PQN70437Two Way Radio with FRS

Fig. 2 MENU PTT/CALL Antenna Speaker Headset port Power/Down button PTT/CALL button LCD panel Menu/Up button Microphone Fig. 1 a. c. b. Belt clip LONG RANGE WALKIE TALKIES Important: Please save this instruction sheet. It contains valuable product information. LONG RANGE WALKIE TALKIES 70437-4000-G1 PS 5/11 Foreign patents pending. Product colors and specifications subject to change. ATTENTION ADULTS—TO REPLACE BATTERIES The Long Range Walkie Talkies requires three AAA batteries (LR03), not included. 1. Remove belt clip: (a.) pinch tab inside the top of the clip; (b.) slide clip up to release; and (c.) slide battery cover down and off. (Fig. 1) 2. Use a small Phillips screwdriver to loosen the screw in the BATTERY COVER. NOTE: Screws will not detach from battery compartment cover. 3. Remove the cover. 4. Place batteries in the compartment as shown. (Fig. 2) 5. Replace BATTERY COVER and tighten screws. BATTERY SAFETY • Only adults should install and replace batteries. • Rechargeable batteries are to be removed from the toy before being charged. • Rechargeable batteries are only to be charged under adult supervision. • Non-rechargeable batteries are not to be recharged. • Remove dead or exhausted batteries. • Insert batteries correctly. Match positive and negative signs. • The supply terminals are not to be short-circuited. • Do not mix alkaline, standard (carbon-zinc), or rechargeable (nickel-cadmium) batteries. • Do not mix old and new batteries. • Only the batteries of the same or equivalent type recommended to be used. • Do not dispose batteries in a fire; they may explode. • Dispose of batteries safely. Warning! Changes or modifications to this equipment not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. NOTE: This unit has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This unit generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this unit does cause harmful interference to radio or television reception, which can be determined by turning the unit off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the unit and receiver. • Connect the unit into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio TV technician for help. Ages 6 and up 70437 Requires three AAA batteries (LR03), not included. Warning: Do not hold close to the ear. Misuse may damage hearing. Long range walkie talkie Model: 74047 RF Power: 0.5W Freq.: 462.5625-467.7125MHz TM TM & © Spin Master Ltd. All rights reserved. SPIN MASTER LTD., 450 FRONT ST. WEST, TORONTO, ON M5V 1B6 CANADA Spin Master Inc., PMB #10053, 300 International Drive, Suite 100, Williamsville, NY 14221 [email protected] 1-800-622-8339 • www.spinmaster.com MADE IN CHINA T70437_4000_20061521_NEN_IS_R2 Body Worn configuration For body worn operation, this unit has been tested and meets FCC RF exposure guidelines when used with the supplied belt-clip. Use of other accessories may not ensure compliance with FCC RF exposure guidelines. Warning: Any adjustment to this equipment is recommended to be performed by or under the immediate supervision and responsibility of a person certified as technically qualified to perform transmitter maintenance and repair duties in the private land mobile services and fixed services by an organization or committee representative of users of those services. Warning: Replacement of any transmitter component (crystal, semiconductor, etc.) for this equipment could result in violation of FCC rules. SAFETY INFORMATION Your wireless hand-held portable transceiver contains a low power transmitter. When the Push-to-Talk (PTT) button is pushed it sends out radio frequency (RF) signals. The device is authorized to operate at a duty factor not to exceed 50%. In August 1996, the Federal Communications Commissions (FCC) adopted RF exposure guidelines with safety levels for hand-held wireless devices. CAUTION: To maintain compliance with the FCC's RF exposure guidelines hold the transmitter and antenna at least 1 inch (2.5 centimeters) from your face and speak in a normal voice, with the antenna pointed up and away from the face. FUNCTION DESCRIPTION Belt clip: The belt clip is attached for easy use. LCD Panel: Displays current channel selection and other radio status symbols. POWER/DOWN BUTTON: Press and hold the button to turn your unit on/off. Press the button to decrease the speaker volume. MENU/UP BUTTON: Press and hold the MENU button to Channel and function selector. Press the MENU button to increase the speaker volume. PTT/CALL button: Press and hold PTT/CALL button to transmit. Press PTT/CALL button twice to Call. LCD PANEL ICON DESCRIPTIONS Receiving icon, displayed when reviving a signal Transmitting icon, displayed when transmitting a signal Display of current volume Displayed during the Channel Scan mode Display of the current battery level Channel number OPERATION Turning the unit ON • Press and hold the button. The unit will beep and the LCD display will display the current channel. Turning the unit OFF • Press and hold the button. The unit will beep and the LCD dis…

Text truncated - open the document above for the full version.

