PQN44422RX49MHZNASCAR 1/24TH RF

SPIN MASTER LTD., 450 FRONT STREET WEST, TORONTO, ON M5V 1B6 CANADA Customer Care / Service consommateurs / Assistenza Clienti: 1-800-622-8339 Fax: 416-364-8005 Email / Courriel [email protected] Spin Master Inc., PMB #10053, 300 International Drive, Suite 100, Williamsville, NY 14221, USA Spin Master Toys Far East Limited, Rm #1113, 11/F, Chinachem Golden Plaza, 77 Mody Rd., Tsimshatsui E., Kowloon, HK Imported into EU by: SPIN MASTER INTERNATIONAL, S.A.R.L., 16 AVENUE PASTEUR, L-2310, LUXEMBOURG www.spinmaster.com Air Hogs ® , related trademarks & © 2012 Spin Master Ltd. All rights reserved. This product conforms to safety requirements of ASTM F-963, EN-71 & CHPA. Please retain this information for future reference. Please remove all packaging materials before giving to children. An adult should periodically check this toy to ensure no damage or hazards exist, if so, remove from use. Children should be supervised during play. Keep addresses and phone numbers for future reference. The item inside this package may vary from the photographs and/or illustrations. MADE IN CHINA. Le logo Air Hogs ® , les marques de commerce apparentées et © 2012 Spin Master Ltd. Tous droits réservés. Ce produit est conforme aux exigences de sécurité ASTM F-963, EN-71 et CHPA. Veuillez conserver ces renseignements pour consultation ultérieure. Retirer tout l’emballage avant de donner le jouet à des enfants. Un adulte doit régulièrement examiner ce jouet afin de s’assurer qu’il ne présente pas de dommages ni de risques. En cas de problème, ne plus l’utiliser. Les enfants doivent être surveillés lorsqu'ils jouent. Veuillez conserver les adresses et les numéros de téléphone pour consultation ultérieure. Le contenu de cet emballage peut différer des photographies et/ou des illustrations. FABRIQUÉ EN CHINE. El logo de Air Hogs ® , las marcas comerciales afines y © 2012 Spin Master Ltd. Todos los derechos reservados. Este producto cumple con las normas de seguridad ASTM F-963, EN-71 y CHPA. Conservar estas informaciones para futuras referencias. Retirar todo el material de embalaje antes de dar el producto a los niños. Un adulto debe examinar el juguete de vez en cuando para comprobar que no presente daños ni riesgos, en caso de haberlos, no utilizarlo. Los niños deben ser vigilados mientras juegan. Conservar las direcciones y los números de teléfono para futuras referencias. El contenido de este embalaje puede variar de las fotografías y/o ilustraciones. HECHO EN CHINA. 20048410, 20048411, 20052016, 20052017 GTL REV 0 T44422_0001_20048410_GTL_IS_R2 © 2011 HGJ Licensing, LLC. The name, likeness and signature of Jimmie Johnson and the likeness of the #48 Lowe’s Chevrolet are used under license granted by HGJ Licensing, LLC. © 2011 Hendrick Motorsports, LLC./The name, likeness and signature of Dale Earnhardt Jr. and the likeness of the #88 Amp Energy/National Guard Chevrolet & #88 National Guard/AMP Energy Chevrolet are used with the permission of Hendrick Motorsports, LLC and JRM Licensing, LLC./The Tony Stewart ® , Stewart-Haas Racing™ and #14™ are trademarks of Stewart-Haas Racing and are used under license. Office Depot ® and the Office Depot logo are registered trademarks of The Office Club, Inc. Mobil 1, Mobil “Pegasus” and the Flying Red Horse Mobil, Mobil 1 and the Pegasus design are registered trademarks of Exxon Mobil Corporation or one of its subsidiaries. The NASCAR Sprint Cup Series™ logo and word mark are used under license by the National Association for Stock Car Auto Racing, Inc., and Sprint. NASCAR ® is a registered trademark of NASCAR, Inc. © 2011 HGJ Licensing, LLC. Le nom, l’image et la signature de Jimmie Johnson et l’image de la Chevrolet n° 48 Lowe’s sont utilisés sous licence accordée par HGJ Licensing, LLC./Le nom, la ressemblance et la signature de Dale Earnhardt Jr. et la ressemblance de la voiture du #88 AMP Energy/National Guard Chevrolet et #88 National Guard/AMP Energy Chevrolet sont usés avec la permission de Hendrick Motosports, LLC et JRM Licensing LLC./The Tony Stewart ® , Stewart-Haas Racing MC et #14 MC sont des marques de commerce de Stewart-Haas Racing utilisées sous licence. Office Depot ® et le logo d’Office Depot sont des marques déposées de The Office Club, Inc. Mobil 1, Mobil “Pegasus” et l’emblème du cheval rouge volant de Mobil, Mobil 1 et le concept de Pégase sont des marques déposées d’Exxon Mobil Corporation ou de l’une de ses filiales. Le logo et la marque NASCAR Sprint Cup Series MC sont utilisés sous licence par la National Association for Stock Racing Inc., et de Sprint. NASCAR ® est une marque déposée de NASCAR, Inc. © 2011 HGJ Licensing, LLC. El nombre, la imagen y la firma de Jimmie Johnson, junto a la imagen del Chevrolet n° 48 Lowes se usan bajo licencia otorgada por HGJ Licensing, LLC./El nombre, el parecido el é la firma de Dale Earnhardt, Jr. é el parecido del automovil de #88 AMP Energy/National Guard y #88 National Guard/AMP Energy estan usados con el permiso de Hendrick Motorsports, LLC é JRM Licensing, LLC./The Tony Stewart ® , Stewart-Haas Racing™ y #14™ sont marcas de comercio de Stewart-Haas Racing usadas bajo licencia. Office Depot ® y el logotipo de Office Depot son marcas registradas de The Office Club, Inc. Las marcas Mobil 1, el “Pegaso” de Mobil y el Caballo rojo volador de Mobil, Mobil 1 y el diseño de Pegaso son marcas registradas de Exxon Mobil Corporation o una de sus filiales. El nombre y el logo de NASCAR Sprint Cup Series™ son usados bajo licencia por la National Association for Stock Car Auto Racing, Inc., y Sprint. NASCAR ® es una marca registrada de NASCAR, Inc. a Warning: CHOKING HAZARD – Small Parts. a Attention ! RISQUE D’ÉTOUFFEMENT – Contient de petits éléments. a Advertencia: PELIGRO DE ASFIXIA – Contiene piezas pequeñas. Hereby, Spin Master Ltd., declares that this Nascar ® is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. http://www.airhogs.com Par la présente Spi…

