PRDMU08Wireless Mouse

Page 1 CONSTRUCTION PHOTOS OF EUT

Page 2 Page 3 Page 4

FCC ID: PRDMU08 Report No.: RF120131C19 Operational Description This device is a Wireless Mouse. The transmitter of the EUT is powered by 1.5Vdc from batteries. The antenna is printed antenna. The other instruction, please have a look at the users manual.

Report No.: RF120131C19 1 Report Format Version 4.2.0 FCC TEST REPORT REPORT NO.: RF120131C19 MODEL NO.: G3T FCC ID: PRDMU08 RECEIVED: Jan. 31, 2012 TESTED: Feb. 02, 2012 ISSUED: Mar. 05, 2012 APPLICANT: Acrox Technologies Co., Ltd ADDRESS: 4F., No. 89, Minshan St., Neihu Dist., Taipei City 114, Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan ( R.O.C. ) TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 22 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product, certification, approval or endorsement by TAF or any government agency. The test results in the report only apply to the tested sample. The test results in this report are traceable to the national or international standards. Report No.: RF120131C19 2 Report Format Version 4.2.0 Table of Contents RELEASE CONTROL RECORD .............................................................................................................. 3 1. CERTIFICATION ......................................................................................................................... 4 2. SUMMARY OF TEST RESULTS ................................................................................................. 5 2.1 MEASUREMENT UNCERTAINTY .............................................................................................. 5 3. GENERAL INFORMATION ......................................................................................................... 6 3.1 GENERAL DESCRIPTION OF EUT ............................................................................................ 6 3.2 DESCRIPTION OF TEST MODES .............................................................................................. 7 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ............................................. 8 3.3 DESCRIPTION OF SUPPORT UNITS ........................................................................................ 9 3.3.1 CONFIGURATION OF SYSTEM UNDER TEST ......................................................................... 9 3.4 GENERAL DESCRIPTION OF APPLIED STANDARDS ............................................................. 9 4. TEST TYPES AND RESULTS ................................................................................................... 10 4.1 RADIATED EMISSION and band edge MEASUREMENT ........................................................ 10 4.1.1 LIMITS OF RADIATED EMISSION MEASUREMENT .............................................................. 10 4.1.2 TEST INSTRUMENTS ............................................................................................................... 11 4.1.3 TEST PROCEDURES ............................................................................................................... 12 4.1.4 DEVIATION FROM TEST STANDARD ..................................................................................... 12 4.1.5 TEST SETUP ............................................................................................................................ 13 4.1.6 EUT OPERATING CONDITIONS .............................................................................................. 13 4.1.7 TEST RESULTS ........................................................................................................................ 14 5. PHOTOGRAPHS OF THE TEST CONFIGURATION ............................................................... 20 6. INFORMATION ON THE TESTING LABORATORIES .............................................................. 21 7. APPENDIX A – MODIFICATION RECORDERS FOR ENGINEERING CHANGES TO THE EUT BY THE LAB ...................................................................................................................... 22 Report No.: RF120131C19 3 Report Format Version 4.2.0 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED RF120131C19 Original release Mar. 05, 2012 Report No.: RF120131C19 4 Report Format Version 4.2.0 1. CERTIFICATION PRODUCT: Wireless Mouse MODEL NO.: G3T BRAND: ACROX / HP APPLICANT: Acrox Technologies Co., Ltd TESTED: Feb. 02, 2012 TEST SAMPLE: ENGINEERING SAMPLE STANDARDS: FCC Part 15, Subpart C (Section 15.249) ANSI C63.10-2009 The above equipment (model: G3T) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE :Mar. 05, 2012 Pettie Chen / Specialist APPROVED BY : , DATE :Mar. 05, 2012 Gary Chang / Technical Manager Report No.: RF120131C19 5 Report Format Version 4.2.0 2. SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: FCC Part 15, Subpart C (Section 15.249) STANDARD PARAGRAPH TEST TYPE RESULTREMARK 15.207 Conducted Emission Test NA Power supply is 1.5Vdc from batteries. 15.209 15.249 15.249 (d) Radiated Emission Test Band Edge Measurement Limit: 50dB less than the peak value of fundamental frequency or meet radiated emission limit in section 15.209 PASS Meet the requirement of limit. Minimum passing margin is -12.0dB at 4948.0MHz. 2.1 MEASUREMENT UNCERTAINTY Where relevant, the following measurement uncertainty levels have been estimated for tests performed on the EUT as specified in CISPR 16-4-2: MEASUREMENT FREQUENCY UNCERTAINTY Radiated emission 30MHz ~ 200MHz 3.19 dB 200MHz ~1000MHz 3.21 dB 1GHz ~ 18GHz 2.26 dB 18GHz ~ 4…
