUTION Unauthorized modifications or changes not expressly approved by Sprint Communications Company L.P. could void compliance withregulatory rules and thereby your authority to use this equipment. WARNING (EMI) - United States FCC Information - This equipment has been tested and found to comply with the limits pursuant to Part 15 & 24of the FCC Rules. These limits are designed to provide reasonableprotection against harmful interference in an appropriate installation.This equipment generates, uses, and can radiate radio frequency energyand, if not installed and used in accordance with the instructions, maycause harmful interference to radio communication. However, there is noguarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or televisionreception, which can be determined by turning the equipment off and on,the user is encouraged to try to correct the interference by one or more ofthe following measures:
Reorient or relocate the receiving antenna
Increase the separation between the equipment and receiver
Connect the equipment into an outlet on a circuit different from that towhich the receiver is connected
Consult the dealer or an experienced radio/TV technician for help WARNING (EMI) - Canada - This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus as set out inthe interference causing equipment standard entitled "DigitalApparatus", ICES-003 of the Department of Communications. Cet appareil numérique respecte les limites de bruits radioélectriquesapplicables aux appareils numériques de Classe B prescrites dans lanorme sur le matériel brouilleur: "Appareils Numériques", NMB-003édictée par le ministre des Communications. If you have purchased this product under a United States Governmentcontract, it shall be subject to restrictions as set forth in subparagraph(c)(1)(ii) of Defense Federal Acquisitions Regulations (DFARs) Section252.227-7013 for Department of Defense contracts, and as set forth inFederal Acquisitions Regulations (FARs) Section 52.227-19 for civilianagency contracts or any successor regulations. If further governmentregulations apply, it is your responsibility to ensure compliance with suchregulations.

Section 5B Regulatory InformationIn This Section

Warning (EMI) - US FCC Information

Warning (EMI) - Canada T his section outlines important regulatory notices concerning your newPCS Connection Card TM . Regulatory Notices This device is compliant with Parts 15 and 24 of the FCC Rules. This PCcard has been tested with the typical laptop computer with the side loadingPCMCIA bay. This PC card must not be co-located or operated inconjunction with any other antenna or transmitter. Use of this device inany other configuration may exceed the FCC RF Exposure compliancelimit. Operation of this device is subject to the following two conditions:1. This device may not cause harmful interference, and 2. This device must accept any interference received, includinginterference that may cause undesirable operations. FCC guidelines stipulate that the antenna should be more than 2.5 cm(1”) from by-standers and 1.0 cm (0.39”) from the user. When in use, theantenna should be fully extended upward at a 90 degree angle. The highest reported SAR values of the PCS Connection Card - ModelPC3200 are: 1. Separation distance of 2.5 cm (1”) to nearby persons (0.85 W/kg). 2. Direct contact to user's lap with PCS Connection Card inserted intothe bottom PC Card slot of the laptop computer with antenna in thestowed (down) position (0.782 W/kg). FCC ID: PNF-PC3200P CAUTION Unauthorized modifications or changes not expressly approved by Sprint Communications Company L.P. could void compliance withregulatory rules and thereby your authority to use this equipment. WARNING (EMI) - United States FCC Information - This equipment has been tested and found to comply with the limits pursuant to Part 15 & 24of the FCC Rules. These limits are designed to provide reasonableprotection against harmful interference in an appropriate installation.This equipment generates, uses, and can radiate radio frequency energyand, if not installed and used in accordance with the instructions, maycause harmful interference to radio communication. However, there is noguarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or televisionreception, which can be determined by turning the equipment off and on,the user is encouraged to try to correct the interference by one or more ofthe following measures:
Reorient or relocate the receiving antenna
Increase the separation between the equipment and receiver
Connect the equipment into an outlet on a circuit different from that towhich the receiver is connected
Consult the dealer or an experienced radio/TV technician for help WARNING (EMI) - Canada - This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus as set out inthe interference causing equipment standard entitled "DigitalApparatus", ICES-003 of the Department of Communications. Cet appareil numérique respecte les limites de bruits radioélectriquesapplicables aux appareils numériques de Classe B prescrites dans lanorme sur le matériel brouilleur: "Appareils Numériques", NMB-003édictée par le ministre des Communications. If you have purchased this product under a United States Governmentcontract, it shall be subject to restrictions as set forth in subparagraph(c)(1)(ii) of Defense Federal Acquisitions Regulations (DFARs) Section252.227-7013 for Department of Defense contracts, and as set forth inFederal Acquisitions Regulations (FARs) Section 52.227-19 for civilianagency contracts or any successor regulations. If further governmentregulations apply, it is your responsibility to ensure compliance with suchregulations.

