PPIRM-615GSM/WCDMA cellular phone w/BT

Nokia 5330 Mobile TV Edition User Guide 5555555 Issue 1 CyanCyanMagentaMagentaYellowYellowBlackBlack 2009-11-24 10:17:31 DECLARATION OF CONFORMITY 0434 Hereby, NOKIA CORPORATION declares that this RM-615 product is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. A copy of the Declaration of Conformity can be found at www.nokia.com/ phones/declaration_of_conformity/. © 2009 Nokia. All rights reserved. Nokia, Nokia Connecting People and Navi are trademarks or registered trademarks of Nokia Corporation. Nokia tune is a sound mark of Nokia Corporation. Other product and company names mentioned herein may be trademarks or tradenames of their respective owners. Portions of the Nokia Maps software are ©1996-2009 The FreeType Project. All rights reserved. Reproduction, transfer, distribution, or storage of part or all of the contents in this document in any form without the prior written permission of Nokia is prohibited. Nokia operates a policy of continuous development. Nokia reserves the right to make changes and improvements to any of the products described in this document without prior notice. Includes RSA BSAFE cryptographic or security protocol software from RSA Security. Java and all Java-based marks are trademarks or registered trademarks of Sun Microsystems, Inc. This product is licensed under the MPEG-4 Visual Patent Portfolio License (i) for personal and noncommercial use in connection with information which has been encoded in compliance with the MPEG-4 Visual Standard by a consumer engaged in a personal and noncommercial activity and (ii) for use in connection with MPEG-4 video provided by a licensed video provider. No license is granted or shall be implied for any other use. Additional information, including that related to promotional, internal, and commercial uses, may be obtained from MPEG LA, LLC. See http://www.mpegla.com. TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, UNDER NO CIRCUMSTANCES SHALL NOKIA OR ANY OF ITS LICENSORS BE RESPONSIBLE FOR ANY LOSS OF DATA OR INCOME OR ANY SPECIAL, INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES HOWSOEVER CAUSED. THE CONTENTS OF THIS DOCUMENT ARE PROVIDED "AS IS". EXCEPT AS REQUIRED BY APPLICABLE LAW, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS DOCUMENT. NOKIA RESERVES THE RIGHT TO REVISE THIS DOCUMENT OR WITHDRAW IT AT ANY TIME WITHOUT PRIOR NOTICE. The availability of particular products and applications and services for these products may vary by region. Please check with your Nokia dealer for details and availability of language options. This device may contain commodities, technology or software subject to export laws and regulations from the US and other countries. Diversion contrary to law is prohibited. FC C / INDUSTRY CANADA NOTICE Your device may cause TV or radio interference (for example, when using a telephone in close proximity to receiving equipment). The FCC /Industry Canada can require you to stop using your telephone if such interference cannot be eliminated. If you require assistance, contact your local service facility. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by Nokia could void the user's authority to operate this equipment. Model number: Nokia 5330-1d 5555555/Issue 1 EN 2 CyanCyanMagentaMagentaYellowYellowBlackBlack 2009-11-24 10:17:31 Contents Safety5 1. Get started6 Keys and parts6 Insert the SIM card and battery6 Insert and remove the memory card7 Charge the battery8 Antenna8 Accessories9 2. Switch it on9 About your device9 Network services10 Access codes10 Switch the device on and off11 Standby mode11 Touch music keys12 Navigate the menus13 Lock the keys13 Functions without a SIM card 13 Flight profile14 3. Make it your device14 Basic settings14 Personalise your phone15 Connect17 Network provider services19 4. Stay in touch21 Make calls21 Text and messages23 Nokia Messaging IM26 Nokia Messaging Mail27 5. Image and video28 Capture images28 Record video clips29 Camera and video settings29 Gallery29 Print images30 Memory card30 6. Entertainment31 Listen to music31 Web 33 Games and applications35 7. Mobile TV36 About Mobile TV36 First start-up36 View and select a program36 Change audio output37 Electronic program guide (EPG)37 Subscribe to a channel or program37 Mobile TV settings38 Start-up Mobile TV after changing SIM card38 8. Maps38 Download maps39 Maps and GPS39 Extra services40 9. Organise40 Manage contacts40 Business cards41 Date and time41 Alarm clock41 Calendar42 To-do list42 Notes42 Nokia PC Suite42 Calculator42 Countdown timer42 Stopwatch43 10. Support and updates43 Support43 My Nokia43 Download content44 Update software using your PC44 Contents3 www.nokia.com/support3 CyanCyanMagentaMagentaYellowYellowBlackBlack 2009-11-24 10:17:31 Software updates over the air44 Restore factory settings45 11. Green tips45 Save energy45 Recycle45 Learn more45 Digital rights management46 Third-party applications46 Accessories46 Battery46 Battery and charger information46 Nokia battery authentication guidelines47 Take care of your device47 Recycle48 Additional safety information48 Magnets and magnetic fields48 Small children48 Operating environment48 Medical devices48 Vehicles48 Potentially explosive environments49 Emergency calls49 Certification information (SAR)49 Index50 4Contents 4www.nokia.com/support CyanCyanMagentaMagentaYellowYellowBlackBlack 2009-11-24 10:17:31 Safety Read these simple guidelines. Not following them may be dangerous or illegal. Read the complete user guide for further info…