Appendix B1 Letter of Agency for FCC Certification Spin Master Toys Far East Ltd ******************************************************************************************************************** [May.9.2013] To whom it may concern, Letter of Agency I, an officer of SPIN MASTER TOYS FAR EAST LTD. do hereby authorize Intertek Testing Services (Mr. Ken Sit/Mr. Melvin Nip) to act on our behalf in front of the Federal Communications Commission with respect to all matters relating to certification of equipment under Part 15 and/or Part 95 of the FCC Rules until further notice. I further certify that no party (as defined in §1.2002(b) of CFR 47, 2004) to this application, including myself, is subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C., 862. Regards, [Signature] [Name] Andy Wong [Title] QA manager

Spin Master Toys Far East Ltd ******************************************************************************************************************** [ May.15.2013 ] To whom it may concern, Request for Permanent Confidentiality Under FCC Part 95 Certification FCC ID: PQN70437 Request is hereby submitted by [ Spin Master Toys Far East Ltd.] to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR § 0.457(d) and § 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential and [ Spin Master Toys Far East Ltd. ] reserves the right to discern which parties can obtain access to these information: • Schematics • Detailed Block diagrams • Detailed Operational/Functional Description • Parts List • Tune up Procedures • Operational Description The rationale for request for confidentiality is as followings: This information represents intellectual property of [Spin Master Toys Far East Ltd.] and it is subject to competition. We have invested considerable time and materials in research and development to produce the referenced product. Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us. If you have questions or need further information, please contact the undersigned. Regards, [Signature] [Name] Andy Wong [Title] QA manager

INTERTEK TESTING SERVICES External Photos FCC ID: PQN70437 IC: 4438B-70437 external photos - 1 of 1 HK13030588 Job Number HK13030588 Job Number

INTERTEK TESTING SERVICES Internal photos FCC ID: PQN70437 IC: 4438B-70437 internal photos - 1 of 4 Assembly INTERTEK TESTING SERVICES Internal photos FCC ID: PQN70437 IC: 4438B-70437 internal photos - 2 of 4 Main PCB View 1 INTERTEK TESTING SERVICES Internal photos FCC ID: PQN70437 IC: 4438B-70437 internal photos - 3 of 4 Main PCB View 2 INTERTEK TESTING SERVICES Internal photos FCC ID: PQN70437 IC: 4438B-70437 internal photos - 4 of 4 RF Module

