PRDHS01Bluetooth Wireless Headset

QuickSetup 736627-B21 Using the power button 1. Turn on: Press and hold the button for 3 seconds. 2.Turn Press and hold the button for 3 seconds. 3. Pairing: Press and hold the button for 10 seconds. 4. Redial the last number: Press the button twice. 5. Answer a call: Press the button.6. Reject a call: Press the button twice. Using the power button 1. Turn on: Press and hold the button for 3 seconds. 2.Turn Press and hold the button for 3 seconds. 3. Pairing: Press and hold the button for 10 seconds. 4. Redial the last number: Press the button twice. 5. Answer a call: Press the button.6. Reject a call: Press the button twice. Using the power button 1. Turn on: Press and hold the button for 3 seconds. 2.Turn Press and hold the button for 3 seconds. 3. Pairing: Press and hold the button for 10 seconds. 4. Redial the last number: Press the button twice. 5. Answer a call: Press the button.6. Reject a call: Press the button twice. Using the power button 1. Turn on: Press and hold the button for 3 seconds. 2.Turn Press and hold the button for 3 seconds. 3. Pairing: Press and hold the button for 10 seconds. 4. Redial the last number: Press the button twice. 5. Answer a call: Press the button.6. Reject a call: Press the button twice. Using the power button 1. Turn on: Press and hold the button for 3 seconds. 2.Turn Press and hold the button for 3 seconds. 3. Pairing: Press and hold the button for 10 seconds. 4. Redial the last number: Press the button twice. 5. Answer a call: Press the button.6. Reject a call: Press the button twice. Using the power button 1. Turn on: Press and hold the button for 3 seconds. 2. Turn Press and hold the button for 3 seconds. 3. Pairing: Press and hold the button for 10 seconds. 4. Redial the last number: Press the button twice. 5. Answer a call: Press the button.6. Reject a call: Press the button twice. Using the power button 1. Turn on: Press and hold the button for 3 seconds. 2.Turn Press and hold the button for 3 seconds. 3. Pairing: Press and hold the button for 10 seconds. 4. Redial the last number: Press the button twice. 5. Answer a call: Press the button.6. Reject a call: Press the button twice. Using the power button 1. Turn on: Press and hold the button for 3 seconds. 2.Turn Press and hold the button for 3 seconds. 3. Pairing: Press and hold the button for 10 seconds. 4. Redial the last number: Press the button twice. 5. Answer a call: Press the button.6. Reject a call: Press the button twice. Using the power button 1. Turn on: Press and hold the button for 3 seconds. 2.Turn Press and hold the button for 3 seconds. 3. Pairing: Press and hold the button for 10 seconds. 4. Redial the last number: Press the button twice. 5. Answer a call: Press the button.6. Reject a call: Press the button twice. Using the power button 1. Turn on: Press and hold the button for 3 seconds. 2.Turn Press and hold the button for 3 seconds. 3. Pairing: Press and hold the button for 10 seconds. 4. Redial the last number: Press the button twice. 5. Answer a call: Press the button.6. Reject a call: Press the button twice. Using the power button 1. Turn on: Press and hold the button for 3 seconds. 2.Turn Press and hold the button for 3 seconds. 3. Pairing: Press and hold the button for 10 seconds. 4. Redial the last number: Press the button twice. 5. Answer a call: Press the button.6. Reject a call: Press the button twice. Using the power button 1. Turn on: Press and hold the button for 3 seconds. 2.Turn Press and hold the button for 3 seconds. 3. Pairing: Press and hold the button for 10 seconds. 4. Redial the last number: Press the button twice. 5. Answer a call: Press the button.6. Reject a call: Press the button twice. Using the power button 1. Turn on: Press and hold the button for 3 seconds. 2.Turn Press and hold the button for 3 seconds. 3. Pairing: Press and hold the button for 10 seconds. 4. Redial the last number: Press the button twice. 5. Answer a call: Press the button.6. Reject a call: Press the button twice. Using the power button 1. Turn on: Press and hold the button for 3 seconds. 2.Turn Press and hold the button for 3 seconds. 3. Pairing: Press and hold the button for 10 seconds. 4. Redial the last number: Press the button twice. 5. Answer a call: Press the button.6. Reject a call: Press the button twice. Using the power button 1. Turn on: Press and hold the button for 3 seconds. 2.Turn Press and hold the button for 3 seconds. 3. Pairing: Press and hold the button for 10 seconds. 4. Redial the last number: Press the button twice. 5. Answer a call: Press the button.6. Reject a call: Press the button twice. Using the power button 1. Turn on: Press and hold the button for 3 seconds. 2.Turn Press and hold the button for 3 seconds. 3. Pairing: Press and hold the button for 10 seconds. 4. Redial the last number: Press the button twice. 5. Answer a call: Press the button.6. Reject a call: Press the button twice. Using the power button 1. Turn on: Press and hold the button for 3 seconds. 2.Turn Press and hold the button for 3 seconds. 3. Pairing: Press and hold the button for 10 seconds. 4. Redial the last number: Press the button twice. 5. Answer a call: Press the button.6. Reject a call: Press the button twice. Using the power button 1. Turn on: Press and hold the button for 3 seconds. 2.Turn Press and hold the button for 3 seconds. 3. Pairing: Press and hold the button for 10 seconds. 4. Redial the last number: Press the button twice. 5. Answer a call: Press the button.6. Reject a call: Press the button twice. Using the power button 1. Turn on: Press and hold the button for 3 seconds. 2.Turn Press and hold the button for 3 seconds. 3. Pairing: Press and hold the button for 10 seconds. 4. Redial the last number: Press the button twice. 5. Answer a call: Press the button.6. Reject a call: Press the button twice. Using the power button 1. Turn on: Press and hold the button for 3 seconds. 2.Turn Press and hold the button for 3 seconds. 3. Pairing: Press and hold the button f…

