POQWCE-100SUCDMA Cellular Phone

FCC RF EXPOSURE INFORMATION In August 1996 the Federal Communications Commission (FCC) of the United States with its action in Report and Order FCC 96-326 adopted an updated safety standard for human exposure to radio frequency (RF) electromagnetic energy emitted by FCC regulated transmitters. Those guidelines are consistent with the safety standard previously set by both U.S. and international standards bodies. The design of this phone complies with the FCC guidelines and these international standards. Use only the supplied or an approved antenna. Unauthorized antennas, modifications, or attachments could impair call quality, damage the phone, or result in violation of FCC regulations. Do not use the phone with a damaged antenna. If a damaged antenna comes into contact with the skin, a minor burn may result. Please contact your local dealer for replacement antenna. Body-worn Operation This device has been tested for body-worn operation and meets FCC RF exposure guidelines when used with an accessory that contains no metal components, and positions the handset at a minimum of 2.0cm from the body. Use of other body-worn accessories may not ensure compliance with FCC RF exposure guidelines and should be avoided. For more information about RF exposure, please visit the FCC website at www.fcc.gov Read this information before using your phone

C o n t e n t s Precautions Checking supplied accessories I c o n s Identifying the parts of the phone Installing, removing and charging the battery Installing, and removing the RUIM Card Advanced Features Power On / Off Standby Mode Receiving a Call Making a Call Ending a Call Menu While Call is in Process Missed Calls / Auto Redial Pause Dialing Short cut Keys Getting started 1. CALL 1 . Outgoing 2 . Incoming 3 . Missed calls 4 . Call Timer 2. PHONE BOOK 1 . Find Entry 2 . Add Entry 3 . Edit Group 3. PIM (Personal Information Manager) 1 . View Schedule 2 . Add Schedule 3 . Alarm 4 . World Time 4. RING 1 . Ring Type 2 . Ring Volume 3 . Ring Tone 5. SOUNDS 1 . Call Volume 2 . Key Pad Tones 3 . 1 Minute Beep 4 . No Service 6. DISPLAY 1 . B a c k l i g h t 2 . Standby 3 . B a n n e r 4 . Language 5 . V e r s i o n 6 . C o n t r a s t 7. SETUP 1 . Auto Redial 2 . Auto Answer 3 . Auto Hyphen 4 .Area Code Rules 8. SECURITY 1 . L o c k 2 . Lock Code 3 . Restrict 4 . Clear Memory 5 . Emergency # 6 . Reset Phone 9. DATA SERVICE 1 . SIO Mode 2 . Incoming Mode 10. SMS 1 . SMS Inbox 2 . SMS Outbox 3 . SMS Setup Menu Tree A p p e n d i x Look 7.Setup for 1.Auto Redial feature. 1. Calls Outgoing/Incoming/Missed calls/Call Timer 2. Phone Book Find Entry/Add Entry/ Edit Group 3. 4. Ring 5.Sounds 6.Display 7.Setup 8.Security 9.Data Service 10.SMS 1. Calls • View and dial the outgoing or incoming numbers. • Delete the numbers in the Call log memory. • View a list of calls you did not answer. • View call duration. ---- Outgoing ------------------------------------------- • The last 20 dialed numbers are displayed. • You can delete individual numbers from the outgoing call list. Menu ? 1. Calls ? 1. Outgoing ? Select a number list Each number in your outgoing call list will have one of the below icons Next to it depending on what type of call was made or if you were just making a note. ? You can select a phone number from the displayed list and delete or store it in the phone book. ? To place a call to the selected number, press ? To delete a number from the outgoing call list: - Follow above steps. - Highlight number you wish to delete. - Choose the view option. - Select delete. - Choose next. ? To save a number from the outgoing call list: - Follow above steps. - Highlight number you wish to save. - Choose the view option. - Select save. - Phone will prompt you to save the number as either home, office, mobile and other, select an option. - You may then edit accordingly a name of category to each saved entry. - Phone then asks if you want to make the number private, choose yes or no to save number. ---- Incoming ------------------------------------------- • The last 20 incoming calls are displayed in sequence. • You can delete individual numbers. Menu ? 