PPIRM-70XGSM 900/1800/1900 w BT

Microsoft Corporation

Click to zoom

Application Details

Equipment Class: JBP - Part 15 Class B Computing Device Peripheral
Date of Grant: May 16, 2006
Application Purpose: Original Equipment
Date of Application: May 16, 2006
Equipment Note: GSM 900/1800/1900 w BT
Company: Microsoft Corporation
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

User guide Nokia 7370 92XXXX Issue 1 DECLARATION OF CONFORMITY We, NOKIA CORPORATION declare under our sole responsibility that the product RM-70 is in conformity with the provisions of the following Council Directive: 1999/5/EC. A copy of the Declaration of Conformity can be found from http://www.nokia.com/phones/declaration_of_conformity/. The crossed-out wheeled bin means that within the European Union the product must be taken to separate collection at the product end-of life. This applies to your device but also to any enhancements marked with this symbol. Do not dispose of these products as unsorted municipal waste. Copyright © 2006 Nokia. All rights reserved. Reproduction, transfer, distribution or storage of part or all of the contents in this document in any form without the prior written permission of Nokia is prohibited. Nokia, Visual Radio, Nokia Connecting People, Xpress-on, and Pop-Port are trademarks or registered trademarks of Nokia Corporation. Other product and company names mentioned herein may be trademarks or tradenames of their respective owners. Nokia tune is a sound mark of Nokia Corporation. Includes RSA BSAFE cryptographic or security protocol software from RSA Security. Java is a trademark of Sun Microsystems, Inc. This product is licensed under the MPEG-4 Visual Patent Portfolio License (i) for personal and noncommercial use in connection with information which has been encoded in compliance with the MPEG-4 Visual Standard by a consumer engaged in a personal and noncommercial activity and (ii) for use in connection with MPEG-4 video provided by a licensed video provider. No license is granted or shall be implied for any other use. Additional information including that relating to promotional, internal and commercial uses may be obtained from MPEG LA, LLC. See <http://www.mpegla.com>. Nokia operates a policy of continuous development. Nokia reserves the right to make changes and improvements to any of the products described in this document without prior notice. Under no circumstances shall Nokia be responsible for any loss of data or income or any special, incidental, consequential or indirect damages howsoever caused. The contents of this document are provided "as is". Except as required by applicable law, no warranties of any kind, either express or implied, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose, are made in relation to the accuracy, reliability or contents of this document. Nokia reserves the right to revise this document or withdraw it at any time without prior notice. The availability of particular products may vary by region. Please check with the Nokia dealer nearest to you. This device may contain commodities, technology or software subject to export laws and regulations from the US and other countries. Diversion contrary to law is prohibited. FCC/INDUSTRY CANADA NOTICE Your phone may cause TV or radio interference (for example, when using a telephone in close proximity to receiving equipment). The FCC or Industry Canada can require you to stop using your telephone if such interference cannot be eliminated. If you require assistance, contact your local service facility. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 92XXXXX/Issue1 4 Contents For your safety.......................... 6 General information ................. 9 Overview of functions........................... 9 Access codes............................................ 9 Configuration settings service ........ 10 Download content and applications 11 Nokia support and contact information 11 1. Get started ......................... 12 Install SIM card and battery ............ 12 Charge the battery.............................. 13 Open and close the phone................ 14 Switch the phone on and off........... 14 Antenna ................................................. 15 Phone strap........................................... 15 2. Your phone......................... 16 Keys and parts...................................... 16 Standby mode ...................................... 17 Keypad lock (keyguard) ..................... 19 3. Call functions..................... 20 Make a call ........................................... 20 Answer or reject a call....................... 21 Options during a call.......................... 22 4. Write text........................... 23 Predictive text input .......................... 23 Traditional text input......................... 24 5. Navigate the menus .......... 25 6. Messaging .......................... 26 Text messages (SMS).......................... 26 SIM messages....................................... 27 Multimedia messages (MMS) .......... 28 Memory full .......................................... 30 Folders .................................................... 30 Flash messages .................................... 31 Nokia Xpress audio messaging........ 31 Instant messaging (IM) ..................... 32 E-mail application .............................. 37 Voice messages.................................... 39 Info messages ...................................... 39 Service commands .............................. 40 Delete messages .................................. 40 Message settings................................. 40 7. Contacts.............................. 44 Search for a contact .......................... 44 Save names and phone numbers.... 44 Save details........................................... 44 Copy contacts ...................................... 45 Edit contact details ............................ 45 Delete contacts.................................... 45 My presence ......................................... 46 Subscribed names ..............…

Text truncated - open the document above for the full version.

