PPIRM-618GSM cellular phone w/BT

Nokia X2–00 User Guide 5555555 Issue 1 CyanCyanMagentaMagentaYellowYellowBlackBlack Contents Safety4 General information6 About your device6 Network services7 Shared memory8 Access codes8 Software updates9 Support12 Get started13 Keys and parts13 Insert the battery15 Insert the SIM card15 Insert a memory card16 Switch on or off18 Charge the battery18 Display19 Home screen20 Keypad lock21 GSM antenna22 Flashlight22 Accessories23 Calls25 Make and answer a call25 Loudspeaker25 Dialling shortcuts26 Write text26 Text input modes26 Traditional text input27 Predictive text input28 Navigate the menus29 Messaging29 Text and multimedia messages30 Nokia Messaging Mail32 Nokia Messaging IM33 Flash messages34 Nokia Xpress audio messages 34 Voice messages35 Message settings35 2Contents CyanCyanMagentaMagentaYellowYellowBlackBlack Contacts 36 Log37 Music38 Media player38 FM radio39 Camera and video41 Photos43 Settings44 Profiles44 Tones45 Display45 Date and time45 Shortcuts46 Synchronisation and backup46 Connectivity47 Call and phone50 Accessories51 Configuration52 Restore factory settings52 Applications53 Alarm clock53 Gallery54 Extras54 Voice recorder55 Web or Internet 56 Connect to a web service57 Visit Ovi57 SIM services 58 Green tips58 Save energy58 Recycle59 Product and safety information59 Index71 Contents3 CyanCyanMagentaMagentaYellowYellowBlackBlack Safety Read these simple guidelines. Not following them may be dangerous or illegal. Read the complete user guide for further information. SWITCH ON SAFELY Do not switch the device on when wireless phone use is prohibited or when it may cause interference or danger. ROAD SAFETY COMES FIRST Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety. INTERFERENCE All wireless devices may be susceptible to interference, which could affect performance. SWITCH OFF IN RESTRICTED AREAS Follow any restrictions. Switch the device off in aircraft, near medical equipment, fuel, chemicals, or blasting areas. 4Safety CyanCyanMagentaMagentaYellowYellowBlackBlack QUALIFIED SERVICE Only qualified personnel may install or repair this product. ACCESSORIES AND BATTERIES Use only approved accessories and batteries. Do not connect incompatible products. WATER-RESISTANCE Your device is not water-resistant. Keep it dry. Safety5 CyanCyanMagentaMagentaYellowYellowBlackBlack General information About your device The wireless device described in this guide is approved for use on the EGSM 850, 900, 1800, 1900 MHz networks. Contact your service provider for more information about networks. Your device may have preinstalled bookmarks and links for third-party internet sites and may allow you to access third-party sites. These are not affiliated with Nokia, and Nokia does not endorse or assume liability for them. If you access such sites, take precautions for security or content. Warning: To use any features in this device, other than the alarm clock, the device must be switched on. Do not switch the device on when wireless device use may cause interference or danger. When using this device, obey all laws and respect local customs, privacy and legitimate rights of others, including copyrights. Copyright protection may prevent some images, music, and other content from being copied, modified, or transferred. 6General information CyanCyanMagentaMagentaYellowYellowBlackBlack Make back-up copies or keep a written record of all important information stored in your device. When connecting to any other device, read its user guide for detailed safety instructions. Do not connect incompatible products. The images in this guide may differ from your device display. Refer to the user guide for other important information about your device. Network services To use the device you must have service from a wireless service provider. Some features are not available on all networks; other features may require that you make specific arrangements with your service provider to use them. Network services involve transmission of data. Check with your service provider for details about fees in your home network and when roaming on other networks. Your service provider can explain what charges will apply. Some networks may have limitations that affect how you can use some features of this device requiring network support such as support for specific technologies like WAP 2.0 protocols (HTTP and SSL) that run on TCP/IP protocols and language-dependent characters. General information7 CyanCyanMagentaMagentaYellowYellowBlackBlack Your service provider may have requested that certain features be disabled or not activated in your device. If so, these features will not appear on your device menu. Your device may also have customized items such as menu names, menu order, and icons. Shared memory The following features in this device may share memory: multimedia messaging (MMS), e-mail application, instant messaging. Use of one or more of these features may reduce the memory available for the remaining features. If your device displays a message that the memory is full, delete some of the information stored in the shared memory. Access codes The security code helps to protect your device against unauthorised use. The preset code is 12345. You can create and change the code, and set the device to request the code. Keep the code secret and in a safe place separate from your device. If you forget the code and your device is locked, your device will require service. Additional charges may apply, and all the personal data in your device may be deleted. For more information, contact a Nokia Care point or your device dealer. The PIN code supplied with the SIM card protects the card against unauthorised use. The PIN2 code supplied with 8General information CyanCyanMagentaMagentaYellowYellowBlackBlack some SIM cards is required to access certain services. If you enter the PIN or PIN2 code incorrectly three times in succession, you a…