Text truncated - open the document above for the full version.

Acrox Technologies Co., Ltd. 4F., No.89, Minshan St., Neihu Dist., Taipei City 114, Taiwan, R.O.C. Date：July 16, 2013 BABT TCB Forsyth House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD Confidentiality Request FCC ID: PRDHS01 Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules, Acrox Technologies Co., Ltd. hereby requests permanent confidential treatment of information accompanying this application as outlined below: Common exhibits for which confidentiality is requested are: Schematics Block Diagrams Theory of Operation The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Your Sincerely, Gavin Hsieh / PM Acrox Technologies Co., Ltd. TEL: 886-2-2796-5888 FAX: 886-2-2793-8999 Acrox Technologies Co., Ltd. 4F., No.89, Minshan St., Neihu Dist., Taipei City 114, Taiwan, R.O.C. E-Mail: [email protected]

Acrox Technologies Co., Ltd. 4F., No.89, Minshan St., Neihu Dist., Taipei City 114, Taiwan, R.O.C. Date：July 23, 2013 BABT FCB Forsyth House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD Dear Sir or Madam, Due to the business consideration, we hereby declare that our product of BT Wireless Headset Model: BH600 ; BT600 ; H7000 have as following difference Serial model BT600 ; H7000 are identical with main model BH600 and the difference is for marketing purpose only. Any questions regarding this declaration, please don’t hesitate to contact us. Your Sincerely, Gavin Hsieh / PM Acrox Technologies Co., Ltd. TEL: 886-2-2796-5888 FAX: 886-2-2793-8999 E-Mail: [email protected]

Acrox Technologies Co., Ltd. 4F., No.89, Minshan St., Neihu Dist., Taipei City 114, Taiwan, R.O.C. Date：July 16, 2013 BABT TCB Forsyth House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD Dear Sir or Madam, We, Acrox Technologies Co., Ltd., hereby authorize Compliance Certification Services Inc / James Chan to act as our agent in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. This authorization expires on 2013/12/31 Your Sincerely, Gavin Hsieh / PM Acrox Technologies Co., Ltd. TEL: 886-2-2796-5888 FAX: 886-2-2793-8999 E-Mail: [email protected]

Report No: T130531D02 Page 1 / 6 Rev.00 EXTERNAL PHOTOGRAPHS OF EUT

DVT Sample Label: 40x8mm DVT Sample S/N: CN13200001 PBCA layout: Ver1.0 FW: Ver1.0 貼至L 邊耳罩之護套上 (位置上下左右置中) 1:1 1:1 1:1 BT WIRELESS HEADSET HP無線耳機/ HP 无线耳机/ Model(型號/ 型号): BH600 SPS: 733786-001 P/N: H6Z97AA S/N: Made in China(中國製造/ 中国制造) Rating(額定電壓電流/ 额定电压电流:) 5VDC 500mA ANA TEL ID: XXXX-XX-XXXX IC: XXXXX-XXX FCC ID: PRDHS01 CNC: XXXXXXX CMIIT ID: 2013XXXXXX SCT: XXXXXXXXX-XXXX HP, HQ-TRE, 71004 Boeblingen, Germany CCAI12LP0780T1 XXXXXXXXXXX MP Label: 40x8mm KCC-CRI-HPK-BH600 해당 무선설비는 전파혼신 가능성이 있으므로 인명안전과 관련된 서비 스는 할 수 없음 CN13XXXXXX

Report No: T130531D02 Page 2 Rev.00 INTERNAL PHOTOGRAPHS OF EUT Report No: T130531D02 Page 3 Rev.00 Report No: T130531D02 Page 4 Rev.00 Report No: T130531D02 Page 5 Rev.00 Report No: T130531D02 Page 6 Rev.00 Antenna

Compliance Certification Services Inc. Report No.: T130531D02 Date of Issue: July 30, 2013 Page 1 Rev.00 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. According to KDB 447498 section 4.3.1, the 1-g SAR test exclusion thresholds at test separation distance ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 The max. power of channel, including tune-up tolerance(mW) is 3 mW @ 2402MHz (With Tune-up tolerance), The min. test separation distance (mm) is 5 mm, So, [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] ·[√f(GHz)] = 0.930 < 3.0 (With Tune-up tolerance). Therefore, standalone SAR measurements are not required for both head and body.

