PPIRM-509HGSM/WCDMA cellular phone w/BT

Nokia 3710 fold User Guide 5555555 Issue 1 CyanCyanMagentaMagentaYellowYellowBlackBlack Contents Safety4 Get started5 Keys and parts5 Insert the SIM card and battery5 Insert and remove the memory card6 Charge the battery7 GSM antenna8 Accessories8 Switch it on9 About your device9 Network services10 Access codes10 Switch the device on and off11 Home screen 11 Navigate the menus12 Lock the keys13 Functions without a SIM card 13 Flight profile13 Support and updates14 Support14 My Nokia14 Download content14 Software updates using your PC14 Software updates over the air15 Restore factory settings15 Make it your device16 Basic settings16 Personalise your device17 Connect19 Network provider services21 Stay in touch22 Make calls22 Text and messages25 Mail and Instant Messaging28 Image and video29 Capture images29 Record video clips30 Camera and video settings30 Gallery30 Print images31 Share images and video clips online31 Memory card31 Entertainment32 Listen to music32 Web 35 Games and applications37 Maps38 About Maps38 Nokia Map Loader38 About GPS39 GPS receiver39 Navigate to your destination39 Organise40 Manage contacts40 Business cards41 Date and time41 Alarm clock41 Calendar42 To-do list42 Notes42 Nokia PC Suite42 Calculator43 Countdown timer43 Stopwatch43 Green tips44 Save energy44 Recycle44 Learn more44 Digital rights management45 Accessories45 2Contents www.nokia.com/support CyanCyanMagentaMagentaYellowYellowBlackBlack Battery45 Battery and charger information45 Nokia battery authentication guidelines46 Taking care of your device46 Recycle47 Additional safety information47 Small children47 Operating environment47 Medical devices47 Telecoil hearing aid47 Vehicles47 Potentially explosive environments48 Emergency calls48 Certification information (SAR)48 Index49 Contents3 www.nokia.com/support CyanCyanMagentaMagentaYellowYellowBlackBlack Safety Read these simple guidelines. Not following them may be dangerous or illegal. Read the complete user guide for further information. SWITCH ON SAFELY Do not switch the device on when wireless phone use is prohibited or when it may cause interference or danger. ROAD SAFETY COMES FIRST Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety. INTERFERENCE All wireless devices may be susceptible to interference, which could affect performance. SWITCH OFF IN RESTRICTED AREAS Follow any restrictions. Switch the device off in aircraft, near medical equipment, fuel, chemicals, or blasting areas. QUALIFIED SERVICE Only qualified personnel may install or repair this product. ACCESSORIES AND BATTERIES Use only approved accessories and batteries. Do not connect incompatible products. WATER-RESISTANCE Your device is not water- resistant. Keep it dry. 4Safety www.nokia.com/support CyanCyanMagentaMagentaYellowYellowBlackBlack Get started Get to know your device, insert the battery, SIM card, and memory card, and learn some important information about your device. Keys and parts 1Earpiece 2Display 3Navi™ key (scroll key) 4Call key 5Microphone 6Keypad 7Secondary camera 8Left and right selection keys 9End/Power key 10Camera flash 11Camera lens 12Nokia AV Connector (2.5 mm) 13Volume keys 14Loudspeaker 15Hidden display 16Charger connector 17Micro USB cable connector 18Wrist strap eyelet Insert the SIM card and battery Note: Switch off the power and disconnect the charger and any other device before removing the covers. Avoid touching electronic components while changing the covers. Always store and use the device with the covers attached. The SIM card and its contacts can be easily damaged by scratches or bending, so be careful when handling, inserting, or removing the card. 1Open the back cover, and remove it. Get started5 www.nokia.com/support CyanCyanMagentaMagentaYellowYellowBlackBlack 2Remove the battery. 3Open the SIM card holder. Insert the SIM card into the holder with the bevelled corner facing down and the contact surface area facing toward the contacts of the device. The side with the bevelled corner fits below the rim of the device. Close the SIM card holder. 4Line up the battery contacts, and insert the battery. 5Place the battery cover on the device, that the hooks at the upper part of the cover are aligned with the corresponding recesses on the device. Slide the back cover to close it. Insert and remove the memory card Use only compatible microSD cards approved by Nokia for use with this device. Nokia uses approved industry standards for memory cards, but some brands may not be fully compatible with this device. Incompatible cards may damage the card and the device and corrupt data stored on the card. Your device supports microSD cards with a c a p a c i t y o f u p t o 8 G B . T h e s i z e o f a s i n g l e file must not exceed 2 GB. 6Get started www.nokia.com/support CyanCyanMagentaMagentaYellowYellowBlackBlack Insert the memory card 1Switch the device off, and remove the back cover and battery. 2Slide the memory card holder inwards to unlock. 3Open the card holder, and insert the memory card into the holder with the contact surface facing inwards. 4Close the card holder, and slide it to lock. 5Replace the battery and back cover. Remove the memory card 1Remove the back cover and the battery. 2Open the memory card holder, and remove the memory card. Close the memory card holder. 3Replace the battery and back cover. Charge the battery Your battery has been partially charged at the factory. If the device indicates a low charge, do the following: 1Connect the charger to a wall outlet. 2Connect the charger to the device. 3When the device indicates a full charge, disconnect the charger from the device, then from the wall outlet. You can also charge the battery with a USB cable, using power from a computer. 1Connect the USB cable to a USB port of a computer and to your device. 2When the battery is fully charged, disconnect the USB cable. If the battery is completely dis…