Text truncated - open the document above for the full version.

NOKIA GmbH Joensuunkatu 7 FIN-24100 SALO FINLAND Tel. +358 7180 08000 April 27, 2010 Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD. 21046 Attention: Equipment Authorization Branch REQUEST FOR CONFIDENTIALITY Pursuant to Sections 0.457 (d) (l) (ii) and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of some of the information accompanying this Application of FCC ID: PPIRM-618 and as outlined below: - Exhibit 4: Block Diagram - Exhibit 5: Schematic Diagrams - Exhibit 10: List of Active Devices and Tune-Up Procedure - Exhibit 12: Theory of Operation / Description of Circuitry These materials contain trade secrets and proprietary information not customarily released to the public and the public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457 (d) (l) (ii) disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this Application. NOKIA CORPORATION Tero Lehtinen Product Certification Officer Devices, Salo

CONFIDENTIAL 12-Apr-2010 External photographs FCC ID: PPIRM-618 Exhibit 3 IC: 661U-RM618 Applicant: Nokia Corporation Copyright © 2010 Nokia. All rights reserved. 1. EXTERNAL PHOTOGRAPHS 1.1 Front and back CONFIDENTIAL 12-Apr-2010 External photographs FCC ID: PPIRM-618 Exhibit 3 IC: 661U-RM618 Applicant: Nokia Corporation Copyright © 2010 Nokia. All rights reserved. 1.2 Disassembled CONFIDENTIAL 12-Apr-2010 External photographs FCC ID: PPIRM-618 Exhibit 3 IC: 661U-RM618 Applicant: Nokia Corporation Copyright © 2010 Nokia. All rights reserved. 1.3 External interfaces

1 (1) NOKIA Corporation 27/04/2010 Copyright © Nokia 2010. All rights reserved. TYPE LABEL FOR PPIRM-618 LABEL LOCATION FOR PPIRM-618

CONFIDENTIAL 14-Apr-2010 Internal photographs FCC ID: PPIRM-618 Exhibit 9 IC: 661U-RM618 Applicant: Nokia Corporation Copyright © 2010 Nokia. All rights reserved. 1. INTERNAL PHOTOGRAPHS 1.1 Pwb back CONFIDENTIAL 14-Apr-2010 Internal photographs FCC ID: PPIRM-618 Exhibit 9 IC: 661U-RM618 Applicant: Nokia Corporation Copyright © 2010 Nokia. All rights reserved. 1.2 Pwb front

