PP4X1Single-Band CDMA PCS Phone with Bluetooth

Pantech Co., Ltd.

Click to zoom

Application Details

Equipment Class: PCE - PCS Licensed Transmitter held to ear
Date of Grant: Mar 11, 2008
Application Purpose: Original Equipment
Date of Application: Mar 11, 2008
Equipment Note: Single-Band CDMA PCS Phone with Bluetooth
Frequency Range: 1851.25000000 - 1908.75000000
Company: Pantech Co., Ltd.
Country: South Korea

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Contents 1 GETTING STARTED ....................................03 Phone overview ............................................04 Manu overview ............................................. 06 Charging the battery ................................... 07 Turn on/off the phone ................................. 08 Display icons ................................................. 08 Entering text ................................................. 08 Activating your Virgin Mobile account ...... 10 Finding your phone’s serial number ........... 10 Programming your phone ........................... 10 MY ACCOUNT ...........................................11 My account ...................................................12 Checking your account balance .................. 12 Top-Up your account .................................... 12 For more information .................................. 13 CALLS & CONTACTS .................................15 Making, receiving & ending a call ..............16 Caller identification ..................................... 17 Call waiting function ................................... 17 Speaker phone ............................................. 17 Vibrate on/off mode .................................... 17 Making an emergency call .......................... 17 Options during a call ................................... 17 Call setting .................................................... 18 Checking all calls .......................................... 19 Speed dialing ................................................ 20 Using contacts .............................................. 20 Voice commands (AVR) ................................ 21 Using your headset ...................................... 23 MESSAGING ..............................................25 Messaging .....................................................26 Received message ......................................... 26 Voicemail ....................................................... 26 Sent message ................................................ 27 Creating and send new message ................ 28 Message templates ....................................... 28 Create and send new multimedia message .........................................................28 Create and send new email message ......... 29 Create and send new instant message ....... 29 Virgin alerts .................................................. 29 Erase messages ............................................. 30 Message setting ............................................ 30 MULTIMEDIA ............................................31 Camera ..........................................................32 Pictures and image album ........................... 33 Music and sound album ............................... 34 Themes album .............................................. 34 Other files ..................................................... 34 Playing game ................................................ 35 USEFUL FEATURES ....................................37 Calendar ........................................................38 Alarm clock ................................................... 38 Calculator, Tip calculator, Stopwatch & World clock ...................................................38 Voice memo .................................................. 39 SETTINGS ..................................................41 Ringtones, Alerts & Tones ............................42 Decorate the display .................................... 43 Call options ................................................... 44 Security ..........................................................44 Msg settings .................................................. 44 Game settings ............................................... 45 Bluetooth ......................................................45 To set other options ..................................... 45 Phone info .................................................... 45 CONNECTIVITY .........................................47 Bluetooth ......................................................48 Using the internet ........................................ 50 VirginXL ........................................................ 51 My stuff ......................................................... 51 APPENDIX .................................................53 About the battery usage .............................54 Error message ............................................... 55 Troubleshooting checklist ............................ 55 12 Month limited warranty ......................... 56 Safety information for wireless handheld phone ............................................................58 Safety information for FCC RF exposure .... 61 SAR information ........................................... 62 FCC Hearing-Aid Compatibility (HAC) regulations for wireless devices .................. 63 FDA consumer update ................................. 64 Avoid potential hearing loss ....................... 69 CTIA user information requirements .......... 70 Index ..............................................................71 2 Contents CHAPTER 1 GETTING STARTED Phone overview Menu overview Charging the battery Turn on/off the phone Display icons Entering text Activating your Virgin Mobile account Finding your phone’s serial number Programming your phone CHAPTER 1 GETTING STARTED Getting Started 5 Left soft key Perform the functions shown at the Left bottom of the display. Microphone Allows the other caller to hear you clearly when you are speaking to them. Camera key Press for quick access to camera function. Headset jeck Plug in the Headset Interface Connector. Side volume key • Adjusts the earpiece volume. When phone is closed: • Press and hold Up to turn the backlight on. • Press and hold Down to turn the melody off when receiving an incoming call. • Press and hold to reject the incoming call. AVR key Press to enable VoiceSignal TM HPHONE…

Text truncated - open the document above for the full version.

