PP4HWP-130Fixed WLL Telephone (CDMA)

Wireless Local Loop Fixed Wireless HWPl30& 230 User’s Guide 4 Y U W D A I 7. lnfroducfion The WLL (Wireless Local Loop) terminal is designed to provide userS with full range of communication services in CDMA (Code Division Multiple Access) networks. Before using the produd, please read carefully this chapter. HWP -1 301230 Main Features -1S-95B support Data rate: 64kbps (ma) Backward compatibility New Sofl Handoff Algorithm Enhanced Hard Handoff True IMSl (International Mobile Subscriber Identification) PC Fax TransmittinglReceiving Modem Originatiorfrermination -. IS-707 Data Capability -. Internet Access -. Speed Dial -. Emergency Call Hold -. Hot Line -. Alarm Reminder -. Line Signal Tone Dial Tone Warning Tone Howler Tone -. Security -. OTASP(0ver-the-Air-Service Provisioning)/OlRPA(Over-the-Air-Parameter Administration) -. SMS (Short Message Service) VMS (Voice Message Service) Page Service Message Service -. Vocoder Select 8K QCELP (Qualcomm Code Excited Linear Prediction) EVRC 13K QCELP -. Call Waiting -. Call Forwarding' -. Call Transfer * -. Threeway Calling* * : System dependant )QQ Y U W D A I 4iYUWDA I. 1 Notices for Using . . . Do not disassemble or alter the WLL terminal on your own. Do not touch antenna during the call. Do not hold the WLL terminal in hot or moist places. Be careful not to moisten the terminal or to spill any liquid on it. This may cause irrevocable damage. Avoid terminal shocks and vibrations. Store the terminal in a safe place. Do not use the terminal near to explosives or in places where combustible liquids are used. Do not wipe the WLL terminal with a chemical solution like solvent or thinner. Switch off the WLL terminal and remove the SMPS (Switch Mode Power Supply) when you do not use the terminal for long. . . . . 1.2 Checking fhe Package Thank you for buying our product. Please check whether the product package contains the following accessories: * WLL Phone * Accessories - Switch Mode Power Supply (SMPS) Unit - - Usets Manual - - Wall Bracket - s - screws - 1QQ Y U W D A I RSSI LED RSSI LED goes “ON”, when the state of ma-ceivine is “GOOD”. Buttons ___ Y DIAL Input telephone numbers or numeric characters (0-9, *, #), and choose menu items. RSSI LED goes “ON and OFF” at the interval of 1 second, when the state of trans-ceiving is ‘NOT GOOD”. RSSI LED goes “ON and OFF” at the interval of 15 seconds, when the state of trans-ceiving is “NO SERVICE. UPmWN Retrieve stored telephone numbers, adjust beep volume and ringer loudness when the phone is ringing, move across menu items, and adjust handset loudness during the call. POWER LED Indicates whether the power is supplied by external SMPS or by internal battery. The LED goes“ ON” when external power is supplied. When the terminal operates on internal backup battery, the LED gd OFF“. FUNCTION Input menu STORE Store the settings and menu Hook Switch Turns call on and off, This switch starts and endsworldngwithwLLtellninal. REDL4L Make a call to the last dialed telephone numb. DC Jack Connects power supply from the SMPS to the WLLtermina. RING Select ring sound from 10 types of ring. serial Port A port through which data services (Modem, PC Fax, Internet access) are available. SEND Make call attempt in the off-hook state. Power Switch Turns the power supply to WLL terminal on and off 1.4 lnsfalling WLL Terminal (INSTALLING ANTENNA) General Observations Connect DC jack as shown below. Q Connect the SMPS plug to the outlet. 4iYUWDAI 4 Y U W D A W Turn on the power switch as shown on the picture. The WLL terminal turns on and a beep sound is heard - @I After initialization, the WLL terminal goes to the waiting mode. Wall Bracket Mounting Q For the concrete wall, place the mounting plate where the WLL terminal should be installed, and drill two according t6 +' marks. Mounting Plate Q Screw up as shown in the figure below. ' J 1 25.Omm : m 9 Wall Wall /---- screw / A 2.b For the wooden wall, screw up the plate directly to the wall. QQYUWDAl The distance between the screw head and the wall is to be 2.0mm as shown on the fisure above. Insert the parts Al, A2 of the wall bracket into the WLL terminal body, and gently push in the parts BI, 82. A1 -A2 BI B2 @ Insert screws into the C1, C2 notches, and pull the body downward. As this takes place, make sure about the distance between the screw head and the wall, lest the body hangs askew. Wallmounting type Telephone \ -rr Wall Screws to tix the bracket to wall Wall Bracket External Antenna Q Disconnect antenna from the phone 4iYUWDAl 1.5 LCD Display The LCD display shows the terminal operating mode, RSSl (Received Signal Strength Indicator), the state of power. 1.5.1 Display for Power On Indicate power LED ON, when the power is supplied by extemel SMPS. (Indicate power LED OFF, when the power is supplied by internel battery. If the voltage of battely is low (below 4.75V), the warning tone will be heard at the interval of 15 semnds). 1.5.2 Display for Weak RSSl (Received Signal Strength Indicator) RSSl LED goes “ON”, when the state of transceiving is ‘GOOD”. RSSl LED goes “ON and OFF at the interval of 1 second, when the state of trans-ceiving is “NOT GOOD. RSSl LED goes “ON and OFF at the interval of 15 seconds, when the state of trans-ceiving is “NO SEFMCE: 4iYUWDAI 2. Using Basic Functions 2.2 To Receiving an Incoming Call 2.2.1 In on-hook state 2. I Call Process 8 Call Process by Special Funcfion 2.1 .I Call press . Pick up the handset. You will hear the dial tone. (In the“ No Service” state however, the . In the No Service” state, you cannot make calls. . Pick up the handset and press [REDIAL] button. The call will be made to the last dialed . Dial the telephone number and press [SEND] button to make a call. . If you do not [SEND] button after dialing the number, the call will be made automatically 6 seconds later. . Speak on the telephone. . Place the handset on-hook to terminate the call. warning tone is heard at the interval of 0.5 second.) number. 2.1.2 Call p…