Compliance Certification Services Inc. Report No.: T130531D02-RP1 FCC ID: PRDHS01 Date of Issue: June 25, 2013 Page 1 Rev.00 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. FCC 47 CFR PART 15 SUBPART C TEST REPORT For BT Wireless Headset Model: BH600; H7000; BT600 Trade Name: Acrox; hp Issued to Acrox Technologies Co., Ltd. 4F., No.89, Minshan St., Neihu Dist., Taipei City 114, Taiwan, R.O.C. Issued by Compliance Certification Services Inc. No.81-1, Lane 210, Bade 2nd Rd., Lujhu Township, Taoyuan County 33841,Taiwan, R.O.C. TEL: 886-3-324-0332 FAX: 886-3-324-5235 http://www.ccsrf.com [email protected] Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. The client should not use it to claim product endorsement by TAF, A2LA, NIST or any government agencies. The test results in the report only apply to the tested sample. Compliance Certification Services Inc. Report No.: T130531D02-RP1 FCC ID: PRDHS01 Date of Issue: June 25, 2013 Page 2 Rev.00 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. Revision History Rev. Issue Date Revisions Effect Page Revised By 00 June 25, 2013 Initial Issue ALL Landy Huang Compliance Certification Services Inc. Report No.: T130531D02-RP1 FCC ID: PRDHS01 Date of Issue: June 25, 2013 Page 3 Rev.00 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. TABLE OF CONTENTS 1 TEST RESULT CERTIFICATION........................................................................................... 4 2 EUT DESCRIPTION ............................................................................................................... 5 3 TEST METHODOLOGY ......................................................................................................... 6 3.1. EUT CONFIGURATION ...................................................................................................... 6 3.2. EUT EXERCISE .................................................................................................................. 6 3.3. GENERAL TEST PROCEDURES ....................................................................................... 6 3.4. FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS ........................................... 7 3.5. DESCRIPTION OF TEST MODES...................................................................................... 8 4 INSTRUMENT CALIBRATION............................................................................................... 9 4.1. MEASUREMENT EQUIPMENT USED ............................................................................... 9 4.2. MEASUREMENT UNCERTAINTY .................................................................................... 11 5 FACILITIES AND ACCREDITATIONS................................................................................. 12 5.1. FACILITIES ....................................................................................................................... 12 5.2. EQUIPMENT..................................................................................................................... 12 5.3. TABLE OF ACCREDITATIONS AND LISTINGS............................................................... 13 6 SETUP OF EQUIPMENT UNDER TEST.............................................................................. 14 6.1. SETUP CONFIGURATION OF EUT ................................................................................. 14 6.2. SUPPORT EQUIPMENT................................................................................................... 14 7 FCC PART 15.247 REQUIREMENTS .................................................................................. 15 7.1. 20DB BANDWIDTH........................................................................................................... 15 7.2. PEAK POWER .................................................................................................................. 19 7.3. AVERAGE POWER .......................................................................................................... 21 7.4. BAND EDGES MEASUREMENT ...................................................................................... 22 7.5. FREQUENCY SEPARATION............................................................................................ 31 7.6. NUMBER OF HOPPING FREQUENCY ............................................................................ 33 7.7. TIME OF OCCUPANCY (DWELL TIME) ........................................................................... 36 7.8. SPURIOUS EMISSIONS................................................................................................... 48 7.9. POWERLINE CONDUCTED EMISSIONS ........................................................................ 66 8 PHOTOGRAPHS OF TEST SETUP..................................................................................... 69 Compliance Certification Services Inc. Report No.: T130531D02-RP1 FCC ID: PRDHS01 Date of Issue: June 25, 2013 Page 4 Rev.00 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. 1 TEST RESULT CERTIFICATION Applicant: Acrox Technologies Co., Ltd. 4F., No.89, Minshan St., Neihu Dist., Taipei City 114, Taiwan, R.O.C. Manufacturer: Acrox Technologies Co., Ltd. 4F., No.89, Minshan St., Neihu Dist., Taipei City 114, Taiwan, R.O.C. Equipment Under Test: BT Wireless Headset Trade Name: Acrox; hp Model: BH600; H7000; BT600 Date of Test: June 11 ~ 21, 2013 APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 15 Subpart C No non-compliance noted We hereby certif…

Text truncated - open the document above for the full version.

Compliance Certification Services Inc. Report No.: T130531D02-RP1 FCC ID: PRDHS01 Date of Issue: June 25, 2013 Page 69 Rev.00 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. 8 PHOTOGRAPHS OF TEST SETUP Radiated Emission Setup Photos Below 1GHz Compliance Certification Services Inc. Report No.: T130531D02-RP1 FCC ID: PRDHS01 Date of Issue: June 25, 2013 Page 70 Rev.00 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. Above 1GHz Compliance Certification Services Inc. Report No.: T130531D02-RP1 FCC ID: PRDHS01 Date of Issue: June 25, 2013 Page 71 Rev.00 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. Conducted Emission Setup Photo Compliance Certification Services Inc. Report No.: T130531D02-RP1 FCC ID: PRDHS01 Date of Issue: June 25, 2013 Page 72 Rev.00 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. Power Line Conducted Emissions Setup Photos