Text truncated - open the document above for the full version.

19 February 2010 External photographs FCC ID: PPIRM-509H Exhibit 3 IC: 661U-RM509 Applicant: Nokia Corporation Copyright © 2010 Nokia. All rights reserved. 1. EXTERNAL PHOTOGRAPHS 1.1 Front and back 19 February 2010 External photographs FCC ID: PPIRM-509H Exhibit 3 IC: 661U-RM509 Applicant: Nokia Corporation Copyright © 2010 Nokia. All rights reserved. 1.1 Disassembled 19 February 2010 External photographs FCC ID: PPIRM-509H Exhibit 3 IC: 661U-RM509 Applicant: Nokia Corporation Copyright © 2010 Nokia. All rights reserved. External interfaces

1 (1) NOKIA Corporation 02/26/2010 Copyright  Nokia 2010. All rights reserved. TYPE LABEL FOR PPIRM-509H LABEL LOCATION FOR PPIRM-509H

12 February 2010 Internal photographs FCC ID: PPIRM-509H Exhibit 9 IC: 661U-RM509 Applicant: Nokia Mobile Phones Copyright © 2010 Nokia. All rights reserved. 1. INTERNAL PHOTOGRAPHS 1.1 Pwb front 12 February 2010 Internal photographs FCC ID: PPIRM-509H Exhibit 9 IC: 661U-RM509 Applicant: Nokia Mobile Phones Copyright © 2010 Nokia. All rights reserved. 1.2 Pwb back