Text truncated - open the document above for the full version.

NOKIA GmbH Joensuunkatu 7 FIN-24100 SALO FINLAND Tel. +358 7180 08000 December 01, 2009 Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD. 21046 Attention: Equipment Authorization Branch REQUEST FOR CONFIDENTIALITY Pursuant to Sections 0.457 (d) (l) (ii) and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of some of the information accompanying this Application of FCC ID: PPIRM-615 and as outlined below: - Exhibit 4: Block Diagram - Exhibit 5: Schematic Diagrams - Exhibit 12: Theory of Operation / Description of Circuitry These materials contain trade secrets and proprietary information not customarily released to the public and the public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457 (d) (l) (ii) disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this Application. NOKIA CORPORATION Tero Lehtinen Product Certification Officer Devices, Salo

26 November 2009 External photographs FCC ID: PPIRM-615 Exhibit 3 IC: 661U-RM615 Applicant: Nokia Corporation Copyright © 2009 Nokia. All rights reserved. 1. EXTERNAL PHOTOGRAPHS 1.1 Front and back 26 November 2009 External photographs FCC ID: PPIRM-615 Exhibit 3 IC: 661U-RM615 Applicant: Nokia Corporation Copyright © 2009 Nokia. All rights reserved. 1.1 Disassembled 1.2 External interfaces

1 (1) NOKIA Corporation 26/10/2009 Copyright © Nokia 2009. All rights reserved. TYPE LABEL FOR PPIRM-615 LABEL LOCATION FOR PPIRM-615

26 November 2009 Internal photographs FCC ID: PPIRM-615 Exhibit 9 IC: 661U-RM615 Applicant: Nokia Corporation Copyright © 2009 Nokia. All rights reserved. 1. INTERNAL PHOTOGRAPHS 1.1 Pwb back 1.2 Pwb front