AIRPRIME, INCORPORATED 2290 COSMOS COURT CARLSBAD, CALIFORNIA 92009 (760) 476-8700 MAIN (760) 476-8701 FAX June 26, 2002 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Re: AirPrime Inc. FCC ID: PNF-PC3200P FCC Part 24 Certification Request for Confidentiality Gentlemen: In accordance with 0.459 of CFR 47, AirPrime Inc. hereby requests confidentiality of the Block Diagram Rev 0.2, Theory Of Operation (Circuit Diagrams/Descriptions) Rev 0.2, Schematics, Antenna Electrical Specifications Rev A, Parts List, Tune-up/ Alignment Procedures Rev 1.0, and Technical Description (Product Specification) Rev 0.1/ Rev 1.4 attachments for the subject application. These documents contain detailed system and equipment description and related information about the product in which AirPrime Inc. considers to be proprietary, confidential, and a custom design and, otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, AirPrime Inc. considers that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give competitors an unfair advantage in the market.

Page 1 of 1 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Attention: Martin Perrine / Review Engineer Subject: Worst Mode Declaration Reference: AirPrime Inc. FCC ID: PNF-PC3200P, Confirmation No: EA270526 Dear Martin: Per out telephone conversation took place on Sept 30, 2002, Compliance Certification Services is issuing the following statement for above reference application: 1. Output power listed on the Form 731a will be listed as 0.955W EIRP based upon the measurement result performed by CCS as documented in page 8 and 9 of CCS test report no:02U1373-1. 2. The highest measured SAR value based upon CCS’s SAR test report no:02U1373-2 dated 07/12/2002 and additional SAR test report dated 09/04/2002 are the following : With 2.5cm separation distance from the by-stander with antenna in vertical position in IBM laptop computer is 0.853W/kg. With 0 cm ( direct contact ) separation distance to the flat phantom to simulate lapheld position and the antenna is perpendicular to the flat phantom:0.173W/kg. Above two highest SAR values are in agreement with those values listed in the revised user manual which already submitted to the Commission. 3. The antenna in fold down position has demonstrated the worst SAR conditions by comparing to the antenna in vertical position. If you have any question, please feel free to contact me. Best Regards Mike Kuo / Compliance Certification Services Oct. 01, 2002

Page 1 of 2 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Attention: Martin Perrine / Review Engineer Subject: Worst Mode Declaration Reference: AirPrime Inc. FCC ID: PNF-PC3200P, Confirmation No: EA270526 Dear Martin: Per out telephone conversation took place on Sept 30, 2002, Compliance Certification Services is issuing the following statement for above reference application: 1. Output power listed on the Form 731a will be listed as 0.955W EIRP based upon the measurement result performed by CCS as documented in page 8 and 9 of CCS test report no:02U1373-1. 2. The highest measured SAR value based upon CCS’s SAR test report no:02U1373-2 dated 07/12/2002 and additional SAR test report dated 09/04/2002 are the following : • With 2.5cm separation distance from the by-stander with antenna in vertical position in IBM laptop computer is 0.853W/kg. • With 0 cm ( direct contact ) separation distance to the flat phantom to simulate lapheld position and the antenna is perpendicular to the flat phantom:0.173W/kg. • With 0 cm ( direct contact ) separation distance to the flat phantom to simulate lapheld position and the antenna is in folded down position parallel to the flat phantom :0.782W/kg. Since only the highest SAR value in typical configuration are listed by the manufacturer in the user manual. The user manual has been revised with the following statements: The highest reported SAR values of the PCS Connection Card - Model PC3200 are: 1. Separation distance of 2.5 cm (1 ”) to nearby persons (0.85 W/kg). 2. Direct contact to user's lap with PCS Connection Card inserted into Page 2 of 2 the bottom PC Card slot of the laptop computer with antenna in the stowed (down) position (0.782 W/kg). 3. The antenna in fold down position has demonstrated the worst SAR conditions by comparing to the antenna in vertical position. If you have any question, please feel free to contact me. Best Regards Mike Kuo / Compliance Certification Services Oct. 02, 2002

PROPOSED FCC ID LABEL AND LOCATION FCC ID LABEL AIRPRIME INC. This device complies with Part 24 of FCC rules. FCC ID: PNF-PC3200P PC3220 Product Specification v1.4 AirPrime Confidential and Proprietary Page 23 7.3 Labeling The PC3220 will be labeled on both the top and bottom side. 7.3.1 Top Side Label • Size: 70mm x 40mm (max) • Non-Removable (may be printed on PC3220) • Contents: oOEM Logo oProduct Name 7.3.2 Bottom Side Label • Size: 40mm x 20mm • Non-Removable • Contents: oOEM Part Number oFCC ID oManufacturing Date Code oElectronic Serial Number (ESN) in Hex and Decimal Formats oBar-coded ESN in Hex and Decimal Formats oQualcomm license acknowledgement: ”CDMA by Qualcomm” 7.4 Packaging The PC3220 will comply with customer’s packaging requirements.