Text truncated - open the document above for the full version.

RF receiver RECEIVER BLOCK DIAGRAM DECODER IC U 2 RACING DRIVER ( Q 6 ,Q 7 ,Q10,Q11,Q12 ) STEERING DRIVER (U3) RX-49.860MHZ Q1 A B CD 1 2 3 4 6 5 A B CD 1 2 3 4 6 5 PA G E :DOC.No: 49.860 MHz

INTERTEK TESTING SERVICE Report No.: HK11090669-1 FCC ID: PQN44422RX49MHZ Equipment Photographs Model : 44422 (External)

27MHz A Pad paint white color 27MHz A 27MHz B 49MHz A 49MHz B Pad painted white color for For 27MHz For 49MHz FCC ID: PQN44422RX49MHZ FCC ID Pad paint white color for date code For 44422 MISE EN GARDE: L INSTALLATION DES PILES DOIT ETRE EFFECTUEE PAR UN ADULTE. CAUTION: TO BE INSTALLED BY ADULTS ONLY.

INTERTEK TESTING SERVICE Report No.: HK11090669-1 FCC ID: PQN44422RX49MHZ Equipment Photographs Model: 44422 (Internal) INTERTEK TESTING SERVICE Report No.: HK11090669-1 FCC ID: PQN44422RX49MHZ Equipment Photographs Model: 44422 (Internal) INTERTEK TESTING SERVICE Report No.: HK11090669-1 FCC ID: PQN44422RX49MHZ Equipment Photographs Model: 44422 (Internal)

General Circuit Description  The Equipment Under Test (EUT) is a Super-regenerative Receiver for a remote controlled Toy operating at 49.860 MHz. The EUT is powered by 4*1.5V "AA" batteries. The EUT can be controlled in four moving directions (forward/backward and left/right turn). The brief circuit description is listed as follows: -Q1, Q2, U1 and associated circuit act as a RF superregenerative receiver. -U3 and associated circuit act as a steering motor driver. -Q6,Q7,Q10,Q11,Q12 and associated circuit act as a racing motor driver. -U2 and associated circuit act as decode IC. 2.0 Product Description (Transmitter) The Equipment Under Test (EUT) is a transmitter for toy operating at 49.860 MHz, whii controlled by a crystal and powered by 3*1.5V "AAA" batteries. There are four switches: Forward and Backward, turn left, turn right  The brief circuit description is listed as follows:  -Q2, Y1 and associated circuit act as oscillator -Q1 and associated circuit act as modulator. -U1 and associated circuit act as encoder IC . Antenna Used: Internal