Text truncated - open the document above for the full version.

HYUNDAI CURITEL INC. San 136-1, Ami-Ri, Bubal-Eub, Ichon -Si Kyoungki-Do, 467-fO1, Korea Date : January 7, 2002 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 U.S.A. In re : HYUNDAI CURITEL INC. FCC ID PP4HWP-130 PCS CDMA WLL Telephone Part 22 Certification Request for Confidentiality Gentlemen : In accordance with 0.459 of CFR 47, Hyundai Curitel Inc. hereby requests confidentiality of the Block Diagrams attachment, Schematic Diagrams attachment,Operational Description attachment, and Part List/Tune-Up Procedure attachment for the above -referenced Certification application. These documents contain detailed system and equipment description and related information about the product which Hyundai Curitel Inc. considers to be proprietary,confidential, and a custom design and, otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, Hyundai Curitel Inc. feels this information would be of benefit to its competitors, and that the discloure of the information in these documents would give our competitors an unfair advantage in the market. Sincerely Yours, Eui -Kwon Park - Project Manager R & D Center

January 16, 2002 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT:Hyundai Curitel, Inc. FCC ID: PP4HWP-130 Part 22 Certification Gentlemen: Attached herewith, on behalf of Hyundai Curitel, Inc., is an application for Part 22 Certification of the following PCS CDMA WLL Phone: FCC ID:PP4HWP-130 TRADE / MODEL(s):HYUNDAI HWP-130 Classification:Licensed Base Station for Part 22 (PCB) Tx Freq. Range:824.70 – 848.31 MHz (CDMA) Rx Freq. Range:869.70 – 893.31 MHz (CDMA) Max. RF Output Power:0.370 W ERP CDMA (25.683 dBm) Max. SAR Measurement:1.0048 W/kg Body SAR Attached is the applicant’s Letter of Authorization, Confidentiality Request, measurement report data and plots, RF Exposure measurement report, FCC ID label and location, test setup photographs, internal and external photographs, block diagrams (confidential), schematic diagrams & circuit description (confidential), operational description (confidential), parts list & tune-up procedure (confidential), and the user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. cc:Hyundai Curitel, Inc.

