PNF-PC3220PDual-Band CDMA PCMCIA Modem Card

23 Basics 22 Basics Part 2: Driver Installation 1.Insert the PCS Connection Card into your computer’s PPCC CCaarrdd sslloott (Sprint label facing up). Then raise the antenna so that it is fully extended and pointed up at a 90 degree angle. Use in any other configuration may exceed FCC RF Exposure limits. WARNING: OOnnccee tthhee ccaarrdd iiss iinnsseerrtteedd,, ddoo nnoott pphhyyssiiccaallllyy rreemmoovvee tthhee WWiirreelleessss PPCC CCaarrdd uunnttiill yyoouu hhaavvee ccoommpplleetteedd tthhee UUnnpplluugg//EEjjeecctt pprroocceessss ddeessccrriibbeedd oonn page 38. TThhiiss mmaayy ccaauussee aa ffaattaall eerrrroorr ttoo yyoouurr nnootteebbooookk ccoommppuutteerr.. 2.Your operating system will determine which Driver Installation instructions you will follow:  Option 1:Hardware Detection for Windows 2000 and Windows ME (page 24)  Option 2:Hardware Detection for Windows 98SE (page 25)  Option 3:Hardware Detection for Windows XP (page 27) 11. Windows 98SE only: You must restart your computer before the new settings will take effect. Click Yesto restart your computer. Note: The following screen shot will appear for Windows 2000 and XP, whereas the same screen shot will appear for Windows 98 and Me after reboot. 12.Click OK to proceed. 13.The PCS Connection Manager will launch. QX Connection Card Start Here-3b 10.30.02.qxd 11/4/2002 12:09 AM Page 22 PC3220 PC Card Regulatory Information In This Section -Warning (EMI)- US FCC Information -Warning (EMI)- Canada This Section outlines important regulatory notices concerning your new PC Card. Section 5: Technical Specifications/Regulatory information 5B: Regulatory Information Regulatory Notices This device is compliant with Parts 15, 22, and 24 of the FCC rules. This PC card has been tested in a typical laptop computer configuration with the side loading PCMCIA bay. This PC card must not be co-location or operated in conjunction with any other antenna or transmitter. Use of this device in any other configuration may exceed the FCC RF Exposure compliance limit. Operation of this device is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesirable operations. FCC guidelines stipulate that the antenna should be more than 1.5 cm (.59”) from by-standers and 1.0cm (0.39”) from the user. When in use, the antenna should be fully extended upward at a 90-degree angle. The highest reported SAR values of the PC card- Model PC3220 are: 1. Separation distance of 1.5 cm (0.59”) to nearby persons (1.26 w/kg). 2. Direct contact to user’s lap with PC card inserted into the bottom PC card slot of the laptop computer with antenna in the stowed (down) position (1.34 w/kg). FCC ID: PNF-PC3220P Caution: Unauthorized modification of this device not expressly approved by the manufacturer could void compliance with RF exposure guidelines. Warning- This equipment has been tested and found to comply with the limits pursuant to Part 15, 22, and 24 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in an appropriate installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction, may cause harmful interference to radio communication. However, there is no guarantee that interference will not occur in a particular installation. [Section 5: Technical Specification/Regulatory Information 5B: Regulatory Information If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna - Increase the separation between the equipment and receiver - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected - Consult the dealer or an experienced radio/TV technician for help WARNING- This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus as set forth in the interference causing equipment standard entitled “Digital Apparatus,” ICES-003 of the Department of Communications. Cet appareil numerique respecte les limites de bruits radioelectriques applicables aux appareils numeriques de Classe B prescrites dans la norme sur le materiel brouilleur. “Appareils Numeriques,” NMB-003 edictee par le ministre de Communications. If you have purchased this product under a United States Government contract, it shall be subject to restrictions as forth in subparagraph (C)(1)(ii) of Defense Federal Acquisitions Regulations (DFARs) Section 252.227-7013 for Department of Defense contracts, and as set forth in Federal Acquisitions Regulations (FARs) Section 52.227-19 for civilian agency contracts or any successor regulations. If further government regulations apply, it is your responsibility to ensure compliance with such regulations. Section 5: Technical Specifications / Regulatory Information 100 5B: Regulatory Information Safety Information And Terms & Conditions Sec. 6 Safety Information and Terms & Conditions ______________________________________________________________ Section 6 A Safety and Notices In this Section - Important Notice - Safety and Hazards This section outlines important liability and safety guidelines concerning your new PC Card. Section 6: Safety Information and Terms and Conditions 6 A: Safety and Notices 105 _____________________________________________ Important Notice Because of the nature of wireless communications, transmission and reception of data can never be guaranteed. Data may be delayed, corrupted (i.e., have errors) or be totally lost. Although significant delays or losses of data are rare when wireless devices such as the PC Card-Model PC3220 CDMA modem are used in a normal …

Text truncated - open the document above for the full version.

