POD-ANG8Analog Transceiver

to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy communications. However, there is no guarantee that interference will not occur in a particular installation,If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: and, if not installed and used in accordance with the instructions,may cause harmful interference to radio Changes or modifications not expressly approved by the party responsible for compliance could void the user's NOTE: This equipment has been tested and found to comply with the limits for a class B digital device,pursuant

TYT ELECTRONICS CO., LTD Office of Engineering Technology Date: 31 July 2020 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA FCC ID: POD-ANG8 Subject: Declaration of compliance to the requirements of §15.121 We declare that, this scanning receiver is incapable of operating (tuning), or readily being altered by the users to operate, within the frequency bands allocated to the Cellular Radiotelephone Service in part 22 of this chapter (cellular telephone bands). This device will not be able to receive transmissions in the cellular telephone bands by means of clipping the leads of, or installing, a simple component such as a diode, resistor or jumper wire; replacing a plug-in semiconductor chip; or programming a semiconductor chip using special access codes or an external device, such as a personal computer. This device is also incapable of converting digital cellular communication transmissions to analog voice audio. This device is designed so that the tuning, control and filtering circuitry is inaccessible. Any attempts to modify the equipment to receive transmissions from the Cellular Radiotelephone Service will render the receiver inoperable. This scanning receiver rejects any signals from the Cellular Radiotelephone Service frequency bands that are 38 dB or lower based upon a 12 dB SINAD measurement. We are aware that the modification of this device to receive transmissions from Cellular Radiotelephone Service frequency bands will be considered to constitute manufacture of such equipment. This includes any individual, individuals, entity or organization that modifies one or more scanners. Any modification to receive transmissions from the Cellular Radiotelephone Service frequency bands voids the certification of the scanning receiver, regardless of the date of manufacture of the original unit. If you have any questions, please feel free to contact me. Thank you. Sincerely, Signatory [Jiamao Lin, General Manager]

TYT ELECTRONICS CO., LTD July 30, 2020 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Subject: Explanation of differences between product types FCC ID : POD-ANG8 Model Number: TH-UV8000D, UV8000E To Whom It May Concern: We, The TYT ELECTRONICS CO., LTD hereby declare that the model : UV8000E is identical with the model : TH-UV8000D except the model name. Except for the different above, no other modification is performed. Sincerely, Signature: TYT ELECTRONICS CO., LTD Contact person: Jiamao Lin

TYT ELECTRONICS CO., LTD Agent Authorization Company: TYT ELECTRONICS CO., LTD Address: Block 39-1, Optoelectronics-information industry base, Nan'an, Quanzhou, Fujian, China. Product Name: Analog Transceiver Model Number(s): TH-UV8000D, UV8000E Product Description: Analog Transceiver We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2020-07-30 Name: Jiamao Lin Company: TYT ELECTRONICS CO., LTD

TYT ELECTRONICS CO., LTD Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2020-07-30 Subject; Request for Confidentiality FCC ID: POD-ANG8 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely TYT ELECTRONICS CO., LTD Contact person: Jiamao Lin

External Photos All VIEW OF EUT TOP VIEW OF EUT Antenna BOTTOM VIEW OF EUT FRONT VIEW OF EUT BACK VIEW OF EUT LEFT VIEW OF EUT RIGHT VIEW OF EUT

FCC ID Label Location 40mm&30mm FCC ID: POD-ANG8

Internal Photos OPEN VIEW OF EUT(FIGURE 1) OPEN VIEW OF EUT(FIGURE 2) OPEN VIEW OF EUT(FIGURE 3) INTERNAL VIEW OF EUT(FIGURE 1) INTERNAL VIEW OF EUT(FIGURE 2) INTERNAL VIEW OF EUT(FIGURE 3) GMRS Antenna INTERNAL VIEW OF EUT(FIGURE 4) INTERNAL VIEW OF EUT(FIGURE 5) INTERNAL VIEW OF EUT(FIGURE 6) INTERNAL VIEW OF EUT(FIGURE 7) INTERNAL VIEW OF EUT(FIGURE 8) INTERNAL VIEW OF EUT(FIGURE 9) INTERNAL VIEW OF EUT(FIGURE 10) INTERNAL VIEW OF EUT(FIGURE 11) INTERNAL VIEW OF EUT(FIGURE 12) INTERNAL VIEW OF EUT(FIGURE 13) INTERNAL VIEW OF EUT(FIGURE 14) INTERNAL VIEW OF EUT(FIGURE 15) INTERNAL VIEW OF EUT(FIGURE 16)