April 24, 2002 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Mr. Martin Perrin SUBJECT: Hyundai Curitel Inc. FCC ID: PP4HWP-130 731 Confirmation No.: EA180606 Correspondence Reference No.: 22106 Request for Tech. Info.: 2/27/2002 Dear Martin: Transmitted herewith, on behalf of Hyundai Curitel Inc., is an amendment provided in response to the request for technical information dated February 27, 2002. EMC 1. Please find attached the data showing compliance with CFR 22.917(f) as referenced in page 5 of the EMC test report. 2. During the radiated measurement the VBW & RBW were set to 3MHz. 3. The optional external antenna and external batery for this device is not available at this time, when one becomes available a class II Permissive Change will be applied. SAR 1. The optional external antenna for this device is not available at this time, when one becomes available a class II Permissive Change will be applied. 2. Please find the attached page of the user’s manual containing the RF warning statement. 3. Please find the attached probe calibration certificate. 4. Please find attached the system verification data per Supplement C appendix B. 5. A Crest Factor of one was used for the SAR testing. 6. The EUT was controlled using Hyundai’s Software Codes and Power was measured before and after each SAR test. We trust this information is sufficient to issue the grant as soon as possible. If you have any further questions, please do not hesitate to contact us. cc: Hyundai Curitel Inc.

June 11, 2002 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Mr. Martin Perrine SUBJECT: Hyundai Curitel Inc. FCC ID: PP4HWP-130 731 Confirmation No.: EA180606 Correspondence Reference No.: 22729 Request for Tech. Info.: 4/26/2002 Dear Martin: Transmitted herewith, on behalf of Hyundai Curitel Inc., is an amendment provided in response to the request for technical information dated April 26, 2002. 1. Please find attached the revised accessory page of the users manual. We trust this information is sufficient to issue the grant as soon as possible. If you have any further questions, please do not hesitate to contact us. cc: Hyundai Curitel Inc.

June 13, 2002 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Mr. Martin Perrine SUBJECT: Hyundai Curitel Inc. FCC ID: PP4HWP-130 731 Confirmation No.: EA180606 Correspondence Reference No.: 23111 Request for Tech. Info.: 6/12/2002 Dear Martin: Transmitted herewith, on behalf of Hyundai Curitel Inc., is an amendment provided in response to the request for technical information dated June 12, 2002. 1. Please find attached the revised users manual pages. We trust this information is sufficient to issue the grant as soon as possible. If you have any further questions, please do not hesitate to contact us. cc: Hyundai Curitel Inc.

© 2002 PCTEST Lab FCC ID: PP4HWP-130 (Model: HWP-130) NVLAP Lab Code: 100431-0 HYUNDAI Fixed WLL Telephone (CDMA) © 2002 PCTEST Lab FCC ID: PP4HWP-130 (Model: HWP-130) NVLAP Lab Code: 100431-0 HYUNDAI Fixed WLL Telephone (CDMA) © 2002 PCTEST Lab FCC ID: PP4HWP-130 (Model: HWP-130) NVLAP Lab Code: 100431-0 HYUNDAI Fixed WLL Telephone (CDMA) © 2002 PCTEST Lab FCC ID: PP4HWP-130 (Model: HWP-130) NVLAP Lab Code: 100431-0 HYUNDAI Fixed WLL Telephone (CDMA) © 2002 PCTEST Lab FCC ID: PP4HWP-130 (Model: HWP-130) NVLAP Lab Code: 100431-0 HYUNDAI Fixed WLL Telephone (CDMA)

© 2002 PCTEST Lab FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §§ 2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. (SEE NEXT PAGE) IDENTIFICATION LABEL with regard to the FCC Rule Part 2.983 According to the requirement section 2.925 an 2.926, the sample label shown below shall be permanently affixed at a conspicuous location on the device supplied to the user and be readily visible to the purchaser at the time purchase. ~~ FCC ID: PP4HWP-130 SERIAL NO. : MADE IN KOREA HYUNDAI CURITEL, INC. MODEL: HWP-130