1 Copyright © 2003 AirPrime, Inc. All rights reserved. -------------------------------------------------------------------------------------------------------------------------------------- Table of Contents for Help File I. Welcome to the Mobile Connection Manager A. About this Guide B. Checklist C. Owner Records D. About your PC3220 Wireless PC Card Modem E. What is the Mobile Connection Manager? F. Caring for your PC3220 G. What is CDMA H. The Basics II. Installing the Mobile Connection Manager and PC3220 on Your Notebook PC A. System Requirements 1. Cautions and Warning 2. Uninstalling the software 1 B. Installing the Mobile Connection Manager Software 1. Installing the Fourelle Venturi 2.1 Data Compression Software C. Connecting the PC3220 and Drivers to your Notebook PC D. Activating Your PC3220 1. Auto Activation 2. Troubleshooting 3. Manual Activation 4. Establishing a Connection after Activation E. Removing the PC3220 from your Notebook PC F. Establishing a Connection 1. Disconnecting from the network G. Exiting the Mobile Connection Manager III. Using the Mobile Connection Manager (My Mobile Connection Manager) A. Understanding The Indicator Area and Icons 1. Signal Strength Indicator 2. Service Indicator 3. Data Compression 4. Roaming Status 5. Connection Indicator 6. Connection Time 7. Byte Counter 8. Service Status Dialog Box B. Understanding the Action Buttons 1. Settings a. Settings: General Tab b. Settings: Connection Profiles Tab c. Settings: About Tab 2. Call Log 3. Help 4. System Tray Shortcut 2 IV. System Tray Mode (Connection Status Icon and Menu) A. System Tray Icon B. System Tray Menu V. Understanding Alert Windows A. Premium Service Alert B. Call Dropped Alert C. Software Mismatch Alert D. Power On Card Alert E. Connection in Progress Alert F. Delete Connection Profile Confirmation G. Reset Call Log Information VI. Networking and Dial-up Connections A. Windows Networking VII. Frequently Asked Questions VIII. Regulatory Information and Safety and Hazards IX. Technical Specifications A. Environmental Specifications B. Radio Frequency and Electrical Specifications C. Software Specifications D. Mechanical Specifications X.. Licensing Agreement XI. Index ---------------------------------------------------------------------------------------------------------------------- 3 I. Welcome to the Mobile Connection Manager Congratulations and thank you for purchasing the PC3220 Wireless PC Card Modem! The PC3220 is a dual band CDMA2000 1X product that enables you to communicate wirelessly from your laptop. Now that you are equipped with a wireless modem, you no longer need to carry chargers, cables, telephone jack converters, and batteries. This product is simple to install and use. The Mobile Connection Manager software allows you to easily monitor your connections and customize your settings. Note: Before using the PC3220, you MUST review the Safety Information outlined on page XX. A. About this Guide This User’s Guide contains all the information you will need to properly install and use your PC3220 Wireless PC Card Modem. Before you can begin using the PC3220, it is essential that you follow the proper instructions for installation. You must load the Mobile Connection Manager software located on the CD-ROM that was included in your kit before you insert the PC3220 into your notebook PC. This initial setup process just takes a few minutes and you’ll soon be on your way to wireless freedom. B. Checklist Make sure that the following items are included in the kit when you unpack it: 1. A PC3220 Wireless PC Card Modem 2. The Installation CD which contains the Mobile Connection Manager Software and the Fourelle Venturi 2.1 Data Compression Software 3. A Quick Start Guide C. Owner Records Be sure to keep handy your PC Card’s ESN number, located at the bottom of your card, for easy reference. Record your information here for easy reference: ESN Number: ___________________________________ Phone Number: _________________________________ Account Number:_________________________________ D. About your PC3220 Wireless PC Card Modem The PC3220 is a wireless PC Card modem designed to fit into a Type II PC Card slot available on most notebook PCs. This uniquely designed card allows you to connect to the Internet, send and receive email efficiently, connect to your company’s network, and maximize productivity when away from the office. 1. Power Management a. Designed to take advantage of the power management and system overhead benefits offered by the 32-bit CardBus electrical interface that extends battery life. CardBus: another name for “advanced PC Card,” the CardBus interface works at lower battery voltage and operates at a greater speed than the standard PC Card interface. 2. Unique Antenna Design a. The PC3220 includes a patent-pending, proprietary antenna design that optimizes data rate transfer speeds, sensitivity, and increases power efficiency. 4 3. Other Features and Benefits a. A Type II PCMCIA format supporting the CardBus I/O interface b. Supports North American CDMA Cellular (800 MHz) and PCS (1900 MHz) bands- (analog not supported) c. Based on the QUALCOMM MSM5100 chip set d. Supports IS-95A/B and cdma2000 1XRTT Release 0 e. Optimized data rates of up to 153.6 kbps on both the forward and reverse links f. Provides dial-up, 3G and 2G services E. What is the Mobile Connection Manager? The Mobile Connection Manager is an application designed to assist you in managing the PC3220. With this application you can easily monitor and customize your connections. The Mobile Connection Manager Software guides you through the wireless connection process. Similar to a mobile phone display, the user interface of the Mobile Connection Manager instructs you when to insert the PC3220 into your laptop, advises you on network availability, displays the time of your session and amount of data being transferred and received, and when your connection becomes dormant. Other features allow you to cu…

