PP4PN-315Dual- Mode CDMA Phone (CDMA/ PCS CDMA)

WELCOME Thank you for choosing the Pantech PN-315 camera phone with built-in flash. Developed by top researchers this product offers multiple features designed to enhance your mobile experience including: web browsing to keep you up to date on news, sports and more, Voice Recognition (VR) offering the convenience of voice dialing, T9 predictive text input to make TXT messaging faster and an easy to navigate animated menu to make accessing and using all these features simpler. Some of the many features of the PN-315 include: Full graphic display of 9 text input lines and 1 icon line with variable font size. Easy dialing with the VR feature. Easy text entry through the T9 text input mode. Enhancements for web browsing & data services (i.e.; wireless internet access, Openwave browser) GUI & Animation display compliant with CDMA2000 1X. Two LCD displays present rich full-color content on either the large inner main display screen, or the smaller outer sub-display screen. Navigation Key and 21 keys positioned for more convenience. Sophisticated speaker phone, and voice recognition features. Mobile Camera (330K pixels) Additional text messaging and Web browsing services in addition to authentication, call forwarding, call transfer, and call waiting. IMPORTANT INFORMATION This PN-315 user guide contains very important information about how to handle and use the product. Please read this manual thoroughly, pay attention to the warranty on the back page and be alert to the exclusions and limitations of your warranty, which are related to the use of unauthorized accessories or components. TABLE OF CONTENTS 1 Chapter 1 Chapter 2 Chapter 3 Chapter 4 CHAPTER 1. BEFORE USING YOUR PHONE .................................5 INSIDE THE PACKAGE .....................................................................................6 HANDSET DESCRIPTION.................................................................................7 DISPLAY INDICATORS ...........................................................................................9 BATTERY USAGE ...........................................................................................11 BATTERY INSTALLATION ....................................................................................11 BATTERY REMOVAL.............................................................................................11 BATTERY CHARGING ...........................................................................................12 POWER CONNECTION ......................................................................................12 BATTERY USAGE TIMES....................................................................................13 BATTERY STANDBY TIME .................................................................................13 BATTERY HANDLING INFORMATION..........................................................14 DOs.........................................................................................................................14 DON’Ts...................................................................................................................14 CHAPTER 2. BASIC OPERATION ..................................................15 TURNING THE PHONE ON / OFF ..................................................................16 TURNING THE PHONE ON...................................................................................16 TURNING THE PHONE OFF..................................................................................16 ACCESSING THE MENU ................................................................................17 MENU SUMMARY .........................................................................................18 BASIC FUNCTIONS ........................................................................................20 MAKING A CALL ...................................................................................................20 ANSWERING CALLS.............................................................................................21 SPEAKER PHONE..................................................................................................21 WAIT/PAUSE FEATURE........................................................................................22 ANSWERING A CALL............................................................................................22 3-WAY CALLING ...................................................................................................23 CALLER ID FUNCTION..........................................................................................23 CALL WAITING FUNCTION ..................................................................................24 ADJUSTING VOLUME ..........................................................................................24 ENTER LOCK MODE .............................................................................................25 DURING A CALL .............................................................................................26 MUTE (UNMUTE)..................................................................................................26 SEND TXT MSG ....................................................................................................26 CONTACTS ............................................................................................................26 RECENT CALLS .....................................................................................................26 VOICE PRIVACY.....................................................................................................26 LOCATION .............................................................................................................27 MAKING AN EMERGENCY CALL ..................................................................28 911 IN LOCK MODE ..............................................................................................28 911 USI…

Text truncated - open the document above for the full version.