FCC Part 15C Compliance Test Report Test Report no.: FCC15C_RM-509_23.doc Date of Report: 25-Feb-2010 Number of pages: 39 Customer’s Contact person: Ralph Schwarz Testing laboratory: TCC Nokia Copenhagen Laboratory Frederikskaj 1790 COPENHAGEN V DENMARK Tel. +45 33 292929 Fax. +45 33 292934 FCC listing no.: IC recognition no.: 99059 661AD-1 Customer: Nokia Corporation Lise Meitner Strasse 10 89081 ULM GERMANY Tel. +49 731 1754 0 Fax. +49 731 1754 6800 Tested devices/ accessories: Phone; RM-509 (HW 0510), Battery; BL-4S, Headset; HS-105, AC Charger; AC-8E FCC ID: PPIRM-509H IC: 661U-RM509 Supplement reports: Testing has been carried out in accordance with: CFR 47, FCC rules Part 15 Subpart C, ANSI C63.4 (2003), Public Notice DA 00-705, DTS procedures KDB 558074, IC standards RSS-GEN (Issue 2, June 2007) and RSS-210 (Issue 7, June 2007). Deviations, modifications or clarifications (if any) to above mentioned documents are written in each section under "Test method and limit". Documentation: The test report must always be reproduced in full; reproduction of an excerpt only is subject to written approval of the testing laboratory. The documentation of the testing performed on the tested devices is archived for 15 years at TCC Nokia. Test Results: The EUT complies with the requirements in respect of all parameters subject to the test. The test results relate only to devices specified in this document. Date and signature for the contents: Sami Lehtonen, System Specialist, EMC FCC Part 15C Compliance Test Report / Template Version 12.0 FCC15C_RM-509_23.doc Copyright © TCC Nokia 1 (39) TCC Nokia Copenhagen Laboratory Frederikskaj 1790 COPENHAGEN V DENMARK Tel. +45 33 292929 Fax. +45 33 292934 FCC Part 15C Compliance Test Report / Template Version 12.0 FCC15C_RM-509_23.doc Copyright © TCC Nokia 2 (39) TCC Nokia Copenhagen Laboratory Frederikskaj 1790 COPENHAGEN V DENMARK Tel. +45 33 292929 Fax. +45 33 292934 1. Summary for FCC Part 15C Compliance Test Report Date of receipt 20-Jul-2009 Testing completed 12-Aug-2009 The customer's contact person Ralph Schwarz Test Plan referred to T:\Projects\RM-509\TestPlan_RS\RS_testplan_RM-509.xls Notes None Document name FCC15C_RM-509_23.doc 1.1. EUT and Accessory Information The EUT is a 7-band (GSM850/900/1800/1900 and WCDMA Band I/IV(1700)/VIII) mobile phone with GPRS, EGPRS and Bluetooth. Bluetooth is tested with maximum rated TX power. Product Type SN HW MV SW DUT Phone RM-509 004401106655471 0510 - 3.10 24937 Battery BL-4S 3932138486260225094;0670577 - - - 24934 Headset HS-105 0694287913411200175 - - - 24927 AC Charger AC-8E 1103339131030310170;0675387 - - - 24924 Phone RM-509 004401106655216 0510 - 3.10 24939 Battery BL-4S 3932138486260225107;0670577 - - - 24936 Headset HS-105 0694287913411200217 - - - 24928 AC Charger AC-8E 1103339131030310156;0675387 - - - 24922 Dummy Battery SD-40 - V.2636 - - 24925 1.2. Summary of Test Results Bluetooth: Section in CFR 47 Section in RSS-GEN or RSS-210 Name of the test Result 15.247(b)(1) A8.4 (2) Conducted peak output power Passed 15.247(d) A8.5 Band edge compliance of RF emissions Passed 15.247(d) A8.5 Spurious RF conducted emissions Passed 15.247(d), 15.209 A8.5 Spurious radiated emissions Passed 15.207 7.2.2 AC powerline conducted emissions Passed 15.247(a)(1) A8.1 (a) 20 dB bandwidth Passed 15.247(a)(1) A8.1 (b) Carrier frequency separation Passed 15.247(a)(1)(iii) A8.1 (d) Number of hopping frequencies Passed 15.247(a)(1)(iii) A8.1 (d) Time of occupancy Passed PASSED The EUT complies with the essential requirements in the standard. FAILED The EUT does not comply with the essential requirements in the standard. NP The test was not performed by the TCC Nokia Copenhagen Laboratory. FCC Part 15C Compliance Test Report / Template Version 12.0 FCC15C_RM-509_23.doc Copyright © TCC Nokia 3 (39) TCC Nokia Copenhagen Laboratory Frederikskaj 1790 COPENHAGEN V DENMARK Tel. +45 33 292929 Fax. +45 33 292934 CONTENTS 1. Summary for FCC Part 15C Compliance Test Report.............................................. 2 1.1. EUT and Accessory Information ............................................................................................2 1.2. Summary of Test Results .......................................................................................................2 2. Test setups.................................................................................................................. 5 2.1. Conducted RF test setup .......................................................................................................5 2.2. AC powerline conducted emissions test setup.......................................................................5 2.3. Radiated test setup ................................................................................................................5 3. Conducted peak output power (FCC §15.247(b)(1), RSS-210 A8.4 (2)) .................. 6 3.1. Test method and limit .............................................................................................................6 3.2. Bluetooth Test results ............................................................................................................7 4. Band edge compliance of RF emissions (FCC §15.247(d), RSS-210 A8.5) .......... 10 4.1. Test method and limit ...........................................................................................................10 4.2. Bluetooth Test results ..........................................................................................................11 5. Spurious RF conducted emissions (FCC §15.247(d), RSS-A8.5).......................... 15 5.1. Test method and limit ...........................................................................................................15 5.2. Bluetooth Test results ..........................................................................................................16 6. Spurious radiated emissions (FCC §15.247(d), §15.209, RSS-210 A8.5).…