Text truncated - open the document above for the full version.

PC3220 REV6 022803 1 A Quick Start Guide 1. Launch the Mobile Connection Manager installation software and Fourelle Venturi 2.1 data compression software 2. Insert your PC3220 Wireless PC Card into your laptop (Driver Installation) 3. Activating your PC3220 4. Get Connected 5. Exiting the Mobile Connection Manager & Removing the PC3220 About your PC3220 This Quick Start Guide provides a brief overview of the installation and configuration process for your PC3220. Please reference the User’s Guide for complete installation and configuration procedures and for detailed instructions on using your PC3220. The Mobile Connection Manager is an application designed to assist you in managing the PC3220. With this application you can easily monitor and customize your connections. This guide outlines the installation procedures and basic functions of the Mobile Connection Manager. For detailed information on the features of the Mobile Connection Manager, consult the User’s Guide. The Fourelle Venturi 2.1 Data Compression Software is also included on the installation CD. You will be given the option to install this software during the installation process. This data compression software is an enhancing feature available with the PC3220. When you install and enable the Venturi software, data compression will automatically occur wherever Venturi is available on the network. In areas where the Venturi server is implemented, you will notice an increase in the speed of your data connections. CAUTION: Do not insert your PC3220 until you have installed the Mobile Connection Manger software onto your notebook PC. WARNING: Once the card is inserted, do not physically remove the PC3220 from the PC Card slot until you have completed the Unplug/Eject process. Removing the card improperly may cause a fatal error to your PC. Note: Your PC3220 will not work in Handhelds or Pocket PCs Note: If you have previous versions of the Mobile Connection Manager or Fourelle Venturi applications installed on your notebook PC, it is strongly recommended that you remove the application by utilizing the Add/Remove Programs Windows utility. Once removed, proceed with the installation procedures of the current version located on your Installation CD. Go to: Start>Control Panel>Add/Remove Programs. Select Mobile Connection Manager or Fourelle Venturi 2.1 and click Change/Remove. Next select Remove and click OK to proceed when prompted. Your computer will need to restart in order to complete the un-install. System Requirements Your PC3220 functions in notebook PCs with these Windows® operating systems: Windows® 98SE/ME/XP/2000. This card is not designed to function in handhelds and Pocket PCs and does not support Windows CE. 2 In order to install the PC3220 and the Mobile Connection Manager software, these minimum system resources are required: • Card slots: Type II PC Card slot (Cardbus) • Disk-Drive: CD-ROM • Memory: 32 MB • Disk Space: 50 MB • Processor: Pentium 150MHz or higher • Browser: Internet Explorer 6.0 or later Note: Windows Internet Explorer version 6.0 or later is required for the activation stage. You can download and install Internet Explorer from www.microsoft.com/windows/ie/default.asp. Windows 98: You may be prompted during installation that you will need the original Microsoft Windows 98 installation CD. Windows 98 and 2000: To function properly, the PC3220 IOTA protocol requires support for high-security 128-bit encryption. If the installer does not detect high-security support on your system, a pop-up window will appear instructing you to update your Internet Explorer to version 6 (Windows 98SE) or update your Windows 2000 to support 128-bit security (Windows 2000). Follow the onscreen instructions to update your system. 3 Software Installation Installing the Mobile Connection Manager 1. Insert the installation CD into your CD-ROM drive. 2. The Setup program should launch automatically and a Welcome window will appear. If the Setup program does not launch automatically, select Start>Run and enter d:\Setup.exe, where d is the designation for the CD-ROM drive. 3. Click Next on the Mobile Connection Manager Setup Welcome Window. 4. Please read the Licensing Agreement carefully and click Yes to agree to the terms. 5. Click Next to install the software in the default folder. You may choose to install a different folder by clicking the Browse button. 6. If you prefer to have the Mobile Connection Manager launch automatically each time your computer starts up, ensure the Run Mobile Connection Manager at Start up checkbox is checked. If you prefer to add the Mobile Connection Manager shortcut to your desktop, ensure the Desktop Shortcut checkbox is checked. Click Next. Windows 2000 and XP only: Please read the “Signature Not Found” notice and click OK to proceed. 7. Wait for the Setup Status to load 100% and the window will close automatically. Windows 2000 and XP only: This “Digital Signature Not Found” window may appear. Please disregard the notice and click Yes or Continue Anyway to proceed with installation. 8. Installing the Fourelle Venturi 2.1 data compression software is recommended for accelerated performance. Click Yes to install the Fourelle Venturi 2.1 and proceed to step 10. 9. Click Finish and proceed to step 19. NOTE: If you choose to install Venturi later, select No and continue to step 9. Your computer will not restart. 4 Installing Fourelle Venturi 2.1 Data Compression Windows 98 only: a. Click OK. Your computer will restart before installation of Fourelle Venturi begins. Once the Installation screen appears, click Finish. b. You must restart your computer before the new settings will take effect. Click Yes to restart your computer. c. Once your computer does reboot, you will need to manually install Venturi. Go to Start>Run and enter d:\Setup.exe, where d is the designation for the CD-ROM drive. Select Fourelle Venturi 2.1 and click OK. 10. If you haven’t saved and closed other active applications an…