PANTECH&CURITEL COMMUNICATIONS, INC. 8F, PEERES BLDG, 222, CHUNGJEONGNO 3-GA, SEODAEMUN-GU, SEOUL, 120-708, KOREA Date: February 2, 2006 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road, Columbia, MD 21046, U.S.A. Subject: Authorization Letter FCC ID: PP4PN-315 PANTECH&CURITEL COMMUNICATIONS, INC. Part 22/ 24 Certification To whom it may concern: We, the undersigned. hereby authorized HYUNDAI Calibration & Certification Technologies Co., Ltd. to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these manners. Any and all acts carried out by HYUNDAI Calibration & Certification Technologies Co., Ltd. on our behalf shall have the same effect as acts of our own. This authorization is valid until Dec. 31, 2006. Sincerely Yours, ---------------------------------------------- Eui-Kwon Park - Project Manager R & D Center PANTECH&CURITEL COMMUNICATIONS, INC. 8F, PEERES BLDG, 222, CHUNGJEONGNO 3-GA, SEODAEMUN-GU, SEOUL, 120-708, KOREA Date: January 02, 2006 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road, Columbia, MD 21046, U.S.A. Subject: Request for Confidentiality PANTECH&CURITEL COMMUNICATIONS, INC. FCC ID: PP4PN-315 Part 22/ 24 Certification Gentlemen: In accordance with 0.459 of CFR 47, PANTECH&CURITEL COMMUNICATIONS, INC. hereby requests confidentiality of the Block Diagrams attachment, Schematic Diagrams attachment, Operational Description attachment, and Part List/Tune-Up Procedure attachment for the above-referenced Certification application. These documents contain detailed system and equipment description and related information about the product which PANTECH&CURITEL COMMUNICATIONS, INC. considers to be proprietary, confidential, and a custom design and, otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, PANTECH&CURITEL COMMUNICATIONS, INC. feels this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give our competitors an unfair advantage in the market. Sincerely Yours, --------------------------------------------- Eui-Kwon Park - Project Manager R & D Center PANTECH&CURITEL COMMUNICATIONS, INC. 8F, PEERES BLDG, 222, CHUNGJEONGNO 3-GA, SEODAEMUN-GU, SEOUL, 120-708, KOREA Date: January 02, 2006 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046, U.S.A. Subject: User's Manual RF Exposure Warning Statement PANTECH&CURITEL COMMUNICATIONS, INC. FCC ID: PP4PN-315 Part 22/24 Certification Gentlemen: PANTECH&CURITEL COMMUNICATIONS, INC. hereby confirms that the attached RF exposure warning page will be readily visible to the user, and will be placed at a prominent location in the front section of the user's manual. Should you have any questions or comments concerning the above, please do not hesitate contact me. Sincerely Yours, ----------------------------------------- Eui-Kwon Park - Project Manager R & D Center PANTECH&CURITEL COMMUNICATIONS, INC. 8F, PEERES BLDG, 222, CHUNGJEONGNO 3-GA, SEODAEMUN-GU, SEOUL, 120-708, KOREA Date: January 02, 2006 AFFIDAVIT FOR ESN PROTECTION OF CELLULAR MOBILE TELEPHONES We hereby certify that the Dual mode CDMA Phone (FCC ID: PP4PN-315) is so designed that it complies with all the requirements for ESN protection specified in Section 22.919 of the FCC Rules. a) The transmitter in service has a unique ESN. b) The ESN host component is permanently attached to a main circuit board of the mobile transmitter and the integrity of the unit operating software cannot be altered. The ESN is plated from fraudulent contact and tampering. The ESN is encoded using multiplication by a polynomial and the ESN data programmed in the memory with other information. c) The ESN is factory-set and cannot be altered, transferred, removed or otherwise able to be manipulated. Cellular mobile equipment is specifically designed such that any attempt to remove, tamper with, or change the ESN chip, its logic system, or firmware originally programmed by the manufacturer will render the mobile transmitter inoperative. Sincerely Yours, ---------------------------------------- Eui-Kwon Park - Project Manager R & D Center

PANTECH&CURITEL COMMUNICATIONS, INC. 8F, PEERES BLDG, 222, CHUNGJEONGNO 3-GA, SEODAEMUN-GU, 120-708, KOREA Date: February 10, 2006 Compliance Certification Services Certification Division 561F Monterey Road Morgan Hill, CA 95037 To whom it may concern: We, the undersigned, hereby authorize Hyundai Calibration & Certification Technologies Co.,Ltd. , to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Hyundai Calibration & Certification Technologies Co.,Ltd. on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing Hyundai Calibration & Certification Technologies Co.,Ltd as our agent, we still recognize that we are responsible to: a) Comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Eui-Kwon Park Project Manager R & D Center PANTECH&CURITEL COMMUNICATIONS, INC. REMARK : 1. This authorization letter will be sent along with your application when filing with the Certification Division. 2. Please follow the format and type it on company letterhead and send original to us.

SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNKI-DO, 467-701, KOREA SUBJECT: PANTECH&CURITEL COMMUNICATIONS, INC. FCC ID: PP4PN-315 MODEL: PN-315 Part 22 / 24 / 2 / 20 Certification Gentlemen: Submitted herewith, on behalf of PANTECH&CURITEL COMMUNICATIONS, INC., is an application for Part 22 / 24 / 20 Certification of the following Dual- Mode CDMA Phone (CDMA/ PCS CDMA): Trade Name/Model(s): PANTECH&CURITEL / PN-315 EUT Type: Dual-Mode Phone (CDMA/ PCS CDMA)- Prototype Tx Frequency: 824.70 — 848.31 MHz (CDMA) 1851.25 — 1908.75 MHz (PCS CDMA) Rx Frequency: 869.70 — 893.31 MHz (CDMA) 1931.25 — 1988.75 MHz (PCS CDMA) Max. RF Output Power: 0.308 W ERP CDMA (24.9 dBm) 0.283 W EIRP PCS CDMA (24.5 dBm) Maximum SAR: 1.24 W/kg CDMA Head SAR / 0.937 W/kg CDMA Body SAR 1.25 W/kg PCS CDMA Head SAR / 1.1 W/kg PCS CDMA Body SAR HAC Rating: M3 Attached is the applicant’s Letter of Authorization, Confidentiality Request, ESN Affidavit, measurement report test data and plots, RF Exposure measurement report and data, FCC ID label and location, test setup photographs, internal and external photographs, block diagram (confidential), circuit diagrams & description (confidential), operational description (confidential), parts list & tune-up procedure (confidential), and the user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. Report prepared by: Ki-Soo Kim Manager of Product Compliance Team cc: Mr. KI YEOUL, LEE – PANTECH&CURITEL COMMUNICATION, INC. February 24, 2006 Test Site: HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. FRN: 0005866421 TEL : +82 31 639 8518 FAX : +82 31 639 8525 http://www.hct.co.kr

Chris Harvey From: Sun-Hee Kim(HCT) [[email protected]] Sent: Thursday, March 02, 2006 10:03 PM To: 'Mike Kuo'; [email protected]; Compliance Certification Services Cc: ???(HCT); ??? (HCT); ???CJ; ??? (HCT); ??? (HCT); 'SCOTT WANG(CCS)'; 'Helen Zhao'; charvey- [email protected] Subject: Re: FCC PART 22, 24, 20, 2 Application [PANTECH&CURITEL COMMUNICATIONS, INC., FCC ID: PP4PN-315 Assessment NO.: AN06T5543] Page 1 of 3PANTECH&CURITEL COMMUNICATIONS, INC., FCC ID: PP4PN-315, Assessment NO.: A... 3/3/2006 Dear Sir, Thank you for your cooperation. Please refer to my below explaination and attachment files. If you have any questions or comments, please do not hesitate to contact us. Thank you. Best Regards, Sun- Hee KIM ----- Original Message ----- From: Compliance Certification Services To: [email protected] Cc: charvey [email protected] Sent: Tuesday, February 28, 2006 4:17 PM Subject: PANTECH&CURITEL COMMUNICATIONS, INC., FCC ID: PP4PN-315, Assessment NO.: AN06T5543, Notice#1 Ki Soo, I have reviewed the above referenced TCB application and find that the following items need to be addressed before the review can be completed: 1. Please provide a CCS format Authorization Letter from Pantech&Curitel to HCT in order to file this application on their behalf (the exhibit submitted is from the old company name Hyundai Curitel). ==> Please review the attachment file. <file name : Authorization Letter (PN-315)-new> 2. The exhibits in this application indicate that this device supports CDMA operation. Please clarify if this is CDMA2000 operation. If yes and in light of the FCC’s concern about proper operation at rated average output and crest factor (max/min) to produce the worst possible RF Exposure during SAR testing, please provide additional explanation to further explain the CDMA2000 modes in this device and the steps taken during testing to ensure the worst case modes were tested. ==> Please review the attachment file. <file name : Ouptput power by radio configuration (PN-315)> The worst case mode : RC2/SO17 Base station simulator is E5515C. Test device is directly connect to base station simulator via mobile cable to measure maximum output power in all applicable mode To get a maximum output power, we set closed power control mode as “all up bits” in all applicable mode. 3. PCS1900 SAR tests were performed and tissue simulant parameters measured on 2/17 but Validation Plots only done on 2/16. Please clarify if the Validation plots for PCS1900 operation were performed within 24 hours of the PCS1900 SAR tests. ==> Please review the attachment file. <file name : ATT. Q (DIPOLE VALIDATION PLOTS)-new> 4. The SAR testing for Body-worn operations were performed with a specific belt clip that appears to contain metallic components. The Users manual indicates that only accessories that contain no metallic components shall be used. Please correct this discrepancy. ==> Please review the attachment file. <file name : ATT. M (Manual)-new> 5. The Users Manual indicates that there is a 1000mAh standard and 1800mAh Extended battery for this phone. The SAR testing has only been performed with a Standard battery. Please correct this discrepancy. ==> Please review the attachment file. <file name : ATT. M (Manual)-new> Best regards, Chris Harvey [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 30 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the e-mail address listed below the name of the sender. ----- Original Message ----- From: Chris Harvey To: 'Sun -Hee Kim(HCT)' ; 'Helen Zhao' ; [email protected] ; 'Mike Kuo' ; 'SCOTT WANG(CCS)' Cc: '???(HCT)' ; '??? (HCT)' ; '??? (HCT)' Sent: Tuesday, February 28, 2006 11:54 AM Subject: RE: FCC PART 22, 24, 20, 2 Application [PANTECH&CURITEL COMMUNICATIONS, INC., FCC ID: PP4PN-315 Assessment NO.: AN06T5543] Dear Keun-Ho Park, I have completed the initial review of the referenced TCB application and have sent the attached request for clarifications to the technical contact in the application form. Please let me know if there is anything else I can do to assist you. Best regards, Chris Harvey Chris Harvey EMC Consultants, Inc. [email protected] Page 2 of 3PANTECH&CURITEL COMMUNICATIONS, INC., FCC ID: PP4PN-315, Assessment NO.: A... 3/3/2006 cell 443-622-3300 -----Original Message----- From: Sun-Hee Kim(HCT) [mailto:[email protected]] Sent: Friday, February 24, 2006 4:51 AM To: 'Helen Zhao'; [email protected]; 'Mike Kuo'; 'SCOTT WANG(CCS)' Cc: ???(HCT); ??? (HCT); ??? (HCT); Sun-Hee Kim(HCT) Subject: FCC PART 22, 24, 20, 2 Application [PANTECH&CURITEL COMMUNICATIONS, INC., FCC ID: PP4PN-315 Assessment NO.: AN06T5543] Dear Sir, We always appreciate your kind cooperations on our FCC applications. We'd like to apply for FCC Certification as below project ; 1. Applicant Name : PANTECH&CURITEL COMMUNICATIONS, INC. 2. Application Product : Dual-Mode CDMA Phone (CDMA/ PCS CDMA) 3. FCC ID : PP4PN-315 4. Model Name : PN-315 5. FCC Rule Part(s): Part 22 / 24 / 2 / 20 6. Application date: February 24, 2006 7. Assessment Number: AN06T5543 Your prompt confirmation on receiving of this application would be much appreciated. If you have questions or comments on this application, please do not hesitate to conatct us. Best Regards, Keun-Ho Park - HCT Page 3 of 3PANTECH&CURITEL COMMUNICATIONS, INC., FCC ID: PP4PN-315, Assessment NO.: A... 3/3/2006