External Photos

ID Label/Location Info

Internal Photos

Report No.: HCT-SAR08-0302 FCC ID: PP4X1 Date of Issue: Mar.04, 2008 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr 1 of 23 H . INTERNAL PHOTOGRAPHS Report No.: HCT-SAR08-0302 FCC ID: PP4X1 Date of Issue: Mar.04, 2008 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr 2 of 23 ■ INTERNAL PHOTO Report No.: HCT-SAR08-0302 FCC ID: PP4X1 Date of Issue: Mar.04, 2008 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr 3 of 23 ■ INTERNAL PHOTO Report No.: HCT-SAR08-0302 FCC ID: PP4X1 Date of Issue: Mar.04, 2008 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr 4 of 23 ■ INTERNAL PHOTO Report No.: HCT-SAR08-0302 FCC ID: PP4X1 Date of Issue: Mar.04, 2008 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr 5 of 23 ■ INTERNAL PHOTO Report No.: HCT-SAR08-0302 FCC ID: PP4X1 Date of Issue: Mar.04, 2008 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr 6 of 23 ■ INTERNAL PHOTO Report No.: HCT-SAR08-0302 FCC ID: PP4X1 Date of Issue: Mar.04, 2008 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr 7 of 23 ■ INTERNAL PHOTO Report No.: HCT-SAR08-0302 FCC ID: PP4X1 Date of Issue: Mar.04, 2008 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr 8 of 23 ■ INTERNAL PHOTO Report No.: HCT-SAR08-0302 FCC ID: PP4X1 Date of Issue: Mar.04, 2008 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr 9 of 23 ■ INTERNAL PHOTO Report No.: HCT-SAR08-0302 FCC ID: PP4X1 Date of Issue: Mar.04, 2008 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr 10 of 23 ■ INTERNAL PHOTO Report No.: HCT-SAR08-0302 FCC ID: PP4X1 Date of Issue: Mar.04, 2008 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr 11 of 23 ■ INTERNAL PHOTO Report No.: HCT-SAR08-0302 FCC ID: PP4X1 Date of Issue: Mar.04, 2008 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr 12 of 23 ■ INTERNAL PHOTO Report No.: HCT-SAR08-0302 FCC ID: PP4X1 Date of Issue: Mar.04, 2008 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr 13 of 23 ■ INTERNAL PHOTO Report No.: HCT-SAR08-0302 FCC ID: PP4X1 Date of Issue: Mar.04, 2008 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr 14 of 23 ■ INTERNAL PHOTO Report No.: HCT-SAR08-0302 FCC ID: PP4X1 Date of Issue: Mar.04, 2008 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr 15 of 23 ■ INTERNAL PHOTO Report No.: HCT-SAR08-0302 FCC ID: PP4X1 Date of Issue: Mar.04, 2008 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr 16 of 23 ■ INTERNAL PHOTO Report No.: HCT-SAR08-0302 FCC ID: PP4X1 Date of Issue: Mar.04, 2008 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr 17 of 23 ■ INTERNAL PHOTO Report No.: HCT-SAR08-0302 FCC ID: PP4X1 Date of Issue: Mar.04, 2008 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr 18 of 23 ■ INTERNAL PHOTO Report No.: HCT-SAR08-0302 FCC ID: PP4X1 Date of Issue: Mar.04, 2008 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr 19 of 23 ■ INTERNAL PHOTO Report No.: HCT-SAR08-0302 FCC ID: PP4X1 Date of Issue: Mar.04, 2008 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr 20 of 23 ■ INTERNAL PHOTO (Antenna Separation)

