PP4L1Dual Band CDMA Phone With Bluetooth

User Guide CDM-8935 TABLE OF CONTENTS 3 TABLE OF CONTENTS2CHAPTER 1. BEFORE USING YOUR PHONE ................... 5 INSIDE THE PACKAGE ......................................................................6 HANDSET DESCRIPTION ..................................................................7 PHONE VIEW .......................................................................................... 7 THE FUNCTION KEYS ............................................................................. 8 DISPLAY INDICATORS ......................................................................9 DISPLAY INDICATORS ............................................................................ 9 BATTERY USAGE ............................................................................11 BATTERY INSTALLATION ..................................................................... 11BATTERY REMOVAL ............................................................................. 11 BATTERY CHARGING ........................................................................... 12 BATTERY HANDLING INFORMATION .............................................13 DO ’ s ..................................................................................................... 13 DON’Ts .................................................................................................. 13 CHAPTER 2. BASIC OPERATION ................................... 15 TURNING THE PHONE ON / OFF .....................................................16 TURNING THE PHONE ON ................................................................... 16 TURNING THE PHONE OFF .................................................................. 16 ACCESSING THE MENU ..................................................................17 MENU SUMMARY ..........................................................................18 BASIC FUNCTIONS .........................................................................21 MAKING A CALL .................................................................................. 21 ANSWERING A CALL ............................................................................ 22 SPEAKERPHONE ................................................................................... 22CALLER ID ............................................................................................ 22 3-WAY CALLING ................................................................................... 23 CALL WAITING ..................................................................................... 23 ADJUSTING MASTER VOLUME ........................................................... 24 WAIT/2-SEC PAUSE .............................................................................. 24 DURING A CALL .............................................................................25 AVAILABLE OPTIONS DURING A CALL ............................................... 25 MAKING AN EMERGENCY CALL ...................................................26 911 USING ANY AVAILABLE SYSTEM ................................................. 26 CHAPTER 3. MEMORY FUNCTION ................................ 29 STORING A PHONE NUMBER .........................................................30 ENTERING LETTERS, NUMBERS & SYMBOLS ................................31 STANDARD INPUT MODE .................................................................... 32 WORD INPUT MODE ........................................................................... 33 NUMERIC MODE .................................................................................. 34 SYMBOL MODE ................................................................................... 34 MAKING A CALL FROM THE PHONE BOOK ...................................35 ONE-TOUCH/TWO-TOUCH DIALING ................................................... 35 CHAPTER 4. MENU FUNCTIONS ................................... 35 CONTACTS ......................................................................................36 NEW CONTACT .................................................................................... 36CONTACT LIST ...................................................................................... 37 GROUPS ................................................................................................ 38 SPEED DIALS ........................................................................................ 41IN CASE OF EMERGENCY .................................................................... 42 RECENT CALLS ...............................................................................43 MISSED ................................................................................................. 43 RECEIVED ............................................................................................. 44DIALLED ............................................................................................... 45ALL ....................................................................................................... 46VIEW TIMERS ....................................................................................... 47 SETTINGS .......................................................................................48 MY ACCOUNT ...................................................................................... 48TOOLS .................................................................................................. 48SOUNDS SETTINGS ............................................................................... 55DISPLAY SETTINGS ............................................................................... 60PHONE SETTINGS ................................................................................. 64CALL SETTINGS .................................................................................... 68BLUETOOTH MENU ............................................................................. 73 TABLE OF CONTENTS4CHAPTER 5. GET IT NOW .............…

Text truncated - open the document above for the full version.