FCC Part 15B Compliance Test Report Test Report no.: FCC15B_RM-615_06.doc Date of Report: 20-Nov-2009 Number of pages: 9 Customer’s Contact person: Vivian Kill-Tollnek Testing laboratory: TCC Nokia Salo Laboratory P.O.Box(86) Joensuunkatu 7H / Kiila 1B FIN-24101 SALO, FINLAND Tel. +358 (0) 7180 08000 Fax. +358 (0) 7180 45220 FCC listing no.: IC recognition no.: 533467 661V-1 Customer: Nokia Corporation Lise Meitner Strasse 10 89081 ULM GERMANY Tel. +49 731 1754 0 Fax. +49 731 1754 6800 Tested devices/ accessories: phone RM-615 / Battery BL-4U / AC Charger AC-8E / WH-205 FCC ID: PPIRM-615 IC: 661U-RM615 Supplement reports: - Testing has been carried out in accordance with: CFR 47, FCC rules Part 15 Subpart B, ANSI C63.4 (2003), ICES-003, CISPR 22 and IC standards RSS-132 (Issue 2, September 2005), RSS-133 (Issue 5, February 2009), RSS-139 (Issue 2, February 2009) and RSS-210 (Issue 7, June 2007). Deviations, modifications or clarifications (if any) to above mentioned documents are written in each section under "Test method and limit". Documentation: The test report must always be reproduced in full; reproduction of an excerpt only is subject to written approval of the testing laboratory. The documentation of the testing performed on the tested devices is archived for 15 years at TCC Nokia. Test Results: The EUT complies with the requirements in respect of all parameters subject to the test. The test results relate only to devices specified in this document. Date and signature for the contents: Sami Lehtonen, System Specialist, EMC FCC Part 15B Compliance Test Report / Template Version 14.0 FCC15B_RM-615_06.doc Copyright © TCC Nokia 1 (9) TCC Nokia Salo Laboratory P.O. Box 86 Joensuunkatu 7H / Kiila 1B FIN-24101 SALO, FINLAND Tel. +358 (0) 7180 08000 Fax. +358 (0) 7180 45220 FCC Part 15B Compliance Test Report / Template Version 14.0 FCC15B_RM-615_06.doc Copyright © TCC Nokia 2 (9) TCC Nokia Salo Laboratory P.O. Box 86 Joensuunkatu 7H / Kiila 1B FIN-24101 SALO, FINLAND Tel. +358 (0) 7180 08000 Fax. +358 (0) 7180 45220 1. Summary for FCC Part 15B Compliance Test Report Date of receipt 29-Sep-2009 Testing completed 03-Nov-2009 The customer's contact person Vivian Kill-Tollnek Test Plan referred to T:\Projects\RM-615\TestPlan_RS\RS_testplan_RM-615.xls Notes - Document name FCC15B_RM-615_06.doc 1.1. EUT and Accessory Information The EUT is a 7-band (GSM850/900/1800/1900 and WCDMA Band I/II(1900)/V(850)) mobile phone with GPRS, EGPRS and Bluetooth. GSM and WCDMA bands are tested in idle mode. Bluetooth is tested with maximum rated TX power. Product Type SN HW MV SW DUT phone RM-615 004401107459477 0112 - bn_mtv_5.05 14222 Headset WH-205 06944219215D1R00263 CE - - 14245 AC Charger AC-8E 3997917527070300134ö0675387 CE - - 14234 Battery BL-4U 4620408325I10174252ö0670560 - - - 14240 1.2. Summary of Test Results GSM 850: Section in CFR 47 Section in ICES-003 (RSS-132) Name of the test Result 15.107, a 5.3 AC powerline conducted emissions NP 15.109, a 5.5 (4.6) Radiated emissions PASSED GSM 1900: Section in CFR 47 Section in ICES-003 (RSS-133) Name of the test Result 15.107, a 5.3 AC powerline conducted emissions NP 15.109, a 5.5 (6.6) Radiated emissions PASSED PASSED The EUT complies with the essential requirements in the standard. FAILED The EUT does not comply with the essential requirements in the standard. NP The test was not performed by the TCC Nokia Salo Laboratory. FCC Part 15B Compliance Test Report / Template Version 14.0 FCC15B_RM-615_06.doc Copyright © TCC Nokia 3 (9) TCC Nokia Salo Laboratory P.O. Box 86 Joensuunkatu 7H / Kiila 1B FIN-24101 SALO, FINLAND Tel. +358 (0) 7180 08000 Fax. +358 (0) 7180 45220 CONTENTS 1. Summary for FCC Part 15B Compliance Test Report.............................................. 2 1.1. EUT and Accessory Information ............................................................................................2 1.2. Summary of Test Results .......................................................................................................2 2. Radiated emissions (FCC §15.109, ICES-003 section 5.5, RSS-132 4.6, RSS-133 6.6, RSS-139 6.6) ............. 4 2.1. Test setup ..............................................................................................................................4 2.2. Test method and limit .............................................................................................................4 2.3. GSM 850 Test results ............................................................................................................5 2.4. GSM 1900 Test results ..........................................................................................................6 3. Test Equipment........................................................................................................... 8 3.1. Conducted measurements .....................................................................................................8 3.2. Radiated measurements ........................................................................................................8 2. Radiated emissions (FCC §15.109, ICES-003 section 5.5, RSS-132 4.6, RSS-133 6.6, RSS-139 6.6) EUT with DUT number RM-615, DUT 14222 Accessories with DUT numbers AC-8E, DUT 14234; WH-205, DUT 14245; BL-4U, DUT 14240 Operation Voltage [V] / [Hz] 115 / 60 Result PASSED Remarks - Temp [°C] / Humidity [%RH] / Air Pressure [kPa] 22 / 50 /101.3 Date of measurements 03-Nov-2009 Measured by Sami Lehtonen 2.1. Test setup Communication Tester EUT Tower / table controller Receiver 2.2. Test method and limit The measurement is made according to ANSI C63.4-2003as follows: The measurement is performed in the Semi-Anechoic Chamber with conducting metal floor. The measurement distance is 3 m. The EUT is placed on a nonconductive plate at 80 cm height. For each suspected frequency, the turntable is rotated 360 degrees and antenna is scanned from 1 to 4 m. This is repeated for both horizontal and vertic…