1 2 3 4 5 6 78 ABCD 8 7 6 5 4 3 2 1 D CBA Title Number Revision Size A3 Date: 27-Sep-2011 Sheet of File: F:\44422\new\44422 RX SCH 49M.DDB Drawn By: R6 330K R7 3.9K R2* 150K R1* 470K R9 3.3M L1 1uH L4 4.7uH C3 5pF C4 15pF C5 222pF C7 0.01uF C1* 68pF C6 4.7uF L3 7KB 1005 R3* 150K R8 1K R5 360 R12330K R101K Q2 C1815GR AT1 49.860 MHz C9 150pF C2 5pF C10 0.01uF C8 0.01uF Q1* 2SC1623L R11 3.3M L2* 5.6uH R4*100 C* 0.01uF Remark:The *mark component is no used(C*) Motor 2 For/Back Q6 3904 Q12 3904 Q7 3904 CM2 0.1uF CM1 0.1uF CM3 0.1uF C160.1uF R22 100K R20 100K R2347K R2447K Q11 3A01N Q10 3A01N Q9 3A02P Q8 3A02P R271K R28100K R26100K R191K R3147K R30 1K R29 0.33R 1W R251K R211K VBAT P67P51 P50 P52 P63 VDD P63 P51 P67 P50 P52 Matel VDD 8 VDD 1 INA 4 INB 5 OUTA 2 OUTB 7 VSS 3 VSS 6 U3 ESW4506A M1 CM6 0.1uF P61P62 P61P62 GND 8 OSCO 1 IN1 4 OUT1 5 OSCI 2 OUT2 7 VDD 3 IN2 6 U1 RX-2 RX C13 0.1uF C200.01uF R161K R15200R R13* TDB R17 10K R14 22K R181K Q4 8550 Q3 2SC2712Y Q5 3904 ZD1 2.4V SW12P2T + C12 100uF + C144.7uF P50 1 P67 2 P66 3 VDD 4 P65/OSCI 5 P64/OSCO 6 P63/RST 7 P51 14 P52 13 P53 12 VSS 11 P60/INT 10 P61 9 P62/TCC 8 U2 EM78P173S P50P67P65P64P63 P51P52 P53 P60P61P62 VCC P50P67P65P64P63 P62 P61P60P53 P52 P51 S1 S2 P64P65 P64P65 C17 0.1uF P60 PTC1W30-135 VBAT BT 4*AA VCC 6V A Channel Channel B Channel P64 P65 11 1 0 Nascar RX 49M First Union CM40.1uF CM5 0.1uF L410uH L510uH L5 10uH J1 100R