Text truncated - open the document above for the full version.

FCC Part 15C Compliance Test Report Test Report no.: FCC15C_RM-509_24.doc Date of Report: 25-Feb-2010 Number of pages: 21 Customer’s Contact person: Ralph Schwarz Testing laboratory: TCC Nokia Tampere Laboratory P.O. Box 68 Sinitaival 5 FIN-33720 TAMPERE, FINLAND Tel. +358 (0) 7180 46800 Fax. +358 (0) 7180 46880 FCC listing no.: IC recognition no.: 94436 661AK-1 Customer: Nokia Corporation Lise Meitner Strasse 10 89081 ULM GERMANY Tel. +49 731 1754 0 Fax. +49 731 1754 6800 Tested devices/ accessories: Phone RM-509 / Battery BL-4S, AC charger AC-8E, Headset HS-105 FCC ID: PPIRM-509H IC: 661U-RM509 Supplement reports: - Testing has been carried out in accordance with: CFR 47, FCC rules Part 15 Subpart C, ANSI C63.4 (2003), Public Notice DA 00-705, DTS procedures KDB 558074, IC standards RSS-GEN (Issue 2, June 2007) and RSS-210 (Issue 7, June 2007). Deviations, modifications or clarifications (if any) to above mentioned documents are written in each section under "Test method and limit". Documentation: The test report must always be reproduced in full; reproduction of an excerpt only is subject to written approval of the testing laboratory. The documentation of the testing performed on the tested devices is archived for 15 years at TCC Nokia. Test Results: The EUT complies with the requirements in respect of all parameters subject to the test. The test results relate only to devices specified in this document. Date and signature for the contents: Sami Lehtonen, System Specialist, EMC FCC Part 15C Compliance Test Report / Template Version 12.0 FCC15C_RM-509_24.doc Copyright © TCC Nokia 1 (21) TCC Nokia Tampere Laboratory P.O. Box 68 Sinitaival 5 FIN-33720 TAMPERE, FINLAND Tel. +358 (0) 7180 46800 Fax. +358 (0) 7180 46880 FCC Part 15C Compliance Test Report / Template Version 12.0 FCC15C_RM-509_24.doc Copyright © TCC Nokia 2 (21) TCC Nokia Tampere Laboratory P.O. Box 68 Sinitaival 5 FIN-33720 TAMPERE, FINLAND Tel. +358 (0) 7180 46800 Fax. +358 (0) 7180 46880 1. Summary for FCC Part 15C Compliance Test Report Date of receipt 14-Aug-2009 Testing completed 19-Aug-2009 The customer's contact person Ralph Schwarz Test Plan referred to T:\Projects\RM-509\TestPlan_RS\RS_testplan_RM- 509_CR_HW0410.xls Notes - Document name FCC15C_RM-509_24.doc 1.1. EUT and Accessory Information The EUT is a 7-band (GSM850/900/1800/1900 and WCDMA Band I/IV(1700)/VIII) mobile phone with GPRS, EGPRS and Bluetooth. Bluetooth is tested with maximum rated TX power. Product Type SN HW MV SW DUT Phone RM-509 004401106632801 0410 - 3.10 41978 Phone RM-509 004401106632843 0410 - 3.10 41977 Battery BL-4S 3820668095140100000;0670577 - - - 41979 AC charger AC-8E 1103338411070317367;0675387 - - - 41980 Headset HS-105 0694287913411200016 - - - 41981 1.2. Summary of Test Results Bluetooth: Section in CFR 47 Section in RSS-GEN or RSS-210 Name of the test Result 15.247(b)(1) A8.4 (2) Conducted peak output power PASSED 15.247(d) A8.5 Band edge compliance of RF emissions PASSED 15.247(d) A8.5 Spurious RF conducted emissions PASSED 15.247(d), 15.209 A8.5 Spurious radiated emissions PASSED 15.207 7.2.2 AC powerline conducted emissions NP 15.247(a)(1) A8.1 (a) 20 dB bandwidth NP 15.247(a)(1) A8.1 (b) Carrier