Text truncated - open the document above for the full version.

PC3220_Safety_REV4_03.25.03 Regulatory Information -------------------------------------------------------------- In This Section Warnings This Section outlines important regulatory notices concerning your new PC Card. ---------------------------------------------------------- Regulatory Notices This device complies with Parts 15, 22, and 24 of the FCC rules. This PC card has been tested with the typical laptop computer with the side loading PCMCIA bay. This PC card must not be co- location or operated in conjunction with any other antenna or transmitter. Use of this device in any other configuration may exceed the FCC RF Exposure compliance limit. Operation of this device is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesirable operations. AirPrime, Inc guidelines stipulate that the antenna should be more than 1.5 cm (0.60”) from by- standers and 1.0cm (0.39”) from the user. When in use, the antenna should be fully extended upward at a 90-degree angle. [File Name: 90_generic.jpg] FCC ID: PNF-PC3220P Caution: Unauthorized modification of changed not expressly approved could void compliance with RF exposure guidelines. Warning- This equipment has been tested and found to comply with the limits pursuant to Part 15, 22, and 24 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in an appropriate installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the PC3220_Safety_REV4_03.25.03 instruction, may cause harmful interference to radio communication. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna • Increase the separation between the equipment and receiver • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected • Consult the dealer or an experienced radio/TV technician for help WARNING- This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus as set out in the interference causing equipment standard entitled “Digital Apparatus,” ICES-003 of the Department of Communications. Cet appareil numerique respecte les limites de bruits radioelectriques applicables aux appareils numeriques de Classe B prescrites dans la norme sur le materiel brouilleur. “Appareils Numeriques,” NMB-003 edictee par le ministre de Communications. If you have purchased this product under a United States Government contract, it shall be subject to restrictions as forth in subparagraph (C)(1)(ii) of Defense Federal Acquisitions Regulations (DFARs) Section 252.227-7013 for Department of Defense contracts, and as set forth in Federal Acquisitions Regulations (FARs) Section 52.227-19 for civilian agency contracts or any successor regulations. If further government regulations apply, it is your responsibility to ensure compliance with such regulations. PC3220_Safety_REV4_03.25.03 Safety Information And Terms & Conditions ------------------------------------------------ Safety and Notices In this Section • Important Notice • Safety and Hazards This section outlines important liability and safety guidelines concerning your new PC Card. ---------------------------------- Important Notice Because of the nature of wireless communications, transmission and reception of data can never be guaranteed. Data may be delayed, corrupted (i.e., have errors) or totally be lost. Although significant delays or losses of data are rare when wireless devices such as the PC Card-Model PC3220 CDMA modem are used in a normal manner with a well constructed network, they should not be