Text truncated - open the document above for the full version.

FCC Part 15B Compliance Test Report FCC Part 15B Compliance Test Report / Template Version 14.0 FCC15B_RM-615_17.doc Copyright © TCC Nokia 1 (10) TCC Nokia Salo Laboratory P.O. Box 86 Joensuunkatu 7H / Kiila 1B FIN-24101 SALO, FINLAND Tel. +358 (0) 7180 08000 Fax. +358 (0) 7180 45220 Test Report no.: 13-Nov-2009 FCC15B_RM-615_17.doc Date of Report: Number of pages: 10 Vivian Kill-Tollnek Customer’s Contact person: Testing laboratory: TCC Nokia Salo Laboratory P.O. Box 86 Joensuunkatu 7H / Kiila 1B FIN-24101 SALO, FINLAND Tel. +358 (0) 7180 08000 Fax. +358 (0) 7180 45220 FCC listing no.: IC recognition no.: 533467 661V-1 Nokia Corporation Customer: Lise Meitner Strasse 10 89081 ULM GERMANY Tel. +49 731 1754 0 Fax. +49 731 1754 6800 Tested devices/ accessories: Phone RM-615 / Battery BL-4U, AC-Charger AC-8E, Laptop T-30, Printer C3941A and CA-101D FCC ID: 661U-RM615 PPIRM-615 IC: Supplement reports: - Testing has been carried out in accordance with: CFR 47, FCC rules Part 15 Subpart B, ANSI C63.4 (2003), ICES-003, CISPR 22 and IC standards RSS-132 (Issue 2, September 2005), RSS-133 (Issue 5, February 2009), RSS-139 (Issue 2, February 2009) and RSS-210 (Issue 7, June 2007). Deviations, modifications or clarifications (if any) to above mentioned documents are written in each section under "Test method and limit". The test report must always be reproduced in full; reproduction of an excerpt only is subject to Documentation: written approval of the testing laboratory. The documentation of the testing performed on the tested devices is archived for 15 years at TCC Nokia. The EUT complies with the requirements in respect of all parameters subject to the test. Test Results: The test results relate only to devices specified in this document. Date and signature for the contents: Anni Manninen, System Specialist, EMC FCC Part 15B Compliance Test Report / Template Version 14.0 FCC15B_RM-615_17.doc Copyright © TCC Nokia 2 (10) TCC Nokia Salo Laboratory P.O. Box 86 Joensuunkatu 7H / Kiila 1B FIN-24101 SALO, FINLAND Tel. +358 (0) 7180 08000 Fax. +358 (0) 7180 45220 1. Summary for FCC Part 15B Compliance Test Report Date of receipt 29-Sep-2009 Testing completed 09-Nov-2009 The customer's contact person Vivian Kill-Tollnek Test Plan referred to T:\Projects\RM-615\TestPlan_RS\RS_testplan_RM-615.xls Notes - Document name FCC15B_RM-615_17.doc 1.1. EUT and Accessory Information The EUT is a 7-band (GSM850/900/1800/1900 and WCDMA Band I/II(1900)/V(850)) mobile phone with GPRS, EGPRS and Bluetooth. GSM and WCDMA bands are tested in idle mode. Bluetooth is tested with maximum rated TX power. Product Type SN HW MV SW DUT Phone RM-615 004401107459477 0112 - bn_mtv_5.05 14222 AC Charger AC-8E 3997917527070300134ö0675387 CE - - 14234 Battery BL-4U 4620408325I10174252ö0670560 - - - 14240 Data Cable CA-101D 07303688522X1214397 CE - - 14250 Laptop T-30 99-ZYGY7 - - - 11358 Printer H&P LaserJet 5L C3941A CNVMO55419 - - - 10854 1.2. Summary of Test Results Bluetooth: Section in CFR 47 Section in ICES-003 Name of the test Result 15.107, a 5.3 AC powerline conducted emissions PASSED 15.109, a 5.5 Radiated emissions PASSED PASSED