Report No.: 13031213HKG-001 Page 1 of 76 - The test report only allows to be revised within the retention period unless further standard or the requirement was noticed. - This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2785 5487 Website: www.hk.intertek-etlsemko.com Specific Absorption Rate (SAR) Evaluation Report For Two Way Radio with FRS Model Number: 70437 Additional Model Number: 6021605, 1029072, 1029260 FCC ID: PQN70437 IC: 4438B-70437 Test Report: 13031213HKG-001 Date of Report: 07 June 2013 Prepared for Spin Master Toys Far East Ltd. Room 1113, 11/F., Chinachem Golden Plaza, 77 Mody Road, Tsim Sha Tsui East, Kowloon, Hong Kong Prepared and Checked by: Approved by: Chan Chun Foo, Bike Senior Lead Engineer Date: 07 June, 2013 Nip Ming Fung, Melvin Assistant Manager Date: 07 June, 2013 2349 Report No.: 13031213HKG-001 Page 2 of 76 Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2785 5487 Website: www.hk.intertek-etlsemko.com Table of Contents 1.0 General Information.............................................................................................. 3 2.0 Measurement System Description and Procedure ............................................... 6 3.0 Tissue Verification .............................................................................................. 14 4.0 SAR Measurement System Verification ............................................................. 16 5.0 SAR Evaluation .................................................................................................. 18 6.0 Test Instruments ................................................................................................ 25 7.0 Measurement Uncertainty .................................................................................. 26 8.0 E-Field Probe and 450 Dipole Antenna Calibration............................................ 28 9.0 References ......................................................................................................... 28 APPENDIX A - System Verification Data .................................................................. 29 APPENDIX B - SAR Evaluation Data ....................................................................... 31 APPENDIX C - E-Field Probe and 450MHz Dipole Antenna Calibration Data ......... 39 APPENDIX D - SAR Tissue Specification ................................................................ 75 APPENDIX E - SAR System Validation.................................................................... 76 Report No.: 13031213HKG-001 Page 3 of 76 - Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2785 5487 Website: www.hk.intertek-etlsemko.com 1.0 General information 1.1 Test Result Summary Applicant : Spin Master Toys Far East Ltd. Applicant Address : Room 1113, 11/F., Chinachem Golden Plaza, 77 Mody Road, Tsmi Sha Tsui East, Kowloon, Hong Kong Model : 70437 Additional Model : 6021605, 1029072, 1029260 EUT Description : Two Way Radio with FRS Exposure Category : General Population/Uncontrolled Exposure Test Device : Production Unit Date of Sample Received : 26 April, 2013 Date of Test: : 23 May, 2013 to 24 May, 2013 Date of Report: : 07 June, 2013 Place of Testing : Intertek Testing Services Hong Kong 5/F Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong Environmental Conidtions: : Temperature: +20 to 25°C Humidity: 30 to 70% Test Specification : ANSI/IEEE C95.1: 1992 IEEE Std 1528: 2003 IEEE Std 1528a: 2005 RSS-102 Issue 4: March 2010 FCC KDB Publication 447498 D01 v05r01 FCC KDB Publication 865664 D01 v01r01 FCC KDB Publication 865664 D02 v01r01 *Remark: The Model: 6021605, 1029072 and 1029260are the same as the Model: 70437 in hardware aspect. The difference in model number serves as marketing strategy and for cosmetic change only. The maximum spatial peak SAR value for the sample device averaged over 1g was found to be: Highest Reported SAR (50% Duty cycle) Band Operating Mode TX Frequency (MHz) 1 g Head 1g Body 462 MHz Voice 462.5625 – 462.7125 0.035 W/kg 0.098 W/kg 467 MHz Voice 467.5625 – 467.7125 0.029 W/kg 0.087 W/kg This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment / general population exposure limits specified in ANSI/IEEE C95.1. Report No.: 13031213HKG-001 Page 4 of 76 - Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2785 5487 Website: www.hk.intertek-etlsemko.com 1.2 Description of Equipment under test (EUT) EUT Description : Two Way Radio with FRS Model : 70437 Additional Model : 6021605, 1029072, 1029260 FCC ID : PQN-70437 IC : 4438B-70437 Serial Number : N/A Manufacturer : Spin Master Toys Manufacturer Address : 450 Front St. West Toronto Ontario M5V 1B6 Canada Device dimension (…

Text truncated - open the document above for the full version.

INTERTEK TESTING SERVICES Front 25mm Separation Back 0mm Separation 25mm Separation

INTERTEK TESTING SERVICES Page 1 of 2 EUT Photo Figure 1 - EUT front view Figure 2 - EUT back view INTERTEK TESTING SERVICES Page 2 of 2 Figure 3 – Headset Unit

INTERTEK TESTING SERVICES Occupied Bandwidth Plots FCC ID: PQN70437 bw - 1 of 1 CH 4

Code: FCC95a IC210a_FreqChar/Effective Date: 11 May 2010 Page 4 of 11 INTERTEK TESTING SERVICES Modulation Frequency Response -30.00-25.00-20.00-15.00-10.00 -5.00 0.00 100 600 1100 1600 2100 2600 3100 3600 4100 4600 Modulation Frequency (Hz) Audio Frequency Response FCC ID: PQN70437 mfr - 1 of 1

Code: FCC95a IC210a/Effective Date: 11 May 2010 INTERTEK TESTING SERVICES Modulation Limiting Characteristic 0.0000.5001.0001.5002.0002.500 47 57 67 77 87 97 107 117 127 137 Modulation Input (dBSPL) Frequency Deviation (kHz) 500Hz1000Hz2500Hz3125Hz FCC ID: PQN70437 mlc - 1 of 1