Peak SAR Location © 2001 PCTEST Lab HYUNDAI FCC ID: PP4HWP-130 (Model: HWP-130) NVLAP Lab Code: 100431-0 Fixed Wireless Local Loop Telephone (CDMA) Body SAR File : c:/idx3/SYSTEM/SARMEAS3/data/Normal/02010307_ZOOM.VLT Start : 3-Jan-102 12:45:54 pm End : 3-Jan-102 01:03:06 pm Radio Type : HYUNDAI Model Number : HWP-130 Serial Number : 1 Frequency : 824.70 MHz Peak Trans. Pwr : 0.320 W Start Trans. Pwr: 0.320 W Antenna Type : Helical Antenna Posn. : Internal Phantom Type : Flat Phantom Posn. : E Field Scan Type : ZOOM/SAR Probe Name : PCTEST Field Type : E Field Orientation : 0 Degrees Mixture Type = Muscle Mixture Dielectric Constant = 56.100 Mixture Conductivity = 0.950 Comment : HYUNDAI FIXED WLL TELEPHONE - CDMA MODE CH 1013 Conducted 25.0 dBm HYUNDAI FIXED WLL TELEPHONE Robot : PCTEST Probe Offset = 0.20 cm Sensor Factor = 0.0108 Conversion Factor = 0.423 PCTEST Amplifier Channel Settings : 0.239 0.278 0.294 Max Location : X = 0.000, Y = -2.000, Z = 0.000 (cm) Value = 29.570 Measured Values (volts) = 2.939E-002 2.247E-002 1.842E-002 1.636E-002 1.390E-002 1.232E-002 1.085E-002 9.574E-003 8.372E-003 7.395E-003 6.662E-003 5.971E-003 5.222E-003 4.712E-003 4.384E-003 3.970E-003 3.629E-003 3.224E-003 3.277E-003 3.122E-003 3.144E-003 Calc. Voltage @ Surface (Vs) = 0.0354 Voltage @ 1.00 cm (Vt) = 0.0159 Ave. Voltage (Vs+Vt)/2 = 0.0257 Ave. SAR over 1 g (mW/g) = 1.0048 0.0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 mW/g -1012345 Z centimeters SAR Scan File : 02010307_ZOOM Start : 3-Jan-102 12:45:54 pm End : 3-Jan-102 01:03:06 pm HYUNDAI/HWP-130/1;824.70MHz;W;Helical/Internal; Flat/E Field;ZOOM/SAR;PCTEST/E Field/0 DegreesMuscle/56.100/0.950 File : 02010307_ZOOM Start : 3-Jan-102 12:45:54 pm End : 3-Jan-102 01:03:06 pm HYUNDAI/HWP-130/1;824.70MHz;W;Helical/Internal; Flat/E Field;ZOOM/SAR;PCTEST/E Field/0 DegreesMuscle/56.100/0.950 1.158 1.079 0.999 0.919 0.840 0.760 0.680 0.601 0.521 0.442 File : 02010307_ZOOM Start : 3-Jan-102 12:45:54 pm End : 3-Jan-102 01:03:06 pm HYUNDAI/HWP-130/1;824.70MHz;W;Helical/Internal; Flat/E Field;ZOOM/SAR;PCTEST/E Field/0 DegreesMuscle/56.100/0.950 1.158 1.079 0.999 0.919 0.840 0.760 0.680 0.601 0.521 0.442 File : c:/idx3/SYSTEM/SARMEAS3/data/Normal/02010308_ZOOM.VLT Start : 3-Jan-102 01:04:28 pm End : 3-Jan-102 01:15:05 pm Radio Type : HYUNDAI Model Number : HWP-130 Serial Number : 1 Frequency : 835.89 MHz Peak Trans. Pwr : 0.320 W Start Trans. Pwr: 0.320 W Antenna Type : Helical Antenna Posn. : Internal Phantom Type : Flat Phantom Posn. : E Field Scan Type : ZOOM/SAR Probe Name : PCTEST Field Type : E Field Orientation : 0 Degrees Mixture Type = Muscle Mixture Dielectric Constant = 56.100 Mixture Conductivity = 0.950 Comment : HYUNDAI FIXED WLL TELEPHONE - CDMA MODE CH 0363 Conducted 25.0 dBm HYUNDAI FIXED WLL TELEPHONE Robot : PCTEST Probe Offset = 0.20 cm Sensor Factor = 0.0108 Conversion Factor = 0.423 PCTEST Amplifier Channel Settings : 0.239 0.278 0.294 Max Location : X = 0.000, Y = -2.000, Z = 0.000 (cm) Value = 26.052 Measured Values (volts) = 2.522E-002 1.983E-002 1.679E-002 1.447E-002 1.268E-002 1.114E-002 9.819E-003 8.637E-003 7.316E-003 6.635E-003 5.923E-003 5.400E-003 4.828E-003 4.414E-003 3.972E-003 3.508E-003 3.438E-003 3.090E-003 2.916E-003 2.966E-003 2.790E-003 Calc. Voltage @ Surface (Vs) = 0.0297 Voltage @ 1.00 cm (Vt) = 0.0141 Ave. Voltage (Vs+Vt)/2 = 0.0219 Ave. SAR over 1 g (mW/g) = 0.8579 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0 1.1 1.2 mW/g -1012345 Z centimeters SAR Scan File : 02010308_ZOOM Start : 3-Jan-102 01:04:28 pm End : 3-Jan-102 01:15:05 pm HYUNDAI/HWP-130/1;835.89MHz;W;Helical/Internal; Flat/E Field;ZOOM/SAR;PCTEST/E Field/0 DegreesMuscle/56.100/0.950 File : 02010308_ZOOM Start : 3-Jan-102 01:04:28 pm End : 3-Jan-102 01:15:05 pm HYUNDAI/HWP-130/1;835.89MHz;W;Helical/Internal; Flat/E Field;ZOOM/SAR;PCTEST/E Field/0 DegreesMuscle/56.100/0.950 1.020 0.951 0.881 0.811 0.741 0.671 0.601 0.532 0.462 0.392 File : 02010308_ZOOM Start : 3-Jan-102 01:04:28 pm End : 3-Jan-102 01:15:05 pm HYUNDAI/HWP-130/1;835.89MHz;W;Helical/Internal; Flat/E Field;ZOOM/SAR;PCTEST/E Field/0 DegreesMuscle/56.100/0.950 1.020 0.951 0.881 0.811 0.741 0.671 0.601 0.532 0.462 0.392 File : c:/idx3/SYSTEM/SARMEAS3/data/Normal/02010309_ZOOM.VLT Start : 3-Jan-102 01:18:36 pm End : 3-Jan-102 01:29:12 pm Radio Type : HYUNDAI Model Number : HWP-130 Serial Number : 1 Frequency : 848.31 MHz Peak Trans. Pwr : 0.320 W Start Trans. Pwr: 0.320 W Antenna Type : Helical Antenna Posn. : Internal Phantom Type : Flat Phantom Posn. : E Field Scan Type : ZOOM/SAR Probe Name : PCTEST Field Type : E Field Orientation : 0 Degrees Mixture Type = Muscle Mixture Dielectric Constant = 56.100 Mixture Conductivity = 0.950 Comment : HYUNDAI FIXED WLL TELEPHONE - CDMA MODE CH 0777 Conducted 25.0 dBm HYUNDAI FIXED WLL TELEPHONE Robot : PCTEST Probe Offset = 0.20 cm Sensor Factor = 0.0108 Conversion Factor = 0.423 PCTEST Amplifier Channel Settings : 0.239 0.278 0.294 Max Location : X = 0.000, Y = -2.000, Z = 0.000 (cm) Value = 25.572 Measured Values (volts) = 2.319E-002 1.788E-002 1.508E-002 1.312E-002 1.140E-002 1.016E-002 8.816E-003 7.755E-003 6.676E-003 6.165E-003 5.550E-003 4.942E-003 4.129E-003 4.145E-003 3.561E-003 3.474E-003 3.230E-003 2.918E-003 2.943E-003 2.677E-003 2.771E-003 Calc. Voltage @ Surface (Vs) = 0.0276 Voltage @ 1.00 cm (Vt) = 0.0128 Ave. Voltage (Vs+Vt)/2 = 0.0202 Ave. SAR over 1 g (mW/g) = 0.7900 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0 1.1 mW/g -1012345 Z centimeters SAR Scan File : 02010309_ZOOM Start : 3-Jan-102 01:18:36 pm End : 3-Jan-102 01:29:12 pm HYUNDAI/HWP-130/1;848.31MHz;W;Helical/Internal; Flat/E Field;ZOOM/SAR;PCTEST/E Field/0 DegreesMuscle/56.100/0.950 File : 02010309_ZOOM Start : 3-Jan-102 01:18:36 pm End : 3-Jan-102 01:29:12 pm HYUNDAI/HWP-130/1;848.31MHz;W;Helical/Internal; Flat/E Field;ZOOM/SAR;PCTEST/E Field/0 DegreesMuscle/56.100/0.950 1.002 0.931 0.861 0.791 0.721 0.651 0.581 0.511 0.440 0.370 File : 02010309_ZOOM Start : 3-Jan-102 01:18:36 pm End : 3-Jan-102 01:29:12 p…

