2.4GHz Wireless BlueTrace Mouse with Windows 8 Hotkeys USER'S GUIDE Ver.:1.00 CAUTION: To use this product properly, please read the user's guide before installing. 1 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 2 How to ...recognize the parts 1. Left button 2. Right button 3. Scrolling Wheel 4. Front hotkey 5. Back hotkey 6. LED switch key 7. Nano Receiver 8. Battery Cover 9. Connect Button 10. OFF/ON Switch How to... set up your wireless mouse Step 1: Take the battery cover off. Step 2: Insert the batteries as shown inside the battery compartment. Step 3: Replace the battery cover 3 Step 4: Turn on power switch. Step 5: Your mouse will connect automatically, letting you use your mouse wirelessly AAA Battery Pull 1’st 2’nd 4 How to... pair your wireless mouse and computer If your wireless Laptop Mouse has not been connected to your computer after completing the previous steps, the following information will help you to complete the connection. 1. Turn off and turn on the POWER SWITCH on your mouse. 2. Make sure the computer is switch on. 3. Disconnect then reconnect the NANO RECEIVER on the computer. 4. Press the CONNECT BUTTON on the underside of the mouse. 5. The LED SWITCH KEY will flash 10 seconds to indicate the mouse is pairing with the nano receiver on the computer. 6. Your mouse will connect automatically. How to... recognize the operating system Step 1: makes sure your wireless mouse is properly connected to your computer Step 2: press the LED SWITCH KEY , follow the indication of below LED lighting on the switch key . LED SWITCH KEY Change to which system BLUE LED on 10sec Window 8 BLUE LED OFF Window7 ,window Vista, Window XP, Windows 2000, Mac OS x 10.5 or later Step 3: If you need to travel with your wireless mouse, you can disconnect the nano receiver. Your mouse will remember the last operating system until the next time you reconnect the nano receiver to the computer. 5 How to... use the hot keys Your wireless mouse has special FRONT HOTKEY and BACKHOT KEY designed for windows systems. For instructions on understanding the functions see below. FRONT HOTKEY System function Window 8 APPs Manu Window7 Window Vista Windows XP Windows 2000 Backward Mac OS x 10.5 or later Not Support BACK HOTKEY system function Window 8 Charms Manu Window7 Window Vista Windows XP Windows 2000 Forward Mac OS x 10.5 or later Not Support Battery Warning Statement... 1. Please insert the batteries with the correct position according to the instruction labeled in the mouse. 2. The batteries shall not be exposed to excessive heat such as sunshine, fire or the like. 3. Do not mix old and new batteries 4. Do not mix alkaline, standard (carbon-zinc), or rechargeable (ni-cad, ni-mh, etc) batteries.

世洋科技股份有限公司 Acrox Technologies Co.,Ltd. 437,8F, Rui Guang Road,Nei Hu District, Tel:+886-2-2796-5888 EXT 9895 Fax: +886-2-2793-8999 Email:[email protected] Date:2012/12/13 To: SIEMIC, INC. 775 Montague Expressway Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, ACROX hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product description: Wireless Mouse model name: ONA13HO501/ ONA13HO502/ONA13HO503/ONA13HO505/ONNGOD/GOD FCC ID: PRDMU16 We affirm that between SIEMIC and ACROX, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Signature: Gavin Hsieh name / title: Manager address: Acrox Technologies Co.,Ltd. 437,8F,Rui Guang Road,Nei Hu District,

SCS-F19: Confidentiality Request Letter Page 1 of 1 Rev 3.0 世洋科技股份有限公司 Acrox Technologies Co.,Ltd.437,8F, Rui Guang Road,Nei Hu District, Tel:+886-2-2796-5888 EXT 9895 Fax: +886-2-2793-8999 Email:[email protected] Date:2011/3/14 Confidentiality Letter To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: PRDMU16 We hereby request confidential treatment of information accompanying this application as outlined below: Block Diagram Schematics Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, signature : Gavin Hsieh name / title : Manager information / address: Acrox Technologies Co.,Ltd.437,8F,Rui Guang Road,Nei Hu District

世洋科技股份有限公司 Acrox Technologies Co.,Ltd. 4F., No.89, Minshan St., Neihu Dist., Taipei City, Taiwan, ROC Tel:+886-2-2796-5888 EXT 9895 Fax: +886-2-2793-8999 Email:[email protected] DECLARATION OF IDENTITY Hereby we: Acrox Technologies Co.,Ltd. Basic Model Number: ONA13HO501 Basic Brand Name: ACROX Basic Product Name: Wireless Mouse Declare the Circuit, PCB Layout, Electrical Parts and Outlook of the following product(s) are identical except for model numbers to the basic model: New / Additional Model Number(s): ONA13HO502/ ONA13HO503/ ONA13HO505/ ONNGOD/GOD New / Additional Brand Name(s): ONN New / Additional Product Name(s): Signature with Company Chop : Printed Name : Gavin Hsieh DATE:2013-1-13