Parts List/Tune Up Info

APCPCWM_4828539:WP_0000003WP_0000003 APCPCWM_4828539:WP_0000003WP_000000 3 ANTENNA SPECIFICATION DATE 2008-03-04 REV. A MODEL X1 TYPE Built in PAGE 1/46 ANTENNA SPECIFICATION Prepared by Reviewed by Check by Approved by R F 08/03/03 08/03/03 R & D 08/03/03 08/03/03 2008-03-03 13:06/192.168.8.159/2004019 2008-03-03 13:06/192.168.8.159/2004019 APCPCWM_4828539:WP_0000003WP_0000003 APCPCWM_4828539:WP_0000003WP_000000 3 ANTENNA SPECIFICATION DATE 2008-03-04 REV. A MODEL X1 TYPE Built in PAGE 2/46 CONTENTS 1. Approval Sheet Check List 2. The quality of the material certification. 3. Technical Specifications 3.1 Electrical Specifications 3.2 Mechanical Specifications 3.3 Packing Specifications 4. Test equipments 5. Electrical Demands 5.1 V.S.W.R. 5.2 Radiation Pattern 5.3 Gain 6. Mechanical Demands 6.1 CONTACT PIN FORCE TEST. 6.2 CONTACT PIN RESISTENCE test. 6.3 Drop test. . 7. Environmental demands 7.1 Operation temperature test 7.2 Temperature Change test 7.3 High Humidity test 7.4 Vibration test 7.5 Salt spray Test 7.6 Storage temperature 2008-03-03 13:06/192.168.8.159/2004019 2008-03-03 13:06/192.168.8.159/2004019 APCPCWM_4828539:WP_0000003WP_0000003 APCPCWM_4828539:WP_0000003WP_000000 3 ANTENNA SPECIFICATION DATE 2008-03-04 REV. A MODEL X1 TYPE Built in PAGE 3/46 8. Antenna Data 8.1. Electrical data (V.S.W.R & GAIN) 8.2. Antenna Drawing 8.3. Packing Spec Drawing 8.4. Reliability Test 8.5. Environment test report 8.6. Manufacturing process 2008-03-03 13:06/192.168.8.159/2004019 2008-03-03 13:06/192.168.8.159/2004019 APCPCWM_4828539:WP_0000003WP_0000003 APCPCWM_4828539:WP_0000003WP_000000 3 ANTENNA SPECIFICATION DATE 2008-03-04 REV. A MODEL X1 TYPE Built in PAGE 4/46 1. Approval Check List Approval Check Lost NO DATE CHANGE CONTENTS CHANGE CAUSEREV 1 2008.03.04 ANTENNA SPECIFICATION A 2 3 4 5 6 7 8 9 10 11 12 13 14 2008-03-03 13:06/192.168.8.159/2004019 2008-03-03 13:06/192.168.8.159/2004019 APCPCWM_4828539:WP_0000003WP_0000003 APCPCWM_4828539:WP_0000003WP_000000 3 ANTENNA SPECIFICATION DATE 2008-03-04 REV. A MODEL X1 TYPE Built in PAGE 5/46 2. The quality of the material certification NO Part material Raw material processingfinishing EA Raw material company Processing plant etc 1 FRAME PC(141R-701) MOLD - 1 G.E 신아 정밀 - 2 SLOT STS301 PRESS - 1 세인금속 유한프리시젼 - 3 4 5 6 7 8 9 10 11 12 13 14 15 2008-03-03 13:06/192.168.8.159/2004019 2008-03-03 13:06/192.168.8.159/2004019 APCPCWM_4828539:WP_0000003WP_0000003 APCPCWM_4828539:WP_0000003WP_000000 3 ANTENNA SPECIFICATION DATE 2008-03-04 REV. A MODEL X1 TYPE Built in PAGE 6/46 3. Technical Specifications 3.1 Electrical Specifications. Electrical Spec. BAND Frequency Range (MHz) GPS PCS 1575 MHz 1850 MHz 1990 MHz V.S.W.R (Max.) 4.0:1 below 2.5:1 below 2.5:1 below PEAK GAIN Rx Tx Rx (Min., E2-Plane) (1575MHz) (1850MHz) (1990MHz) -4.5 dBi -1.5 dBi 0.0 dBi AVERAGE GAIN Rx Tx Rx (Min., H-Plane) (1575MHz) (1850MHz) (1990MHz) -3 .0 dBi -0.5 dBi -0.5 dBi Impedance(Nominal) 50 ohms Polarization VERTICAL Radiation