Text truncated - open the document above for the full version.

© 2002 PCTEST Lab FCC ID: PP4HWP-130 (Model: HWP-130) NVLAP Lab Code: 100431-0 HYUNDAI Fixed WLL Telephone (CDMA) © 2002 PCTEST Lab FCC ID: PP4HWP-130 (Model: HWP-130) NVLAP Lab Code: 100431-0 HYUNDAI Fixed WLL Telephone (CDMA) © 2002 PCTEST Lab FCC ID: PP4HWP-130 (Model: HWP-130) NVLAP Lab Code: 100431-0 HYUNDAI Fixed WLL Telephone (CDMA) © 2002 PCTEST Lab FCC ID: PP4HWP-130 (Model: HWP-130) NVLAP Lab Code: 100431-0 HYUNDAI Fixed WLL Telephone (CDMA)

For more information about RF exposure, please visit the FCC website at www.fcc.gov FCC RF EXPOSURE INFORMATION In August 1996 the Federal Communications Commission (FCC) of the United States with its action in Report and Order FCC 96-326 adopted an updated safety standard for human exposure to radio frequency electromagnetic energy emitted by FCC regulated transmitters. Those guidelines are consistent with the safety standard previously set by both U.S. and international standards bodies. The design of this phone complies with the FCC guidelines and these international standards. Operating Requirements To comply with FCC exposure requirements, a minimum separation distance of 2.5cm must be maintained between the users/bystander and the back of the unit, including the antenna. WARNING! Read this information before using your phone

The low pass filter inserted after the amplifier reduces the effect of harmonics and noise from the amplifier. For most amplifiers in normal operation the filter is not necessary. The attenuator after the amplifier improves the source matching and the accuracy of the power sensor. (Consult the power meter manual.) The directional coupler (recommended -20 dB coupling coefficient) is used to monitor the forward power and adjust the signal generator output for constant forward power. A medium -quality coupler is sufficient because the loads (dipole and power head) are both well -matched. The power meters PM2 and PM3 should have low drift and a resolution of 0.01 am, but otherwise the accuracy has negligible impact on the power setting. (Absolute calibration is not required.) The power meter PM1 and attenuator Attl must be high-quality components. These should be calibrated, preferably together. The attenuator ( -10 dB) improves the accuracy of the power reading. (Some high -power heads come with a built-in calibrated attenuator.) The exact attenuation of the attenuator at the test frequency must be known; many attenuators vary up to 0.2 dB from the specified value. Use the same power level for PM1 test as used for the actual measurement to avoid linearity and range switching errors in the power meters PM2 and PM3. If the power level is changed, the power level setting procedure should be repeated. The dipole must be connected directly to the cable at location “X”. If the power meter has a different connector system, use high -quality adapters. 7.2.5 System Check Procedure The system check is a complete 1 g or 10 g averaged SAR measurement. The measured 1 g (or 10 g) averaged SAR value is normalized to the target input power of the standard source and compared with the previously recorded target 1 g (or 10 g) value corresponding to the measurement frequency, the Standard Source and specific phantom. The acceptable tolerance must be determined for each system check and should be within f 10 % of previously recorded system check target values. 7.3 System Validation 7.3.1 Purpose The system validation procedure tests the system against reference SAR values, and the performance of probe, readout electronics and software. The test system utilizes a flat phantom and a reference dipole. Thus, the system validation process does not include data scatter due to the use of anthropomorphic phantoms, or uncertainty due to handset positioning variability. System validation is performed before each test, or when a new system is put into operation, or whenever modifications have been made to the system, such as a new software release, different readout electronics or different types of probes. System validation should be done after the probe calibration has taken place. The objective of this clause is to provide a methodology for SAR measurement verification. Since SAR measurement equipment and calibration technique scan vary widely between various