used in situations where failure to transmit or receive data could result in damage of any kind to the user or another party, including but not limited to personal injury, death or loss of personal property. No responsibility for damages of any kind resulting from delays or errors in data transmitted or received using the PC Card-Model PC3220 CDMA modem, or for failure of the PC Card-Model PC3220 to transmit or receive such data. Safety and Hazards [File Names: explosive.jpg; hospital.jpg; plane.jpg; car.jpg] Do not operate the PC Card-Model PC3220 in areas where blasting is in progress, where explosive atmospheres may be present, near medical equipment, life support equipment, or any equipment which may be susceptible to any form of radio interference. In such areas the PC Card-Model PC3220 MUST BE POWERED OFF. It can transmit signals that could interfere with this equipment. Do not operate the PC Card- Model PC3220 in any aircraft whether the aircraft is on the ground or in flight. In aircraft, the PC Card- Model PC3220 MUST BE POWERED OFF. When operating it can transmit signals that could interfere with various onboard systems. The driver or operator of any vehicle should not operate the PC Card- Model PC3220 while in control of a vehicle. Doing so will detract from the driver or operator’s control and operation of that vehicle. In some jurisdictions, operating such communications devices while in control of a vehicle is an offense. PC3220_Safety_REV4_03.25.03 IX. Technical Specifications A. Environmental Specifications Operating temperature: - 20° to 60° C Storage temperature: - 30° to 65°C Humidity: 60° @ 15 - 95 % RH Vibration stability: Sinusoidal vibration @ 15g peak Mechanical shock @ 50g peak Drop: 1 meter on vinyl surface Contact discharge (Level 2): +/- 1.5k V Air discharge (Level 3): +/- 15k V B. Radio Frequency & Electrical Specifications Approvals: FCC (pa…

Text truncated - open the document above for the full version.

December 12, 2002 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: AIR PRIME, INC. FCC ID: PNF-PC3220P Part 22/24 Certification Gentlemen: Attached herewith, on behalf of AIR PRIME, INC. is an application for Part 22/24 Certification of the Dual-Band CDMA PCMCIA Modem Card. Attached is the applicant’s Letter of Authorization, Confidentiality Request, measurement report data and plots, RF Exposure measurement report, FCC ID label and location, test setup photographs, internal and external photographs, block diagrams (confidential), schematic diagrams & circuit description (confidential), operational description (confidential), antenna specifications (confidential), parts list & tune-up procedure (confidential), and the user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. cc: AIR PRIME, INC.

February 20, 2003 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Mr. Steve Dayhoff SUBJECT: AirPrime, Inc. FCC ID: PNF-PC3220P 731 Confirmation No.: EA408547 Correspondence Reference No.: 24813 Request for Tech. Info.: 2/13/03 Dear Steve: Transmitted herewith, on behalf of AirPrime, Inc. is an amendment provided in response to the request for technical information dated, February 13, 2003. 1. The EUT was tested for radiated power in all three host devices and the highest output power was reported. The EUT produced the highest ERP when it was installed in the Fujitsu Life book laptop. If you have any further questions, please do not hesitate to contact us. Cc: AirPrime, Inc.