frequency separation NP 15.247(a)(1)(iii) A8.1 (d) Number of hopping frequencies NP 15.247(a)(1)(iii) A8.1 (d) Time of occupancy NP PASSED The EUT complies with the essential requirements in the standard. FAILED The EUT does not comply with the essential requirements in the standard. NP The test was not performed by the TCC Nokia Tampere Laboratory. FCC Part 15C Compliance Test Report / Template Version 12.0 FCC15C_RM-509_24.doc Copyright © TCC Nokia 3 (21) TCC Nokia Tampere Laboratory P.O. Box 68 Sinitaival 5 FIN-33720 TAMPERE, FINLAND Tel. +358 (0) 7180 46800 Fax. +358 (0) 7180 46880 CONTENTS 1. Summary for FCC Part 15C Compliance Test Report.............................................. 2 1.1. EUT and Accessory Information ............................................................................................2 1.2. Summary of Test Results .......................................................................................................2 2. Test setups.................................................................................................................. 4 2.1. Conducted RF test setup .......................................................................................................4 2.2. AC powerline conducted emissions test setup.......................................................................4 2.3. Radiated test setup ................................................................................................................4 3. Conducted peak output power (FCC §15.247(b)(1), RSS-210 A8.4 (2)) .................. 5 3.1. Test method and limit .............................................................................................................5 3.2. Bluetooth Test results ............................................................................................................6 4. Band edge compliance of RF emissions (FCC §15.247(d), RSS-210 A8.5) ............ 8 4.1. Test method and limit .............................................................................................................8 4.2. Bluetooth Test results ............................................................................................................9 5. Spurious RF conducted emissions (FCC §15.247(d), RSS-A8.5).......................... 13 5.1. Test method and limit ...........................................................................................................13 5.2. Bluetooth Test results ..........................................................................................................14 6. Spurious radiated emissions (FCC §15.247(d), §15.209, RSS-210 A8.5).............. 16 6.1. Test method and limit ........................................................................................…

Text truncated - open the document above for the full version.

RM-509 Test Setups Picture 1. FCC Part 15C Radiated emissions Picture 2. FCC Part 15B Radiated emissions Picture 3. FCC Part 15B AC powerline conducted emissions EMC Test Setup Photos / Template Version 1.0 FCC Setup pictures RM-509.doc Copyright © TCC Nokia 1 (2) Picture 4. FCC Part 15C AC powerline conducted emissions EMC Test Setup Photos / Template Version 1.0 FCC Setup pictures RM-509.doc Copyright © TCC Nokia 2 (2)