1. Calls ? 2. Incoming ? Select a number list Each number in your incoming call list will have one of the below icons next to it. ? Follow the same steps as listed delete numbers from the outgoing call list. ? You can also save numbers from the incoming call list by entering your incoming call menu and following the same steps as listed to save numbers from the outgoing call list. ? To place a call to the selected number, press ---- Missed Calls ------------------------------------------- • The last 20 missed calls are displayed. Menu ? 1. Calls ? 3. Missed Calls ? Select a number list Each number in your missed call list will have one of the below icons next to it. ? Follow the same steps as listed delete numbers from the outgoing call list. ? You can also save numbers from the Missed call list by entering your Missed Calls menu and following the same steps as listed to save numbers from the outgoing call list. ? To place a call to the selected number, press ---- Call Timers ------------------------------------------- • This menu displays the duration of your last call, outgoing calls and the total duration of all of your incoming and outgoing calls. Menu ? 1. Calls ? 4. Call Timers ? Select an option 2 Phone Book • This menu is designed to store and retrieve phone numbers. • You can categorize each stored contact as family, friend, work or any of three use defined category choices. • You can store up to 200 contacts in your phone book. • The icons used in your phone book are as follows. Menu ? 2. Phone Book ? 1. Find Entry ? Select an option Select 1.Find Entry ? ? Enter the desired name and press ? [view] [DELETE] The selected items is deleted. ? [EDIT] The selected items is edited. See page ?? (메뉴얼작성후 삽입) for entering characters. Select 1.Find Entry ? ? Enter the desired location and press ? [view] [DELETE] The selected items is deleted. ? [EDIT] The selected items is edited. Select 1.Find Entry ? ? Enter the desired number and press ? [view] [DELETE] The selected items is deleted. ? [EDIT] The selected items is edited Select 1.Find Entry ? ? Enter the desired group and press ? [view] [DELETE] The selected items is deleted. ? [EDIT] The selected items is edited Menu ? 2. Phone book ?2. Add Entry ? Enter the name and and press [save] [EDIT] Go to entry mode. ? Select an item ? [SAVE] It is stored in the Phone Book. See page ?? (메뉴얼 완성후 삽입) for additional information on entering characters. Menu ? 2. Phone Book ? 3. Edit Group ? Select an option Select 3. Edit Group ? Select 3. Edit Group ? Select [SAVE] and press [OK]. Select 3. Edit Group ? Select 3. Edit Group ? ? Select a Group ? Choose a ring tone. 3 Menu ? 3. PIM ? 1. View Schedule ? After Select the required date, press [select] [DELETE] Deletes the selected item. ? Select an item ? [VIEW] The day’s schedule is displayed. [VIEW] ??( 메뉴얼 완성후 page 삽입 ). Menu ? 3. PIM ? 2. Add Schedule ? After Select the required date ? [select] Select the type ? Setup time and press [TEXT] ? Input the message for details. [SAVE] After inputting the message for details, you can set reminder alarm. The [NEXT] key toggles the reminder alarm yes and no. Menu ? 3. PIM ? 3. Alarm ? Select an option Select 3. Alarm ? ? Se…

Text truncated - open the document above for the full version.

FCC ID: POQWCE-100SU Acknowledging Special Precautions and the FCC Industry Canada Notice Cautions Modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance Information This device complies with part 15 of FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received. Including interference that may cause undesired operation. Information to User This equipment has been tested and found to comply with the limits for a Class B digital device, Pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio Frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ▪ Reorient or relocate the receiving antenna. ▪ Increase the separation between the equipment and receiver ▪ Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help.