March 7, 2003 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Mr. Steve Dayhoff SUBJECT: AirPrime, Inc. FCC ID: PNF-PC3220P 731 Confirmation No.: EA408547 Correspondence Reference No.: 24858 Request for Tech. Info.: 2/27/03 Dear Steve: Transmitted herewith, on behalf of AirPrime, Inc. is an amendment provided in response to the request for technical information dated, February 27, 2003. 1. Please find the attached complete installation and user’s manual. 2. Please find the attached SAR data summary table listing the maximum SAR values per mode, band, host, and distances to the phantom. 3. The applicant intends for the antenna of the device to be operated as described in the user’s manual. SAR tests performed on the “antenna in” position are for informational purposes only. If you have any further questions, please do not hesitate to contact us. Cc: AirPrime, Inc.

March 26, 2003 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Mr. Steve Dayhoff SUBJECT: AirPrime, Inc. FCC ID: PNF-PC3220P 731 Confirmation No.: EA408547 Correspondence Reference No.: 24959 Request for Tech. Info.: 3/17/03 Dear Steve: Transmitted herewith, on behalf of AirPrime, Inc. is an amendment provided in response to the request for technical information dated, March 17, 2003. 1. Please find attached the revised page 27 of the user’s manual, which states, “AirPrime, Inc. guidelines stipulate that the antenna should be more than 1.5 cm (0.60”) from by-standers and 1.0 cm (0.39”) from the user”. 2. Please find attached the revised page 29 of the user’s manual with the correct transmitter power. 3. Please find attached the revised SAR data summary pages with the correct conducted power measurements of 23.5 dBm, which agrees with the SAR plots already submitted. If you have any further questions, please do not hesitate to contact us. Cc: AirPrime, Inc.

© 2002 PCTEST Lab AIR PRIME FCC ID: PNF-PC3220P Dual-Band CDMA PCMCIA Modem Card © 2002 PCTEST Lab AIR PRIME FCC ID: PNF-PC3220P Dual-Band CDMA PCMCIA Modem Card © 2002 PCTEST Lab AIR PRIME FCC ID: PNF-PC3220P Dual-Band CDMA PCMCIA Modem Card © 2002 PCTEST Lab AIR PRIME FCC ID: PNF-PC3220P Dual-Band CDMA PCMCIA Modem Card © 2002 PCTEST Lab AIR PRIME FCC ID: PNF-PC3220P Dual-Band CDMA PCMCIA Modem Card © 2002 PCTEST Lab AIR PRIME FCC ID: PNF-PC3220P Dual-Band CDMA PCMCIA Modem Card © 2002 PCTEST Lab AIR PRIME FCC ID: PNF-PC3220P Dual-Band CDMA PCMCIA Modem Card

© 2002PCTEST Lab FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §§ 2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. (SEE NEXT PAGE) SHEET 1 OF 1SCALE 1:1 SIZE A DRAWING NO. REV. 01003-000035-0004 2290 Cosmos Court Carlsbad, CA 92009 Tel: (760) 476-8700 Fax: (760) 476-8701 PART DESCRIPTION ARTWORK, LABEL, PRODUCT ID, PC 3220 UNLESS OTHERWISE SPECIFIED, DIMENSIONS ARE IN MILLIMETERS WITH TOLERANCE AS FOLLOWS: DIMENSIONS: ANGLES: .X = 0.25 X = 0.5 DEG. .XX = 0.13 X.X = 1 DEG. PROJECT NAME: DIAMOND DRAWN:DATE: 11/21/02 RELEASE DATE:RELEASE LEVEL: APPROVED: DATE: --/--/02 DO NOT SCALE DRAWING UNLESS OTHERWISE NOTED, THIS DOCUMENT CONTAINS AIRPRIME CONFIDENTIAL INFORMATION. REPRODUCTION, USE, DISCLOSURE, OR TRANSMITAL OF ALL OR ANY PORTION OF THIS DOCUMENT IS PROHIBITED, EXCEPT TO THE EXTENT APPROVED BY AIRPRIME. AIRPRIME EXPRESSLY RESERVES ALL RIGHTS UNDER PATENTS, TRADEMARKS, COPYRIGHTS, AND TRADE SECRETS. COPYRIGHT (C) 2001, AIRPRIME, INC. ARTWORK NO. 003-000035-0004 REV.DESCRIPTION ECODATE DRAWN APPD 01 INITIAL RELEASE 11/21/02 230 Scale 2:1 Scale 1:1 PC3220 - "DIAMOND" PRODUCT I.D. LABEL ARTWORK Approved Colors: Pant one 425CV 02 --- A B.G. 11/21/02 Production