Pattern OMNI-DIRECTIONAL Maximum Power 2 W 3.2 Mechanical Specifications Mechanical Spec. Connector Board contact pin type Overall length See drawing Operating Temperature -40°C ∼+85 °C Weight 1.416g (Unit) 3.3 Packing Specifications Packing Spec. PRODUCT QUANTITY (Antenna) MATERIAL TRAY 80EA P.S (0.8t) TRAY INNER PAD 2EA SW 2 type (B corrugated paper) CARTON BOX 1600EA/1BOX DW 2 type (AB corrugated paper) 2008-03-03 13:06/192.168.8.159/2004019 2008-03-03 13:06/192.168.8.159/2004019 APCPCWM_4828539:WP_0000003WP_0000003 APCPCWM_4828539:WP_0000003WP_000000 3 ANTENNA SPECIFICATION DATE 2008-03-04 REV. A MODEL X1 TYPE Built in PAGE 7/46 4. Test Equipment The equipment for antenna test is as follows, ♦ Network Analyzer (Agilent 8752C) to measure the V.S.W.R., Standing wave ratio(SWR) and impedance bandwidth of antenna ♦ Standard horn antennas adjustable to the GPS bands ♦ Standard horn antennas adjustable to the PCS bands ♦ Anechoic Chamber installed the cables, connectors and equipments for measurements ♦ Digital Caliper to measure the dimensions ♦ Torque Driver to measure the torque force of the helix ♦ Push/Pull gauge to measure the pulling forces ♦ Climatic Chamber for environmental tests 2008-03-03 13:06/192.168.8.159/2004019 2008-03-03 13:06/192.168.8.159/2004019 APCPCWM_4828539:WP_0000003WP_0000003 APCPCWM_4828539:WP_0000003WP_000000 3 ANTENNA SPECIFICATION DATE 2008-03-04 REV. A MODEL X1 TYPE Built in PAGE 8/46 5. Electrical Demands 5.1 V.S.W.R The V.S.W.R characteristics must be satisfied the electrical demands with folder open in the below table. Frequency Range GPS : 1575 MHz PCS:1850MHz ~ 1990MHz 1575MHz 1850MHz 1990MHz V.S.W.R 4.0:1 below 2.5:1 below 2.5:1 below 2008-03-03 13:06/192.168.8.159/2004019 2008-03-03 13:06/192.168.8.159/2004019 APCPCWM_4828539:WP_0000003WP_0000003 APCPCWM_4828539:WP_0000003WP_000000 3 ANTENNA SPECIFICATION DATE 2008-03-04 REV. A MODEL X1 TYPE Built in PAGE 9/46 5.2 Radiation Pattern The radiation pattern must have the omni-directional characteristic in Cellular Band and GPS Band and PCS Band. 5.3 Gain The gain is expressed as dBi. with condition (E2, H-Plane), the minimum Gain of antenna must be satisfied the electrical demands in the below table. BAND Electrical Spec. GPS PCS Rx Tx Rx Frequency Range (MHz) (1575MHz) (1850MHz) (1990MHz) Folder open (Min., E2-Plane) -3.0 dBi -1.5 dBi 0.0 dBi Rx Tx Rx Frequency Range (MHz) (1575MHz) (1850MHz) (1990MHz) Folder Open (Min., H-Plane) -4.5 dBi -0.5 dBi -0.5 dBi 2008-03-03 13:06/192.168.8.159/2004019 2008-03-03 13:06/192.168.8.159/2004019 APCPCWM_4828539:WP_0000003WP_0000003 APCPCWM_4828539:WP_0000003WP_000000 3 ANTENNA SPECIFICATION DATE 2008-03-04 REV. A MODEL X1 TYPE Built in PAGE 10/46 6. Mechanical Demands 6.1. CONTACT PIN FORCE TEST Contact pin of antenna must keep 200g/f ±150 in operation distance. (Operation distance of antenna is same to under drawing. / PCB over rap : ⓐ, ⓑ0.0mm~1.65mm,ⓒ 0.0mm~1.4mm ) 6.2. CONTACT PIN RESISTENCE test . After assemble antenna to test …