Page 1 of 33 FCC ID : POD-ANG8 PRODUCT DESIGNATION : Analog Transceiver BRAND NAME : TYT MODEL NAME : TH-UV8000D, UV8000E APPLICANT : TYT ELECTRONICS CO., LTD DATE OF ISSUE : Jul. 22, 2020 STANDARD(S) : FCC Part 15 Rules REPORT VERSION : V 1.0 Attestation of Global Compliance (Shenzhen) Co., Ltd CAUTION: This report shall not be reproduced except in full without the written permission of the test laboratory and shall not be quoted out of context. FCC Test Report Report No.: AGC02931200610FE08 Report No.: AGC02931200610FE08 Page 2 of 33 Report Revise Record Report Version Revise Time Issued Date Valid Version Notes V1.0 / Jul. 22, 2020 Valid Initial Release Report No.: AGC02931200610FE08 Page 3 of 33 TABLE OF CONTENTS 1. VERIFICATION OF COMPLIANCE ..........................................................................................4 2. PRODUCT INFORMATION ......................................................................................................5 3. IDENTIFICATION OF THE RESPONSIBLE TESTING LOCATION .........................................6 4. SUPPORT EQUIPMENT LIST ..................................................................................................7 5. SYSTEM DESCRIPTION ..........................................................................................................7 6. SUMMARY OF TEST RESULTS ..............................................................................................8 7. FCC RADIATED EMISSION TEST ...........................................................................................9 7.1. TEST EQUIPMENT OF RADIATED EMISSION .................................................................................. 9 7.2. LIMITS OF RADIATED EMISSION TEST ............................................................................................ 9 7.3 BLOCK DIAGRAM OF RADIATED EMISSION TEST ......................................................................... 10 7.4 PROCEDURE OF RADIATED EMISSION TEST ................................................................................ 11 7.5 TEST RESULT OF RADIATED EMISSION TEST .............................................................................. 12 8. CONDUCTED EMISSION TEST ............................................................................................. 20 8.1 PROVISIONS APPLICABLE ............................................................................................................... 20 8.2 MEASUREMENT PROCEDURE ........................................................................................................ 20 8.3 TEST SETUP BLOCK DIAGRAM ....................................................................................................... 21 8.4 TEST RESULT .................................................................................................................................... 22 9. ANTENNA CONDUCTED POWER FOR RECEIVERS .......................................................... 26 10. SANNING RECEIVERS AND FREQUENCY CONVERTERS USED WITH SANNING RECEIVERS. .............................................................................................................................. 29 APPENDIX 1 PHOTOGRAPHS OF TEST SETUP ..................................................................... 31 Report No.: AGC02931200610FE08 Page 4 of 33 1. VERIFICATION OF COMPLIANCE Applicant TYT ELECTRONICS CO., LTD Address Block 39-1, Optoelectronics-information industry base, Nan'an, Quanzhou, Fujian, China. Manufacturer TYT ELECTRONICS CO., LTD Address Block 39-1, Optoelectronics-information industry base, Nan'an, Quanzhou, Fujian, China. Factory TYT ELECTRONICS CO., LTD Address Block 39-1, Optoelectronics-information industry base, Nan'an, Quanzhou, Fujian, China. Product Designation Analog Transceiver Brand name TYT Test Model TH-UV8000D Series Model UV8000E Declaration of Difference All the same, only model different. Measurement Procedure ANSI C63.4: 2014 Date of test Jun. 23, 2020~Jul. 22, 2020 Deviation No any deviation from the test method. Condition of Test Sample Normal Test Result Pass The above equipment was tested by Attestation Of Global Compliance (Shenzhen) Co., Ltd. for compliance with the requirements set forth in the FCC Rules and Regulations Part 15, the measurement procedure according to ANSI C63.4:2014. This said equipment in the configuration described in this report shows the maximum emission levels emanating from equipment are within the compliance requirements. The test results of this report relate only to the tested sample identified in this report. Prepared By Calvin Liu (Project Engineer) Jul. 22, 2020 Reviewed By Max Zhang (Reviewer) Jul. 22, 2020 Approved By Forrest Lei (Authorized Officer) Jul. 22, 2020 Report No.: AGC02931200610FE08 Page 5 of 33 2. PRODUCT INFORMATION The EUT is a Analog Transceiver designed for voice communication. It is designed by way of utilizing the F3E modulation achieves the system operating. A major technical description of EUT is described as following: Communication Type Voice / Tone only Modulation FM RX Frequency Range RX: 136MHz-174MHz, 400MHz -520MHz Emission Type F3E Antenna Designation Detachable Antenna Type Integral Antenna Antenna Gain Long antenna: 1.5dBi Short antenna: 1.5dBi Power Supply DC 7.4V, 3600mAh by battery Adapter Parameter Input: AC 100-240V 50/60Hz, 0.2A Output: DC 12V 0.5A Charger Parameter Input: DC 12V 0.5A Output: DC 8.4V 400mA I/O Port Information (Applicable Not Applicable) I/O Port of EUT I/O Port Type Q’TY Cable Tested with Antenna Port 1 0 1 Report No.: AGC02931200610FE08 Page 6 of 33 3. IDENTIFICATION OF THE RESPONSIBLE TESTING LOCATION List Of Test Equipment: TEST EQUIPMENT OF CONDUCTED EMISSION TEST Equipment Manufacturer Model S/N Cal. Date Cal. Due TEST RECEIVER R&S ESCI 10096 May 15, 2020 May 14, 2022 AMN/LISN R&S ESH2-Z5 100086 Aug. 22, 2019 Aug. 21, 2020 TEST SOFTWARE FR EZ-EMC AGC-CON03 A -- -- TEST EQUIPMENT OF RADIATED EMISSION TEST Equipment M…

Text truncated - open the document above for the full version.

Test Setup Photos CONDUCTED EMISSION TEST SETUP-LONG ANTENNA CONDUCTED EMISSION TEST SETUP-SHORT ANTENNA RADIATED EMISSION TEST SETUP-BELOW 1GHZ-LONG ANTENNA RADIATED EMISSION TEST SETUP-BELOW 1GHZ-SHORT ANTENNA RADIATED EMISSION TEST SETUP-ABOVE 1GHZ-LONG ANTENNA RADIATED EMISSION TEST SETUP-ABOVE 1GHZ-SHORT ANTENNA