FCC ID: PRDMU16 FCC ID: PRDMU16 FCC ID: PRDMU16 FCC ID: PRDMU16

Label Location

FCC ID: PRDMU16 FCC ID: PRDMU16 Antenna Location

FCC ID: PRDMU16 Keyway Testing Technology Co., Ltd. Report No. 13KWE01431F Page 1 of 29 FCC TEST REPORT for Acrox Technologies Co., Ltd. Wireless Mouse Model Number: ONA13HO501/ ONA13HO502/ ONA13HO503/ONA13HO505/ONNGOD/GOD FCC ID: PRDMU16 Prepared for : Acrox Technologies Co., Ltd. Address : 4F., No.89, Minshan St., Neihu Dist.,Taipei City 114, , Taiwan, R.O.C Prepared by : Keyway Testing Technology Co., Ltd. Address : Baishun Industrial Zone, Zhangmutou Town, Dongguan, Guangdong, China Tel: 86-769-8718 2258 Fax: 86-769-8718 1058 Report No. : 13KWE01431F Date of Test : Jan. 15~17, 2013 Date of Report : Jan. 20,2013 FCC ID: PRDMU16 Keyway Testing Technology Co., Ltd. Report No. 13KWE01431F Page 2 of 29 TABLE OF CONTENTS Test Report Declaration Page 1. GENERAL PRODUCT INFORMATION....................................................................................4 1.1. Product Function................................................................................................................................. 4 1.2. Description of Device (EUT)............................................................................................................. 4 1.3. Independent Operation Modes......................................................................................................... 4 2. TEST SITES...................................................................................................................................5 2.1. Test Facilities...................................................................................................................................... 5 2.2. List of Test and Measurement Instruments.................................................................................... 6 3. TEST SET-UP AND OPERATION MODES..............................................................................7 3.1. Principle of Configuration Selection................................................................................................. 7 3.2. Block Diagram of Test Set-up........................................................................................................... 7 3.3. Test Operation Mode and Test Software........................................................................................ 7 3.4. Special Accessories and Auxiliary Equipment............................................................................... 7 3.5. Countermeasures to Achieve EMC Compliance........................................................................... 7 4. EMISSION TEST RESULTS.......................................................................................................8 4.1. Radiated Emission Test..................................................................................................................... 8 5. 20DB OCCUPY BANDWIDTH..................................................................................................18 5.1. Limits.................................................................................................................................................. 18 6. BAND EDGE COMPLIANCE TEST.........................................................................................20 6.1. Limits.................................................................................................................................................. 20 6.2. Test set.............................................................................................................................................. 20 7. PHOTOGRAPHS OF TEST SET-UP.......................................................................................25 7.1. Set-up for Radiated Emission Test................................................................................................ 26 8. PHOTOGRAPHS OF THE EUT................................................................................................27 FCC ID: PRDMU16 Keyway Testing Technology Co., Ltd. Report No. 13KWE01431F Page 3 of 29 Keyway Testing Technology Co., Ltd. Applicant: Address: Acrox Technologies Co., Ltd. 4F., No.89, Minshan St., Neihu Dist.,Taipei City 114, Taiwan, R.O.C Manufacturer: Address: Acrox Technologies Co., Ltd. 4F., No.89, Minshan St., Neihu Dist.,Taipei City 114, Taiwan, R.O.C Factor: Address: Acrox Technologies Co., Ltd. Hsinmin Industria,Changan Town,Dongguan City, Guangdong,China E.U.T: Wireless Mouse Model Number: ONA13HO501/ ONA13HO502/ONA13HO503/ ONA13HO505/ONNGOD/GOD Trade Name: ONN/ACROX Serial No.: ------ Date of Receipt: Jan.15, 2013 Date of Test: Jan.15~17, 2013 Test Specification: FCC Part 15 Subpart C Section 15.249:2010 ANSI C63.4:2003 Test Result: The equipment under test was found to be compliance with the requirements of the standards applied. Issue Date: Jan. 20, 2013 Tested by: Reviewed by: Approved by: Andy Gao / Engineer Jade Yang/ Supervisor Chris Du / Manager Other Aspects: None. Abbreviations: OK/P=passed fail/F=failed n.a/N=not applicable E.U.T=equipment under tested This test report is based on a single evaluation of one sample of above mentioned products. It is not permitted to be duplicated in extracts without written approval of Keyway Testing Technology Co., Ltd. FCC ID: PRDMU16 Keyway Testing Technology Co., Ltd. Report No. 13KWE01431F Page 4 of 29 1. GENERAL PRODUCT INFORMATION 1.1. Product Function Refer to Technical Construction Form and User Manual. 1.2. Description of Device (EUT) Description : Wireless Mouse M/N : ONA13HO501/ ONA13HO502/ ONA13HO503/ONA13HO505/ ONNGOD/GOD Power Supply : DC 3V (1.5V AAA Battery*2) Operation Frequency : 2408~2474MHz Modulation Technology : GFSK Antenna Type : Integrated PCB antenna Antenna Gain : 0.5dBi 1.3. Independent Operation Modes The basic operation modes are: 1.3.1. EUT work continues TX mode and frequency as below: Channel :Frequency Low : 2408MHz Middle :2440MHz High :2474MHz Note: New battery used for all test. 1.4. Difference between Model Numbers Note: The products are all the same except t…