Canyon Graphics Corporation .... LABELSNAMEPLATESOVERLAYSMEMBRANESWITCHESINSULATORS .... LABELSNAMEPLATESOVERLAYSMEMBRANESWITCHESINSULATORS CGC 6680 Cobra Way San Diego, California 92121 Company Name: P/N: Rev: Artwork Number: Label Size: Radius: Tolerance: Print Process: Format: Copy Position: Material: Adhesive: Lamination: Job Number: Artist Name: Creation Date: Modification Date: PMS 425C Grey Art Proof Color is shown for placement only. All color will be matched per your documented specification. 6 . 0 0 0 " 10.000" Tel: 858-646-0444 Fax: 858-646-0440 www.canyongraphics.com Air Prime 004-000027-0003 02 003-000035-0002 Rev 02 1.762" x 2.224" 0.079" x 4 +/- .010 Flexo PC 3 SEE PRINT SEE PRINT SEE PRINT 36566 LM 09/10/02 100% 150% die line doesn't print

in accordance with the requirements of FCC Report and Order: ET Docket 93-62, and OET Bulletin 65 Supplement C for WIRELESS PCMCIA CDMA DATA MODEM MODEL: PC3200 FCC ID: PNF-PC3200P JULY 12, 2002 REPORT NO: 02U1373-2 Prepared for AIRPRIME INC. 5201 GREAT AMERICA PKWY. STE. 432 SANTA CLARA, CA 95054, USA Prepared by COMPLIANCE CERTIFICATION SERVICES 561F MONTEREY ROAD, MORGAN HILL, CA 95037, USA TEL: (408) 463-0885 REPORT NO: 02U1373-2 DATE: July 12, 2002 FCC ID: PNF-PC3200P COMPLIANCE CERTIFICATION SERVICES Page: 2 of 23 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. CERTIFICATE OF COMPLIANCE (SAR EVALUATION) Dates of Tests: June 27 & July 11, 2002 Report No: 02U1373-2 APPLICANT: AirPrime Inc 5201 Great America Pkwy. Ste. 432 Santa Clara, CA 95054, USA MODEL: PC3200 FCC ID: PNF-PC3200P DEVICE CATEGORY: PORTABLE DEVICES EXPOSURE CATEGORY: GENERAL POPULATION/UNCONTROLLED EXPOSURE Test Sample is a: Production unit Operating mode: CDMA Tx Frequency: 1851.25 – 1908.75 MHz Rx Frequency: 1931.25 – 1988.75 MHz Max. Output Power (Conducted): 24.48dBm (1851.25MHz) Max. SAR (1g): 0.853mW/g (1851.25MHz) Separation distance: 2.5 cm Application Type: Certification FCC Rule Part(s): 24 (E) This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in FCC OET 65 Supplement C (released on 6/29/2001 see Test Report). I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Steve Cheng EMC Engineering Manager REPORT NO: 02U1373-2 DATE: July 12, 2002 FCC ID: PNF-PC3200P COMPLIANCE CERTIFICATION SERVICES Page: 3 of 23 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. TABLE OF CONTENT 1. EUT DESCRIPTION........................................................................................4 2. MEASUREMENT RESULTS............................................................................5 2.1. SETUP PHOTOS....................................................................................................................................8 3. REQUIREMENTS FOR COMPLIANCE TESTING DEFINED BY THE FCC.............10 4. DOSIMETRIC ASSESSMENT SETUP.............................................................10 4.1. MEASUREMENT SYSTEM DIAGRAM...............................................................................................11 4.2. SYSTEM COMPONENTS....................................................................................................................12 5. MEASUREMENT UNCERTAINTY...................................................................16 6. EUT TUNE-UP PROCEDURE.........................................................................16 7. EVALUATION PROCEDURE.........................................................................17 7.1. SYSTEM VALIDATION.........................................................................................................................18 7.2. SAR EVALUATION PROCEDURE......................................................................................................18 7.3. EXPOSURE LIMIT................................................................................................................................19 8. EUT PHOTOS.................................................................................................20 9. EQUIPMENTS LIST & CALIBRATION STATUS................................................21 10. REFERENCES.............................................................................................22 11. ATTACHMENT............................................................................................23 REPORT NO: 02U1373-2 DATE: July 12, 2002 FCC ID: PNF-PC3200P COMPLIANCE CERTIFICATION SERVICES Page: 4 of 23 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 1. EUT DESCRIPTION APPLICANT: AirPrime Inc 5201 Great America Pkwy. Ste. 432 Santa Clara, CA 95054, USA MODEL: PC3200 FCC ID: PNF-PC3200P DEVICE CATEGORY: PORTABLE DEVICES EXPOSURE CATEGORY: GENERAL POPULATION/UNCONTROLLED EXPOSURE Test Sample is a: Production unit Operating mode: CDMA Tx Frequency: 1851.25 – 1908.75 MHz Rx Frequency: 1931.25 – 1988.75 MHz Max. Output Power (Conducted): 24.48dBm (1851.25MHz) Max. SAR (1g): 0.853mW/g (1851.25MHz) Application Type: Certification Separation distance: 2.5 cm FCC Rule Part(s): 24 (E) Antenna Type: Dipole Antenna Dimensions: 27 mm x 17 mm (L x W) Battery option: N/A 1 Specific Absorption Rate (SAR) is a measure of the rate of energy absorption due to exposure to an RF transmitting source (wireless portable device). 2 IEEE/ANSI Std. C95.1-1992 limits are used to determine compliance with FCC ET Docket 93-62. REPORT NO: 02U1373-…
