PRDMU142.4G Wireless mouse

2.4GHz Wireless Windows 8 hot key BlueTrace Mouse w/Nano Receiver USER'S GUIDE Ver.:1.00 CAUTION: To use this product properly, please read the user's guide before installing. 1 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 2 Functional Introduction Installing the batteries Step 1: Take the battery cover off. Step 2: Insert the battery as shown inside the battery compartment. Step 3: Replace the cover. **Warning: *Please insert the battery with the correct position according to the instruction labeled on the mouse. AA Battery Left button Right button Battery Cover Metallic Wheel Connect Button ON/OFF Switch Nano Receiver LED Indicator Pull Charms Menu Switching APP 3 Setup the Connection between the Receiver and the Mouse 1. Insert the battery into the mouse, then follow the steps below. 2. In the meantime, to open the mouse under the cover, take the nano receiver out. 3. Plug the Nano receiver into the USB port on your computer. 4. If the mouse does not work, please put it into pairing mode. 5. Pairing: Re-plug the receiver into the USB port on your computer, then press the connect button on the mouse. If the mouse does not work after 10 seconds, pair them again. (The receiver has auto pairing function). 6. The LED indicator on mouse flashes steadily when it is in pairing mode and stops blinking when it is successfully paired with the receiver. 7. When low battery, the battery indicator on the mouse will start to blink. 4 LED Indicator *Mouse Indicator LED is on for 3 sec. Power ON LED Blinks for 3 times During Pairing (LED OFF when paired or failed after 10 sec.) LED Blinks for 10 sec. Low Battery Warning

世洋科技股份有限公司 Acrox Technologies Co.,Ltd. 4F., No.89, Minshan St., Neihu Dist., Taipei City, Taiwan, ROC Tel:+886-2-2796-5888 EXT 9895 Fax: +886-2-2793-8999 Email:[email protected] Date:2012/12/11 To: SIEMIC, INC. 2206 Ringwood Avenue, San Jose, CA 95131 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, ACROX hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product description: 2.4G Wireless Mouse model name: GMY/GMX/GMZ FCC ID: PRDMU14 We affirm that between SIEMIC and ACROX, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Signature: name / title : Gavin Hsieh/ Product Manager information / address: Acrox Technologies Co.,Ltd. 4F., No.89, Minshan St., Neihu Dist., Taipei City, Taiwan, ROC

世洋科技股份有限公司 Acrox Technologies Co.,Ltd.437,8F, 4F., No.89, Minshan St., Neihu Dist., Taipei City, Taiwan, ROC Tel:+886-2-2796-5888 EXT 9895 Fax: +886-2-2793-8999 Email:[email protected] Date:2012/12/11 Confidentiality Letter To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: PRDMU14 We hereby request confidential treatment of information accompanying this application as outlined below: Block Diagram Schematics Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, signature : name / title : Gavin Hsieh/ Product Manager information / address: Acrox Technologies Co.,Ltd. 4F., No.89, Minshan St., Neihu Dist., Taipei City, Taiwan, ROC

世洋科技股份有限公司 Acrox Technologies Co.,Ltd. 4F., No.89, Minshan St., Neihu Dist., Taipei City, Taiwan, ROC Tel:+886-2-2796-5888 EXT 9895 Fax: +886-2-2793-8999 Email:[email protected] DECLARATION OF IDENTITY Hereby we: Acrox Technologies Co.,Ltd. Basic Model Number: GMY Basic Brand Name: ACROX Basic Product Name: 2.4G Wireless Mouse Declare the Circuit, PCB Layout, Electrical Parts and Outlook of the following product(s) are identical to the basic model: New / Additional Model Number(s): GMX New / Additional Brand Name(s): GMZ New / Additional Product Name(s): Signature with Company Chop : Printed Name : Gavin Hsieh DATE:2012-12-11