Text truncated - open the document above for the full version.

RF Exposure Info

Report No.: HCT-SAR08-0302 FCC ID: PP4X1 Date of Issue: Mar.04, 2008 HCT CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : +82 31 639 8565 FAX : +82 31 639 8525 www.hct.co.kr 2 of 58 Table of Contents 1. INTRODUCTION..........................................................................................................................................３ 2. DESCRIPTION OF DEVICE .........................................................................................................................４ 3. DESCRIPTION OF TEST EQUIPMENT ......................................................................................................５ 3.1 SAR MEASUREMENT SETUP ....................................................................................................５ 3.2 DASY E-FIELD PROBE SYSTEM ................................................................................................６ 3.3 PROBE CALIBRATION PROCESS ..............................................................................................７ 3.4 SAM Phantom .............................................................................................................................９ 3.5 Device Holder for Transmitters .....................................................................................................９ 3.6 Brain & Muscle Simulating Mixture Characterization ..................................................................１０ 3.7 SAR TEST EQUIPMENT ..........................................................................................................１１ 4. SAR MEASUREMENT PROCEDURE .....................................................................................................１２ 5. DESCRIPTION OF TEST POSITION .......................................................................................................１３ 5.1 HEAD POSITION .....................................................................................................................１３ 5.2 Body Holster/Belt Clip Configurations ........................................................................................１４ 6. MEASUREMENT UNCERTAINTY ...........................................................................................................１５ 7. ANSI/ IEEE C95.1 - 2005 RF EXPOSURE LIMITS ..................................................................................１６ 8. SYSTEM VERIFICATION .........................................................................................................................１７ 8.1 Tissue Verification ....................................................................................................................１７ 8.2 System Validation .....................................................................................................................１７ 9. 3G MEASUREMENT PROCEDURES .....................................................................................................１８ 9.1 Procedures Used To Establish Test Signal .................................................................................１８ 9.2 SAR Measurement Conditions for CDMA2000 1x ......................................................................１８ 10. SAR Evaluation Considerations for Handsets with Multiple Transmitters and Antennas .....................1 9 11. SAR TEST DATA SUMMARY .................................................................................................................２０ 11.1 Measurement Results (PCS1900 Head SAR Touch) ................................................................２１ 11.2 Measurement Results (PCS1900 Head SAR Tilt) .....................................................................２２ 11.3 Measurement Results (PCS1900 Body SAR) ...........................................................................２３ 12. CONCLUSION ........................................................................................................................................２４ 13.REFERENCES ........................................................................................................................................２５ Attachment 1. – SAR Test Plots....................................................................................................................２６ Attachment 2. – Dipole Validation Plots........................................................................................................３９ Attachment 3. – Probe Calibration Data.......................................................................................................４３ Attachment 4. – Dipole Calibration Data......................................................................................................５３ Report No.: HCT-SAR08-0302 FCC ID: PP4X1 Date of Issue: Mar.04, 2008 HCT CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : +82 31 639 8565 FAX : +82 31 639 8525 www.hct.co.kr 3 of 58 1. INTRODUCTION The FCC has adopted the guidelines for evaluating the environmental effects of radio frequency radiation in ET Docket 93-62 on Aug. 6, 1996 to protect the public and workers from the potential hazards of RF emissions due to FCC-regulated portable devices. The safety limits used for the environmental evaluation measurements are based on the criteria published by the American National Standards Institute (ANSI) for localized specific absorption rate (SAR) in IEEE/ANSI C95.1-2005 Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. 1992 by the Institute of Electrical and Electronics Engineers, Inc., New York, New York 10017. The measurement procedure described in IEEE/ANSI C95.3-1992 Recommended Practice for the Measurement of Potentially Hazardous Electromagnetic Fields - RF and Microwave is used for guidance in measuring SAR due to the RF radiation exposure from the Equipment Under Test (EUT). These criteria for SAR evaluation are similar to those recommended by…

Text truncated - open the document above for the full version.