PANTECH&CURITEL COMMUNICATIONS, INC. Date: December 20, 2006 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road, Columbia, MD 21046, U.S.A. Subject: Request for Confidentiality FCC ID: PP4L1 Part 22/ 24/ 20/ 15C/ 2 Certification Gentlemen: In accordance with 0.459 of CFR 47, PANTECH&CURITEL COMMUNICATIONS, INC. hereby requests confidentiality of the Block Diagrams attachment, Schematic Diagrams attachment, Operational Description attachment, and Part List/Tune-Up Procedure attachment for the above-referenced Certification application. These documents contain detailed system and equipment description and related information about the product which PANTECH&CURITEL COMMUNICATIONS, INC. considers to be proprietary, confidential, and a custom design and, otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, PANTECH&CURITEL COMMUNICATIONS, INC. feels this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give our competitors an unfair advantage in the market. Sincerely Yours, ------------------------------------------------------ PANTECH&CURITEL COMMUNICATION, INC. PANTECH&CURITEL COMMUNICATIONS, INC. Date: December 20, 2006 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046, U.S.A. Subject: User's Manual RF Exposure Warning Statement FCC ID: PP4L1 Part 22/ 24/ 20/ 15C/ 2 Certification Gentlemen: PANTECH&CURITEL COMMUNICATIONS, INC. hereby confirms that the attached RF exposure warning page will be readily visible to the user, and will be placed at a prominent location in the front section of the user's manual. Should you have any questions or comments concerning the above, please do not hesitate contact me. Sincerely Yours, ------------------------------------------------------ PANTECH&CURITEL COMMUNICATION, INC.

PANTECH&CURITEL COMMUNICATIONS, INC. Date: December 20, 2006 Compliance Certification Services Certification Division 561F Monterey Road Morgan Hill, CA 95037 To whom it may concern: We, the undersigned, hereby authorize Hyundai Calibration & Certification Technologies Co.,Ltd. , to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Hyundai Calibration & Certification Technologies Co.,Ltd. on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing Hyundai Calibration & Certification Technologies Co.,Ltd as our agent, we still recognize that we are responsible to: a) Comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, --------------------------------------------------------------- PANTECH&CURITEL COMMUNICATION, INC. REMARK: 1. This authorization letter will be sent along with your application when filing with the Certification Division. 2. Please follow the format and type it on company letterhead and send original to us.

PANTECH&CURITEL COMMUNICATIONS, INC. Date: December 27, 2006 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 RE: Request of Confidentiality for FCC ID: PP4L1 To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, PANTECH&CURITEL COMMUNICATIONS, INC. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 45 days after the grant as outlined in Public Notice DA 04-1705. This provision will give PANTECH&CURITEL COMMUNICATIONS, INC. temporary confidentiality of commercially sensitive information prior to product release. The requested Confidential and Temporary Confidential exhibits are listed as follows: CONFIDENTIAL AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description 1 Block Diagram 2 Operational Descriptions 3 Parts Lists and Tune-Up Procedure CONFIDENTIAL 4 Schematics 5 External Photos 6 Internal Photos 7 Test-Setup Photos SHORT-TERM CONFIDENTIAL 8 User’s Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, ------------------------------------------------------ PANTECH&CURITEL COMMUNICATION, INC.

Chris Harvey From: SUN-HEE KIM (HCT) [[email protected]] Sent: Wednesday, January 03, 2007 9:03 PM To: [email protected] Cc: kentkim (HCT America); [email protected]; khpark (HCT) Subject: Re: PANTECH&CURITEL COMMUNICATIONS, INC., FCC ID: PP4L1, Assessment NO.: AN06T6407, Notice#1 Attachments: ATT. C (RF REPORT) _L1_ Rev.1.pdf; ATT. M (User Manual).pdf; ATT. N (SAR REPORT) _L1.pdf; Tune-up procedure.pdf Page 1 of 2 1/4/2007 Hello Chris, Thank you for your cooperation. Please find the attached revised exhibits and below explanation. If you have any other comments, please let me know. Best Regards, SunHee Kim ================================================================= Sun-Hee Kim Test Engineer, Product Compliance Division Hyundai Calibration & Certification Co.,Ltd (HCT) San 136-1, Ami-ri , Bubal-eup, Icheon-si, Kyounki- do, Korea (467-701) TEL.: (82-31) 639-8565/ 8518 FAX : (82-31) 639-8525/ 8535 C.P: (82-11) 9558-9875 ================================================================= ----- Original Message ----- From: <charvey [email protected]> To: <[email protected]> Cc: <[email protected]> Sent: Thursday, January 04, 2007 12:39 AM Subject: PANTECH&CURITEL COMMUNICATIONS, INC., FCC ID: PP4L1, Assessment NO.: AN06T6407, Notice#1 > Dear Sun Hee, > > The above referenced TCB application exhibits have been reviewed and the following items are needed before the review can be completed: > > 1. Please provide a tune-up procedure and SAR test report exhibits. ==> We attach the tune-up procedure and SAR test report. > > 2. The FCC ID listed in the RF Exposure section of the manual is incorrect. Please correct the FCC ID number listed in the users' manual. ==> Please find the User Manual again Page.54 of 62. The FCC ID is PP4L1. > > 3. When submitting the SAR test report please be sure to follow the FCC's 3G policy about sub-set test mode RC/SO selection for SAR to be based upon AVERAGE output power (in the past you have used peak power). ==> Please find the SAR test report Page.17 of 24. > > 4. There is no information on Mobile Station (MS) Protocol number and revision supported for this device. Please provide this information. ==> MS protocol revision number during CDMA 2000 1X mode. = 6 > > 5. When a base station simulator is required to establish communication, directional coupler should be used between base station simulator and EUT. Directional coupler is not listed in the RF test equipment list (only power divider is listed). Please confirm that a Directional Coupler was used for EMC testing. ==> We used the Directional Coupler. Please find the revised RF test report Page 25 of 27. > > 6. The following exhibits submitted for the Pt. 22/24 portion of this device will be used in this Bluetooth application since the Bluetooth application must be complete application: Internal and External photos, ID Label exhibit, Authorization letter and Confidentiality letter. > > The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 30 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the e-mail address listed below the name of the sender. > > Best regards, > > Chris Harvey > Charvey [email protected] > > Page 2 of 2 1/4/2007