Nokia ____________________________________________________________________________ SAR Report FCC_RM-618_04 Applicant: Nokia Corporation Type: RM-618 Copyright © 2010 TCC Nokia 1/24 SAR Compliance Test Report Test report no.: FCC_RM-618_04 Date of report: 2010-04-16 Template version: 14.0 Number of pages: 24 Testing laboratory: TCC Nokia Salo Laboratory P.O.Box 86 Joensuunkatu 7H / Kiila 1B FIN-24101 SALO, FINLAND Tel. +358 (0) 7180 08000 Fax. +358 (0) 7180 45220 Client: Nokia Corporation Lise Meitner Strasse 10 89081 ULM GERMANY Tel. +49 731 1754 0 Fax. +49 731 1754 6800 Responsible test engineer: Heikki Kuusela Product contact person: Bruno Ramelli Measurements made by: Heikki Kuusela, Virpi Tuominen Tested device: RM-618 FCC ID: PPIRM-618 IC: 661U-RM618 Supplement reports: SAR_Photo_RM-618_05, FCC_RM-618_01 Testing has been carried out in accordance with: 47CFR §2.1093 Radiofrequency Radiation Exposure Evaluation: Portable Devices FCC OET Bulletin 65 (Edition 97-01), Supplement C (Edition 01-01) Evaluating Compliance with FCC Guidelines for Human Exposure to Radiofrequency Electromagnetic Fields RSS-102 Evaluation Procedure for Mobile and Portable Radio Transmitters with Respect to Health Canada’s Safety Code 6 for Exposure of Humans to Radio Frequency Fields IEEE 1528 - 2003 IEEE Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Technique Documentation: The documentation of the testing performed on the tested devices is archived for 15 years at TCC Nokia. Test results: The tested device complies with the requirements in respect of all parameters subject to the test. The test results and statements relate only to the items tested. The test report shall not be reproduced except in full, without written approval of the laboratory. Date and signatures: For the contents: Nokia ____________________________________________________________________________ SAR Report FCC_RM-618_04 Applicant: Nokia Corporation Type: RM-618 Copyright © 2010 TCC Nokia 2/24 CONTENTS 1. SUMMARY OF SAR TEST REPORT............................................................................................................................................. 3 1.1 TEST DETAILS.............................................................................................................................................................................3 1.2 MAXIMUM RESULTS....................................................................................................................................................................3 1.2.1 Head Configuration........................................................................................................................................................ 3 1.2.2 Body Worn Configuration............................................................................................................................................ 3 1.2.3 Maximum Drift................................................................................................................................................................ 4 1.2.4 Measurement Uncertainty........................................................................................................................................... 4 2. DESCRIPTION OF THE DEVICE UNDER TEST........................................................................................................................... 4 2.1 DESCRIPTION OF THE ANTENNA..................................................................................................................................................4 3. TEST CONDITIONS..................................................................................................................................................................... 5 3.1 TEMPERATURE AND HUMIDITY....................................................................................................................................................5 3.2 TEST SIGNAL, FREQUENCIES AND OUTPUT POWER......................................................................................................................5 3.3 TEST CASES AND TEST MINIMISATION........................................................................................................................................6 4. DESCRIPTION OF THE TEST EQUIPMENT...............................................................................................................................8 4.1 MEASUREMENT SYSTEM AND COMPONENTS................................................................................................................................8 4.1.1 Isotropic E-field Probe Type ES3DV3......................................................................................................................... 9 4.2 PHANTOMS................................................................................................................................................................................9 4.3 TISSUE SIMULANTS....................................................................................................................................................................9 4.3.1 Tissue Simulant Recipes............................................................................................................................................ 10 4.3.2 System Checking.......................................................................................................................................................... 10 4.3.3 Tissue Simulants used in the Measurements....................................................................................................... 11 5. DESCRIPTION OF THE TEST PROCEDURE............................................................................................................................. 12 5.1 DEVICE HOLDER.....................................…

Text truncated - open the document above for the full version.