- The test report only allows to be revised within the retention period unless further standard or the requirement was noticed. - This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2785 5487 Website: www.hk.intertek-etlsemko.com TEST REPORT Report No.: HK11090669-1 Spin Master Toys Far East Limited Application For Certification (Original Grant) (FCC ID: PQN44422RX49MHz) Superregenerative Receiver Prepared and Checked by: Approved by: Signed On File Wong Cheuk Ho, Herbert Engineer Chan Chi Hung, Terry Assistant Supervisor Date: October 13, 2011 INTERTEK TESTING SERVICES Report No.: HK11090669-1 FCC ID: PQN44422RX49MHz i GENERAL INFORMATION Spin Master Toys Far East Limited BRAND NAME: Spin Master Ltd., MODEL: 44422 FCC ID: PQN44422RX49MHz Grantee: Spin Master Toys Far East Limited Grantee Address: Room 1113, 11/F., Chinachem Golden Plaza, 77 Mody Road, Tsim Sha Tsui East, Kowloon, Hong Kong. Contact Person: Allen Yang Tel: N/A Fax: N/A e-mail: alleny/[email protected] Manufacturer: First Union Toys Co., Ltd Manufacturer Address: Gong Lian Industrial Estate, Wan Jiang, Dong Guan City, China. Brand Name: Spin Master Ltd. Model: 44422 Additional Model: 1021361/6016876, 1023913/6018296, 1023915/6018296, 1023996/6018354, 1023999/6018357, 1024001/6018360 Type of EUT: Superregenerative Receiver Description of EUT: NASCAR 1/24TH RF (44422), AHN RDC NASCAR 1:24th RF Ast GTL 4pk M01 (1021361/6016876), AHN RDC NASCAR1:24thScl Ast GTL 2pk M01A (1023913/6018296), AHN RDC NASCAR1:24thScl Ast GTL 2pk M01B (1023915/6018296), AHN RDC NASCAR1:24DaleJRsRFAst GTL4pkM01 (1023996/6018354), AHN RDC NASCAR1:24th Jimmy RF GTL 4pkSLD, (1023999/6018357), AHN RDC NASCAR1:24th Tony RF GTL 4pkSLD (1024001/6018360) Serial Number: N/A FCC ID: PQN44422RX49MHz Date of Sample Submitted: September 19, 2011 Date of Test: September 21, 2011 Report No.: HK11090669-1 Report Date: October 13, 2011 Environmental Conditions: Temperature: +10 to 40°C Humidity: 10 to 90% INTERTEK TESTING SERVICES Report No.: HK11090669-1 FCC ID: PQN44422RX49MHz ii SUMMARY OF TEST RESULT Spin Master Toys Far East Limited BRAND NAME: Spin Master Ltd., MODEL: 44422 FCC ID: PQN44422RX49MHz TEST SPECIFICATION REFERENCE RESULTS Maximum Peak Output Power 15.247(b), (c) / RSS-210 A8.4 N/A Hopping Channel Carrier Frequencies Separation 15.247(e) / RSS-210 A8.1 N/A 20dB Bandwidth of the Hopping Channel 15.247(a) / RSS-210 A8.1 N/A Number of Hopping Frequencies 15.247(e) / RSS-210 A8.1 N/A Average Time of Occupancy of Hopping Frequency 15.247(e) / RSS-210 A8.1 N/A Anteann Conducted Spurious Emissions 15.247(d) / RSS-210 A8.5 N/A Radiated Spurious Emissions 15.247(d) / RSS-210 A8.5 N/A RF Exposure Compliance 15.247(i) / RSS-Gen 5.5 N/A Transmitter Power Line Conducted Emissions 15.207 / RSS-Gen 7.2.2 N/A Transmitter Field Strength 15.227 / RSS-310 3.8 N/A Transmitter Field Strength 15.229 / RSS-210 A2.7 N/A Transmitter Field Strength, Bandwidth and Timing Requirement 15.231(a) / RSS-210 A1.1.1 N/A Transmitter Field Strength, Bandwidth and Timing Requirement 15.231(e) / RSS-210 A1.1.5 N/A Transmitter Field Strength and Bandwidth Requirement 15.239 / RSS-210 A2.8 N/A Transmitter Field Strength and Bandwidth Requirement 15.249 / RSS-210 A2.9 N/A Transmitter Field Strength and Bandwidth Requirement 15.235 / RSS-310 3.9 N/A Receiver Radiated Eissions 15.109 / ICES-003 Pass Digital Device Conducted Emissions 15.107 / ICES-003 N/A Note: 1. The EUT uses a permanently attached antenna which, in accordance to section 15.203, is considered sufficient to comply with the pervisions of this section. 2. Pursuant to FCC part 15 Section 15.215(c), the 20 dB bandwidth of the emission was contained within the frequency band designated (mentioned as above) which the EUT operated. The effects, if any, from frequency sweeping, frequency hopping, other modulation techniques and frequency stability over excepted variations in temperature and supply voltage were considered. INTERTEK TESTING SERVICES Report No.: HK11090669-1 FCC ID: PQN44422RX49MHz iii Table of Contents 1.0 General Description............................................................................................ 1 1.1 Product Description ............................................................................................... 1 1.2 Related Submittal(s) Grants................................................................................... 1 1.3 Test Methodology.................................................................................................. 1 1.4 Test Facility ........................................................................................................... 1 2.0 System Test Configuration ................................................................................. 2 2.1 Justification ........................................................................................................... 2 2.2 EUT Exercising Software...............................................................................…

Text truncated - open the document above for the full version.

INTERTEK TESTING SERVICES Report No.: HK11090669-1 FCC ID: PQN44422RX49MHZ Bandwidth / Bandedge Plot – Pursuant to FCC Part 15 Section 15. 109 Requirement (Pass/Fail)

INTERTEK TESTING SERVICE Report No: HK11090669-1 FCC ID: PQN44422RX49MHZ Configuration Photographs Worst-Case Radiated Emissions (Front View) Model: 44422 INTERTEK TESTING SERVICE Report No: HK11090669-1 FCC ID: PQN44422RX49MHZ Configuration Photographs Worst-Case Radiated Emissions (Rear View) Model: 44422