Report No.: HCT-SAR06-1209 FCC ID: PP4L1 DATE: December 13, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr ATTACHMENT G – EXTERNAL PHOTOGRAPHS Report No.: HCT-SAR06-1209 FCC ID: PP4L1 DATE: December 13, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr EXTERNAL PHOTO Report No.: HCT-SAR06-1209 FCC ID: PP4L1 DATE: December 13, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr EXTERNAL PHOTO Report No.: HCT-SAR06-1209 FCC ID: PP4L1 DATE: December 13, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr EXTERNAL PHOTO Report No.: HCT-SAR06-1209 FCC ID: PP4L1 DATE: December 13, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr EXTERNAL PHOTO Report No.: HCT-SAR06-1209 FCC ID: PP4L1 DATE: December 13, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr EXTERNAL PHOTO Report No.: HCT-SAR06-1209 FCC ID: PP4L1 DATE: December 13, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr EXTERNAL PHOTO Report No.: HCT-SAR06-1209 FCC ID: PP4L1 DATE: December 13, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr EXTERNAL PHOTO

Report No.: HCT-SAR06-1209 FCC ID: PP4L1 DATE: December 13, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr ATTACHMENT E – FCC ID LABEL/ LOCATION Report No.: HCT-SAR06-1209 FCC ID: PP4L1 DATE: December 13, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr LABELLING REQUIREMENTS PER §§ 2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. ( SEE NEXT PAGE ) Report No.: HCT-SAR06-1209 FCC ID: PP4L1 DATE: December 13, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr

Report No.: HCT-SAR06-1209 FCC ID: PP4L1 DATE: December 13, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr ATTACHMENT H – INTERNAL PHOTOGRAPHS Report No.: HCT-SAR06-1209 FCC ID: PP4L1 DATE: December 13, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr INTERNAL PHOTO Report No.: HCT-SAR06-1209 FCC ID: PP4L1 DATE: December 13, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr INTERNAL PHOTO Report No.: HCT-SAR06-1209 FCC ID: PP4L1 DATE: December 13, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr INTERNAL PHOTO Report No.: HCT-SAR06-1209 FCC ID: PP4L1 DATE: December 13, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr INTERNAL PHOTO Report No.: HCT-SAR06-1209 FCC ID: PP4L1 DATE: December 13, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr INTERNAL PHOTO Report No.: HCT-SAR06-1209 FCC ID: PP4L1 DATE: December 13, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr INTERNAL PHOTO Report No.: HCT-SAR06-1209 FCC ID: PP4L1 DATE: December 13, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr INTERNAL PHOTO Report No.: HCT-SAR06-1209 FCC ID: PP4L1 DATE: December 13, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr INTERNAL PHOTO Report No.: HCT-SAR06-1209 FCC ID: PP4L1 DATE: December 13, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr INTERNAL PHOTO Report No.: HCT-SAR06-1209 FCC ID: PP4L1 DATE: December 13, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr INTERNAL PHOTO Report No.: HCT-SAR06-1209 FCC ID: PP4L1 DATE: December 13, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr INTERNAL PHOTO Report No.: HCT-SAR06-1209 FCC ID: PP4L1 DATE: December 13, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr INTERNAL PHOTO Report No.: HCT-SAR06-1209 FCC ID: PP4L1 DATE: December 13, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr INTERNAL PHOTO Report No.: HCT-SAR06-1209 FCC ID: PP4L1 DATE: December 13, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr INTERNAL PHOTO Report No.: HCT-SAR06-1209 FCC ID: PP4L1 DATE: December 13, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr INTERNAL PHOTO Report No.: HCT-SAR06-1209 FCC ID: PP4L1 DATE: December 13, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr INTERNAL PHOTO Report No.: HCT-SAR06-1209 FCC ID: PP4L1 DATE: December 13, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr INTERNAL PHOTO