FCC Part 22/24 Compliance Test Report / Template Version 15.0 FCC22&24_RM-618_10.doc Copyright © TCC Nokia 1 (15) TCC NOKIA SALO LABORATORY P.O.BOX(86) JOENSUUNKATU 7H / KIILA 1B FIN-24101 SALO, FINLAND TEL. +358 (0) 7180 08000 FAX. +358 (0) 7180 45220 FCC Part 22/24 Compliance Test Report Test Report no.: FCC22&24_RM-618_11.doc Date of Report: 19-Apr-2010 Number of pages: 15 Customer’s Contact person: Bruno Ramelli Testing laboratory: TCC Nokia Salo Laboratory P.O.Box(86) Joensuunkatu 7H / Kiila 1B FIN-24101 SALO, FINLAND Tel. +358 (0) 7180 08000 Fax. +358 (0) 7180 45220 Customer: Nokia Corporation Lise Meitner Strasse 10 89081 ULM GERMANY Tel. +49 731 1754 0 Fax. +49 731 1754 6800 FCC listing no.: IC recognition no.: 533467 661V-1 Tested devices/ accessories: Phone RM-618 / Battery BL-4C FCC ID: PPIRM-618 IC: 661U-RM618 Supplement reports: - Testing has been carried out in accordance with: CFR 47, FCC rules Parts 22/24 , TIA-603-C-2004 and IC standards, RSS-GEN (Issue 2, June 2007), RSS-132 (Issue 2, September 2005), RSS-133 (Issue 5, February 2009). Deviations, modifications or clarifications (if any) to above mentioned documents are written in each section under "Test method and limit". Documentation: The test report must always be reproduced in full; reproduction of an excerpt only is subject to written approval of the testing laboratory. The documentation of the testing performed on the tested devices is archived for 15 years at TCC Nokia. Test Results: The EUT complies with the requirements in respect of all parameters subject to the test. The test results relate only to devices specified in this document. Date and signature for the contents: Teuvo Miettinen, Engineer, EMC FCC Part 22/24 Compliance Test Report / Template Version 15.0 FCC22&24_RM-618_10.doc Copyright © TCC Nokia 2 (15) TCC NOKIA SALO LABORATORY P.O.BOX(86) JOENSUUNKATU 7H / KIILA 1B FIN-24101 SALO, FINLAND TEL. +358 (0) 7180 08000 FAX. +358 (0) 7180 45220 1. Summary for FCC Part 22/24 Compliance Test Report Date of receipt 24-Mar-2010 Testing completed 16-Apr-2010 The customer's contact person Bruno Ramelli Test Plan referred to T:\Projects\RM-618\TestPlan\RS_testplan_RM-618.xls Notes - Document name T:\Projects\RM-618\EMC\FCC22&24_RM-618_10.doc 1.1. EUT and Accessory Information The EUT is a 4-band (GSM850/900/1800/1900) mobile phone with GPRS, EGPRS and Bluetooth. The EUT is tested with maximum rated TX power, modulated with pseudo random bit sequence (PRBS9). Product Type SN HW MV SW DUT Phone RM-618 004401019903844 0301 vp ju3.07 14565 Battery BL-4C 0670386382066Q42412CC30867 14567 1.2. Summary of Test Results GSM850: Section in CFR 47 Section in RSS-GEN or RSS-132 Name of the test Result §2.1046(a), 22.913(a) 4.4 Conducted RF output power np §22.913(a) 4.4 Radiated RF output power passed §2.1049(h) 4.6.1 99 % occupied bandwidth np §22.917(a) 4.5 Band edge compliance passed §22.917(a), §2.1051 4.5 Spurious emissions at antenna terminals np §22.917(a), §2.1053 4.5 Spurious radiated emissions np §2.1055(a) 4.3 Frequency stability, temperature variation np §2.1055(d) 4.3 Frequency stability, voltage variation np GSM1900: Section in CFR 47 Section in RSS-GEN or RSS-133 Name of the test Result §2.1046(a) 6.4 Conducted RF output power np §24.232(b) 6.4 Radiated RF output power passed §2.1049(h) 4.6.1 99 % occupied bandwidth np §24.238(a) 6.5 Band edge compliance passed §24.238(a), §2.1051 6.5 Spurious emissions at antenna terminals np §24.238(a), §2.1053 6.5 Spurious radiated emissions np §2.1055(a) 6.3 Frequency stability, temperature variation np §2.1055(d) 6.3 Frequency stability, voltage variation np FCC Part 22/24 Compliance Test Report / Template Version 15.0 FCC22&24_RM-618_10.doc Copyright © TCC Nokia 3 (15) TCC NOKIA SALO LABORATORY P.O.BOX(86) JOENSUUNKATU 7H / KIILA 1B FIN-24101 SALO, FINLAND TEL. +358 (0) 7180 08000 FAX. +358 (0) 7180 45220 PASSED The EUT complies with the essential requirements in the standard. FAILED The EUT does not comply with the essential requirements in the standard. NP The test was not performed by the TCC Nokia Laboratory. FCC Part 22/24 Compliance Test Report / Template Version 15.0 FCC22&24_RM-618_10.doc Copyright © TCC Nokia 4 (15) TCC NOKIA SALO LABORATORY P.O.BOX(86) JOENSUUNKATU 7H / KIILA 1B FIN-24101 SALO, FINLAND TEL. +358 (0) 7180 08000 FAX. +358 (0) 7180 45220 CONTENTS 1. Summary for FCC Part 22/24 Compliance Test Report ........................................... 2 1.1. EUT and Accessory Information .......................................................................................... 2 1.2. Summary of Test Results .................................................................................................... 2 2. Radiated RF output power (FCC §22.913(a), §24.232(b), RSS-132 4.4, RSS-133 6.4) ............................................... 5 2.1. Test Setup ........................................................................................................................... 5 2.2. Test method and limit .......................................................................................................... 5 2.3. GSM850 TX Test results ..................................................................................................... 7 2.4. GSM1900 TX Test results ................................................................................................... 7 3. Band edge compliance (FCC §22.917(a), §24.238(a), RSS-132 4.5, RSS-133 6.5) ............................................... 8 3.1. Test Setup ........................................................................................................................... 8 3.2. Test method and limit .......................................................................................................... 8 3.3. GSM850 Test results ........................................................................................................... 9 3.4. GSM1900 Test results ..............................…