Cover Letter(s)

NOKIA Mobile Phones R&D Ulm 05/09/2006 Copyright © Nokia 2006. All rights reserved. TYPE LABEL FOR PPIRM-70X 09-May-06 Scale 1:1 Type Label for China 21 x 10 or Type Label for America 21 x 10 or extra label for Singapore, Malaysia, Taiwan Type Label 32.5 x 13 or Chinese extra label or American barcode label China 12X30 not metal Singapore 6x12 not metal. Malaysia 10x15 metal. American barcode label 32.5 x 13 Work label 11 x 16 taped on plastic bag Country specific extra labels Code: 0500000MYDDFL IMEI:01007430/041487/0 Cingular Part#: 75XXXXXXXXXX 123456789012345 Taiwan 12x12 not metal. 123456789012345 Nokia Corporation 434 FCC ID:PPIRM-70X IC: 661U-RM70 MADE IN GERMANY 0123456 Type: RM-70 Model: 7370 New Zealand

External Photos

09 May 2006 External photographs FCC ID: PPIRM-70X Exhibit 3 IC: 661U-RM70 Applicant: Nokia Corporation Copyright © 2005Nokia. All rights reserved. 1. EXTERNAL PHOTOGRAPHS 1.1 Front and back – phone open 09 May 2006 External photographs FCC ID: PPIRM-70X Exhibit 3 IC: 661U-RM70 Applicant: Nokia Corporation Copyright © 2005Nokia. All rights reserved. 1.2 Front and back – phone closed 09 May 2006 External photographs FCC ID: PPIRM-70X Exhibit 3 IC: 661U-RM70 Applicant: Nokia Corporation Copyright © 2005Nokia. All rights reserved. 1.3 Disassembled 1.4 Bottom side

ID Label/Location Info

Internal Photos

09 May 2005 Bluetooth internal photographs FCC ID: PPIRM-70X Exhibit 9 IC: 661U-RM70 Applicant: Nokia Corporation Copyright © 2006Nokia. All rights reserved. 1. BLUETOOTH INTERNAL PHOTOGRAPHS 1.1 PWB BT antenna feeding it BT electronics 09 May 2005 Bluetooth internal photographs FCC ID: PPIRM-70X Exhibit 9 IC: 661U-RM70 Applicant: Nokia Corporation Copyright © 2006Nokia. All rights reserved. 1.2 BT antenna in cover BT antenna placement in C-cover 09 May 2005 Bluetooth internal photographs FCC ID: PPIRM-70X Exhibit 9 IC: 661U-RM70 Applicant: Nokia Corporation Copyright © 2006Nokia. All rights reserved. 1.3 BT antenna