- The test report only allows to be revised the retention period issued date unless further standard or the requirement was noticed. - This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2785 5487 Website: www.hk.intertek-etlsemko.com Application For Certification Two Way Radio with FRS FCC ID: PQN70437 For Spin Master Toys Far East Ltd IC: 4438B-15211 For Spin Master Toys 13030588HKG-001 MN/ cl May 13, 2013 INTERTEK TESTING SERVICES Test Report Number: 13030588HKG-001 FCC ID: PQN70437 IC: 4438B-70437 Page 1 of 39 MEASUREMENT/TECHNICAL REPORT FCC Applicant : Spin Master Toys Far East Ltd. Trade Name/Model No : 70437 6021605, 1029072, 1029260 Date : May 13, 2013 This report concerns (check one:)Original Grant X Class II Change Equipment Type: FRF – Part 95 Family Radio Face Held Transmitter Deferred grant requested per 47 CFR 0.457(d)(1)(ii)? Yes No X If yes, defer until: date Company Name agrees to notify the Commission by: date of the intended date of announcement of the product so that the grant can be issued on that date. Report prepared by: Nip Ming Fung, Melvin Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Phone: 852-2173-8535 Fax: 852-2741-1693 INTERTEK TESTING SERVICES Test Report Number: 13030588HKG-001 FCC ID: PQN70437 IC: 4438B-70437 Page 2 of 39 Table of Contents 1.0 General Description................................................................................................. 4 1.1 Product Description ................................................................................................. 4 1.2 Related Submittal(s) Grants .................................................................................... 5 1.3 Test Methodology.................................................................................................... 5 1.4 Test Facility............................................................................................................. 5 2.0 System Test Configuration...................................................................................... 7 2.1 Justification ............................................................................................................. 7 2.2 EUT Exercising Software......................................................................................... 8 2.3 Special Accessories ................................................................................................ 8 2.4 Measurement Uncertainty ....................................................................................... 8 2.5 Equipment Modification ........................................................................................... 8 2.6 Support Equipment.................................................................................................. 8 3.0 RF Power Output (FCC Section 2.1046(a), 95.639(d) / RSS-210 A6.1.4)............ 10 4.0 Modulation Characteristics (FCC Section 2.1047(a)(b), 95.637(a))....................... 14 4.1 Modulation Frequency Response......................................................................... 15 4.2 Modulation Limiting Characteristics...................................................................... 17 4.3 Audio Low Pass Filter Response.......................................................................... 19 5.0 Occupied Bandwidth (FCC Section 95.633(c) / RSS-210 A6.1.3)....................... 22 6.0 Spurious Emission (FCC Section 2.1053, 95.635(b) / RSS-210 A6.1.5)............... 25 6.1 Power of Spurious Radiation ................................................................................ 26 7.0 Frequency Stability (FCC Section 2.1055(a)(b)(d), 95.627(b) / RSS-210 A6.1.6).31 7.1 Frequency Tolerance ........................................................................................... 32 7.2 Temperature Extreme Condition .......................................................................... 34 7.3 Voltage Extreme Condition................................................................................... 36 8.0 Equipment List....................................................................................................... 38 INTERTEK TESTING SERVICES Test Report Number: 13030588HKG-001 FCC ID: PQN70437 IC: 4438B-70437 Page 3 of 39 EXHIBIT 1 GENERAL DESCRIPTION INTERTEK TESTING SERVICES Test Report Number: 13030588HKG-001 FCC ID: PQN70437 IC: 4438B-70437 Page 4 of 39 1.0 General Description 1.1 Product Description The Equipment Under Test (EUT) is a Two Way Radio with FRS operating between 462.5625MHz and 467.7125MHz. The EUT is powered by 4.5V (3 x “AAA” size 1.5V alkaline batteries). Transmitter Portion (i) Type of Emission : 5K80F3E (ii) Frequency Range : 14 Channels from 462.5625MHz to 467.7125MHz (iii) Maximum Power Rating : 0.04W ERP (iv) Antenna Type : Integral, vertically polarized with 0dBi gain (iv) dc voltage of radio frequency amplifying device : 1.5V dc current of radio frequency amplifying device : 50mA For FCC…

Text truncated - open the document above for the full version.

INTERTEK TESTING SERVICES Spurious Emission Plots FCC ID: PQN70437 spurious - 1 of 1 CH4

INTERTEK TESTING SERVICES The Worst Case Configuration Photographs - Mode: TX without headset FCC ID: PQN70437 IC: 4538B-70437 config photos (Radiated emission) - 1 of 1 Radiated Emission – TX Front View Rear View