Test Report

Report No.: HCT-F08-0306 FCC ID: PP4X1 DATE: March 6, 2008 HCT CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8539 FAX : +82 31 639 8535 www.hct.co.kr 2 / 16 TABLE OF CONTENTS PAGE 1. GENERAL INFORMATION 3 1.1 Product Description.................................................................. 3 1.2 Related submittal(s)/Grant(s)..................................................... . 3 1.3 Tested System Details............................................................... 4 1.4 Cable Description..................................................................... 4 1.5 Noise Suppression Parts on Cable. (I/O CABLE) ........................... 4 1.6 Test Methodology..................................................................... 5 1.7 Test Facility............................................................................ 5 2. SYSTEM TEST CONFIGURATION..................................................... 6 2.1 Configuration of Tested System................................................... 6 3. PRELIMINARY TEST....................................................................... 7 3.1 Conducted Emission Test......................................................... 7 3.2 Radiated Emission Test............................................................ 7 4. CONDUCTED AND RADIATED EMISSION TEST SUMMARY.................. 8 4.1 Conducted Emission Test.......................................................... 9 – 12 4.2 Radiated Emission Test............................................................. 13 5. FIELD STRENGTH CALCULATION...................................................... 14 6. Test Equipment................................................................................ 15 7. Conclusion...................................................................................... 16 ATTACHMENT : TEST SETUP PHOTOGRAPHS Report No.: HCT-F08-0306 FCC ID: PP4X1 DATE: March 6, 2008 HCT CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8539 FAX : +82 31 639 8535 www.hct.co.kr 3 / 16 1. GENERAL INFORMATION 1.1 Product Description The PANTECH&CURITEL COMMUNICATION,INC. CDM8074 Single-Band CDMA PCS Phone with Bluetooth. It’s basic purpose is used for communications. It transmits from PCS1900 (1851.25 MHz – 1908.75 MHz) and receives from PCS1900 (1931.25 MHz – 1988.75 MHz). MODEL CDM8074 FCC ID PP4X1 EUT Type Single-Band CDMA PCS Phone with Bluetooth TX Frequency 1851.25 MHz – 1908.75 MHz (PCS1900) 2402 MHz – 2480 MHz (Bluetooth) RX Frequency 1931.25 MHz – 1988.75 MHz (PCS1900) 2402 MHz – 2480 MHz (Bluetooth) Modulation PCS1900 Bluetooth 1.2 Related Submittal(s) / Grant(s) ORIGINAL SUBMITTAL ONLY Report No.: HCT-F08-0306 FCC ID: PP4X1 DATE: March 6, 2008 HCT CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8539 FAX : +82 31 639 8535 www.hct.co.kr 4 / 16 1.3 Tested System Details All equipment descriptions used in the tested system (including inserted cards) are: DEVICE TYPE MANUFACTURER MODEL NUMBER/ PART NUMBER FCC ID / DoC CONNECTED TO Single-Band CDMA PCS Phone with Bluetooth PANTECH&CURITEL COMMUNICATION,INC CDM8074 PP4X1 TA,Notebook PC Travel Adaptor UTSTARCOM CNR4 - EUT Notebook PC Toshiba PSMA2K-01D002 DoC EUT Notebook Adaptor Delta SADP-65KB B - Notebook PC Mouse DELL MO56U0 DoC Notebook PC Ear phone - - - EUT USB Cable - - - EUT, PC 1.4 Cable Description Product Name Port Power Cord Shielded (Y/N) I/O Cable Shielded (Y/N) Length (M) DC-In N N/A (P)1.9 Ear Jack N/A N (D)1.6 Single-Band CDMA PCS Phone with Bluetooth USB Data N/A Y (D)1.1 Notebook PC USB (Mouse) N/A Y (D)1.8 The marked "(D)" means the Data Cable and "(P)" means the Power Cable. 1.5 Noise Suppression Parts on Cable. (I/O CABLE) Product Name Port Ferrite Bead (Y/N) Location Metal Hood (Y/N) Location DC-In Y PC End Y EUT End Ear Jack N - Y EUT End Dual-Band CDMA Phone with Bluetooth USB Data N - Y Both End Notebook USB (Mouse) N - Y Notebook End Report No.: HCT-F08-0306 FCC ID: PP4X1 DATE: March 6, 2008 HCT CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8539 FAX : +82 31 639 8535 www.hct.co.kr 5 / 16 1.6 Test Methodology Both conducted and radiated testing were performed according to the procedures in ANSI C63.4/2003. Radiated testing was performed at an antenna to EUT distance of 3 meters. 1.7 Test Facility The open area test site and conducted measurement facility used to collect the radiated data are located at the 254-1,Maekok-Ri, Hobup-Myun, Ichon-Si, Kyoungki-Do, 467-701, KOREA. The site is constructed in conformance with the requirements of ANSI C63.4 and CISPR Publication 22. Detailed description of test fac…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Ki Pyeo Son(Senior MTS)

[email protected]82-2-2030-1220Fax: 82-2-2030-2520

Test Firm

HCT Co., LTDSang Lee

[email protected]82-31-645-6420Fax: 82-31-645-6401

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
1	24E	1.85 GHz - 1.91 GHz	331.00 mW	1M28F9W	2.5000000000 ppm

Confidentiality

Long Term

Grant Notes

Power Output is EIRP. Body-worn operations are restricted to the specific belt-clips/holsters tested with this device. End users must be informed of the body worn requirements for satisfying RF Exposure compliance. Collocated Bluetooth transmitter is evaluated in this filing. The highest reported SAR values are: PCS Band Head: 1.37 W/kg; Body-worn 0.422 W/kg. HAC rating: M4