Text truncated - open the document above for the full version.

FCC Part 22/24 Compliance Test Report / Template Version 15.0 FCC22 &24_RM-618_11.doc Copyright © TCC Nokia 1 (13) TCC Nokia Salo Laboratory P.O.Box(86) Joensuunkatu 7H / Kiila 1B FIN-24101 SALO, FINLAND Tel. +358 (0) 7180 08000 Fax. +358 (0) 7180 45220 FCC Part 22/24 Compliance Test Report Test Report no.: FCC22&24_RM-618_01.docx Date of Report: 19-Apr-2010 Number of pages: 13 Customer’s Contact person: Bruno Ramelli Testing laboratory: TCC Nokia Salo Laboratory P.O.Box(86) Joensuunkatu 7H / Kiila 1B FIN-24101 SALO, FINLAND Tel. +358 (0) 7180 08000 Fax. +358 (0) 7180 45220 Customer: Nokia Corporation Lise Meitner Strasse 10 89081 ULM GERMANY Tel. +49 731 1754 0 Fax. +49 731 1754 6800 FCC listing no.: IC recognition no.: 533467 661V-1 Tested devices/ accessories: Phone RM-618 / Battery BL-4C FCC ID: PPIRM-618 IC: 661U-RM618 Supplement reports: - Testing has been carried out in accordance with: CFR 47, FCC rules Parts 22/24 , TIA-603-C-2004 and IC standards, RSS-GEN (Issue 2, June 2007), RSS-132 (Issue 2, September 2005), RSS-133 (Issue 5, February 2009). Deviations, modifications or clarifications (if any) to above mentioned documents are written in each section under "Test method and limit". Documentation: The test report must always be reproduced in full; reproduction of an excerpt only is subject to written approval of the testing laboratory. The documentation of the testing performed on the tested devices is archived for 15 years at TCC Nokia. Test Results: The EUT complies with the requirements in respect of all parameters subject to the test. The test results relate only to devices specified in this document. Date and signature for the contents: Teuvo Miettinen, Engineer, EMC FCC Part 22/24 Compliance Test Report / Template Version 15.0 FCC22 &24_RM-618_11.doc Copyright © TCC Nokia 2 (13) TCC Nokia Salo Laboratory P.O.Box(86) Joensuunkatu 7H / Kiila 1B FIN-24101 SALO, FINLAND Tel. +358 (0) 7180 08000 Fax. +358 (0) 7180 45220 1. Summary for FCC Part 22/24 Compliance Test Report Date of receipt 24-Mar-2010 Testing completed 19-Apr-2010 The customer's contact person Bruno Ramelli Test Plan referred to T:\Projects\RM-618\TestPlan\RS_testplan_RM-618.xls Notes - Document name T:\Projects\RM-618\EMC\FCC22&24_RM-618_11.doc 1.1. EUT and Accessory Information The EUT is a 4-band (GSM850/900/1800/1900) mobile phone with GPRS, EGPRS and Bluetooth. The EUT is tested with maximum rated TX power, modulated with pseudo random bit sequence (PRBS9). Product Type SN HW MV SW DUT Phone RM-618 004401019905385 0302 Vp ju92_10w11 14678 Battery BL-4C 0670386382066Q42412CC30882 14566 1.2. Summary of Test Results GSM850: Section in CFR 47 Section in RSS-GEN or RSS-132 Name of the test Result §2.1046(a), 22.913(a) 4.4 Conducted RF output power np §22.913(a) 4.4 Radiated RF output power Passed §2.1049(h) 4.6.1 99 % occupied bandwidth np §22.917(a) 4.5 Band edge compliance Passed §22.917(a), §2.1051 4.5 Spurious emissions at antenna terminals np §22.917(a), §2.1053 4.5 