Marianne Bosley From: Kyung-Taek LEE [[email protected]] Sent: Thursday, July 31, 2003 9:55 PM To: [email protected] Subject: RE: FCC ID:POQWCE100-SU--add Documents 8/4/2003 Hello, I send again the Ddcument.( 4.0 version of adobe). I informed our customer about adding the users infor page, and he confirmed it. Thanks and best regards. K.T. Lee Digital EMC Co., Ltd. -----Original Message----- From: [email protected] [mailto:[email protected]] Sent: Friday, August 01, 2003 3:13 AM To: [email protected] Cc: [email protected] Subject: RE: FCC ID:POQWCE100-SU--add Documents Thank you for such a quick response. Some problems remain. The following still have opening errors - the error appear to be the lack of coordination between our adobe and the Korean version? Is it possible to send it ffrom a version of adobe without that? Still need, free of error: 1.Manual 2.Schematics Also, please confirm in your email that you will be adding the users info page that you sent to me in your manual. Any questions, please let me know. Regards, Marianne Marianne Bosley -----Original Message----- From: Kyung-Taek LEE [mailto:[email protected]] Sent: Thursday, July 31, 2003 5:31 AM To: [email protected] Subject: FCC ID:POQWCE100-SU--add Documents

Modottel Co., Ltd. 2F., DongNam B/D., 448-16, ShinGil-5Dong, YngDungPo-Ku, Seoul, Korea o Tel:+82-2-868-3030 Fax: +82-2-847-9992 Aug 08, 2003 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 In re : Modottel Co., Ltd. FCC ID : POQWCE-100SU FCC Part 22 Certification Request for Confidentiality Gentlemen: In accordance with 0.459 of CFR 47, Modottel Co., Ltd hereby requests confidentiality of the Block diagram, Circuit diagrams, Schematics, Circuit description, Parts list, Tune-up Procedure, Operational Description of the attached test report. These documents contain detailed system and equipment description and related information about the product which Modottel Co., Ltd considers to be proprietary, confidential, and a custom design and, otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, Modottel Co., Ltd. considers that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Sincerely, Joong-ill Hwang Principal Engineer Modottel Co., Ltd

FCC ID : POQWCE-100SU ATTACHMENT G - External Photographs DIGITAL EMC FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU

DIGITALEMC SAR REPORT FCC CERTIFICATION Reviewed by: Quality Manager Test report S/N : DR50110307F Test Date: July.22-July.25,2003 Phone Type: Single-Band CDMA FCC ID: POQWCE-100SU Page 1 of 30 DIGITAL EMC CO., LTD. 683-3, Yubang-Dong, Yongin-Si, Kyunggi-Do, Korea. 449-080 Tel: +82-31-321-2664 Fax: +82-31-321-1664 http://www.digitalemc.com CERTIFICATE OF COMPLIANCE(SAR EVALUATION) MODOTTEL Co.,Ltd. Dates of Tests: July 22~25,2003 2F.,DongNam B/D,448-16,Shingil-5Dong, Test Report S/N:DR50110307F YoungDeungPo-Ku,Seoul 150-851,Korea Test Site : DIGITAL EMC CO., LTD. Attn:Joong-Ill Hwang(Principle Engineer) FCC ID APPLICANT EUT Type: Single-Band Cellular Phone (CDMA) TX Frequency Range: 824.70 ~848.31 MHz (CDMA) RX Frequency Range: 869.70 ~893.31 MHz (CDMA) Max.RF Output Power: 0.333W ERP CDMA (25.23dBm)/23.5dBm conducted(CDMA) Max. SAR Measurement: 1.46W/kg CDMA Head SAR (RUIM REAR COVER) 0.689W/kg CDMA Body SAR (RUIM REAR COVER) 1.29W/kg CDMA Head SAR (Nomal REAR COVER) 0.685W/kg CDMA Body SAR (Nomal REAR COVER) Model(s): WCE-100SU FCC Classification: Non-Broadcast Transmitter Held to Ear(TNE) FCC Rule Part(s): §2.1093; FCC/OET Bulletin Supplement C[July 2001] Application Type: Certification Test Device Serial No.: Identical prototype This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in FCC/OET Bulletin 65 Supplement C (2001) and IEEE Std. 1528-200X (Draft 6.4, July 2001). I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. . D.M.JUNG (Manager) POQWCE-100SU MODOTTEL Co.,Ltd. DIGITALEMC SAR REPORT FCC CERTIFICATION Reviewed by: Quality Manager Test report S/N : DR50110307F Test Date: July.22-July.25,2003 Phone Type: Single-Band CDMA FCC ID: POQWCE-100SU Page 2 of 30 1. INTRODUCTION ...................................................................................................... 3 SAR DEFINITION .................................................................................................... 3 2. SAR MEASUREMENT SETUP......................................................................................... 4 Robotic System.......................................................................................................... 4 System Hardware ....................................................................................................... 4 System Electronics...................................................................................................... 4 3. DASY3 E-FIELD PROBE SYSTEM................................................................................... 5 Probe Measurement System......................................................................................... 5 Probe Specifications .................................................................................................... 5 4. Probe Calibration Process............................................................................................ 6 Dosimetric Assessment Procedure.................................................................................. 6 Free Space Assessment ............................................................................................... 6 Temperature Assessment ............................................................................................ 6 5. PHANTOM & EQUIVALENT TISSUES.............................................................................. 7 SAM Phantom ........................................................................................................... 7 Brain & Muscle Simulating Mixture Characterization ....................................................... 7 Device Holder for Transmitters..................................................................................... 7 6. TEST SYSTEM SPECIFICATIONS.................................................................................. 8 Automated Test System Specifications.......................................................................... 8 7. DOSIMETRIC ASSESSMENT & PHANTOM SPECS ........................................................... 9 Measurement Procedure............................................................................................. 9 Specific Anthropomorphic Mannequin (SAM) Specifications.............................................. 9 8. DEFINITION OF REFERENCE POINTS .......................................................................... 10 EAR Reference Point................................................................................................... 10 Handset Reference Points............................................................................................ 10 9. TEST CONFIGURATION POSITIONS ............................................................................. 11 Positioning for Cheek/Touch ........................................................................................ 11 Positioning for Ear /15° Tilt ......................................................................................... 11 Body Holster /Belt Clip Configurations .......................................................................... 13 10. ANSI/IEEE C95.1 - 1992 RF EXPOSURE LIMITS.......................................................... 14 Uncontrolled Environment ........................................................................................... 14 Controlled Environment............................................................................................... 14 11. MEASUREMENT UNCERTAINTIES...............................…

Text truncated - open the document above for the full version.

835MHz Validation SAM(835M) Phantom; Flat Section; Probe: ET3DV6 - SN1703; ConvF(6.80,6.80,6.80); Med. parameter 835 MHz Brain: σ = 0.89 mho/m ε r = 39.6 ρ = 1.00 g/cm 3 ; Antenna Position -- In; Crest factor: 1.0; SAR (1g): 2.51 mW/g, SAR (10g): 1.60 mW/g Dipole validation: for f < 1 GHz, distance to the liquid d = 15 mm for f > 1 GHz, distance to the liquid d=10 mm SAR Tot [mW/g] 3.23E-16.46E-19.69E-11.29E+01.62E+01.94E+02.26E+02.58E+02.91E+03.23E+0 Digital EMC Co.,Ltd

FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU

FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU

FCC ID : POQWCE-100SU ATTACHMENT F – TEST PLOTS DIGITAL EMC FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU FCC ID : POQWCE-100SU