The EUT complies with the essential requirements in the standard. FAILED The EUT does not comply with the essential requirements in the standard. NP The test was not performed by the TCC Nokia Salo Laboratory. FCC Part 15B Compliance Test Report / Template Version 14.0 FCC15B_RM-615_17.doc Copyright © TCC Nokia 3 (10) TCC Nokia Salo Laboratory P.O. Box 86 Joensuunkatu 7H / Kiila 1B FIN-24101 SALO, FINLAND Tel. +358 (0) 7180 08000 Fax. +358 (0) 7180 45220 CONTENTS 1. Summary for FCC Part 15B Compliance Test Report.............................................. 2 1.1. EUT and Accessory Information ............................................................................................2 1.2. Summary of Test Results .......................................................................................................2 2. AC powerline conducted emissions (FCC §15.107, ICES-003 section 5.3) ................................................................................ 4 2.1. Test setup ..............................................................................................................................4 2.2. Test method and limit .............................................................................................................4 2.3. Bluetooth Test results ............................................................................................................5 3. Radiated emissions (FCC §15.109, ICES-003 section 5.5, RSS-132 4.6, RSS-133 6.6, RSS-139 6.6) ............. 6 3.1. Test setup ..............................................................................................................................6 3.2. Test method and limit .............................................................................................................6 3.3. Bluetooth Test results ............................................................................................................7 4. Test Equipment........................................................................................................... 9 4.1. Conducted measurements .....................................................................................................9 4.2. Radiated measurements ........................................................................................................9 2. AC powerline conducted emissions (FCC §15.107, ICES-003 section 5.3) RM-615, DUT 14222 EUT with DUT number BL-4U, DUT 14240; AC-8E; DUT 14234; CA-101D, DUT 14250; Accessories with DUT numbers T-30, DUT 11358; C3941A, DUT 10854 115 / 60 Operation Voltage [V] / [Hz] PASSED Result Continuous data transfer was active between the phone and the computer during the test. Remarks 21 / 43 / 101 Temp [°C] / Humidity [%RH] / Air Pressure [kPa] 09-Nov-2009 Date of measurements Anni Manninen Measured by 2.1. Test setup Recei…

Text truncated - open the document above for the full version.

RM-615_test_setup_photographs.DOC 1 (2) TCC Nokia EUT test setups Picture 1 Radiated emission 15C Picture 2 Radiated emission 15B RM-615_test_setup_photographs.DOC 2 (2) TCC Nokia Picture 3 AC powerline conducted emission measurement 15C Picture 4 AC powerline conducted emission measurement 15B