Spurious radiated emissions np §2.1055(a) 4.3 Frequency stability, temperature variation np §2.1055(d) 4.3 Frequency stability, voltage variation np GSM1900: Section in CFR 47 Section in RSS-GEN or RSS-133 Name of the test Result §2.1046(a) 6.4 Conducted RF output power np §24.232(b) 6.4 Radiated RF output power Passed §2.1049(h) 4.6.1 99 % occupied bandwidth np §24.238(a) 6.5 Band edge compliance Passed §24.238(a), §2.1051 6.5 Spurious emissions at antenna terminals np §24.238(a), §2.1053 6.5 Spurious radiated emissions np §2.1055(a) 6.3 Frequency stability, temperature variation np §2.1055(d) 6.3 Frequency stability, voltage variation np FCC Part 22/24 Compliance Test Report / Template Version 15.0 FCC22 &24_RM-618_11.doc Copyright © TCC Nokia 3 (13) TCC Nokia Salo Laboratory P.O.Box(86) Joensuunkatu 7H / Kiila 1B FIN-24101 SALO, FINLAND Tel. +358 (0) 7180 08000 Fax. +358 (0) 7180 45220 PASSED The EUT complies with the essential requirements in the standard. FAILED The EUT does not comply with the essential requirements in the standard. NP The test was not performed by the TCC Nokia Laboratory. FCC Part 22/24 Compliance Test Report / Template Version 15.0 FCC22 &24_RM-618_11.doc Copyright © TCC Nokia 4 (13) TCC Nokia Salo Laboratory P.O.Box(86) Joensuunkatu 7H / Kiila 1B FIN-24101 SALO, FINLAND Tel. +358 (0) 7180 08000 Fax. +358 (0) 7180 45220 CONTENTS 1. Summary for FCC Part 22/24 Compliance Test Report ............................................ 2 1.1. EUT and Accessory Information ........................................................................................... 2 1.2. Summary of Test Results ..................................................................................................... 2 2. Radiated RF output power (FCC §22.913(a), §24.232(b), RSS-132 4.4, RSS-133 6.4) ............................................... 5 2.1. Test Setup ............................................................................................................................ 5 2.2. Test method and limit ........................................................................................................... 5 2.3. GSM850 TX Test results ...................................................................................................... 7 2.4. GSM1900 TX Test results .................................................................................................... 7 3. Band edge compliance (FCC §22.917(a), §24.238(a), RSS-132 4.5, RSS-133 6.5)................................................ 8 3.1. Test Setup ............................................................................................................................ 8 3.2. Test method and limit ........................................................................................................... 8 3.3. GSM850 Test results ............................................................................................................ 9 3.4. GSM1900 Test results ...........…

Text truncated - open the document above for the full version.