FCC ID: PRDMU14 FCC ID: PRDMU14 FCC ID: PRDMU14

Label Location

FCC ID: PRDMU14 Antenna Location FCC ID: PRDMU14

FCC ID: PRDMU14 Keyway Testing Technology Co., Ltd. Report No. 12KWE12258F Page 1 of 28 FCC TEST REPORT for Acrox Technologies Co., Ltd. 2.4G WIRELESS MOUSE Model Number: GMY/GMX/GMZ FCC ID: PRDMU14 Prepared for : Acrox Technologies Co., Ltd. Address : 4F., No.89, Minshan St., Neihu Dist.,Taipei City 114, , Taiwan, R.O.C Prepared by : Keyway Testing Technology Co., Ltd. Address : Baishun Industrial Zone, Zhangmutou Town, Dongguan, Guangdong, China Tel: 86-769-8718 2258 Fax: 86-769-8718 1058 Report No. : 12KWE12258F Date of Test : Dec.2~9, 2012 Date of Report : Dec.12,2012 FCC ID: PRDMU14 Keyway Testing Technology Co., Ltd. Report No. 12KWE12258F Page 2 of 28 TABLE OF CONTENTS Test Report Declaration Page 1. GENERAL PRODUCT INFORMATION....................................................................................4 1.1. Product Function................................................................................................................................. 4 1.2. Description of Device (EUT)............................................................................................................. 4 1.3. Independent Operation Modes......................................................................................................... 4 2. TEST SITES...................................................................................................................................5 2.1. Test Facilities...................................................................................................................................... 5 2.2. List of Test and Measurement Instruments.................................................................................... 6 3. TEST SET-UP AND OPERATION MODES..............................................................................7 3.1. Principle of Configuration Selection................................................................................................. 7 3.2. Block Diagram of Test Set-up........................................................................................................... 7 3.3. Test Operation Mode and Test Software........................................................................................ 7 3.4. Special Accessories and Auxiliary Equipment............................................................................... 7 3.5. Countermeasures to Achieve EMC Compliance........................................................................... 7 4. EMISSION TEST RESULTS.......................................................................................................8 4.1. Radiated Emission Test..................................................................................................................... 8 5. 20DB OCCUPY BANDWIDTH..................................................................................................18 5.1. Limits.................................................................................................................................................. 18 6. BAND EDGE COMPLIANCE TEST.........................................................................................20 6.1. Limits.................................................................................................................................................. 20 6.2. Test set.............................................................................................................................................. 20 7. PHOTOGRAPHS OF TEST SET-UP.......................................................................................25 7.1. Set-up for Radiated Emission Test................................................................................................ 25 8. PHOTOGRAPHS OF THE EUT................................................................................................26 FCC ID: PRDMU14 Keyway Testing Technology Co., Ltd. Report No. 12KWE12258F Page 3 of 28 Keyway Testing Technology Co., Ltd. Applicant: Address: Acrox Technologies Co., Ltd. 4F., No.89, Minshan St., Neihu Dist.,Taipei City 114, Taiwan, R.O.C Manufacturer: Address: Acrox Technologies Co., Ltd. 4F., No.89, Minshan St., Neihu Dist.,Taipei City 114, Taiwan, R.O.C Factor: Address: Acrox Technologies Co., Ltd. Hsinmin Industria,Changan Town,Dongguan City, Guangdong,China E.U.T: 2.4G Wireless Mouse Model Number: GMY/GMX/GMZ Trade Name: ------ Serial No.: ------ Date of Receipt: Dec.1, 2012 Date of Test: Dec.2~9, 2012 Test Specification: FCC Part 15, Subpart B: Oct. 1, 2010 ANSI C63.4:2009 Test Result: The equipment under test was found to be compliance with the requirements of the standards applied. Issue Date: Dec.11, 2012 Tested by: Reviewed by: Approved by: Andy Gao / Engineer Jade Yang/ Supervisor Chris Du / Manager Other Aspects: None. Abbreviations: OK/P=passed fail/F=failed n.a/N=not applicable E.U.T=equipment under tested This test report is based on a single evaluation of one sample of above mentioned products. It is not permitted to be duplicated in extracts without written approval of Keyway Testing Technology Co., Ltd. FCC ID: PRDMU14 Keyway Testing Technology Co., Ltd. Report No. 12KWE12258F Page 4 of 28 1. GENERAL PRODUCT INFORMATION 1.1. Product Function Refer to Technical Construction Form and User Manual. 1.2. Description of Device (EUT) Description : 2.4G Wireless Mouse M/N : GMY/GMX/GMZ Power Supply : DC 1.5V Operation Frequency : 2408~2474MHz Modulation Technology : GFSK Antenna Type : Integrated PCB antenna Antenna Gain : 0.5dBi 1.3. Independent Operation Modes The basic operation modes are: 1.3.1. EUT work continues TX mode and frequency as below: Channel :Frequency Low : 2408MHz Middle :2440MHz High :2474MHz 1.4. Difference between Model Numbers Note: The products are all the same except the model number. FCC ID: PRDMU14 Keyway Testing Technology Co., Ltd. Report No. 12KWE12258F Page 5 of 28 2. TEST SITES 2.1. Test Facilities Lab Qualifications : 944 Shielded Room built by ETS-L…
