PNK2G4-AVLow Power Audio-Video Transmitter

ELANsat Technologies Inc.

Click to zoom

Application Details

Equipment Class: DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant: Jun 07, 2001
Application Purpose: Original Equipment
Date of Application: Jun 07, 2001
Equipment Note: Low Power Audio-Video Transmitter
Frequency Range: 2414.00000000 - 2468.00000000
Company: ELANsat Technologies Inc.
Country: Taiwan

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Block Diagram

Cover Letter(s)

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 June 1, 2001 RE: ELANsat Technologies Inc. FCC ID: PKN2G4-AV Good Morning, Many of my comments on PNK4M0-EXT also apply here. 1.) The equipment appears to be larger than the palm of the hand. Therefore, the two-part label that now appears in the manual must appear on the equipment. Please follow the guidelines for labels specified in 15.19(a)(3) and 2.925, 2.926. If it is not possible to place the labels on the device, please provide a written explanation. 2.) Please confirm if the radiated testing was performed with the EUT in three orthogonal planes. 3.) Please provide inside photographs of the solder side of the PCBs. Bill William H. Graff Examining Engineer President and Director of Engineering mailto:[email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

Cover Letter(s)

External Photos

ID Label/Location Info

Internal Photos

Operational Description