DIGITALEMC PT.22 REPORT FCC CERTIFICATION Reviewed by: Quality Manager Test Report S/N: DR50110307H Test Date: July 24~29,2003 Phone Type: Single Mode CDMA FCC ID: POQWCE-100SU Page 1 of 16 DIGITAL EMC CO., LTD. 683-3, Yubang-Dong, Yongin-Si, Kyunggi-Do, Korea. 449-080 Tel: +82-31-321-2664 Fax: +82-31-321-1664 http://www.digitalemc.com CERTIFICATE OF COMPLIANCE FCC Part 22 Certification MODOTTEL Co.,Ltd. Dates of Tests: July 24~29,2003 2F.,DongNam B/D,448-16,Shingil-5Dong, Test Report S/N:DR50110307H YoungDeungPo-Ku,Seoul 150-851,Korea Test Site : DIGITAL EMC CO., LTD. Attn:Joong-Ill Hwang(Principle Engineer) FCC ID APPLICANT Classification: Non-Broadcast Transmitter Held to Ear(TNE) FCC Rule Part(s): §22.901(d), §2 EUT Type: Single-Band Cellular Phone (CDMA) Model(s): WCE-100SU TX Frequency Range: 824.70 ~848.31 MHz (CDMA) RX Frequency Range: 869.70 ~893.31 MHz (CDMA) Max. RF Output Power: 0.333W ERP CDMA (25.23dBm) Max. SAR Measurement: 1.46W/kg CDMA Head SAR (RUIM REAR COVER) 0.689W/kg CDMA Body SAR (RUIM REAR COVER) 1.29W/kg CDMA Head SAR (Nomal REAR COVER) 0.685W/kg CDMA Body SAR (Nomal REAR COVER) Emission Designators: 1M25F9W(CDMA) Test Device Serial No.: Identical prototype This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the Measurement procedures specified in §2,947. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. D.M.JUNG (Manager) POQWCE-100SU MODOTTEL Co.,Ltd. DIGITALEMC PT.22 REPORT FCC CERTIFICATION Reviewed by: Quality Manager Test Report S/N: DR50110307H Test Date: July 24~29,2003 Phone Type: Single Mode CDMA FCC ID: POQWCE-100SU Page 2 of 16 TABLE OF CONTENTS ATTACHMENT A:COVER LETTER(S) ATTACHMENT B: ATTESTATION STATEMENT(S) ATTACHMENT C: TEST REPORT 1.1 SCOPE 3 2.1 INTRODUCTION 4 3.1 INSERTS 4 4.1 DESCRIPTION OF TESTS 5-6 5.1 EFFECTIVE RADIATED POWER OUTPUT 7 6.1 RADIATED MEASUREMENTS 8-10 7.1 FREQUENCY STABILITY 11-12 8.1 PLOTS OF EMISSIONS 13 9.1 LIST OF TEST EQUIPMENT 14 10.1 SAMPLE CALCULATIONS 15 11.1 CONCLUSION 16 ATTACHMENT D: TEST PLOTS ATTACHMENT E: FCC ID LABEL & LOCATION ATTACHMENT F: TEST SETUP PHOTOGRAPHS ATTACHMENT G: EXTERNAL PHOTOGRAPHS ATTACHMENT H: INTERNAL PHOTOGRAPHS ATTACHMENT I : BLOCK DIAGRAM(S) ATTACHMENT J: SCHEMATIC DIAGRAM(S) ATTACHMENT K: OPERATIONAL / CIRCUIT DESCRIPTION ATTACHMENT L: PARTS LIST/TUNE UP PROCEDURE ATTACHMENT M: USER’S MANUAL ATTACHMENT O: SAR MEASUREMENTS REPORT ATTACHMENT P: SAR TEST DATA ATTACHMENT Q: SAR TEST SETUP PHOTOGRAPHS ATTACHMENT R: DIPOLE VALIDATION(S) ATTACHMENT S: PROBE CALIBRATION DIGITALEMC PT.22 REPORT FCC CERTIFICATION Reviewed by: Quality Manager Test Report S/N: DR50110307H Test Date: July 24~29,2003 Phone Type: Single Mode CDMA FCC ID: POQWCE-100SU Page 3 of 16 MEASUREMENT REPORT 1.1 Scope Measurement and determination of electromagnetic emissions (EME) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission. §2.1033 General Information z FCC ID: z Quantity: z Emission Designators: z Tx Freq. Range: z Rx Freq. Range: z Max. Power Rating: z FCC Classification(s): z Equipment (EUT) Type: z Modulation(s): z Frequency Tolerance: z FCC Rule Part(s): z Dates of Tests: z Place of Tests: z Test Report S/N: POQWCE-100SU Quantity production is planned 1M25F9W (CDMA) 824.70 ~848.31 MHz (CDMA) 869.70 - 893.31 MHz (CDMA) 0.333 ERP CDMA (25.23 dBm) Non-Broadcast Transmitter Held to Ear(TNE) Single-Band Cellular Phone (CDMA) CDMA ± 