File : c:/idx3/SYSTEM/SARMEAS3/data/Normal/0112926_ZOOM.VLT Start : 29-Nov-101 05:57:03 pm End : 29-Nov-101 06:12:55 pm Radio Type : Validation Model Number : Serial Number : C Frequency : 835 MHz Peak Trans. Pwr : 0.250 W Start Trans. Pwr: 0.250 W Antenna Type : Dipole Antenna Posn. : Internal Phantom Type : Flat Phantom Posn. : E Field Scan Type : ZOOM/SAR Probe Name : PCTEST Field Type : E Field Orientation : 0 Degrees Mixture Type = Brain Mixture Dielectric Constant = 41.500 Mixture Conductivity = 0.900 Comment : 835 MHz Brain Validation SN: C Robot : PCTEST Probe Offset = 0.20 cm Sensor Factor = 0.0108 Conversion Factor = 0.325 PCTEST Amplifier Channel Settings : 0.239 0.278 0.294 Max Location : X = 1.500, Y = -2.000, Z = 0.000 (cm) Value = 101.253 Measured Values (volts) = 9.975E-002 7.499E-002 6.126E-002 5.159E-002 4.321E-002 3.764E-002 3.264E-002 2.797E-002 2.391E-002 2.107E-002 1.924E-002 1.651E-002 1.477E-002 1.300E-002 1.135E-002 9.757E-003 8.477E-003 7.363E-003 7.077E-003 6.347E-003 5.514E-003 Calc. Voltage @ Surface (Vs) = 0.1210 Voltage @ 1.00 cm (Vt) = 0.0498 Ave. Voltage (Vs+Vt)/2 = 0.0854 Ave. SAR over 1 g (mW/g) = 2.5699 0 1 2 3 4 mW/g -1012345 Z centimeters SAR Scan File : 01112926_ZOOM Start : 29-Nov-101 05:57:03 pm End : 29-Nov-101 06:12:55 pm Validation//C;835MHz;W;Dipole/Internal; Flat/E Field;ZOOM/SAR;PCTEST/E Field/0 DegreesBrain/41.500/0.900 File : 02012926_ZOOM Start : 29-Nov-101 05:57:03 pm End : 29-Nov-102 06:12:55 pm Validation//C;835MHz;W;Dipole/Internal; Flat/E Field;ZOOM/SAR;PCTEST/E Field/0 DegreesBrain/41.500/0.900 2.93 2.81 2.69 2.57 2.44 2.32 2.20 2.08 1.96 1.84 File : 02012926_ZOOM Start : 29-Nov-101 05:57:03 pm End : 29-Nov-102 06:12:55 pm Validation//C;835MHz;W;Dipole/Internal; Flat/E Field;ZOOM/SAR;PCTEST/E Field/0 DegreesBrain/41.500/0.900 2.93 2.81 2.69 2.57 2.44 2.32 2.20 2.08 1.96 1.84