PRODUCT SPECIFICATION DATE 2006-12-07 REV. IR MODEL L1 TYPE EMBEDDED ANTENNA PAGE 1 Product Specification CUSTOMER ： P a n t e c h & C u r I t e l ITEM ： L1 MODEL NAME ： DANT-T3-PC03 CUSTOMER P/NO ： DATE ： 2006-12-07 #680-9, JAKJEUN-DONG, KYEYANG-GU, INCHON, KOREA TEL : 82-32-676-9224 FAX : 82-32-546-4797 Check Check Check Approval DYKTX JH, LEE 12/07 12/07 12/07 PRODUCT SPECIFICATION DATE 2006-12-07 REV. IR MODEL L1 TYPE EMBEDDED ANTENNA PAGE 2 A. Contents A. Contents B. Document Change Record C. List of Material D. Electrical & Mechanical Specifications 1. Electrical Specifications 2, Mechanical Specifications 3, Package E. Electrical properties 1. Test equipment 2. V.S.W.R 3. Radiation pattern and gain F. Environmental resistance properties 1. Operational temperature 2. Temperature cycling 3. Humidity 4. Sinusoidal vibration 5. Corrosion 6. Aging G. Measurement Data 1. V.S.W.R 2. Radiation pattern H. Mechanical Drawing 1. Assembly 2. Package PRODUCT SPECIFICATION DATE 2006-12-07 REV. IR MODEL L1 TYPE EMBEDDED ANTENNA PAGE 3 B. Document Change Record Rev.No Rev. Date Page History Drafter 1 2006-12-07 Initial release JH,LEE PRODUCT SPECIFICATION DATE 2006-12-07 REV. IR MODEL L1 TYPE EMBEDDED ANTENNA PAGE 4 C. List of Material Raw Material Material Supplier Tooling & Injection Finishing & Spec. Remark Carrier PC HF-1023IM Cheil Industies Mpla - - Radiator STS 304 (t=0.15) Pung-San Metal Deayoung KTX - - Assembly Tolerance of heat staking height should not bk over 0.6mm the surface of pattern PRODUCT SPECIFICATION DATE 2006-12-07 REV. IR MODEL L1 TYPE EMBEDDED ANTENNA PAGE 5 D. Electrical & Mechanical Specifications 1. Electrical Specifications Frequency Range CDMA (824 ~ 894MHz) GPS (1575.42MHz) PCS (1850 ~ 1990MHz) Peak gain (E2 Plane) -0.5dBi over -3.5dBi over -2.0dBi over VSWR 3.5:1 below 2.0:1 below 4.0:1 below Impedance 50Ω Polarization Linear Radiation pattern Omni-directional Power Handling 2 Watt 2, Mechanical Specifications Connector Contact Type Dimension 35.0(W) x 10.0(H) x 7.0(D) Operating Temperature -30°C ~ +80°C Weight 2.0g 3, Package Name Quantity Material Remark Tray 50EA P.S(0.5t) N/A Carton BOX 1,000EA DW 2(AB) N/A PRODUCT SPECIFICATION DATE 2006-12-07 REV. IR MODEL L1 TYPE EMBEDDED ANTENNA PAGE 6 E. Electrical properties 1. Test equipment The equipment for the antenna measurement we used is as follows. A. Agilent 8720 Series Network Analyzer to measure the V.S.W.R and input impedance. B. Three-dimensional anechoic chamber to measure the gain (Standard dipole and horn were used to calibrate the chamber) C. Digital caliper to measure the dimensions. D. Climatic chamber for mechanical tests. 