FCC Part 22/24/27 Compliance Test Report / Template Version 15.0 FCC22&24_RM-618_08.doc Copyright © TCC Nokia 1 (8) TCC Nokia Tampere Laboratory P.O. Box 68 Sinitaival 5 FIN-33720 TAMPERE, FINLAND Tel. +358 (0) 7180 46800 Fax. +358 (0) 7180 46880 FCC Part 22/24 Compliance Test Report Test Report no.: FCC22&24_RM-618_08.doc Date of Report: 28-Apr-2010 Number of pages: 8 Customer’s Contact person: Bruno Ramelli Testing laboratory: TCC Nokia Tampere Laboratory P.O. Box 68 Sinitaival 5 FIN-33720 TAMPERE, FINLAND Tel. +358 (0) 7180 46800 Fax. +358 (0) 7180 46880 FCC listing no.: IC recognition no.: 94436 661AK-1 Customer: Nokia Corporation Lise Meitner Strasse 10 89081 ULM GERMANY Tel. +49 731 1754 0 Fax. +49 731 1754 6800 Tested devices/ accessories: Phone RM-618, Battery BL-4C, Charger AC-3E, Headset HS-125 FCC ID: PPIRM-618 IC: 661U-RM618 Supplement reports: - Testing has been carried out in accordance with: CFR 47, FCC rules Parts 22 and 24, TIA-603-C-2004 and IC standards RSS-GEN (Issue 2, June 2007), RSS-132 (Issue 2, September 2005) and RSS-133 (Issue 5, February 2009). Deviations, modifications or clarifications (if any) to above mentioned documents are written in each section under "Test method and limit". Documentation: The test report must always be reproduced in full; reproduction of an excerpt only is subject to written approval of the testing laboratory. The documentation of the testing performed on the tested devices is archived for 15 years at TCC Nokia. Test Results: The EUT complies with the requirements in respect of all parameters subject to the test. The test results relate only to devices specified in this document. Date and signature for the contents: Jari Jantunen Test System Manager, EMC FCC Part 22/24/27 Compliance Test Report / Template Version 15.0 FCC22&24_RM-618_08.doc Copyright © TCC Nokia 2 (8) TCC Nokia Tampere Laboratory P.O. Box 68 Sinitaival 5 FIN-33720 TAMPERE, FINLAND Tel. +358 (0) 7180 46800 Fax. +358 (0) 7180 46880 1. Summary for FCC Part 22/24 Compliance Test Report Date of receipt 27-Apr-2010 Testing completed 28-Apr-2010 The customer's contact person Bruno Ramelli Test Plan referred to T:\Projects\RM-618\TestPlan\RS_testplan_RM-618.xls Notes - Document name FCC22&24_RM-618_08.doc 1.1. EUT and Accessory Information The EUT is a 4-band (GSM850/900/1800/1900) mobile phone with GPRS, EGPRS and Bluetooth. The EUT is tested with maximum rated TX power, modulated with pseudo random bit sequence (PRBS9). Product Type SN HW MV SW DUT Phone RM-618 004401019905617 0302 - Vp ju92_10w11 42230 Battery BL-4C 0670386392066 - - - 42220 Charger AC-3E 1103337517172104375;0675370 - - - 42222 Headset HS-125 06943239443F4108319 - - - 42224 1.2. Summary of Test Results GSM 850: Section in CFR 47 Section in RSS-GEN or RSS-132 Name of the test Result §2.1046(a), 22.913(a) 4.4 Conducted RF output power NP §22.913(a) 4.4 Radiated RF output power NP §2.1049(h) 4.6.1 99 % occupied bandwidth NP §22.917(a) 4.5 Band edge compliance NP §22.917(a), §2.1051 4.5 Spurious emissions at antenna terminals NP §22.917(a), §2.1053 4.5 Spurious radiated emissions PASSED §2.1055(a) 4.3 Frequency stability, temperature variation NP §2.1055(d) 4.3 Frequency stability, voltage variation NP GSM 1900: Section in CFR 47 Section in RSS-GEN or RSS-133 Name of the test Result §2.1046(a) 6.4 Conducted RF output power NP §24.232(b) 6.4 Radiated RF output power NP §2.1049(h) 4.6.1 99 % occupied bandwidth NP §24.238(a) 6.5 Band edge compliance NP §24.238(a), §2.1051 6.5 Spurious emissions at antenna terminals NP §24.238(a), §2.1053 6.5 Spurious radiated emissions PASSED §2.1055(a) 6.3 Frequency stability, temperature variation NP §2.1055(d) 6.3 Frequency stability, voltage vari…