© 2002 PCTEST Engineering Lab., Inc. A PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road • Columbia, MD 21045 • U.S.A. TEL (410) 290-6652 • FAX (410) 290-6654 www.pctestlab.com CERTIFICATE OF COMPLIANCE FCC Part 22 Certification HYUNDAI Curitel Inc. Dates of Tests: January 3-4, 2002 San 136-1, Ami-Ri, Bubal-Eub Test Report S/N: 22.221207680.PP4 Ichon-Si, Kyungki-Do, KOREA 467-701 Test Site: PCTEST Lab, Columbia MD USA Attn: Mr. Ki-Soo Kim, QM Dept. System Quality Assurance Office FCC ID PP4HWP-130 APPLICANT HYUNDAI Curitel Inc. Classification: Non-Broadcast Transmitter held to ear (TNE) FCC Rule Part(s): §22(H), §22.901(d), §2 EUT Type: Fixed WLL Telephone (CDMA) Trade Name/Model(s): HYUNDAI HWP-130 Tx Frequency Range: 824.70 - 848.31 MHz (CDMA) Rx Frequency Range: 869.70 - 893.31 MHz (CDMA) Max. RF Output Power: 0.370 W ERP CDMA (25.683 dBm) Max SAR Measurement: 1.0048mW/g CDMA Body SAR Frequency Tolerance: 0.00025% (2.5 ppm) Emission Designators: 1M25F9W This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in § 2.947. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. 220107680.PP4 FCC Part 22 Certification © 2002 PCTEST Engineering Laboratory, Inc. FCC Part 22 TABLE OF CONTENTS ATTACHMENT A: COVER LETTER(S) ATTACHMENT B: ATTESTATION STATEMENT(S) ATTACHMENT C: TEST REPORT 1.1 SCOPE 1 2.1 INTRODUCTION 2 3.1 INSERTS 3 4.1 DESCRIPTION OF TESTS 4-6 5.1 EFFECTIVE RADIATED POWER OUTPUT 7 6.1 RADIATED MEASUREMENTS 8-10 7.1 FREQUENCY STABILITY 11-12 8.1 PLOTS OF EMISSIONS 13 9.1 LIST OF TEST EQUIPMENT 14 10.1 SAMPLE CALCULATIONS 15 11.1 CONCLUSION 16 ATTACHMENT D: TEST PLOTS ATTACHMENT E: FCC ID LABEL & LOCATION ATTACHMENT F: TEST SETUP PHOTOGRAPHS ATTACHMENT G: EXTERNAL PHOTOGRAPHS ATTACHMENT H: INTERNAL PHOTOGRAPHS ATTACHMENT I: BLOCK DIAGRAM(S) / CIRCUIT DIAGRAMS ATTACHMENT J: SCHEMATIC DIAGRAM(S) ATTACHMENT K PARTS LIST/TUNE UP PROCEDURE ATTACHMENT L: OPERATIONAL DESCRIPTION ATTACHMENT M: USER’S MANUAL ATTACHMENT N: SAR MEASUREMENT REPORT ATTACHMENT O: SAR TEST DATA ATTACHMENT P: SAR TEST SETUP PHOTOGRAPHS Test Report S/N: 22.221207680.PP4 FCC Part 22 Dates of Tests: January 3-4, 2002 Certification FCC ID: PP4HWP-130 (Model: HWP-130) © 2002 PCTEST Lab HYUNDAI Fixed WLL Telephone (CDMA) 1 MEASUREMENT REPORT 1.1 Scope Measurement and determination of electromagnetic emissions (EME) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission. General Information Applicant: HYUNDAI Curitel Inc. Address: San 136-1, Ami-ri, Bubal-Eub Ichon-Si, Kyungki-Do, KOREA 467-701 Attention: Mr. Ki-Soo Kim, QM Dept System Quality Assurance Office • FCC ID: PP4HWP-130 • Trade Name(s): HYUNDAI • Model(s): HWP-130 • Quantity: Quantity production is planned • Tx Freq. Range: 824.70 ~ 848.31 (CDMA) Rx Freq. Range: 869.70 ~ 893.31 (CDMA) • Equipment Class: Non-Broadcast Transmitter Held to Ear (TNE) • Equipment Type: Fixed WLL Telephone (CDMA) • Modulation(s): CDMA • Frequency Tolerance: ± 0.00025% (2.5 ppm) • Max. RF Output Power: 0.370W ERP CDMA (25.683 dBm) • Max SAR Measurement: 1.0048mW/g CDMA Body SAR • FCC Rule Part(s): §22(H), §22.901(d), §2 • Dates of Tests: January 3-4, 2002 • Place of Tests: PCTEST Lab, Columbia, MD U.S.A. Test Report S/N: 22.221207680.PP4 FCC Part 22 Dates of Tests: January 3-4, 2002 Certification FCC ID: PP4HWP-130 (Model: HWP-130) © 2002 PCTEST Lab HYUNDAI Fixed WLL Telephone (CDMA) 2 2.1 INTRODUCTION These measurement tests were conducted at PCTEST Engineering Laboratory, Inc. facility in New Concept Business Park, Guilford Industrial Park, Columbia, Maryland. The site address is 6660-B Dobbin Road, Columbia, MD 21045. The test site is one of the highest points in the Columbia area with an elevation of 390 feet above mean sea level. The site coordinates are 39° 11'15" N latitude and 76° 49'38" W longitude. The facility is 1.5 miles North of the FCC laboratory, and the ambient signal and ambient signal strength are approximately equal to those of the FCC laboratory. There are no FM or TV transmitters within 15 miles of the site. The detailed description of the measurement facility was found to be in compliance with the requirements of § 2.948 according to ANSI C63.4 on October 19, 1992. Measurement Procedure The radiated and spurious measurements were made outdoors at a 3-meter test range (see Figure2). The equipment under test is placed on a wooden turntable 3- meters from the receive antenna. The receive antenna height and turntable rotations were adjusted for the highest reading on the receive spectrum analyzer. A half-wave dipole was substit…