Test Report

FCC Part 15B Compliance Test Report / Template Version 3.0 T:\Projects\RM-70\results\emc\FCC\Cph_FCC_0542_09.doc Copyright © TCC Nokia 1 (9) TCC Nokia Copenhagen Laboratory Frederikskaj 1790 COPENHAGEN V DENMARK Tel. +45 33 292929 Fax. +45 33 292934 FCC Part 15B Compliance Test Report Test Report no.: Cph_FCC_0542_09.doc Date of Report: 20-10-2005 Number of pages: 9 Customer’s Contact person: Thomas Reitmayer Testing laboratory: TCC Nokia Copenhagen Laboratory Frederikskaj 1790 COPENHAGEN V DENMARK Tel. +45 33 292929 Fax. +45 33 292934 FCC listing no.: IC recognition no.: 99059 4820 and 4820-1 Client: Nokia Corporation Lise Meitner Strasse 10 89081 ULM GERMANY Tel. +49 731 1754 0 Fax. +49 731 1754 6800 Tested devices/ accessories: Phone; RM-70 (HW: 4031), Battery; BL-4B, AC-Charger; AC-3E, Data Cable; DKU-2 FCC ID: PPIRM-70 IC: 661U-RM70 Supplement reports: Testing has been carried out in accordance with: CFR 47, FCC rules Part 15 Subpart B, ANSI C63.4 (2003), ICES-003, CISPR 22 and IC standards RSS-132, RSS-133 and RSS-210. Deviations, modifications or clarifications (if any) to above mentioned documents are written in each section under "Test method and limit". Documentation: The test report must always be reproduced in full; reproduction of an excerpt only is subject to written approval of the testing laboratory. The documentation of the testing performed on the tested devices is archived for 15 years at TCC Nokia. Test Results: The EUT complies with the requirements in respect of all parameters subject to the test. The test results relate only to devices specified in this document. Date and signature for the contents: Allan F. Henriksen, Engineer FCC Part 15B Compliance Test Report / Template Version 3.0 T:\Projects\RM-70\results\emc\FCC\Cph_FCC_0542_09.doc Copyright © TCC Nokia 2 (9) TCC Nokia Copenhagen Laboratory Frederikskaj 1790 COPENHAGEN V DENMARK Tel. +45 33 292929 Fax. +45 33 292934 1. Summary for FCC Part 15B Compliance Test Report Date of receipt 13-10-2005 Testing completed 20-10-2005 The customer's contact person Thomas Reitmayer Test Plan referred to \EMC\TESTPLAN\ Notes Laptop connected to Phone with Data Cable Document name T:\Projects\RM-70\results\emc\FCC\Cph_FCC_0542_09.doc 1.1. EUT and Accessory Information The EUT is a triple band (GSM900/1800/1900) mobile phone with GPRS, EGPRS and Bluetooth. GSM band is tested in idle mode. Bluetooth is tested with maximum rated TX power. Product Type SN HW MV SW DUT Phone RM-70 004400/56/170758/7 4031 - 3.01.1 28400 Battery BL-4B 0670491363563M203110200104 - - - 28395 AC-Charger AC-3E 4090495276921002523;0675370 - - - 28389 Data Cable DKU-2 IL39083821 - - - 28330 1.2. Summary of Test Results GSM 1900: Section in CFR 47 Section in ICES-003 (RSS-133) Name of the test Result 15.107, a 5.3 AC powerline conducted emissions Passed 15.109, a 5.5 (9) Radiated emissions Passed PASSED The EUT complies with the essential requirements in the standard. FAILED The EUT does not comply with the essential requirements in the standard. NP The test was not performed by the TCC Nokia Copenhagen Laboratory. FCC Part 15B Compliance Test Report / Template Version 3.0 T:\Projects\RM-70\results\emc\FCC\Cph_FCC_0542_09.doc Copyright © TCC Nokia 3 (9) TCC Nokia Copenhagen Laboratory Frederikskaj 1790 COPENHAGEN V DENMARK Tel. +45 33 292929 Fax. +45 33 292934 CONTENTS 1. Summary for FCC Part 15B Compliance Test Report..............................................2 1.1. EUT and Accessory Information ............................................................................................2 1.2. Summary of Test Results .......................................................................................................2 2. AC powerline conducted emissions (FCC §15.107, ICES-003 section 5.3)......................4 2.1. Test setup ..............................................................................................................................4 2.2. Test method and limit .............................................................................................................4 2.3. GSM 1900 Test results ..........................................................................................................5 3. Radiated emissions (FCC §15.109, ICES-003 section 5.5, RSS-132 6.6, RSS-133 9).............6 3.1. Test setup ..............................................................................................................................6 3.2. Test method and limit .............................................................................................................6 3.3. GSM 1900 Test results ..........................................................................................................7 4. Test Equipment...........................................................................................................8 4.1. Conducted measurements .....................................................................................................8 4.2. Radiated measurements ........................................................................................................8 FCC Part 15B Compliance Test Report / Template Version 3.0 T:\Projects\RM-70\results\emc\FCC\Cph_FCC_0542_09.doc Copyright © TCC Nokia 4 (9) TCC Nokia Copenhagen Laboratory Frederikskaj 1790 COPENHAGEN V DENMARK Tel. +45 33 292929 Fax. +45 33 292934 2. AC powerline conducted emissions (FCC §15.107, ICES-003 section 5.3) EUT with DUT number RM-70 Dut # 28400 Accessories with DUT numbers BL-4B Dut # 28395 + AC-3E Dut # 28389 + DKU-2 Dut # 28330 Operation Voltage [V] / [Hz] 230/50 Result Passed Remarks IBM Labtop connected to Phone via Data Cable Temp [°C] / Humidity [%RH] / Air Pressure [kPa] 22.5 / 36.5 1037 Date of measurements 17-10-2005 Measured by Allan F. Henriksen 2.1. Test setup Receiver Pulse limiter LISN EUT 2.2. Test method and limit The measurement is made according to ANSI C63.4-2003 as follows: The EUT is placed on a wooden table 80 cm a…

Text truncated - open the document above for the full version.

Test Setup Photos

RM-70_test_setup_photographs.DOC 1 (2) TCC Tampere EUT test setups Picture 1 Spurious radiated emission measurement TCC Tampere P.O. Box 68 FIN -33721 Tampere FINLAND Tel. +358 7180 46800 Fax. +358 7180 46880