0.00025 % (2.5ppm) §22.901(d), §2 July 24~29,2003 DIGITAL EMC DR50110307H Applicant: MODOTTEL Co.,Ltd. Address : 2F.,DongNam B/D,448-16,Shingil-5Dong, YoungDeungPo-Ku,Seoul 150-851,Korea Attention: Joong-Ill Hwang(Principle Engineer) DIGITALEMC PT.22 REPORT FCC CERTIFICATION Reviewed by: Quality Manager Test Report S/N: DR50110307H Test Date: July 24~29,2003 Phone Type: Single Mode CDMA FCC ID: POQWCE-100SU Page 4 of 16 2.1 INTRODUCTION Quality control in the testing laboratory is implemented as per ISO/IEC 17025 which is the “General requirements for the competents of calibration and testing laboratory”. This laboratory is accredited by NVLAP for NVLAP Lab. Code : 200559-0. DIGITAL EMC CO., LTD. Address : 683-2, Yubang-Dong, Yongin-Si, Kyunggi-Do, Korea. 449-080 http://www.digitalemc.com E-mail : [email protected] Tel: +82-31-321-2664 Fax: +82-31-321-1664 3.1 INSERTS Function of Active Devices (Confidential) The Function of active devices are shown in Attachment K. Block & Schematic Diagrams (Confidential) The block diagrams are shown in Attachment I, and the schematic diagrams are shown in Attachment J. Operating Instructions The instruction manual is shown in Attachment M. Parts List & Tune-Up Procedure (Confidential) The parts list & tune-up procedure is shown in Attachment L. Description of Freq. Stabilization Circuit (Confidential) The description of frequency stabilization circuit is shown in Attachment K. Description for Suppression of Spurious Radiation, for Limiting Modulation, and Harmonic Suppresion Circuits (Confidential) The description of suppression stabilization circuits is shown in Attachment K. DIGITALEMC PT.22 REPORT FCC CERTIFICATION Reviewed by: Quality Manager Test Report S/N: DR50110307H Test Date: July 24~29,2003 Phone Type: Single Mode CDMA FCC ID: POQWCE-100SU Page 5 of 16 4.1 DESCRIPTION OF TESTS 4.2 Occupied Bandwidth Emission Limits (a) On any frequency outside a licensee’s frequency block, the power of any emission shall be attenuated below the transmitter power (P) by at least 43 + 10 log(P) dB. (b) When measuring the emission limits, the nominal carrier frequenc…

Text truncated - open the document above for the full version.

TCBF009-2 rev 10 July 2003 Page 1 of 1 FCC GRANT OF EQUIPMENT AUTHORIZATION APPLICATION ALL RULE PARTS OTHER THAN 11, 15, AND 18 (PLEASE COMPLETE QUESTIONAIRE) 1. Type or types of emissions: _____Nom-Broadcast Transmitter Held to Ear (TNE)_______________________ 2. Frequency Range ______824.7-848.31MHz_____________________________________________________ 3. Range of operating power values or specific operating power levels, and description of any means provided for variation of operating power _____________________________________________________________________ _________________ ERP 21 ~ 25dBm (Conducted level 23.5dBm) _____________________________________ 4. Maximum power rating as defined in the applicable rule part(s) ______________________________________ __________________ERP Max level 25.23 dBm(Conducted level 23.5dBm)______________________________ 5. dc voltages applied to and dc currents into the several elements of the final radio frequency amplifying device for normal operation over the power range _____________________________________________________________ _________Normal voltage:3.7Vdc / BATT. endpoint 2.97Vdc___________________________________________