2. V.S.W.R The VSWR characteristics must satisfy the electrical demands. The VSWR is measured with Agilent 8720 Series network analyzer. All the measurements are performed with the customer provided fixture. PRODUCT SPECIFICATION DATE 2006-12-07 REV. IR MODEL L1 TYPE EMBEDDED ANTENNA PAGE 7 3. Radiation pattern and gain Radiation pattern of this antenna has Omni-directional specification in H-Plane. Antenna gain is satisfied with customer demand based on folder-open as dBi after calibration with standard horn antenna. PRODUCT SPECIFICATION DATE 2006-12-07 REV. IR MODEL L1 TYPE EMBEDDED ANTENNA PAGE 8 F. Environmental resistance properties 1. Operational temperature 1.1 Low and high operational temperature TLO = -20°C THO = +85°C 1.2 Measuring method The antenna is kept at +20°C at least 1 hour and placed at TLO. The antenna 1 hour and placed at THO. The antenna is taken out and the VSWR is measured. 2. Temperature cycling 2.1 Low and high cycling temperature TLC = -40°C THC = +85°C 2.2 Measuring method The antenna is placed in the climatic chamber. The temperature is cycled as follows; the temperature is kept constant at TLC for 1 hour, increased to THC during 1 hour, kept constant at THC for 1 hour, and then decreased to TLC during 1 hour. This procedure is repeated 24 times ending at room temperature. 3. Humidity 3.1 Relative humidity : 90% 3.2 Temperature : +70°C 3.3 Measuring method The antenna is placed in a climatic chamber for 48 hours. The antenna is taken out from the chamber and measured after another 24 hours in +20°C. PRODUCT SPECIFICATION DATE 2006-12-07 REV. IR MODEL L1 TYPE EMBEDDED ANTENNA PAGE 9 4. Sinusoidal vibration 4.1 Vibration frequency : F = 5 - 55 - 5Hz (1cycle) 4.2 Sweep rate : 0.5octave/min (logarithm) 4.3 Maximum amplitude : A = 1.5mm 4.4 Maximum acceleration : 2g 4.5 Crossover frequency : 18.2Hz 4.6 Measuring method The antenna is assembled to the test equipment. The vibration test is done both in X- and Z-direction. 5. Corrosion 5.1 Demands No permanent mechanical damage after the test. 5.2 Measuring method The antenna is placed in an atmosphere saturated with 5% sodium chloride solution for 96 hours at +35°C. 6. Aging No permanent mechanical damage after equivalent of 3 years dark storage. PRODUCT SPECIFICATION DATE 2006-12-07 REV. IR MODEL L1 TYPE EMBEDDED ANTENNA PAGE 10 G. Measurement Data 1. V.S.W.R Folder Close Folder Open PRODUCT SPECIFICATION DATE 2006-12-07 REV. IR MODEL L1 TYPE EMBEDDED ANTENNA PAGE 11 2. Radiation pattern Folder Close H plane Folder Close E1 PRODUCT SPECIFICATION DATE 2006-12-07 REV. IR MODEL L1 TYPE EMBEDDED ANTENNA PAGE 12 Folder Close E2 Folder Open H plane PRODUCT SPECIFICATION DATE 2006-12-07 REV. IR MODEL L1 TYPE EMBEDDED ANTENNA PAGE 13 Folder Open H E1 Folder Open H E2 PRODUCT SPECIFICATION DATE 2006-12-07 REV. IR MODEL L1 TYPE EMBEDDED ANTENNA PAGE 14 H. Mechanical Drawing 1. Assembly PRODUCT SPECIFICATION DATE 2006-12-07 REV. IR MODEL L1 TYPE EMBEDDED ANTENNA PAGE 15 2. Package

HYUNDAI CALIBRATION & CERTIFICATION TECH. CO., LTD. PRODUCT COMPLIANCE DI…