Report No.: HCT-SAR06-0209 FCC ID: PP4PN-315 DATE: February 20, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr ATTACHMENT G – EXTERNAL PHOTOGRAPHS Report No.: HCT-SAR06-0209 FCC ID: PP4PN-315 DATE: February 20, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr ■ EXTERNAL PHOTO Report No.: HCT-SAR06-0209 FCC ID: PP4PN-315 DATE: February 20, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr ■ EXTERNAL PHOTO Report No.: HCT-SAR06-0209 FCC ID: PP4PN-315 DATE: February 20, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr ■ EXTERNAL PHOTO Report No.: HCT-SAR06-0209 FCC ID: PP4PN-315 DATE: February 20, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr ■ EXTERNAL PHOTO Report No.: HCT-SAR06-0209 FCC ID: PP4PN-315 DATE: February 20, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr ■ EXTERNAL PHOTO Report No.: HCT-SAR06-0209 FCC ID: PP4PN-315 DATE: February 20, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr ■ EXTERNAL PHOTO Report No.: HCT-SAR06-0209 FCC ID: PP4PN-315 DATE: February 20, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr ■ EXTERNAL PHOTO

Report No.: HCT-SAR06-0209 FCC ID: PP4PN-315 DATE: February 20, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr ATTACHMENT E – FCC ID LABEL/ LOCATION Report No.: HCT-SAR06-0209 FCC ID: PP4PN-315 DATE: February 20, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr LABELLING REQUIREMENTS PER §§ 2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. ( SEE NEXT PAGE ) Report No.: HCT-SAR06-0209 FCC ID: PP4PN-315 DATE: February 20, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr

Report No.: HCT-SAR06-0209 FCC ID: PP4PN-315 DATE: February 20, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr ATTACHMENT H – INTERNAL PHOTOGRAPHS Report No.: HCT-SAR06-0209 FCC ID: PP4PN-315 DATE: February 20, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr ■ INTERNAL PHOTO Report No.: HCT-SAR06-0209 FCC ID: PP4PN-315 DATE: February 20, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr ■ INTERNAL PHOTO Report No.: HCT-SAR06-0209 FCC ID: PP4PN-315 DATE: February 20, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr ■ INTERNAL PHOTO Report No.: HCT-SAR06-0209 FCC ID: PP4PN-315 DATE: February 20, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr ■ INTERNAL PHOTO Report No.: HCT-SAR06-0209 FCC ID: PP4PN-315 DATE: February 20, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr ■ INTERNAL PHOTO Report No.: HCT-SAR06-0209 FCC ID: PP4PN-315 DATE: February 20, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr ■ INTERNAL PHOTO Report No.: HCT-SAR06-0209 FCC ID: PP4PN-315 DATE: February 20, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr ■ INTERNAL PHOTO Report No.: HCT-SAR06-0209 FCC ID: PP4PN-315 DATE: February 20, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr ■ INTERNAL PHOTO Report No.: HCT-SAR06-0209 FCC ID: PP4PN-315 DATE: February 20, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr ■ INTERNAL PHOTO Report No.: HCT-SAR06-0209 FCC ID: PP4PN-315 DATE: February 20, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr ■ INTERNAL PHOTO Report No.: HCT-SAR06-0209 FCC ID: PP4PN-315 DATE: February 20, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr ■ INTERNAL PHOTO Report No.: HCT-SAR06-0209 FCC ID: PP4PN-315 DATE: February 20, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr ■ INTERNAL PHOTO Report No.: HCT-SAR06-0209 FCC ID: PP4PN-315 DATE: February 20, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr ■ INTERNAL PHOTO Report No.: HCT-SAR06-0209 FCC ID: PP4PN-315 DATE: February 20, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr ■ INTERNAL PHOTO Report No.: HCT-SAR06-0209 FCC ID: PP4PN-315 DATE: February 20, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr ■ INTERNAL PHOTO

ANTENNA SPECIFICATION DATE 2006-01-27 REV. IR MODEL PN-315 TYPE RETRACTABLE PAGE 1 /20 Prepared Reviewed Checked Approved APPROVAL SPECIFICATION TITLE Retractable Antenna Model PN-315 CUSTOMER Pantech & Curitel DOCUMENT NO. CONTENTS SHEETS 1 APPROVAL SPECIFICATION 1 2 ANTENNA SPECIFICATION 1 We want to approval the submitted product. Apporved date : JAN. 27. 2006. ANTENNA SPECIFICATION DATE 2006-01-27 REV. IR MODEL PN-315 TYPE RETRACTABLE PAGE 2 /20 ANTENNA SPECIFICATION ANTENNA SPECIFICATION DATE 2006-01-27 REV. IR MODEL PN-315 TYPE RETRACTABLE PAGE 3 /20 - CONTENTS - 1. Revision LIST 2. Technical Items 2.1 Electrical Spec 2.2 Mechanical Spec 2.3 Packing Spec 3. Test Equipment 4. Electrical Demands 4.1 V.S.W.R. 4.2 Radiation Pattern 4.3 Gain 5. Mechanical Demands 5.1 Helix Deformation Test 5.2 Torque Test 5.3 Pulling force test 5.4 Drop test 5.5 Retraction/Extension force test 5.6 Retractions and Extension Force Consistency 5.7 Bend test 6. Environmental demands 6.1 Operation Temperature test 6.2 salt spray test 6.3 Temperature Change Test 6.4 High Humidity Test 7. Antenna Data 7.1 Electrical data (V.S.W.R,GAIN & Matching Circuit Diagram) 7.2 Antenna drawing 7.3 Packing Spec Drawing ANTENNA SPECIFICATION DATE 2006-01-27 REV. IR MODEL PN-315 TYPE RETRACTABLE PAGE 4 /20 1. REVISION LIST REVISION LIST NO DATE CHANGE CONTENTS CHANGE CAUSE REV 1 01.27.2006 N/A N/A IR 2 3 4 5 6 7 8 9 10 ANTENNA SPECIFICATION DATE 2006-01-27 REV. IR MODEL P…
